19" LCD Color Monitor AOCM19W531
1
Service
Service
Service
Horizontal Frequency
31-80 kHz
TABLEOFCONTENTS
Description Page Description Page
SAFETY NOTICE
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING
ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
Table Of Contents.......…….................……..........…........1
Revision List.…........................………................……......2
Important Safety Notice.………….…...............……......3
1. Monitor Specification.................................………........4
2. Operation Instruction………….........……………...........7
2.1 General Instructions.....................................…...........7
2.2 Control Button…………………………………………...7
2.3 Connector………………………………………………..6
2.4 Adjusting the Picture...........................…............7
3. Input/Output Specification............……………............11
3.1 Input Signal Connector............………….................11
3.2 Factory Preset Display Modes..................................12
3.3 Panel Specification.....………………........................13
4.Block Diagram…….…................……..…..............16
4.1Software Flow Chart…………………...............16
4.2 Electrical Block Diagram………....………..………....18
5. Schematic…………………….…..............................20
5.1 Main Board…………..............................................20
5.2 Power Board....……………....................................28
5.3 Key Board ……………………………..…………….31
5.4 Tuner Board……………………………………...…..32
6. PCB Layout..………….......................................33
6.1. Main Board………........................................33
6.2 Power Board….......................................36
6.3 Key Board....…….......................................37
6.4 Tuner Board……….............................................37
7. Maintainability………...............................................38
7.1. Equipments and Tools Requirement.....................38
7.2. Trouble Shooting…………....................................39
8. White-Balance, Luminance adjustment...................43
9. Monitor Exploded View……....…………...…............45
10. BOM list....……......................................................46
12.Different Parts List……………………………………67
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

19" LCD Color Monitor AOCM19W531
2
Revision List
Revision Date Revision History TPV Model
A00 Dec.-21-2006 Initial release V196HXNSW9AENP
A01 Mar.-19-2007 Add TPV MODEL in item 12 V196HXNSW9AXNP

19" LCD Color Monitor AOCM19W531
3
Important Safety Notice
Proper service and repair is important to the safe, reliable operation of all AOC Company Equipment. The service
procedures recommended by AOC and described in this service manual are effective methods of performing service
operations. Some of these service operations require the use of tools specially designed for the purpose. The
special tools should be used when and as recommended.
It is important to note that this manual contains various CAUTIONS and NOTICES which should be carefully read in
order to minimize the risk of personal injury to service personnel. The possibility exists that improper service
methods may damage the equipment. It is also important to understand that these CAUTIONS and NOTICES ARE
NOT EXHAUSTIVE. AOC could not possibly know, evaluate and advise the service trade of all conceivable ways in
which service might be done or of the possible hazardous consequences of each way. Consequently, AOC has not
undertaken any such broad evaluation. Accordingly, a servicer who uses a service procedure or tool which is not
recommended by AOC must first satisfy himself thoroughly that neither his safety nor the safe operation of the
equipment will be jeopardized by the service method selected.
Hereafter throughout this manual, AOC Company will be referred to as AOC.
WARNING
Use of substitute replacement parts, which do not have the same, specified safety characteristics may create shock,
fire, or other hazards.
Under no circumstances should the original design be modified or altered without written permission from AOC.
AOC assumes no liability, express or implied, arising out of any unauthorized modification of design.
Servicer assumes all liability.
FOR PRODUCTS CONTAINING LASER:
DANGER-Invisible laser radiation when open AVOID DIRECT EXPOSURE TO BEAM.
CAUTION-Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
CAUTION -The use of optical instruments with this product will increase eye hazard.
TO ENSURE THE CONTINUED RELIABILITY OF THIS PRODUCT, USE ONLY ORIGINAL MANUFACTURER'S
REPLACEMENT PARTS, WHICH ARE LISTED WITH THEIR PART NUMBERS IN THE PARTS LIST SECTION OF
THIS SERVICE MANUAL.
Take care during handling the LCD module with backlight unit
-Must mount the module using mounting holes arranged in four corners.
-Do not press on the panel, edge of the frame strongly or electric shock as this will result in damage to the screen.
-Do not scratch or press on the panel with any sharp objects, such as pencil or pen as this may result in damage to
the panel.
-Protect the module from the ESD as it may damage the electronic circuit (C-MOS).
-Make certain that treatment person’s body is grounded through wristband.
-Do not leave the module in high temperature and in areas of high humidity for a long time.
-Avoid contact with water as it may a short circuit within the module.
-If the surface of panel becomes dirty, please wipe it off with a soft material. (Cleaning with a dirty or rough cloth may
damage the panel.)

