AOpen MK79G-N User manual

Rese
t
able Fuse
A
TX Power Connecto
r
SYSFAN2 Connecto
r
A
GP 8x Expansion Slot
(For 1.5V AGP card only)
462-pin CPU Socket with Voltage and
Frequency Auto-Detection that supports
AMDTM AthlonTM / DuronTM / and
AthlonTMXP ( with CPU Overheat Protection
circuit to AthlonTMXP CPU onl
y)
NVidia nForce2-G (MK79G-N)
NVidia nForce2-GT (MK79G-1394)
CPUFAN1 Connector
184-pin DIMMx2 supports 128-bit dual
channel DDR400/DDR333/DDR266/DDR200
(Max. to 2GB) (When enabling VGA
onboard, memory can run max. up to
333MHz
)
IDE Connector x2 (ATA/66/100/133 supported) FDD Connector
CD-IN Connecto
r
Onboard AC97 CODEC RealTek ALC650
A
U
X
-IN Connecto
r
CNR Expansion Slot
32-bit PCI Expansion Slot x3
2n
d
USB 2.0 Port Connecto
r
Game Port Connecto
r
SYSFAN3
Front Audio Connecto
r
Front Panel Connecto
r
JP14 CMOS Data Clear Jumpe
r
STBY LED
Chassis Intrusion Sensor Connecto
r
S/PDIF Connector (MK79G-1394 only)
JP28 USB Keyboard/Mouse Wakeup
4Mbit Phoenix Award Flash ROM
JP27 USB keyboard/Mouse Wakeup
IrDA Connecto
r
RealTek RTL8201BL
PS/2 Mouse
Connector SPP/EPP/ECP Parallel Port
USB2.0
Ports
RJ45 10/100
LAN Jack
PS/2 Keyboard
Connector USB2.0 Port
COM 1 Port VGA Port
Line-In
MIC-In
Speaker
Out
A
Open reserves the right to revise all the specifications and information contained in this documentation, which are subject to change without notice.
IEEE1394 Connectors x 2
(For MK79G-1394 only)
COM2 Connecto
r
TV OU
T
Connecto
r
A
GP LED
4-
p
in 12V. ATX Power Connecto
r

2nd USB Channel 1st USB Channel
1. JP14 Clear CMOS
2. JP27/28 USB Keyboard/Mouse Wakeup Jumper
Everything you need to boot this
motherboard is included in this
Easy Installation Guide. For more
information, a complete Online
User's Manual can be found in the
Bonus Pack CD Disc. Thanks for
the help of saving our earth.
PART NO: 49.8B102.002 DOC. NO: MK79GN-EG-E0301D
This Easy Installation Guide x 1
80-Wire IDE Cable x 1
Floppy Drive Cable x 1
IEEE1394 Cable x 1 (MK79G-1394 only)
I/O Shield x 1
Bonus Pack CD disc x 1
This motherboard provides USB and PS2 keyboard / mouse wake-up function. You can use JP27 / JP28 to
enable or disable this function, which could resume your system from suspend mode with keyboard o
r
mouse installed. JP28 controls 1st USB channel, and JP27 controls 2nd USB channel. The factory defaul
t
setting is set to “Disable”(1-2), and you may enable this function by setting the jumper to 2-3.
You can clear CMOS to restore system default setting. To
clear the CMOS, follow the procedure below.
1. Turn off the system and unplug theAC power.
2. Remove ATX power cable from connector PWR2.
3. Locate JP14 and short pins 2-3 for a few seconds.
4. Return JP14 to its normal setting by shorting pin 1 & pin 2.
5. Connect ATX power cable back to connector PWR2.
Tip: When should I Clear CMOS?
1. Boot fail because of overclocking…
2. Forget password…
3. Troubleshooting…
Normal Operation
(default)
Clear CMOS
11
Pin 1
JP27
Pin 1
Pin 1
Enable
Disable
(Default)
1
Enable
Disable
(Default)
1
JP2
8

Plug in the CPU fan cable to the 3-pin CPUFAN1 connector. If you have chassis fan, you
can also plug it on SYSFAN2 or SYSFAN3 connector.
