AOM WS001 User manual

Color Weather Station
WS001
USER MANUAL

01
PACKAGING CONTENTS
Thank you for purchasing this device, Please read the operating instructions
carefully to familarise yourself with the features and modes of operation before
using the instrument.
WS001

02

03
Overview of icons and buttons
Front side and display
1. Outdoor Temperature
2. RF symbol
3. Weather forecast
4. Weather trend
5. Indoor humidity
6. Indoor Temperature
7. Low battery indication indoor
8. Max/Min for indoor
9. Trend of indoor
10. Day of week
11.Alarm
12. Date
13.Month
14.Time
15.Trend of outdoor
16. Outdoor humidity
17. Low battery indication outdoor
18.MAX/MIN for outdoor
Press button Press and hold (3 seconds)
(A) MODE -
Setting the time format,time shift,hours,
year,date,day of the week language
(B) +
Displays max/min temperature and
humidity readings
(C) - Displays temperature units
°C/°F
-
(D) ALARM
Alarm time display/alarm activation
when alarm time display Setting an alarm when alarm time display
(E) SEARCH Searches for the sensor
Back side
-
Top side
F= For AC 4.5V adaptor
G=SNOOZE/LIGHT – Activates display backlight and snooze feature
Wireless sensor
H= Outdoor temperature and humidity
I = LED of signal transmission from the sensor
J = A hole to hang the device on the wall

Correct way for mounting the outdoor sensor:
Suggest the outdoor sensor to be hung on as below showing, better not stand it
at outside place,try to avoid direct sun shine or rain as much as possible.
04
Manual set-up
1.Press and hold key "MODE " for 3 seconds.
2.The 12/24 hour flashing. Use "+ "and "- " to select
3.Press "MODE " to confirm
4.The display for the hour is flashing. Use "+ " and "- " to select the hour.
5.Press "MODE "to confirm.
6.The display for the minutes is flashing. Use "+ " and "- " to select the minutes.
7.Press "MODE "to confirm.
8.The display for the year is flashing. Use "+ "and "- " toselect the year.
9.Press "MODE "to confirm.
10.The display for the month is flashing. Use "+ " and "- " to select the month.
11.Press "MODE "to confirm.

05
The clock automatically changes from set-up mode to time display mode if no
keys are pressed for 15 seconds.
Information:
Setting time manually
1. Press and hold the MODE button.
2. Set the 12/24 time format - hour - minute - year - month –day of week-
languages of calendar by "+ " and "- " . languages sequence is as below :
EN - English, GE- German, IT- Italian, FR - French, DU - Dutch, SP - Spanish,
DA- Danish
DST (Daylight saving time)
1.Turn on/off the DST(Daylight saving time) function, the setting step is: press
the "MODE" key into time and date setting, at the last part of this setting, select
the "on" for open the DST function, select the "OFF" for close the DST function.
2.When you receive the item, please set the right summer time or winter time
manually. When the summer time or winter time almost finish, please set the
time back and it will enter summer time or winter time automatically when the
summer time or winter time start.
3.The unit will exit the Winter time and enter the Summertime at 2 AM on the
second Sunday of March.
4.The unit will exit the Summertime and enter the Winter time at 2 AM on the
first Sunday of November.
Daily alarm set-up
a) Press "ALARM " toshow alarmtime
b) Press and hold the key "ALARM " for 3 seconds ,the flashing alarm time are shown
c) c)The hour display of the alarm time is flashing. Use "+ " and "- " to select the hour.

06
Daily alarm ON/OFF
1.When showing alarm time, press "ALARM "to activate the alarm with alarm
symbol showing.
2.Press "ALARM " again cancel the alarm
1.The clock automatically changes from set-up mode to time mode if no keys
are pressed for 15 seconds.
2.The alarm sounds for 2 minutes if no key is pressed to stop it.
Information:
Snooze function
To activate the snooze function, follow the steps below
Press the key "SNOOZE/LIGHT", while the alarm sounds, to activate the snooze
function.
If the snooze function is activated, Snooze symbol Zz is flashing.
The alarm repeat after 5 minutes.
The snooze function can be stopped by pressing any key.
12/24 hours mode
The time display can be in 12 （AM/PM）or 24 hours mode.
°C/°F temperature display
The temperature display can be in °C or °F. Press the key "-"to switch
between the mode.
Max/Min for indoor and outdoor temperature and humidity
Press the key “+“ to show the Max/Min of temperature and humidity
Hold the “+ ”button to delete readings from the memory