19" LCD Color Monitor AOCM19W531
4
1. Monitor Specifications
Item Spec
Screen Size 19W” TFT-LCD Panel
Aspect Ratio 16:10
Resolution 1440x900(WXGA)
Display Area (opening) H x V 408.24mm x 255.15mm
Pixel Pitch 0.2835mm x 0.2835mm
Display Colors 16.2 million
Lamp Type/Life 50000 hr
LCD Panel
Color Temperature Normal /Cool / Warm
Input support definition 1440*900 /60Hz
VGA Function
Audio input Mini jack for stereo headphones (3.5ø)
TV Standard NTSC/M PAL/M,PAL/N
Sound System STEREO
TV Function
Color systems NTSC , PAL
AV RCA x 1
S-VIDEO S-Videox 1
Video Input
Component YPbPr x 1
Audio L/R x 1
Speaker (built-in): Two 3 watt speakers
Audio output Audio output: L / R
Headphone Mini-jack for stereo (3.5ø)
OSD Language English, Deutsch, French, Spanish, Italian, Português, Pycckий, Chinese Simplify
Table Stand Yes
Wall Mount VESA 100 x 100 mm
Power AC100V-240V, 50/60Hz
Power Power Consumption <65W
Panel Tilt Forwards/Backwards/
Rotation -4°/ +18° / ± 35°
Temperature + 0 °C ~ + 40 °C
storage - 25 °C ~ + 60 °C
Environment
operating 10% ~ 85%
Dimension W x H x D (with stand) 467 x 400 x 105 (mm)
Net weight Without accessory 6.0 Kg
Accessory Remote controller, Battey, Power cord, Adapter, Signal Cable,
Audio Cable, Microphone Cable, RCA Cable, S-Video Cable, User manual

19" LCD Color Monitor AOCM19W531
5
2. Operating Instructions
2.1 The Use of Remote Control
Turn on the PIP function or
0~9/ ~/~~ Digit buttons
To select a TV channel.
PC
Select your input source:
press repeatedly to select
VGA.DVI
Up & Down
Press Up and Down
we can select the submenu
or adjust the
TV channel.
MENU
Press repeatedly to
display OSD menu
MUTE
Temporarily interrupt the
sound or restore it.
PIP
Change the sub-window size
SLEEP
With this key you can set a
time period after which the
TV should switch itself to
standby. Press the key
repeatedly to select the
number of minutes. The
counter runs from
15.30.45.60 minutes
POWER
Press to turn on/off the
TV. The TV is never
completely powered off
unless it is physically
unplugged.
PRE-CH
To display the previously
selected TV channel.
TV/VIDEO
Select your input source:
press repeatedly to select TV,
Video, S- Video, YPbPr
Left & Right
Press Left and Right ,we can
change the Setting of
submenu or adjust the
volume.
INFO
Press this button to
Display Channel number
on the right-top corner
WIDE
Change the main-window
size. The counter runs from
4:3.16:9. ZOOM1.ZOOM2

19" LCD Color Monitor AOCM19W53
6
2.2 Control Buttons
FRONT PANEL CONTROL KNOBS
MENU Key①: Press to show the OSD menu and exit OSD menu at the TV.
AUDIO Key②: Adjustment volume hot key.
ECO Mode Key③: Press to select the ECO Mode.
Power Key : Press to turn on or off the TV
Auto Adjust Key⑤: The Auto Adjustment function is used to set the HPos, VPos, Clock and Focus in VGA Mode.
Source Key⑥: Press to select your input source.
Light Sensor⑦:When you turn on the light sensor in the menu, the brightness will change as the light of
environment.
Remote Sensor and Microphone⑧:It will receive the information from the Remote Control and voice by
Microphone.

