AORUS AD27QD User manual

- 2 -
LCD Monitor User’s Manual
Copyright
© 2018 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their
respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the
property of GIGABYTE.
Changes to the specications and features in this manual may be made
by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated,
transmitted, or published in any form or by any means without
GIGABYTE’s prior written permission.
• In order to assist in the use of this monitor, carefully read the User
Guide.
• For more information, check on our website at:
https://www.gigabyte.com

- 3 -
LCD Monitor User’s Manual
SAFETY INFORMATION
Regulatory Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

- 4 -
LCD Monitor User’s Manual
European Community Restriction of Hazardous Substances
(RoHS) Directive Statement
GIGABYTE products have not intended to add and safe from hazardous
substances (Cd, Pb, Hg, Cr+6, PBDE and PBB). The parts and components
have been carefully selected to meet RoHS requirement. Moreover, we
at GIGABYTE are continuing our eorts to develop products that do not
use internationally banned toxic chemicals.
European Community Waste Electrical & Electronic
Equipment (WEEE) Directive Statement
GIGABYTE will fulll the national laws as interpreted from the 2012/19/
EU WEEE (Waste Electrical and Electronic Equipment) directive. The
WEEE Directive species the treatment, collection, recycling and
disposal of electric and electronic devices and their components. Under
the Directive, used equipment must be marked, collected separately,
and disposed of properly.
WEEE Symbol Statement
The symbol shown below is on the product or on its
packaging, which indicates that this product must not be
disposed of with other waste. Instead, the device should be
taken to the waste collection centers for activation of the
treatment, collection, recycling and disposal procedure.
For more information about where you can drop o your waste
equipment for recycling, please contact your local government oce,
your household waste disposal service or where you purchased the
product for details of environmentally safe recycling.

- 5 -
LCD Monitor User’s Manual
Safety Precautions
Read through the following Safety Precautions before using the monitor.
• Only use the accessories that are provided with the monitor or that
which are recommended by the manufacturer.
• Keep the plastic packaging bag for the product in a place that
cannot be reached by children.
• Before connecting the monitor to the power outlet, make sure that
the voltage rating of the power cable is compatible with the power
specication in the country where you are located.
• The power cord plug must be connected to a properly wired and
grounded power outlet.
• Do not touch the plug with wet hands, otherwise easily cause
electric shock.
• Place the monitor in a stable and well-ventilated place.
• Do not place the monitor near any heat sources such as electric
radiators or direct sunlight.
• The holes or openings on the monitor are for ventilation. Do not
cover or block the ventilation holes with any objects.
• Do not use the monitor near water, drinks, or all types of liquids.
Failure to do so may result in electric shock or damage to the
monitor.
• Make sure to unplug the monitor from the power outlet before
cleaning.
• As the screen surface is easy to be scratched, avoid touching the
surface with any hard or sharp object.
• Use a soft lint-free cloth instead of a tissue to wipe the screen. You
may use a glass cleaner to clean the monitor if required. However,
never spray the cleaner directly onto the screen.
• Disconnect the power cable if the monitor is not being used for a
long period of time.
• Do not attempt to disassemble or repair the monitor yourself.

- 6 -
LCD Monitor User’s Manual
CONTENTS
Safety Information .....................................................................................................................3
Regulatory Notices...........................................................................................................3
Safety Precautions............................................................................................................5
Introduction .................................................................................................................................7
Unpacking...........................................................................................................................7
Package Contents.............................................................................................................9
Product Overview..........................................................................................................10
Getting Started.........................................................................................................................12
Installing the Monitor Base ........................................................................................12
Adjusting the Viewing Angle.....................................................................................14
Installing a Wall-Mount Bracket (Optional) ..........................................................16
Making Connections ....................................................................................................18
Using the Device......................................................................................................................19
Turning the Power On/O..........................................................................................19
Managing the Cables ...................................................................................................20
User Comfort Recommendations............................................................................20
Selecting the Input Source.........................................................................................21
Operations .................................................................................................................................22
Quick Menu......................................................................................................................22
Congure the Device Settings ..................................................................................27
Appendices................................................................................................................................37
Specications..................................................................................................................37
Supported Timing List..................................................................................................38
Troubleshooting.............................................................................................................39
Basic Care..........................................................................................................................40
Notes on USB Charging ...............................................................................................40
GIGABYTE Service Information.................................................................................40

- 7 -
LCD Monitor User’s Manual
INTRODUCTION
Unpacking
1. Open the upper cover of the packaging box. Then observe the
unpacking label attached on the inner cover.
2. Making sure the box is in the correct orientation, carefully lay the
box on the stable surface.
UP
3. Open the inner cover.
Openings
4. Grab the EPS foam assembly (through the openings) to pull it out of
the box.

- 8 -
LCD Monitor User’s Manual
5. Remove the items from the upper EPS foam.
6. Remove the upper EPS foam. Then you can remove the monitor from
the lower EPS foam.