5. Setting CPU Voltage & Frequency
4. Memory Module (128-Bit DDR Dual Channel)
3. Installing CPU & Housing Fan
Note: Some CPU fans do not have
sensor pin, so that cannot support
fan monitorin
g
.
SYSFAN2 Connector
CPUFAN1 Connector
Full-range Adjustable CPU Core Voltage
This motherboard supports CPU VID function. The CPU core voltage will be automatically
detected and the range is from 1.1V to 1.85V. It is not necessary to set CPU Core Voltage.
Setting CPU Frequency
This motherboard is CPU jumper-less design, you can set CPU frequency through the
BIOS setup, and no jumpers or switches are needed.
BIOS Setup > Frequency / Voltage Control > CPU Speed Setup
Core Frequency = CPU FSB Clock * CPU Ratio
CPU Ratio From 5.5x to 16x step 0.5x
CPU FSB (Adjustment
manually) FSB = 100MHz-200MHz by 1MHz Stepping CPU Overclocking
CPU CPU Core Frequency EV6 Bus Clock Ratio
Athlon 1G 1GHz 200MHz 10.0x
Athlon 1.1G 1.1GHz 200MHz 11.0x
Athlon 1.2G 1.2GHz 200MHz 12.0x
Athlon 1.3G 1.3GHz 200MHz 13.0x
Athlon 1G 1GHz 266MHz 7.5x
Athlon 1.13G 1.13GHz 266MHz 8.5x
Athlon 1.2G 1.2GHz 266MHz 9.0x
Athlon 1.33G 1.33GHz 266MHz 10.0x
Athlon 1.4G 1.4GHz 266MHz 10.5x
AthlonXP 1500+ 1.3GHz 266MHz 10.0x
AthlonXP 1600+ 1.4GHz 266MHz 10.5x
AthlonXP 1700+ 1.46GHz 266MHz 11.0x
AthlonXP 1800+ 1.53GHz 266MHz 11.5x
AthlonXP 1900+ 1.6GHz 266MHz 12.0x
AthlonXP 2000+ 1.667GHz 266MHz 12.5x
AthlonXP 2100+ 1.73GHz 266MHz 13x
AthlonXP 2200+ 1.80GHz 266MHz 13.5x
AthlonXP 2400+ 2.0GHz 266MHz 15x
AthlonXP 2600+ 2.13GHz 266MHz 16x
AthlonXP 2700+ 2.16GHz 333MHz 13x
AthlonXP 2800+ 2.25GHz 333MHz 13.5x
Duron 800 800MHz 200MHz 8.0x
Duron 850 850MHz 200MHz 8.5x
Duron 900 900MHz 200MHz 9.0x
Duron 950 950MHz 200MHz 9.5x
Duron 1G 1GHz 200MHz 10.0x
Duron 1.1G 1.1GHz 200MHz 11.0x
Note: With CPU speed changing rapidly, there might be fastest CPU on the
market by the time you received this installation guide. This table is kindly for
your references only.
Warning: Nvidia nForce2-G/GT supports 166MHz FSB (with performance reaches
maximum 333MHz EV6 system bus) and 66MHz AGP clock, higher clock setting
may cause serious system damage.
GND
+12V
SENSOR
SYSFAN3 Connector
SENSOR
+12V
GND
In the past, we used to have 64-bit memory bandwidth for memory access. No matter how
many memory modules have been installed, though capacity added, the speed of access
remains the same. With 128-bit dual channel introduced, it doubles the memory bandwidth
up to 5.4GB in advanced 128-bit mode. This motherboard supports DDR400/333/266 with
Maximum capacity up to 2GB (When enabling VGA onboard, memory can run max. up to
333MHz)
128-bit DDR Dual Channel
Memory module
Note: You have to adjust CPU FSB in BIOS after installing
CPU; otherwise CPU will run at default speed of CPU FSB
value.
SENSOR
+12V
GND

USB2 Connector
7. Support 2nd USB Ports
6. IEEE 1394 Connectors (MK79G-1394 only)
9. Connecting Front Panel Cable
With IEEE1394 MAC Embedded in nVIDIA nForce2-GT chipsets (with AGERE FW802A),
the IEEE 1394 provides data transfer rate up to 400Mb/s, and USB just has 12Mbps.