19" LCD Color Monitor AOCM19W53
7
2.3 Connector
1: Headphone outlet
2: DC power input terminal
3: DVI-I input
4: AV signal input
5: Left video/audio track input
6: Right video/audio track input
7: S-Video signal input
8: Microphone input
9: TV signal input
10: PC audio input
11, 12 and 13: Y Pb Pr Component signal input
VGA/DVI: Receive the signals from the host, which is used as the display of the computer.
AV: Receive the video/audio signals of the NTSC, PAL.
S-VIDEO(S-VHS): i.e. video Y/C component. Receive the HD Y/C component signal.
Y Pb Pr: The modes it supports are HD signals such as 480i, 480p, 576i, 576p, 720p ,1080 i.
TV: Receive the TV signals of NTSC-M, PAL-M/N.
2.4 Adjusting the Picture
To use the menu
1. Press the MENU button to display or close main menu.
2. Use the cursor up/down to select a menu item.
3. Use the cursor left/right to enter a submenu or enable/disable the function.
4. Press the MENU button to exit the menu.
MAIN MENU
Press the MENU button to enter the main OSD (On Screen Display). Adjust the items including Picture Setup, Audio
setup, TV Setup, Function Setup and OSD setup.

19" LCD Color Monitor AOCM19W53
8
When the input source is Video, S-Video or YPbPr mode, the Sound Setup, Picture Setup, OSD Setup and Function
Setup can be selected;
When the input source is TV mode, the Sound Setup, Picture Setup, OSD Setup, Function Setup and TV Setup can
be selected.
Sound Setup (Same as in DVI, VGA, TV, Video, S-Video and Components modes)
1.Bass/ Treble / Balance : The range can be adjusted from 0~100.
2.Sound mode: you can set it “stereo”. “eala L”. “eala s” .“OFF”.
3.Source:When PIP it’s turn on. You can choose audio input by main-window or sub-window.
Picture Setting
When the input source is in VGA or DVI mode, you can select Contrast, Brightness, Position, Clock, Phase, Color

19" LCD Color Monitor AOCM19W53
9
Temp. Auto Adjust,
1.Brightness and Contrast: The range can be adjusted from 0~100.
2.H-Position and V- Position: The range can be adjusted from 0~100.
3.Clock: The range can be adjusted from 0~100.
4.Phase: The range can be adjusted from 0~100.
5.Color Temp.: There are four options of color temperature provided for users -normal, cold, user and Warm. You
can select the three-color temperatures of normal, cold and warm or manually adjust red, green or blue in the user
setting (you can only adjust red, green and blue in the user setting).
6.Auto Adjust: Automatically adjust VGA input to the optimal screen size
When the input source is in TV/Video/S-Video/YPbPr mode, you can select Contrast, Brightness, Hue, Saturation,
Sharpness, Size, Color Temp, Picture mode;
1: CONTRAST: You can adjust contrast from 0~100
2: BRIGHTNESS: You can adjust brightness from 0~100
3: HUE: You can adjust HUE from 0~100
4: SATURATION: You can adjust saturation from 0~100
5: SHARPNESS: You can adjust sharpness from 0~100
6: SIZE: You can change in 16:9,4:3,ZOOM1, ZOOM2 mode
7: COLOR TEMP: You can choose in NORMAL,WARM and COOL temperature
8: PICTURE MODE: You can choose in USER, STANDARD, MOVIE, VIVID mode
Function Setup
When the input source is in all mode, you can select Sleep Timer, Smart sensor , But PIP-windows just only for
VGA/DVI mode

