APM CO., LTD
ASP-242-1 ASP-243-1 ASP-244-1
Applications
Technical Sheet ●CDMA/GSM900/3G/WLAN/GSM1800/PCS
●Signal Splitter
●Outdoor used
Features:
●Broadband
●Low VSWR
●High Isolation
●Constructed by Microstrip
●Die cast Aluminum Cavity
●Integral N-Female
Specification Install Sketch
Category 2 Way
Splitter
3 Way
Splitter
4 Way
Splitter
Model ASP-242-1 ASP-243-1 ASP-244-1
Freq. Rang -MHz
Insertion loss-dB ≤3.5 ≤5.4 ≤6.6
Isolation-dB
Impedance-Ω
VSWR
Max. Power-W
Connector Type
Temperature-℃
Humidity-%
Size-mm 117×83×21 135×83×21 115×112×21
Weight-g 240 245 330
5~95
≤1.4
50
N Female
-30～+60
SPLITTER
800～2500
≥20
50
1F, No.49, Alley 24, Lane 75, Sec 3, Kang-Ning Rd, Nei-Hu Dist, Taipei 114, Taiwan, R.O.C.
www.apm.com.tw [email protected] Tel: [phone] Fax: [phone]