07
Weather forecast
Trend of humidity and Weather forecast
1.The station forecasts weather on the basis of changes in atmospheric pressure
for the next 12–24 hours for an area within the range of 15–20 km.
2.Accuracy of weather forecast is 70–75 %.
3.As the weather forecast may not be 100% accurate, neither the manufacturer
nor the seller can be responsible for any loss caused by an incorrect forecast.
The weather station shows 5 animated weather forecast icons.
Low battery condition display
The weather station displays the low battery condition symbol to remind the
batteries of the weather station or the outdoor sensor need to be exchanged.
1.Weather station low battery condition display: within indoor area of the
display
2.Outdoor sensor low battery condition display: in the outdoor area of the
display

08
Illumination
Press and hold the key “SEARCH“ for 3 seconds to search for outdoor sensor .
Wireless connection to the outdoor sensor
1.Press the key "SNOOZE/LIGHT" to activate the display illumination for
5 seconds.
2.There are 3 levels of the light by pressing the "SNOOZE/LIGHT" button when
AC power on:Off backlight, Light on, More bright light
Putting into operation
1.Insert batteries into the weather station (3 x AAA,LR03,1.5V),connect the 4.5V
AC adaptor and then into the wireless sensor (2 x AAA,LR03,1.5V).When
inserting the batteries make sure the polarity is correct to avoid damaging the
weather station or sensor.
2.Place the two units next to each other. The weather station finds signal from the
remote sensor in 3 minutes. If it is not found, press and hold the "SEARCH"
button to repeat the search
.
3.If the outdoor temperature and humidity on the display disappears, press and
hold SEARCH on the weather station. The weather station repeats search for
the sensor signal.
4.The sensor is waterproof to dripping water from upside, however, it should not
be exposed to rain permanently.
5.Do not place the sensor on metallic object , otherwise it will reduce its
transmission range.
6.If low battery icon is displayed, replace batteries in the sensor or weather
station.
Note: Batteries in the weather station are used as a backup of the readings/set
values. If AC power supply is disconnected, with no batteries inserted, all data
will be lost.

Dimensions(L x W x H)
Daily alarm set-up
Temperature
Humidity
09
Specifications:
Main station 110 x 145 x 45 mm
Remote sensor 90.8 x 65 x 32.5mm
Thermometer measuring range inside: 32°F to 122°F(0°C to 50°C)
Thermometer measuring range outside: -22°F to 140°F(-30°C to 60°C)
Temperature display elective：°C or °F
Tempetrature measurement accuracy ：0°C~40°C(32°F~104°F): ±1°C（1.8°F )
-30°C~0°C, 40°C~60°C(-22°F~32°F,104°F~140°F):±2°C（3.6°F )
Hygrometer measuring range 20% to 95% RH
Hygrometer measurement accuracy 30% ~ 80%：±5%；
Other : ±8%
1.Six keys: MODE, +, - , ALARM,SEARCH, SNOOZE/ LIGHT.
2.Colorful background illumination
( 3 level by pressing SNOOZE/LIGHT : off backlight, light on, more bright light)
3.Time display in 12/24 format
4.Continuous perpetual calendar up to 2099
5.Display of Date, Month and Day of week
6.Alarm with snooze function (5 minutes alarm interruption)
7.5 weather forecast: sunny, partly sunny, cloudy, rainy,storm with trend
8.Indoor /outdoor temperature
9.Indoor/outdoor humidity with trend
10.Max/Min indoor/outdoor temperature and humidity
11.Low battery indication