19" LCD Color Monitor AOCM19W53
10
1. Sleep timer: You can set time period after which the TV should switch itself to standby. Select the number of
minutes. The counter runs from15.30.45.60 minutes.
2. Smart sensor: Turn on this function, the system can auto detect light of environment be to change brightness
3. PIP-WINDOWS: When the input source is in VGA/DVI mode, you can turn on PIP function and you can
choose sub-window source, size or position

19" LCD Color Monitor AOCM19W53
11
TV Setting
The following menu appears only in the TV mode.
1.Auto Scan: Select "Auto Scan" to search all signaled channel; when the searching is complete, it stays at the first
channel with signal and all channels that have been located are stored. If you would like to stop "Auto Scan" during
the process, simply by pressing the function button.
2.Channel Tuning mode: The demonstration chooses now channel
3.Fine tune:Fine tune the frequency of current channel.
4.Erase: The elimination chooses now channel .

19" LCD Color Monitor AOCM19W53
12
3. Input/Output Specification
3.1 Input Signal Connector
1 TX2- 9 TX1- 17 TX0-
2 TX2+ 10 TX1+ 18 TX0+
3 Shield (TX2 / TX4) 11 Shield (TX1 / TX3) 19 Shield (TX0 / TX5)
4 Not connected 12 Not connected 20 Not connected
5 Not connected 13 Not connected 21 Not connected
6 DDC-Serial Clock 14 +5V power 22 Shield (TXC)
7 DDC-Serial Data 15 Ground (H/V sync) 23 TXC-
8 VSYNC 16 Hot plug detect 24 TXC+
C1 RED C2 GREEN C3 BLUE
C4 HSYC C5 GROUND

19" LCD Color Monitor AOCM19W53
13
3.2 Factory Preset Display Modes
VESA MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
640x480@60Hz 800 x 525 31.469 N 59.940 N 25.175
640x480@72Hz 832 x 520 37.861 N 72.809 N 31.500
VGA
640x480@75Hz 840 x 500 37.500 N 75.00 N 31.500
800x600@56Hz 1024 x 625 35.156 N/P 56.250 N/P 36.000
800x600@60Hz 1056 x 628 37.879 P 60.317 P 40.000
800x600@72Hz 1040 x 666 48.077 P 72.188 P 50.000
SVGA
800x600@75Hz 1056x625 46.875 P 75.000 P 49.500
1024x768@60Hz 1344x806 48.363 N 60.004 N 65.000
1024x768@70Hz 1328x806 56.476 N 70.069 N 75.000
XGA
1024x768@75Hz 1312x800 60.023 P 75.029 P 78.750
1280x1024@60Hz 1688x1066 63.981 P 60.020 P 108.000
SXGA 1280x1024@75Hz 1688x1066 79.976 P 75.025 P 135.000
WXGA+ 1440x900@60Hz 1904x934 55.935 N 59.887 P 106.500
WXGA+ 1440x900@75Hz 1936x942 70.635 N 74.984 P 136.750
IBM MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequency
(KHz)
Sync
Polarity
Nominal
Freq.
(Hz)
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
DOS 720x400@70Hz 900 x 449 31.469 N 70.087 P 28.322
DOS 640x350@70Hz 800 x 449 31.469 P 70.087 N 25.175
XGA 1024x768@72Hz 1304 x 798 57.515 P 72.1 P 75.000
MAC MODES
VGA 640x480@67Hz 864x525 35.000 N 66.667 N 30.240
SVGA 832x624@75Hz 1152x667 49.725 N 74.551 N 57.2832
1024x768@60Hz 1312x813 48.780 N 60.001 N 64.000
XGA 1024x768@75Hz 1328x804 60.241 N 74.927 N 80.000

