APG Exhibits CSNR-13FS Manual

Step 5: Move to the center of cable
and hand tighten remaining turn
buckle to remove any remaining
slack. Do not over tighten.
Step 6: Start in one corner of the
frame and push the silicone edge
of graphic into the inside groove.
Insert for 4-6 inches in both direc-
tions. Repeat on all corners.
Step 7: Continue inserting silcone
edge of graphic into the frame
working towards the center of
frame on each side. Do not over pull
or stretch.
Step 2: Connect all corner sections
to straight sections of the frame by
matching color on pipes.
Step 3: Build two outer frames and
connect top and bottom frames
together in the corners with small
connecting pipes.
Step 4: At the top of the frame
attach cable to left and right side.
Tighten or loosen with hand pull.
x2
Step 1: Assemble all straight pipes
with bungee cords by pushing and
pulling together.
CSNR-13FS
USE DROP CLOTH
TO PROTECT GRAPHICS:
Unfold drop cloth and place on
smooth flat surface. Install graph-
ics on top of drop cloth to keep
clean. Do not walk on plastic or
graphics with dirty shoes.
Top of graphic is side with cable.

Step 12: Repeat step 11 until all
Light Arrays are attached. Lights
Arrays do not attach to bottom of
frame, but hang under their own
weight in final upright position.
Step 13: Repeat Steps 6 and 7 to
attch printed graphic for double
-sided display or light block panel
for single-sided display.
Step 14: Front and back graphic
complete.
Continue: Next page.
Step 9: Flip frame and graphic over.
Note: make sure you are using
the drop cloth and working on a
smooth surface to prevent damage
to your graphic.
Step 10: Take out the LED Lights
and gently unroll on the graphic
with lights face down. WARNING!
Do not drag lights across ground or
it could break the LED lights.
Step 11: Attach Light Array at top
of frame onto wire harness clips.
x8
Step 8: Completed graphic frame
for front side.
CSNR-13FS

x4
Step 17: Attach LED Light Array to
one power supply. Stand display
into upright poition over top of
power supply with power cord
showing.
Step 18: With display in upright
position, insert silicone edge of
graphic into groove of frame. Start
at opposite corners first, then work
your way around entire edge.
Step 19: Move display into position
and plug power cords into outlet to
illuminate display.
Step 16: Insert feet into 4 corners
of the frame base.
x2
CSNR-13FS