- 9 -
LCD Monitor User’s Manual
Package Contents
The following items come with your packaging box. If any of them is
missing, please contact your local dealer.
Monitor Monitor Base Power Cable
HDMI Cable USB Cable DP Cable
Multilingual
Installation
Guide
AORUS AD27QD
Warranty Card
Cable Holder Quick Start Guide Warranty Card
CD
Note: Please keep the packaging box and packing materials for future
transportation of the monitor.

- 10 -
LCD Monitor User’s Manual
Product Overview
Front View
1
2
1Power LED 2Control button

- 11 -
LCD Monitor User’s Manual
Rear View
USB 3.0HDMI-2DPHDMI-1
USB 3.0HDMI-2DPHDMI-1
1 2 3 4 6 7 85
1AC IN jack
2Kensington lock
3Headphone jack
4Microphone jack
5HDMI ports (x2)
6DisplayPort
7USB upstream port
8USB 3.0 ports (x2)

- 12 -
LCD Monitor User’s Manual
GETTING STARTED
Installing the Monitor Base
1. Place the monitor on a at surface, with the screen facing down.
Note: We recommend that you cover the table surface with soft cloth to
prevent damage to the monitor.
2. Align the monitor base with the stando underneath the stand. Then
attach the base onto the stand.
3. Tighten the screw to secure the monitor base in place.
Note: You can either use a coin or a small athead screwdriver to tighten
the screw.

- 13 -
LCD Monitor User’s Manual
4. Lift the monitor to an upright position and place it on a table. Then
lower the screen to allow the safety plate to automatically release
from its slot.

- 14 -
LCD Monitor User’s Manual
Adjusting the Viewing Angle
Note: Hold the monitor base so that the screen does not topple when you
make the adjustment.
Adjusting the Tilt Angle
Tilt the screen forward or backward to the desired viewing angle
(-5˚ to 21˚).
5°
21°
Adjusting the Swivel Angle
Swivel the screen to the left or right for the desired viewing angle (20˚).
20° 20°

- 15 -
LCD Monitor User’s Manual
Changing the Screen Orientation
1. Raise the screen to the highest position (130mm).
130 mm
Note: Before making the height adjustment, make sure you have removed
the safety plate from the stand.
2. Rotate the monitor (90˚ clockwise) to portrait orientation.
90°

- 16 -
LCD Monitor User’s Manual
Installing a Wall-Mount Bracket (Optional)
Use only the 100 x 100 mm wall mount kit recommended by the
manufacturer.
1. Place the monitor on a at surface, with the screen facing down.
Note: We recommend that you cover the table surface with soft cloth to
prevent damage to the monitor.
2. Push the locking clips inward to detach the stand from the monitor.
3. Pull down the stand slightly to disengage the hooks. Then remove
the stand.

- 17 -
LCD Monitor User’s Manual
4. Attach the mounting bracket to the mounting holes at the rear of
the monitor. Then use the screws to secure the bracket in place.
USB 3.0HDMI-2DPHDMI-1
100 mm
100 mm
Note: To mount the monitor on the wall, refer to the installation guide that is
included in the wall-mount bracket kit.

- 18 -
LCD Monitor User’s Manual
Making Connections
USB 3.0HDMI-2 DPHDMI-1
1
1
2
2 4 6
3 5
7
Keyboard
Mouse & USB disk
drive
Computer
Computer
Microphone
Headphone
Power outlet
1Power cable
2Headphone cable
3Microphone cable
4HDMI cable
5DisplayPort cable
6USB (A-Male to B-Male)
cable
7USB cable

- 19 -
LCD Monitor User’s Manual
USING THE DEVICE
Turning the Power On/O
Power On
1. Connect one end of the power cable to the AC IN jack at the rear of
the monitor.
2. Connect other end of the the power cable to a power outlet.
3. Press the Control button to turn on the monitor. The Power LED will
light in white, indicating the monitor is ready to use.
Note: If the Power LED remains o after you turn on the monitor, please check
the LED Indicator setting in the Settings menu. Refer to page 34.
Power O
Press the Control button for 2 seconds to turn o the monitor.
Note: When the Main menu appears on the screen, you can also turn o the
monitor by moving the Control button down ( ). Refer to page 24.

- 20 -
LCD Monitor User’s Manual
Managing the Cables
1. Align the cable clip with the clip holes at the rear of the monitor.
2. Press the cable clip rmly until it is fully seated. Then route the
connected cables through the clip.
User Comfort Recommendations
The following are some tips for comfortable viewing of your monitor:
• Optimal viewing distances for monitors range from approximately
510 mm to 760 mm (20”to 30”).
• A general guideline is to position the monitor such that the top
of the screen is at or slightly below your eye-height when you are
comfortably seated.
• Use adequate lighting for the type of work you are performing.
• Take regular and frequent breaks (at least for 10 minutes) every half-
hour.
• Be sure to periodically look away from your monitor screen and focus
on a far object for at least 20 seconds during the breaks.
• Eye exercise can help reduce eye strain. Repeat these exercises
frequently: (1) look up and down (2) slowly roll your eye (3) move
your eyes diagonally.