Hence, the IEEE 1394 interface can connect with the devices that need high data
transferring performance, such as digital camera, scanner or others IEEE 1394 devices.
Please use the proper cable to connect with devices.
This motherboard provides six USB connectors to connect USB devices, such as mouse,
keyboard, modem, printer, etc. There are four connectors on the PC99 back panel. You
can use proper cable to connect the other USB connector to the back panel or front panel
of chassis.
A
ttach the power LED, speaker, and reset switch connector
s
to the corresponding pins. If you enable “Suspend Mode
”
item in BIOS Setup, the ACPI & Power LED will kee
p
flashing while the system is in suspend mode.
Locate the power switch cable from your ATX housing. It is
2-pin female connector from the housing front panel. Plug
this connector to the soft-power switch connector marked
SPWR.
8. Connecting IDE, Floppy Cables
Pin 1
ATA 66/100/133
IDE Connecto
r
Connect 34-pin floppy cable and 40-pin IDE cable to floppy connector FDC connector. Be
careful of the pin1 orientation. Wrong orientation may cause system damage.
IDE 2
IDE 1
Pin 1
FDD Connector
Pin 1
Pi
n
1
IEEE 1394
Port 1 & 2
KEY
1394_PWR
TPB+
GND
TPA+
Shielding GND
1394_PW
R
TPB-
GND
TPA-2 1
10 9
Warning: Please be noted
that Hot-Plug in is not
allowed on IEEE 1394
header, because it will burn
the IC of the controller and
damage the
motherboard.
+5V GND
2
1 +5V
NC
KE
Y
GND
SBD3-
SBD2-
SBD3+
SBD2+
1
SPWR
GND
ACPI LED-
GND
ACPILED
NC
ACPI_B
GND
RESET
GND
NC
NC
+5
V
IDE LED
IDE LED
+5
V
+5
V
GND
NC
SPEAKE
R
1
Speaker
IDE LED
SPWR
ACPI & PWR
LED
Reset
ACPI LED
(
Blue
)

11. Front Audio Connector
10. Connect IrDA Connector
If the housing has been designed with an audio port on the front panel, you’ll be able to
connect onboard audio to front panel through this connector. By the way, please remove
5-6 and 9-10 jumper caps from the Front Audio Connector before connecting the cable.
Please do not remove these 5-6 and 9-10 yellow jumper caps if there’s no audio port on
the front panel.
Pin 1
12. S/PDIF (Sony/Philips Digital Interface) Connector
(MK79G-1394 only)
The IrDA connector can be configured to support wireless infrared module, with this
module and application software such as Laplink or Windows 95 Direct Cable
Connection, the user can transfer files to or from laptops, notebooks, PDA devices and
printers. This connector supports HPSIR (115.2Kbps, 2 meters) and ASK-IR (56Kbps).
Install the infrared module onto the IrDA connector and enable the infrared function from
BIOS Setup, UART mode select, make sure to have the correct orientation when you plug
in the IrDA connector.
Pin 1
S/PDIF (Sony/Philips Digital Interface) is a newest audio transfer file format, which provides
impressive audio quality through optical fiber and allows you to enjoy digital audio instead o
f
analog audio. Through a specific audio cable, you can connect the S/PDIF connector to othe
r
end of the S/PDIF audio module, which bears S/PDIF digital output. Normally there are two
S/PDIF outputs as shown, one for RCA connector, the most common one used for consume
r
audio products, and the other for optical connector with better audio quality. Same as outputs,
you can also connect RCA or optical audio products to input connectors on the module and
have the voice or music come out from your computer. However, you must have a S/PDIF
supported speaker/amplifier/decoder with S/PDIF digital input/output to connect to the S/PDIF
di
g
ital in
p
ut/out
p
ut to make the most out of this function.