19" LCD Color Monitor AOCM19W53
14
3.3 Panel Specification
HannStar Display model HSD190MGW1-A00 is a color active matrix thin film transistor (TFT) liquid crystal
display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel,
the voltage reference, common voltage, DC-DC converter, column, and row driver circuit. This TFT LCD has a
19-inch diagonally measured active display area with WXGA+ resolution (900 vertical by 1440 horizontal pixel
array).
3.3.1 Display Characteristics

19" LCD Color Monitor AOCM19W53
15
3.3.2 Optical Characteristics

19" LCD Color Monitor AOCM19W53
16
3.3.3 Parameter guide line for CCFL Inverter
TFT LCD Module:
Back Light Unit:

19" LCD Color Monitor AOCM19W53
17
4. Block Diagram
4.1 Software Flow Chat
1
Y
23
N
4
N
5
Y
6
N
7
8
Y
9
N
10 11
Y
NN
12 13
Y Y
N
14 16
15
Y
17
N
18 19
Y

19" LCD Color Monitor AOCM19W53
18
1) MCU initialize.
2) Is the EPROM blank?
3) Program the EPROM by default values.
4) Get the PWM value of brightness from EPROM.
5) Is the power key pressed?
6) Clear all global flags.
7) Are the AUTO and SELECT keys pressed?
8) Enter factory mode.
9) Save the power key status into EPROM.
Turn on the LED and set it to green color.
Scalar initializes.
10) In standby mode?
11) Update the lifetime of back light.
12) Check the analog port, are there any signals coming?
13) Does the scalar send out an interrupt request?
14) Wake up the scalar.
15) Are there any signals coming from analog port?
16) Display "No connection Check Signal Cable" message. And go into standby mode after the message
disappear.
17) Program the scalar to be able to show the coming mode.
18) Process the OSD display.
19) Read the keyboard. Is the power key pressed?

