ARAG NINJA User manual

INSTALLATION
4670900
MONITOR NINJA
WITH INTEGRATED GPS NAVIGATOR

2
• LEGENDA SIMBOLI
=Generic danger
=Warning
ECU =remote control unit IBX100
This manual is an integral part of the equipment to which it refers and must accompany the equipment in case of sale or change of ownership. Keep it for any
future reference; ARAG reserves the right to modify product specications and instructions at any moment and without notice.
LEGEND OF SYMBOLS
CONTENTS
1 Risks and protections before assembly...................................................................................................................................................... 3
2 Intended use .................................................................................................................................................................................................. 3
3 Precautions .................................................................................................................................................................................................... 3
4 Package content ............................................................................................................................................................................................ 3
5 Position on farming machine ....................................................................................................................................................................... 4
5.1 Monitor positioning................................................................................................................................................................................ 4
5.2 Visor attachment................................................................................................................................................................................... 5
5.3 NINJA fixing outside of the machine..................................................................................................................................................... 5
6 Wiring connections ....................................................................................................................................................................................... 6
6.1 NAVIGATOR SYSTEM MODE: auxiliary function and power supply connection .................................................................................. 6
6.1.1 AUXILIARY FUNCTIONS................................................................................................................................................................................... 6
6.1.2 POWER SUPPLY CONNECTION....................................................................................................................................................................... 6
6.2 Connector connection NINJA................................................................................................................................................................ 7
7 Accessories ................................................................................................................................................................................................... 7
7.1 SD memory card................................................................................................................................................................................... 7
8 Maintenance / diagnostics / repairs ............................................................................................................................................................. 8
8.1 Troubleshooting..................................................................................................................................................................................... 8
8.2 Cleaning rules....................................................................................................................................................................................... 8
9 Technical data................................................................................................................................................................................................ 8
10 End-of-life disposal ....................................................................................................................................................................................... 9
11 Guarantee terms ............................................................................................................................................................................................ 9

3
INTRODUCTION
1 RISKS AND PROTECTIONS BEFORE ASSEMBLY
All installation works must be done with battery disconnected, using suitable tools and any individual protection equipment
deemed necessary.
Use ONLY clean water for treatment tests and simulations: using chemicals during simulated treatment runs can seriously injure
persons in the vicinity.
2 INTENDED USE
NINJA features a satellite navigator that – through the external GPS receiver – can be used for agricultural applications and navigation.
The device you have purchased is a monitor which, when connected to an adequate remote control unit (ECU), makes it possible to control all phases
of treatment in agricultural applications directly from the cabin of the farming machine it is installed in.
IMPORTANT:
the monitor does not manage section status: any intervention on the valves must be done separately by referring to the
instruction manual of the relevant control: for any reference to the system conguration refer to the manual attached to the ECU.
Communicating what happens on the eld, the monitor can collect data on the job.
NINJA is not designed for use on public roads and should only be used on farmland.
This device is designed to work on agricultural machinery for spraying and crop spraying applications.
The machine is designed and built in compliance with ISO 14982 standard (Electromagnetic compatibility - Forestry and farming
machines), harmonized with 2014/30/UE Directive.
3 PRECAUTIONS
• Do not aim water jets at the equipment.
• Do not use solvents or fuel to clean the case outer surface.
• Do not clean equipment with direct water jets.
• Comply with the specied power voltage (12 VDC).
• In case of voltaic arc welding, remove connectors from NINJA and disconnect the power cables.
• Only use ARAG genuine spare parts and accessories.
• NINJA ,when connected to a suitable IBX 100 control unit, can control hydraulic valves to open / close the boom.
The monitor does not feature emergency stop devices: the manufacturer must provide all necessary safety devices for the
hydraulic boom control.
Any time one hydraulic boom section is opened or closed the monitor emits an acoustic signal and the display shows the rele-
vant indication.The manufacturer should also provide acoustic and optical warnings in the vicinity of the boom.
4 PACKAGE CONTENT
The table below indicates the components that you will nd in the NINJA monitor package:
NINJA
Legenda:
1 NINJA
2 Visor kit
3 Fixing kit
4 Instruction manual (DVD-ROM)
Fi g . 1