Pin 1
S/PDIF Module
(User Upgrade Optional)
S/PDIF
Cable
S/PDIF OUT
S/PDIF IN
(RCA)
S/PDIF IN
(Optical)
S/PDIF OUT
+5V
NC
S/PDIFOUT
GND
S/PDIFIN
1
13. Super 5.1 Channel Audio Effects
This motherboard comes with an ALC650 CODEC, which supports high quality of 5.1
Channel audio effects, bringing you a brand new audio experience. On the strength of the
innovative design of ALC650, you're able to use standard line-jacks for surround audio outpu
t
without connecting any external module. To apply this function, you have to install the audio
driver in the Bonus Pack CD as well as an audio application supporting 5.1 Channel. Picture
bellow represents the standard location of all speakers in 5.1Channel sound track. Please
connect the plug of your front speakers to the green “Speaker out” port, rear speakers’ plug
to the blue “Line in” port and both of the center and subwoofer speakers to the red “MIC in”
port.
1
IR_TX
+5V
NC
IR_R
X
GND
KEY
IrDA Connector
A
UD_FPOUT_L
HP_ON
A
UD_RET_
R
A
UD_VCC
A
UD_GND2
110
9
A
UD_MIC
A
UD_MIC_BIAS
A
UD_FPOUT_
R
KE
Y
AUD_RET_L

A
fter you finish the setting of jumpers and connect correct cables. Power on
and enter the BIOS Setup, press <Del> during POST (Power On Self Test).
Choose "Load Setup Defaults" for recommended optimal performance.
15. Power-on and Load BIOS Setup
16. AOpen Bonus Pack CD
You can use the autorun menu of Bonus CD disc. Choose the utility and driver and selec
t
model name.
Del
Warning: Please avoid of using "Load
Turbo Defaults", unless you are sure
your system components (CPU,
SDRAM, HDD, etc.) are good enough for
turbo settin
g
.
1 2
5 6
Composite Video
GND
Luma
KEY
GND
Chroma
Pin 1
TV Output Connecto
r
S-Terminal
AV-Terminal
This motherboard comes with Nvidia nForce2-GT chipsets, which allows you to accept digital
graphic input signal, and encodes, and transmit data through DVI or TV Output. Both NTSC
and PAL TV formats are supported for this function. You may just install a Video Port bracke
t
(as shown) to your back panel, connecting S-Terminal or AV-terminal to your TV, then using i
t
as your another monitor.
14. TV Output Connector
Warning: The upgrade of new BIOS will permanently replace your original BIOS
content after flashing. The original BIOS setting and Win2000/WinXP PnP
information will be refreshed and you probably need to re-configure your system.
17. BIOS Upgrade under Windows Environment
You may accomplish BIOS upgrade procedure with EzWinFlash by the following steps,
and it’s STRONGLY RECOMMENDED to close all the applications before you start the
upgrading.
1. Download the new version of BIOS package zip file from AOpen official web site.
(ex: http://english.aopen.com.tw)
2. Unzip the download BIOS package (ex: WMK79GN102.ZIP) with WinZip
(http://www.winzip.com) in Windows environment.
3. Save the unzipped files into a folder, for example, WMK79GN102.EXE &
WMK79GN102.BIN.
4. Double click on the WMK79GN102.EXE, EzWinFlash will detect the model name
and BIOS version of your motherboard. If you had got the wrong BIOS, you will no
t
be allowed to proceed with the flash steps.
5. You may select preferred language in the main menu, then click [Start Flash] to star
t
the BIOS upgrade procedure.
6. EzWinFlash will complete all the process automatically, and a dialogue box will pop
up to ask you to restart Windows. You may click [YES] to reboot Windows.
7. Press <Del> at POST to enter BIOS setup, choose "Load Setup Defaults", then
“Save & Exit Setup”. Done!

If you encounter any trouble to boot you system, follow the procedures
accordingly to resolve the problem.
Part Number and Serial Number
The Part Number and Serial number are printed on bar code label. You can find this
bar code label on the outside packing, on component side of PCB. For example:
Model name and BIOS version
MK79G-N R1.02 Jan. 01. 2003 AOpen Inc.
Award Plug and Play BIOS Extension v1.0A
Copyright © 1998,Award Software, Inc.