LCD Color Monitor AOCM19W53
19
DVI_CAB
AU_12V
VS_RGB
B_TX0-
ADJ_PWM
HS_RGB
+5VU SB
MIC
MSC L -3 . 3
+AVDD_DVI
TV_AUDIOR
ON_PBACK
WR
Panel_Powe
WE
4.2 Electric Block Diagram
4.2.1 Main Board
r
AUDIO1_L
SCA_PWR
ALL-RST
04 VIDEO Decoder
04 VIDEODecoder
MSD A- 3. 3
MSC L-3 . 3
VLLC
VVS
VHS
VD[0..7]
ALL-RST
Y+
Pb+
Pr+
AUDIO1_L AUDIO1_R
VD_5V
TV_AUDIOL TV_AUDIOR
SWITCH
TUNER_12V
MSCL-5
MSDA-5
RIN-
TXCLK-
TXCLK+
R_TX2-
WP_DDC
MCU5V
MSD A-5
+3.3V
AIR_PWR
RAS
G_TX1+
SDA_DVI
SDA_DVI
MI C
MSD A-3. 3
VLLC
+AVDD_ADC
ALL-RST
Pr+
AIR_PWR
GIN-
BIN-
+5V
10 USB
10 USB
+5VUSB
Bluetooth
08 Sound Processor
08 Sound Processor
A_L
A_R
MSD A-3. 3
MSC L -3 . 3
AUDIO1_L
AUDIO1_R
TV_AUDIOR
TV_AUDIOL
AU_12V
MI C
MSD A-5
MSC L-5
+5V
03 DVI
03 DVI
B_TX0+
B_TX0-
G_TX1-
G_TX1+
R_TX2+
R_TX2-
TXCLK+
TXCLK-
SDA_DVI
SCL_DVI
DVI_CAB
+5V
DVI_+5V
RIN+
RIN-
BIN-
GIN-
GIN+
BIN+
SOG
HS_RGB
VS_RGB
DDC_SW
HPD_CTL
SCL_VGA
SDA_VGA
DDC_SW
WP_DDC
INT
SWITCH
06 Memory
06 Memory
MDATA[0..31]
MADR[0..10]
CKE
DQM[0..1]
SBA
RAS
CAS
WE
MCLK
+3.3V
TV_AUDIOL
MSC L -3 . 3
SCA_PWR
HPD_CTL
RIN+
VHS
+AVDD_PLL
SCL_DVI
+VDDP
WP_DDC
HWRESET
TUNER_12V
MSC L-5
SDA_VGA
Pb+
+AVDD_PLL2
DDC_SW
ON_PBACK
MCU5V
+5V
VD_PWR
ALE
SWITCH
AD[0..3]
MSD A-3. 3
AU_PWR
R_TX2+
02 Power
02 Power
+VDD C
+VDDP
+VDDM
+AVDD_PLL2
+AVD D_PLL
+AVDD_MPLL
+AVD D_DVI +AVD D_ADC
ADJ_PWM
MCU5V
ON_PBACK
AU_12V
VD_5V
Panel_Power
+3.3V
+5V
+5VUSB
VD_PWR
AU_PWR
SCA_PWR
AIR_PWR
ON_PANEL
TUNER_12V
CKE
+AVDD_MPLL
MSD A- 3. 3
+3.3V
+VDDC
+5V
VVS
ON_PANEL
BIN+
TUNER_12V
MSD A-5
SCL_VGA
09 Audio AMP
09 Audio AMP
A_L
A_R
AU_12V
SOG
A_R
SDA_VGA
AUDIO1_R
DVI_+5V
AU_PWR
MCLK
SBA
AU_12V
CAS
VD_5V
05 MST51512
05 MST51512
B_TX0+
B_TX0-
G_TX1-
G_TX1+
R_TX2+
R_TX2-
TXCLK+
TXCLK-
SDA_DVI
SCL_DVI
RIN+
+AVDD_ADC
+AVD D_DVI
+AVDD_MPLL
+AVD D_PLL
+AVDD_PLL2
+VDDM
+VDDP +VDDC
RIN-
GIN-
BIN-
BIN+
GIN+
SOG
HS_RGB
VS_RGB
Y+
Pb+
Pr+
VLLC
VVS
VHS
VD[0..7]
HWRESET
INT
ALE
RD
WR
AD[0..3]
MDATA[0..31]
MADR[0..10]
CKE
SBA
DQM[0..1]
RAS
CAS
WE
MCLK
ADJ_PWM
Panel_Power
DDC_SW
HPD_CTL
VD_PWR
MSCL-3.3
Y+
DVI_+5V
VD[0..7]
AU_12V
MDATA[0..31]
MADR[0..10]
GIN+
MSC L-5
A_L
B_TX0+
SCL_VGA
DQM[0..1]
ON_PANEL
DVI_CAB
DDC_SW
G_TX1-
SCL_DVI RD
VD_5V
07 MCU
07 MCU
HWRESET
ALE
RD
WR
INT
AD[0..3]
DVI_+5V
MCU5V
DVI_CAB
MSD A -3 . 3
MSC L-3. 3
SCL_DVI
SDA_DVI
SWITCH
WP_DDC
SDA_VGA
SCL_VGA
ALL-RST
ON_PBACK
ON_PANEL
VD_PWR
AU_PWR
SCA_PWR
AIR_PWR
MI C
Bluetooth
+VDDM
19"

1 9" LCD Color Monitor AOCM19W53
20
4.2.2 Inverter / Power Board.2.2 Inverter / Power Board
Lamp
EMI filter
Feedback
Circuit
Start Circuit: R903、R904
Output
Circuit
PWM
Control IC
Bridge
Rectifier
and Filter
Transformer
Transformer
Over
Voltage
Protect
PWM
Control IC
MOSFET
Q203
、
Q204
PWM
Rectifier
diodes
Feedback
Circuit
CN102CN102
ON/OFF Control
DIM
12V
U101
ON/OFF
12V
5V
