AOpen AK73(A)-V Setup guide

A
AK K7
73 3(
(A A) )- -V V
/
/
A
AK K7
73 3-
-V V
O
On
nl
li in
ne e M
Ma
an nu ua al
l
AK73(A)-V / AK73-V
DOC. NO.: AK73AV-OL-E0111B
1

A
AK K7
73 3(
(A A) )- -V V
/
/
A
AK K7
73 3-
-V V
O
On
nl
li in
ne e M
Ma
an nu ua al
l
W
Wh ha at t’ ’s s i in n t th hi is s m ma an nu ua al l
AK73(A)-V / AK73-V............................................................................................................................1
What’s in this manual ................................................................................................................................................................ 2
You Must Notice ........................................................................................................................................................................ 8
Before You Start ........................................................................................................................................................................ 9
Overview ................................................................................................................................................................................. 10
Quick Installation Procedure.................................................................................................................................................... 15
Motherboard Map .................................................................................................................................................................... 16
Block Diagram......................................................................................................................................................................... 17
Hardware Installation..................................................................................................................18
JP14 Clear CMOS ................................................................................................................................................................... 19
CPU Installation....................................................................................................................................................................... 20
JP21 FSB/PCI Clock & Ratio................................................................................................................................................... 21
Setting CPU Frequency........................................................................................................................................................... 22
Supported CPU Frequency...................................................................................................................................................... 23
CPU Overheat Protection ........................................................................................................................................................ 25
CPU and Housing Fan Connector (With H/W Monitoring)........................................................................................................ 27
2
CPU Fan on North Bridge........................................................................................................................................................ 28
DIMM Socket........................................................................................................................................................................... 29

A
AK K7
73 3(
(A A) )- -V V/ /
A
AK K7
73 3-
-V V
O
On
nl
li in
ne e M
Ma
an nu ua al
l
Front Panel Connector ............................................................................................................................................................ 31
ATX Power Connector ............................................................................................................................................................. 33
AC Power Auto Recovery ........................................................................................................................................................ 34
IDE and Floppy Connector ...................................................................................................................................................... 35
IrDA Connector........................................................................................................................................................................ 38
WOM (Zero Voltage Wake on Modem) .................................................................................................................................... 39
WOL (Wake on LAN) ............................................................................................................................................................... 42
AGP (Accelerated Graphic Port).............................................................................................................................................. 44
CNR (Communication and Network Riser)............................................................................................................................... 45
PC99 Color Coded Back Panel................................................................................................................................................ 46
Support 2nd USB Port............................................................................................................................................................... 47
CD Audio Connector................................................................................................................................................................ 48
Modem Audio Connector ......................................................................................................................................................... 49
Video-Audio-IN Connector....................................................................................................................................................... 50
Front Panel Audio.................................................................................................................................................................... 51
Battery-less and Long Life Design........................................................................................................................................... 52
Over-current Protection ........................................................................................................................................................... 53
Hardware Monitoring ............................................................................................................................................................... 55
3
Resettable Fuse ...................................................................................................................................................................... 56

AK73(A)-V /AK73-V Online Manual
AK73(A)-V / AK73-V Online Manual
Low ESR Capacitor ................................................................................................................................................................. 57
Layout (Frequency Isolation Wall) ........................................................................................................................................... 59
Driver and Utility..........................................................................................................................60
Autorun Menu from Bonus CD Disc......................................................................................................................................... 61
Installing Windows 95.............................................................................................................................................................. 62
Installing Windows 98.............................................................................................................................................................. 63
Installing Windows 98 SE, Windows ME & Windows2000........................................................................................................ 64
Installing VIA 4 in 1 Driver....................................................................................................................................................... 65
Installing Onboard Sound Driver.............................................................................................................................................. 66
Installing Hardware Monitoring Utility ...................................................................................................................................... 67
ACPI Suspend to Hard Drive................................................................................................................................................... 68
ACPI Suspend to RAM (STR).................................................................................................................................................. 73
AWARD BIOS ................................................................................................................................75
About BIOS Function Description…......................................................................................................................................... 76
How To Use Award™ BIOS Setup Program............................................................................................................................. 77
How To Enter BIOS Setup ....................................................................................................................................................... 79
BIOS Upgrade......................................................................................................................................................................... 80
4
Overclocking ................................................................................................................................82
VGA Card & Hard Disk ............................................................................................................................................................ 83