Station indoor
Sensor outdoor
10
Clock display HH:MM:SS
Hour format 12hr AM/PM or 24hr
Calendar MM/DD
Weekday in 7 languages (EN, GE, FR, IT, DU,SP,DA)
Battery: 3 x AAA, LR03, 1.5V
AC 4.5V adaptor included
Wireless sensor transmission frequency 433 MHz
Transmitting distance up to 35 m in open area
1 channel
Sitting at least one meter above the ground
Battery: 2 x AAA, LR03, 1.5V
Trouble shooting
When placing both the inside and outside units remember they are subject to
interference.
Try to:
A) Install both units as close as possible to each other.
B) Try and avoid outside interference by not placing them near computers,
T.V.’s or T.V. Arials etc.
C) Also remember concrete walls & floors can interupt transmissions. Try and
avoid as much as possible.
D) If the connection is successful initially & then fails occassionally, try to reduce
the distance

11
The product is designed to provide trouble-free service for many years if operated
appropriately. Here is some advice for proper operation:
Care and maintenance
1.Read the manual carefully before using this product.
2.Do not expose the product to direct sunlight, extreme cold and moisture, and
sudden changes in temperature. This would reduce the accuracy of detection.
3. Do not place the product in locations prone to vibration and shocks – these may
cause damage
4.Do not expose the product to excessive force, impacts, dust, high temperatures
or humidity - these may cause malfunction, shorter battery life, damage to batteries
and deformation of plastic parts.
5.Do not expose the product to rain or moisture, if it is not intended for outdoor use.
6.Do not place any open flame sources on the product vents.
7.Do not place the product to places with inadequate air flow.
8.Do not insert any objects in the product vents.
9. Do not tamper with the internal electric circuits of the product – you may damage
it, which will automatically terminate the guarantee. The product should only be
repaired by a qualified professional.
10.To clean the product, use a slightly moistened soft cloth. Do not use solvents or
cleaning agents - they could scratch the plastic parts and cause corrosion of the
electric circuits.
11.The product may not be exposed to dripping or splashing water.
12. In the event of damage or defect of the product, do not perform any repairs by
yourself. Have it repaired in the shop where you bought it.
13.This device is not intended for use by persons (including children) whose
physical, sensory or mental disability or lack of experience and expertise prevents
safe use, unless they are supervised or instructed regarding use of the appliance
by a person responsible for their safety. It is necessary to supervise children to
ensure they do not play with the appliance.

Do not dispose of the product or the batteries after the end of life as unsorted
municipal waste, use sorted waste collection points. Correct disposal of the
product will prevent adverse on human health and the environment.
Recycling of materials contributes to the protection of natural resources. For more
information about recycling of this product, contact the municipal authority,
organization for processing household waste or the point of sale where you
purchased the product.
12
Safety warnings
Read the safety warnings carefully and only use the article as described in these
instructions to avoid accidental injury or damage. Keep this manual for future
reference . If you pass this product on to someone else , remember to give them
these instructions.
Intended use
The weather station for domestic use and is not suitable for commercial purposes.
Danger to Children
a.Batteries can be highly dangerous if swallowed. Therefore ,keep batteries and
weather station out of the reach of infants. If a battery has been swallowed, seek
medical advice immediately.
b.Keep packing material away from children. Risk of suffocation !
Warning-risk of injury
a.If a battery has leaked, avoid contact with your skin , eyes and mucous
membranes. If applicable, rinse the affected parts with water and consult a
doctor at once.
b.Batteries must not be charged, taken apart, thrown into fire or short-circuited.

13
Caution-material damage
Never expose the weather station to severe temperature fluctuations, moisture,
direct sunlight, dust or impacts.
Protect the batteries from intense heat. Remove the exhausted batteries from the
weather station.This will avoid damage that can be caused by leakage.
Always replace all the batteries simultaneously. Do not use different types or
brands of batteries or batteries with different capacities.
When inserting the batteries, ensure correct polarity (+/-).
Suggest not use rechargeable batteries which not providing the required voltage.
Do not use abrasive or solvent-based products to clean the weather station

14
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
(2)This device must accept any interference received, including interference that
may cause undesired operation.
WARNING Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the
equipment.
NOTE This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
To generate and use this equipment can radiate radio frequency energy, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio / TV technician for help.
