AOCHUAN Master M20 User manual

Quick Start Guide
Wireless Remote Control Electric Tripod

Product Overview
Power indicator
Graduatedscale
Leveling instrument
Sponge
Fixed buckle
1/4, 3/8
screw interfaces
Remote controller
Type -C
charging port
Power button
Fixed knob

Extended status
540mm
1265mm 1565mm
890mm
1
3 4
2

Product list
Before use, please check and ensure that the kit consists of
all following items. In case of deficiency, please contact the
customer service or your local agent.
Function Introduction
Power On/Off of the tripod
* After 60 minutes when no operation
sent on the working tripod, it will
automatically enter standby status to
save power. Single-click the power
button then it will start working again.
Tripod×1 User manual×1
快速入门手册
电动遥控三脚架
Quick Start Guide
Electric Remote Cont rol Tripod
Type -C
charging cable×1
Remote
controller×1
Power button
Hold down the power button for over 3
seconds: switch On/Off the tripod
Double-click the power button: The motor
ascends.
Triple-click the power button: The motor
descends.
Single-click: The motor pauses.

Low battery: Red indicator flickers.
Normal battery: Solid green indicator is on.
Charging: Solid red indicator is on.
Finish charging: Green indicator flickers.
Function Introduction
* If the tripod runs out of battery, its
extension rod will automatically fold
itself. After charging, the tripod can
work normally again.
Charging the tripod
Power indicator

Function Introduction
Connect the Bluetooth
1.Hold down the camera button on the remote for over
five seconds, the Bluetooth is opened and the blue
indicator flickers. Open the Bluetooth setting on your
mobile phone. Search for the Bluetooth name
“SelfieCom” and connect with it. When the indicator
turns off, it indicates a successful connection with the
Bluetooth.
2.Select the original camera/video on your mobile phone:
single-click the camera button on the remote to take a
picture / video with your original mobile phone.
* The remote needs to be connected with the Bluetooth Within five
minutes after switching on the tripod. Or it will automatically turn off to
save power. After ten minutes’ connection with the Bluetooth, the remote
will automatically enter standby status. Single-click the camera button to
activate the remote controller.
* The max. remote distance of camera function is 20 meters. The max.
remote distance of ascend/descend function is 10 meters.
* In case of replacing the battery, please order CR2032 button battery in
the store.
Bluetooth Connection and Use
Ascending button
Camera button
Descending button
Pause button
Indicator

Using Scenario
1/4, 3/8 screw interfaces may fix the mobile phone,
camera, hydraulic gimbal, fill-light, etc.
Mount the
camera
Mount the
mobile phone
Camera
Mobile phone clip

Using Scenario
Mount the
hydraulic gimbal
Mount the
fill-light
Fill-light
Hydraulic gimbal
1/4, 3/8 screw interfaces may fix the mobile phone,
camera, hydraulic gimbal, fill-light, etc.

Tripod parameters
Master M20
1.3kg
5kg
10kg
113*600*102mm（folded size）
200 times
-10~50℃
3.7V/1500mAh
3.7V
5V/1A
About 3 hours
Product size
Product weight
Max. weight capacity
Max. weight capacity of the hook
Battery Life
(max. Weight capacity)
Operation temperature
while charging
Charging time
Li-ion Battery
Operation voltage
Power input

Cautions
1. Do not put the tripod into the fire or near hightempera-
ture objects;
2. The tripod may be broken by dropping or crashing.
Please use it with care;
3. Do not place the tripod near liquid or clean it with
cleanser.;
4. Do not dismantle, repair or modify the tripod without
professional guide;
5. This product is not suitable for children.
Thank you for selecting Mster M20. All the contents
mentioned in this article are related to your safety, legal
rights and responsibilities. Before use, please read the
instruction carefully. Operate the tripod as per the
product instructions and warnings so as to avoid injury or
damage to yourself or others around you. We reserve the
right of final interpretation on all relevant documents,
which are subject to update without notice. Please visit
the official website www.yg-free.com to obtain the latest
product information.
Once you use this product, we will regard that you have
read the disclaimer and warning carefully; furthermore
comprehend and accept all the terms and contents of
this statement. It means that you agree to take full
responsibility as well as possible consequences while
using this product. Furthermore, you promise to use the
product for legitimate purposes only, as well as agree to
these terms and any relevant regulations, policies and
guidelines formulated by our company.

Cautions
My company shall not be responsible for the loss, injury
and any legal liability caused by the direct or indirect use
of the product. The user shall follow but not limited to all
safety guidelines mentioned herein.
This user instruction is for reference only, which isn’t any
form of commitment. The tripod (including color, sizes,
etc.) refers to the real product.
FCC Statement
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
·Reorient or relocate the receiving antenna.
·Increase the separation between the equipment and receiver.
·Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
·Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.

Warranty Services:
Warranty Clauses
1.In case of poor performance or problems on the
product within 7 days to the date of receipt, users may
ask for replacement or money refund as per the invoice;
2.In case the product occurs quality problems within 12
months, users can enjoy free maintenance;
3.Dismantling, modifying without authority doesn’t enjoy
free warranty.
4.Users should provide the proof of purchase.
Non-Warranty Clauses
1.Dismantle or modify the product without authorization;
Drop the product , etc.;
2.Damage caused by force majeure (fire disaster, flood
disaster, etc.);
3.Damage caused by non-compliance of the user
instruction;
4.Exceeding the warranty period.
Cautions
1.Users may send the faulty products back to our
post-sale service centre. After receiving it, our
technicians will test and clear the issues and responsibili-
ties.
2.After tests, In case the returned product doesn’t meet
the free-repair conditions, reasonable maintenance fees
will be charged accordingly. The users may ask for repair
or return it.
3.We hold the final explanation right.