A
AK K7
73 3(
(A A) )- -V V/ /
A
AK K7
73 3-
-V V
O
On
nl
li in
ne e M
Ma
an nu ua al
l
Glossary .......................................................................................................................................84
AC97 ....................................................................................................................................................................................... 84
ACPI (Advanced Configuration & Power Interface).................................................................................................................. 84
AGP (Accelerated Graphic Port).............................................................................................................................................. 84
AMR (Audio/Modem Riser)...................................................................................................................................................... 85
AOpen Bonus Pack CD ........................................................................................................................................................... 85
APM (Advanced Power Management)..................................................................................................................................... 85
ATA (AT Attachment)................................................................................................................................................................ 85
ATA/66..................................................................................................................................................................................... 85
ATA/100................................................................................................................................................................................... 86
BIOS (Basic Input/Output System) .......................................................................................................................................... 86
Bus Master IDE (DMA mode)................................................................................................................................................... 86
CNR (Communication and Networking Riser).......................................................................................................................... 86
CODEC (Coding and Decoding) .............................................................................................................................................. 87
DDR (Double Data Rated) SDRAM.......................................................................................................................................... 87
DIMM (Dual In Line Memory Module) ...................................................................................................................................... 87
DMA (Direct Memory Access).................................................................................................................................................. 87
5
ECC (Error Checking and Correction)...................................................................................................................................... 88
EDO (Extended Data Output) Memory..................................................................................................................................... 88

AK73(A)-V /AK73-V Online Manual
AK73(A)-V / AK73-V Online Manual
EEPROM (Electronic Erasable Programmable ROM).............................................................................................................. 88
EPROM (Erasable Programmable ROM)................................................................................................................................. 88
EV6 Bus .................................................................................................................................................................................. 89
FCC DoC (Declaration of Conformity)...................................................................................................................................... 89
FC-PGA (Flip Chip-Pin Grid Array) .......................................................................................................................................... 89
Flash ROM .............................................................................................................................................................................. 89
FSB (Front Side Bus) Clock..................................................................................................................................................... 90
I2C Bus .................................................................................................................................................................................... 90
IEEE 1394 ............................................................................................................................................................................... 90
Parity Bit.................................................................................................................................................................................. 91
PBSRAM (Pipelined Burst SRAM)........................................................................................................................................... 91
PC-100 DIMM.......................................................................................................................................................................... 91
PC-133 DIMM.......................................................................................................................................................................... 91
PC-1600 or PC-2100 DDR DRAM ........................................................................................................................................... 92
PCI (Peripheral Component Interface) Bus.............................................................................................................................. 92
PDF Format............................................................................................................................................................................. 92
PnP (Plug and Play) ................................................................................................................................................................ 92
6
POST (Power-On Self Test)..................................................................................................................................................... 93
RDRAM (Rambus DRAM)........................................................................................................................................................ 93

A
AK K7
73 3(
(A A) )- -V V/ /
A
AK K7
73 3-
-V V
O
On
nl
li in
ne e M
Ma
an nu ua al
l
RIMM (Rambus Inline Memory Module)................................................................................................................................... 93
SDRAM (Synchronous DRAM) ................................................................................................................................................ 93
Shadow E2PROM .................................................................................................................................................................... 94
SIMM (Single In Line Memory Module).................................................................................................................................... 94
SMBus (System Management Bus) ......................................................................................................................................... 94
SPD (Serial Presence Detect) ................................................................................................................................................. 94
Ultra DMA................................................................................................................................................................................ 95
USB (Universal Serial Bus)...................................................................................................................................................... 95
VCM (Virtual Channel Memory)............................................................................................................................................... 96
ZIP file..................................................................................................................................................................................... 96
Troubleshooting...........................................................................................................................97
Technical Support......................................................................................................................101
Product Registration..................................................................................................................105
7