4
5 POSITION ON FARMING MACHINE
5.1 Monitor positioning
• The monitor NINJA can be positioned outside the agricultural machinery. Observe the following precautions:
-Do NOT install the monitor in areas where it would be subjected to excessive vibrations or shocks, to prevent any damage.
- Install the device in a well visible and handy position.
Consider all necessary connections of the monitor (Fig. 2 / Fig. 3), he cable length, and make sure there is enough space for
connectors and cables.
An identication symbol is located next to each connector to indicate its function.
ITEM CONNECTION POINTS
*For any reference to the system conguration refer to the
manual attached to the ECU.
AGPS receiver
B
NAVIGATOR SYSTEM MODE:
Auxiliary functions / Battery
SPRAYER/SPREADER MODE*
Auxiliary functions / ECU / Battery
CSD memory card slot
Tab. 1
A B C
Fi g . 2
A B C
Fi g . 3
INSTALLATION

5
INSTALLATION
5.2 Visor attachment
The visor kit comes standard in the package.It must be xed by tting the supplied nuts in the seats indicated in the gure and tightening the supplied
screws.
Fi g . 4
5.3 NINJA xing outside of the machine
-NINJA can be tted outside the machine by observing the hole sizes indicated in Fig. 6 / Fig. 7.
-It must be xed by tting the supplied nuts in the seats indicated in the gure and tightening the supplied screws.
Fi g . 5
Fi g . 6
ARAG IS NOT LIABLE FOR ANY DAMAGE RESULTING FROM
INSTALLATION BY UNSKILLED PERSONNEL. ANY SYSTEM
DAMAGE CAUSED BY A WRONG INSTALLATION AND/OR
CONNECTION AUTOMATICALLY VOIDS THE WARRANTY.
Fi g . 7

6
6 WIRING CONNECTIONS
• Use only the cables provided with the ARAG monitors.
• Take care not to break, pull, tear or cut the cables.
• Use of unsuitable cables not provided by ARAG automatically voids the warranty.
• ARAG is not liable for damages to the equipment, persons or animals caused by failure to observe the above instructions.
6.1 NAVIGATOR SYSTEM MODE: auxiliary function and power supply connection
WARNING:
To avoid short circuits, do not connect the power cables to battery before the installation is completed.
Before powering up the monitor, make sure the tractor battery voltage is as specied (12 VDC).
6.1.1 AUXILIARY FUNCTIONS
CABLE COLOR FUNCTION LABEL STATUS
1RED Enable spraying MASTER IN Active low
2GREEN General status MASTER OUT Output +12Vdc
3BLACK Ground GND --
4BROWN Reverse REVERSE IN Active high
Fi g . 8
6.1.2 POWER SUPPLY CONNECTION
NINJA is supplied directly by the farming machine battery (12 VDC): ALWAYS switch on the system through the monitor, and then remember to switch
it off using the specic key on the control panel.
If NINJA remains on for a long time with machine off, the tractor battery could run at: in case of prolonged breaks of the
machine with engine off, make sure the monitor is off, too.
The power source must be connected as indicated in Fig. 9:
Fi g . 9
Connect the power cable directly to the battery using the
suitable eyelets.
WARNING! DO NOT connect to key-operated switch (15/54).
INSTALLATION

7
INSTALLATION
6.2 Connector connection NINJA
According to the instructions in "Tab. 1" on page 4, connect the connectors to NINJA by ensuring that the cables are not bent along the rst
20 mm (0.79") from the connector.
Push the connector all the way down until engaging the retaining tooth.
If space is limited and you need to bend a cable, be sure not to bend it by less than 90°.

Fi g . 10 Fi g . 11
To remove the connector from NINJA, lift the retainer and move the connector in the indicated direction .
Fi g . 1 2
7 ACCESSORIES
7.1 SD memory card
The SD memory card may be used to exchange data with monitor NINJA.
Before use, format the SD board in FAT 32
mode; make sure that the board is not
protected and can be read by the system
(Fig. 13).
The system is ONLY compatible with SD
or SDHC memory cards, up to 8 Gb of
memory. Fi g . 1 3
A
Fi g . 1 4
1) To reach the SD card slot, loosen the two screws on the cover and remove it.
2) Insert the SD card in the slot by keeping the cut edge faced down and push it fully
home.
3) Perform the necessary programming / copy operations.
4) Push and release the SD card to remove it.
5) Fit the slot cover in its original position and x it by tightening the screws.
WARNING: A WRONG POSITIONING OF THE COVER CAN ALLOW
WATER INFILTRATIONS INSIDE NINJA!