Model name and BIOS version can be found on upper left corner of first boot screen
(POST screen). For example:
MK79G-N is model name of motherboard; R1.02 is BIOS version
Make sure if the jumper settings for CPU and DRAMs are correct.
Clear CMOS.
Install the VGA card. Then connect your monitor and keyboard.
The problem was probably caused
by power supply or motherboard
failure. Please contact your reselle
r
or local distributor for repairing.
Perhaps your VGA card or monito
r
is defective.
No
Yes
No
Yes
It is very possible that your keyboard
is defective.
During system rebooting, press Del to enter BIOS Setup. Choose
“Load Setup Default".
The problem should be caused by the
IDE cables or HDD itself.
Re-install Windows 95, Windows 98 or Windows NT.
Yes
Yes
Turn off the power and unplug the AC power cable, then remove all
of the addon cards and cables, including VGA, IDE, FDD, COM1,
COM2 and Printer.
Turn on the power, and check if
the power supply and CPU fan
work properly.
Start
Check if there is display.
Press Ctrl, and Alt key at the
same time, hold them and then
press Del to see if the
s
y
stem reboots.
Turn off the system and
re-connect the IDE cable.
Check if the system can
reboot successfully.
End
No
No
P/N: 91.88110.201 is part number, S/N: 91949378KN73 is serial number.
Part No. Serial No.
Part No. Serial No.

Dear Customer,
Thanks for choosing AOpen products. To provide the best and fastest service to
our customer is our first priority. However, we receive numerous emails and
p
hone-calls worldwide everyday, it is very hard for us to serve everyone on time.
We recommend you follow the procedures below and seek help before contact
us. With your help, we can then continue to provide the best quality service to
more customers.
Thanks very much for your understanding!
A
Open Technical Supporting Team
Web Site: http://www.aopen.com/
E-mail: Send us email by going through the contact form below.
English http://english.aopen.com.tw/tech/default.htm
Japanese http://www.aopen.co.jp/tech/default.htm
Chinese http://www.aopen.com.tw/tech/default.htm
German http://www.aopencom.de/tech/default.htm
Simplified Chinese http://www.aopen.com.cn/tech/default.htm
Pacific Rim
AOpen Inc.
Tel: [phone]
Fax: [phone]
America
AOpen America Inc.
Tel: [phone]
Fax: [phone]
Europe
AOpen Computer b.v.
Tel: [phone]
Fax: [phone]
Germany
AOpen Computer GmbH.
Tel: [phone]
Fax: [phone]
China
艾爾鵬國際貿易(上海)有限公司
Tel: [phone]
Fax: [phone]
Japan
AOpen Japan Inc.
Tel: [phone]
Fax: [phone]
Online Manual: To download manual, please log on and then select your
preferred language. Under “Type” directory, choose “Manuals” to go to our
manual database. You can also find the manual and EIG in AOpen Bonus Pack.
http://club.aopen.com.tw/downloads
1
1
Test Report: We recommend you to choose board/card/device from the
compatibility test reports for assembling your PC. It may prevent incompatibility
problems.
http://english.aopen.com.tw/tech/report/default.htm
2
2
FAQ: Here we list problems that users often encounter and FAQ
(Frequently Asked Questions). You may select your preferred language
after log on, and may be able to find a solution to your problem.
http://club.aopen.com.tw/faq/
5
5
Download Software: After log on and having language selected, you may
get the latest updated BIOS/utility and drivers you need under “Type”
directory. In most case, newer versions of drivers and BIOS have solved
earlier bugs or compatibility problems.
http://club.aopen.com.tw/downloads
3
3
eForum: AOpen eForum is provided to discuss our products with other users, in
which your problem probably had been discussed before or will be answered.
After log on, you may select your preferred language under “Multi-language”.
http://club.aopen.com.tw/forum/
4
4
Contact Distributors/Resellers: We sell our products through resellers
and integrators. They should know your system configuration very well
and should be able to solve your problem efficiently and provide important
reference for you.
6
6
Contact Us: Please prepare detail system configuration and error
symptom before contacting us. The part number, serial number
and BIOS version are also very helpful.
7
7
