Apco FullView Series User manual

1. Remove the base plate from the carton
and remove protective packing materials.
Caution: Steel plate is heavy, take
precatutions to prevent dropping.
Set aside.
2. Remove kiosk from the carton and leave
protective channels in place until base is
secured. Place the kiosk across the
shipping carton.
3. Use the (4) phillips head machine screws
to attach base plate to kiosk as shown
(Fig 1).
4. Stand kiosk upright and remove
remaining packing materials.
1. Use the Magnetic Tool to remove Locking
Pin. Access the Locking PIn by removing
green tape at top right hand corner of
kiosk. Place the magnet over the steel
pin as shown in Fig 2.
Should the pin be difficult to magnetically
remove, shift Clear Lens (CL) to the left
using the SCT.
2. Use the SCT to shift the CL to the RIGHT.
The LEFT side of the CL will release from
the vertical edge.
3. Set aside CL. A special low tack tape to
hold and position graphic insert is located
at the top center of the display area. Peel
the white liner on the tape and position
graphic. Press across the tape area to
secure graphic while replacing the CL.
4. Replace CL using SCT, inserting acrylic
into the right side vertical edge. Secure
the lens by compressing special
‘cushions’ on the right side until lens is flat
against graphic. Release CL and the
cushion will shift the lens left and under
the vertical edge. Replace Locking Pin.
388 Grant Street, SE, Atlanta, Georgia USA 30312-2227 Telephone [phone] Web: www.apcosigns.com IS459
Assembly
Instructions
Prepare Kiosk for Base Attachment
11/3/2016
FullView Kiosk Series
Kiosk Clear Lens Removal
1.
2.
Clear Lens
Clear Lens
Base Plate
Suction Cup Tool
(SCT)
Fig 1
Protective channel
Steel Base Plate
Crate
Fig 2
Low tack tape
for graphic

Description Code* QTY/Assy
1. Top Clear Lens
2. Lower Decorative insert
3. Rear Panel or Clear Lens
4. Base Plate
5. Attachment screws
6. Vertical Frame Assembly
(1)
(1)
(1)
(1)
(1)
(4)
(1)
Assembly Hardware
#3 drive bit for #14 FH - Phillips screw
Quantity: (1)
Flat Head-Phillips - Self Threading machine screw
(#1/4-20 x 1” Type F)
Quantity: (4)
Tools
4
3.
2.
1.
5.
6.
Assembly
Instructions
388 Grant Street, SE, Atlanta, Georgia USA 30312-2227 Telephone [phone] Web: www.apcosigns.com IS459
SCTMagnetic Pin Removal Tool
*Note: If replacements are needed,
specify kiosk size. ____H x _____W
11/3/2016
FullView Kiosk Series