A
AK K7 73 3( (A A) )- -V V / / A AK K7 73 3- -V V O On nl li in ne e M Ma an nu ua al l
Y
Yo ou u M Mu us st t N No ot ti ic ce e
Adobe, the Adobe logo, Acrobat is trademarks of Adobe Systems Incorporated.
AMD, the AMD logo, Athlon and Duron are trademarks of Advanced Micro Devices, Inc.
Intel, the Intel logo, Intel Celeron, PentiumII, Pentium!!! are trademarks of Intel Corporation.
Microsoft, Windows, and Windows logo are either registered trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
All product and brand names used on this manual are used for identification purposes only and may be the registered
trademarks of their respective owners.
All of the specifications and information contained in this manual are subject to change without notice. AOpen reserves the right
to revise this publication and to make reasonable changes. AOpen assumes no responsibility for any errors or inaccuracies that
may appear in this manual, including the products and software described in it.
This documentation is protected by copyright law. All rights are reserved.
No part of this document may be used or reproduced in any form or by any means, or stored in a database or retrieval
system without prior written permission from AOpen Corporation.
Copyright©1996-2000, AOpen Inc. All Rights Reserved.
8

A
AK K7
73 3(
(A A) )- -V V
/
/
A
AK K7
73 3-
-V VO On
nl
li in
ne e M
Ma
an nu ua al
l
B
Be ef fo or re e Y Yo ou u S St ta ar rt t
This Online Manual will introduce to the user how this product is installed. All useful information will be described in later
chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved
in PDF format, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD disc or you can
get free download from Adobe web site.
Although this Online Manual is optimized for screen viewing, it is still capable for hardcopy printing, you can print it by A4 paper
size and set 2 pages per A4 sheet on your printer. To do so, choose File > Page Setup and follow the instruction of your printer
driver.
Thanks for the help of saving our earth.
9

A
AK K7 73 3( (A A) )- -V V / / A AK K7 73 3- -V V O On nl li in ne e M Ma an nu ua al l
O
Ov ve er rv vi ie ew w
Thank you for choosing AOpen AK73(A)-V / AK73-V. The AK73(A)-V / AK73-V is AMD®Socket 462 motherboard (M/B) based on
the ATX form factor featuring the VIA Apollo KT133A chipset. As high performance chipset built in the M/B, the AK73(A)-V /
AK73-V can support AMD®Socket 462 series Athlon™ & Duron™ processor and 200/266MHz (EV6) system bus. In the AGP
performance, it has one AGP slot and supports AGP 1X/2X/4X mode and pipelined spilt-transaction long burst transfer up to
1066MB/sec. According to different customer’s requirements, SDRAM and VCM (Virtual Channel Memory) can be applied to the
AK73(A)-V / AK73-V and the maximum memory size can be up to 1.5GB. The on-board IDE controller supports Ultra DMA
33/66/100 mode and the transfer rate up to 100MB/s. Further flexibility can be achieved by taking advantage of the
Communication and Network Riser (CNR) card option that allows audio and modem configuration on a single baseboard design.
Besides, the on-board AC97 CODEC chip (Optional) provides high performance
and magic surround stereo sound to let people enjoy working with AK73(A)-V /
AK73-V. Now, enjoy all features from AOpen AK73(A)-V / AK73-V.
10

A
AK K7
73 3(
(A A) )- -V V
/
/
A
AK K7
73 3-
-V VO On
nl
li in
ne e M
Ma
an nu ua al
l
About “Optional” and “Upgrade Optional”…
When you read this online manual and start to assemble your computer system, you may find some of functions are “Optional”,
and some are “Upgrade Optional”. This is because all of AOpen motherboards include many amazing and powerful features;
however, some of these are not frequently used on daily operation. Therefore, we define some key features as optional to meet
different requirements. Functions that can be upgraded by users, we define them as “Upgrade Optional”. The other optional
functions that may have been built on the motherboards and you cannot upgrade by yourself, we call them “Optional”. If needed,
you can contact your local distributors or resellers to purchase “Upgrade Optional” components. Also you can visit AOpen official
web site: www.aopen.com.tw <http://www.aopen.com.tw> to get detailed information.
11