8
8 MAINTENANCE / DIAGNOSTICS / REPAIRS
8.1 Troubleshooting
FAULT CAUSE REMEDY
The display does not switch on No power supply • Check power supply connection
Monitor is OFF • Press the ON key
8.2 Cleaning rules
- Clean only with a soft wet cloth.
- DO NOT use aggressive detergents or products.
- DO NOT aim water jets directly.
9 TECHNICAL DATA
DESCRIPTION NINJA
Display LCD 5,7", VGA 65000 colour, 500 cd/m2
Rated supply voltage 12 Vdc (9 ÷ 15 Vdc)
Consumption monitor: 0,4 A
Operating temperature 0 °C ÷ 45 °C
+32 °F ÷ +113 °F
Storage temperature -10 °C ÷ 60 °C
14 °F ÷ +140 °F
Weight (without cables) monitor: 590 g
Driving direction input (REVERSE IN) Active high (PNP)
Spraying activation input (MASTER IN) Active low (NPN)
Spraying status output (MASTER OUT) Active high (PNP) max 100 mA
No. 2 camera inputs Pal
No. 2 RS232 serial ports until 115200 baud
No. 1 Can Bus port until 1 Mbit/sec
SD card reader •
Power supply for GPS receiver 12 Vdc (max 300 mA)
Power supply for cameras max 300 mA
Protection against polarity inversion •
Protection against short-circuit •
Protection rating IP65
MAINTENANCE / DIAGNOSTICS / REPAIRS

9
10 END-OF-LIFE DISPOSAL
This device contains a lithium polymer battery that, at end of life, must be disposed of according to the prevailing rules.
Should it be necessary to replace the battery, do not disassemble the device but contact ARAG directly.
The device must be used and stored at the temperature indicated in chapter "Technical data" of this manual.
Excessive temperature oscillations may cause acid leakage, overheating, explosion or self-combustion of the battery and conse-
quent injuries and/or damages to persons.
Do not open, remove, drill or throw the device in the re.
In case of battery leakage and accidental contact with the leaked out uids, thoroughly rinse the concerned area and seek imme-
diately medical advice.
11 GUARANTEE TERMS
1. ARAG s.r.l. guarantees this apparatus for a period of 360 days (1 year) from the date of sale to the client user (date of the goods delivery
note).
The components of the apparatus, that in the unappealable opinion of ARAG are faulty due to an original defect in the material or
production process, will be repaired or replaced free of charge at the nearest Assistance Center operating at the moment the request for
intervention is made. The following costs are excluded:
- disassembly and reassembly of the apparatus from the original system;
- transport of the apparatus to the Assistance Center.
2. The following are not covered by the guarantee:
- damage caused by transport (scratches, dents and similar);
- damage due to incorrect installation or to faults originating from insufficient or inadequate characteristics of the electrical system, or to
alterations resulting from environmental, climatic or other conditions;
- damage due to the use of unsuitable chemical products, for spraying, watering, weedkilling or any other crop treatment, that may damage
the apparatus;
- malfunctioning caused by negligence, mishandling, lack of know how, repairs or modications carried out by unauthorized personnel;
- incorrect installation and regulation;
- damage or malfunction caused by the lack of ordinary maintenance, such as cleaning of lters, nozzles, etc.;
- anything that can be considered to be normal wear and tear.
3. Repairing the apparatus will be carried out within time limits compatible with the organizational needs of the Assistance Center.
No guarantee conditions will be recognized for those units or components that have not been previously washed and cleaned to remove
residue of the products used;
4. Repairs carried out under guarantee are guaranteed for one year (360 days) from the replacement or repair date.
5. ARAG will not recognize any further expressed or intended guarantees, apart from those listed here.
No representative or retailer is authorized to take on any other responsibility relative to ARAG products.
The period of the guarantees recognized by law, including the commercial guarantees and allowances for special purposes are limited, in
length of time, to the validities given here.
In no case will ARAG recognize loss of prots, either direct, indirect, special or subsequent to any damage.
6. The parts replaced under guarantee remain the property of ARAG.
7. All safety information present in the sales documents regarding limits in use, performance and product characteristics must be transferred
to the end user as a responsibility of the purchaser.
8. Any controversy must be presented to the Reggio Emilia Law Court.
12CONFORMITY DECLARATION
The declaration of conformity is available at www.aragnet.com, in the relevant section.

Note
10

D20352_GB-m01 04/2016
42048 RUBIERA (Reggio Emilia) - ITALY
Via Palladio, 5/A
Tel. [phone]
Fax [phone]
http://www.aragnet.com
[e-mail]
Only use genuine ARAG accessories or spare parts to make sure manufacturer guaranteed safety conditions are maintained in time. Always refer to the internet
address www.aragnet.com