A
AK K7 73 3( (A A) )- -V V / / A AK K7 73 3- -V V O On nl li in ne e M Ma an nu ua al l
Feature Highlight
CPU
Supports AMD® Socket 462 Athlon®& Duron®600MHz~1.4GHz with 200/266MHz EV6 system bus designed for Socket 462
technology.
Chipset
The VIA Apollo KT133/KT133A chip incorporated a VIA VT8363A north bridge is in charge of the host bus interface and memory
bus control. The memory bus control supports two and four-way interleaved of PC-100 and PC-133 SDRAM DIMM and VCM up
to 1.5GB. The north bridge provides one 32bit PCI bus running at 33MHz.
Memory
The three 168-pin DIMM system memory sockets support up to 1.5GB of PC-100/133 compliant SDRAM (Synchronous Dynamic
Random Access Memory), VCM (Virtual Channel Memory) and PC-100/PC-133 DIMMs. You can install 32, 64, 128, 256 and
512MB SDRAM DIMM module into each socket.
Expansion Slots
Including five 32-bit/33MHz PCI slots, one CNR and one AGP slot. The PCI local bus throughput can be up to 132MB/s. The
CNR (Communication and Networking Riser) slot provided from AK73(A)-V / AK73-V can support CNR interface for a
Modem/Lan/Audio card.
12

A
AK K7
73 3(
(A A) )- -V V
/
/
A
AK K7
73 3-
-V VO On
nl
li in
ne e M
Ma
an nu ua al
l
Ultra DMA 33/66/100 Bus Master IDE
Comes with an on-board PCI Bus Master IDE controller with two connectors that supports four IDE devices in two channels,
supports Ultra DMA 33/66/100 Bus Master IDE.
CPU Overheat Protection
Provides two ways to prevent CPU caused damage by overheat. You can enable/disable these two special functions by BIOS
setup program. Please refer to page 32 for more information.
On-board AC97 Sound
AK73(A)-V / AK73-V uses AC97 sound chip. This on-board audio includes a complete audio recording and playback system.
Power Management/Plug and Play
The AK73(A)-V / AK73-V supports the power management function that confirms to the power-saving standards of the U.S.
Environmental Protection Agency (EPA) Energy Star program. It also offers Plug-and-Play, which helps save users from
configuration problems, thus making to system user-friendlier.
Hardware Monitoring Management
Supports CPU or system fans status, temperature and voltage monitoring and alert, through the on-board hardware monitor
module and AOpen Hardware Monitoring Utility.
13

A
AK K7 73 3( (A A) )- -V V / / A AK K7 73 3- -V V O On nl li in ne e M Ma an nu ua al l
Enhanced ACPI
Fully implement the ACPI standard for Windows®95/98/ME/NT/2000 series compatibility, and supports Soft-Off, STR (Suspend
to RAM, S3), STD (Suspend to Disk, S4), WOM (Wake On Modem), WOL (Wake On LAN) features.
Super Multi-I/O
The AK73(A)-V / AK73-V provides two high-speed UART compatible serial ports and one parallel port with EPP and ECP
capabilities. UART2 can also be directed from COM2 to the Infrared Module for the wireless connections.
14

A
AK K7
73 3(
(A A) )- -V V
/
/
A
AK K7
73 3-
-V VO On
nl
li in
ne e M
Ma
an nu ua al
l
Q
Qu ui ic ck k I In ns st ta al ll la at ti io on n P Pr ro oc ce ed du ur re e
This page gives you a quick procedure on how to install your system. Follow each step accordingly.
1Installing CPU and Fan
2 Installing System Memory (DIMM)
3 Connecting Front Panel Cable
4 Connecting IDE and Floppy Cable
5 Connecting ATX Power Cable
6 Connecting Back Panel Cable
7 Power-on and Load BIOS Setup Default
8 Setting CPU Frequency
9 Reboot
10 Installing Operating System (such as Windows 98)
11 Installing Driver and Utility
15

A
AK K7 73 3( (A A) )- -V V / / A AK K7 73 3- -V V O On nl li in ne e M Ma an nu ua al l
Motherboard Map
CD-IN Connecto
r
Onboard AC’97 CODEC
(Optional) PC99 Color coded
Back Panel
MODEM-CN Connecto
r
AUX-IN Connecto
r
Resettable Fuse
Front Audio Connecto
r
Low ESR Capacitor
CNR Slot
A
GP Slot
462-pin CPU socket supports
A
MD Athlon & Duron
600MHz~1.4GHz
WOM Connecto
r
WOL Connecto
r
IrDA Connector CPU Fan Connector
with H/W monitoring
32-bit PCI slot x5
A
TX Power Connecto
r
Su
pp
ort 2nd USB Port VIAApollo KT133A (AK73(A)-V
or KT133 (AK73-V) chipset
PC-100/133 DIMM Slot x3
su
pp
orts maximum u
p
to 1.5GB
2MB Flash ROM BIOS
Front Panel Connecto
r
JP21 FSB Select Jum
p
e
r
FDD Connecto
r
JP14 Clear
CMOS Jumper
A
TA33/66/100 IDE
Connector x2
Chassis Fan Connector with
H/W Monitoring
16

17
VT8363A
VT8363A SDRAM
(3 DIMM sockets)
SDRAM
(3 DIMM sockets)
System
BIOS
System
BIOS
64 BIT CPU Data BUS
32BIT PCI Address/Data BUS
Primary IDE
VT686B
VT686B Secondary IDE
IDE 1
5 * PCI Slots
CNR
Socket A
100/133 MHz SDRAM and VCM
100MHz Register SDRAM
AC97
CODEC
AC97
CODEC
AGP Slot :1/2/4X
USB 1 X Printer port
2 X Com port
PS2 KB/Mouse
Hardware Monitoring
MIDI/Game Ports
66MHz 1x,2x
and 4xmode
200/266MHz FSB (EV6)
33MHz
USB PORT X2
IDE 2
USB Connector X2
AC97 Link ATA 33/66/100
I/O
Floppy Interface Floppy
A
AK K7
73 3(
(A A) )- -V V
/
/
A
AK K7
73 3-
-V VO On
nl
li in
ne e M
Ma
an nu ua al
l
B
Bl lo oc ck k D Di ia ag gr ra am m

A
AK K7 73 3( (A A) )- -V V / / A AK K7 73 3- -V V O On nl li in ne e M Ma an nu ua al l
H
Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
This chapter describes jumpers, connectors and hardware devices of this motherboard.
Note: Electrostatic discharge (ESD) can damage your processor, disk
drives, expansion boards, and other components. Always observe the
following precautions before you install a system component.
1. Do not remove a component from its protective packaging until
you are ready to install it.
2. Wear a wrist ground strap and attach it to a metal part of the
system unit before handling a component. If a wrist strap is not
available, maintain contact with the system unit throughout any
procedure requiring ESD protection.
18

A
AK K7 73 3( (A A) )- -V V / / A AK K7 73 3- -V V
O
On nl li in ne e M Ma an nu ua al l
J
JP P1 14 4 C Cl le ea ar r C CM MO OS S
You can clear CMOS to restore system default setting. To
clear the CMOS, follow the procedure below.
1. Turn off the system and unplug the AC power.
2. Remove ATX power cable from connector PWR2.
3. Locate JP14 and short pins 2-3 for a few seconds.
4
. Return JP14 to its normal setting by shorting pin 1 & pin 2.
5. Connect ATX power cable back to connector PWR2.
Tip: When should I Clear CMOS?
1. Boot fail because of overclocking…
2. Forget password…
3. Troubleshooting…
1
1
Normal Operation
(Default) Clear CMOS
19

AK73(A)-V / AK73-V Online Manual
AK73(A)-V / AK73-V Online Manual
C
CP PU U I In ns st ta al ll la at ti io on n
This motherboard supports AMD Athlon & Duron Socket 462 CPU. Be careful of CPU orientation when you plug it into CPU
socket.
1. Pull up the CPU socket lever and up to 90-degree angle.
2. Locate Pin 1 in the socket and look for a black dot or cut
edge on the CPU upper interface. Match Pin 1 and cut
edge. Then insert the CPU into the socket.
3. Press down the CPU socket lever and finish CPU
installation.
Note: If you do not match the CP
U
socket Pin 1 and CPU cut edge well,
y
ou ma
y
damage the CPU.
20
