APM CO., LTD
AAIP-W610
Complies with IEEE 802.11b/g standard for 2.4GHz Wireless LAN.
Support 64-bit and 128-bit WEP, WPA, WPA2, encryption/decryption and WPA with Radius.
Support IEEE 802.1x Authentication, IAPP, WDS.
Support IEEE 802.3x full duplex flow control on 10/100M Ethernet interface.
Support DHCP server to provide clients auto IP addresses assignment and
DHCP client, static IP, PPPoE, PPTP of WAN Interface.
Support firewall security with port filtering, IP filtering, MAC filtering, port
forwarding, trigger port and DMZ hosting functions.
WEB based management and configuration.
Support UPnP for automatic Internet access and Dynamic DNS service.
Support NTP client service and Log table and remote Log service.
Setup Wizard mode, Supports Virtual Private Network (VPN) connection.
Supports the AP / Client / WDS/ AP+WDS features and functional
Supports firmware upgrade function via Web
Supports security log
Supports authentication for wireless connectivity based on ESSID
Provides MAC access control and hidden SSID function
WDS supported with WEP, TKIP and AES encryption
Support IPSEC tunnel encryption (3DES/AES128) and authentication
(MD5/SHA1) functions
Features:
IEEE 802.11g Wireless Broadband Route
r
Full Passive PoE Support (4LAN+1WAN)
22F,-6 No.180 Jingping, Rd.,Jhonghe City, Taipei County 23581, Taiwan, R.O.C.
www.apm.com.tw [email protected] Tel: [phone] Fax: [phone]

2 of 2
APM CO., LTD
AAIP-W610
Standards IEEE 802.11g IEEE 802.11b, IEEE 802.3, IEEE 802.3u
Interface 1*WAN Ports 4* LAN Ports
Security 64/128-bit WEP, WPA(TKIP with IEEE 802.1x), WPA2, AES
54Mbps OFDM, 8%PER, -71dBm; 11Mbps CCK, 10%PER, -81dBm;
1Mbps BPSK, 10%PER, -92dBm
Data rate 802.11b: 1, 2, 5.5 and 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, and 54Mbps
Channel USA 11, Europe 13, Japan 14
Memory 2M Flash, 16M SDRAM
Modulation Method CCK (802.11b), OFDM (802.11g)
Frequency Band 2.4GHz – 2.497GHz ISM Band, DSSS
Antenna Reverse SMA detachable 2dBi antenna
Operating Temperature 0~40℃ambient temperature
Storage Temperature : -10~70℃
Receiver Sensitivity 54Mbps OFDM, 10% PER, -68dBm; 11Mbps CCK, 8% PER,
-86dBm; 1Mbps BKSK,8%,-92dBm
Transmit Power 18dBm
LED Power, Active (WLAN), Act/Link (Ethernet)
Power Power Switching adapter (+12V/1A)
Humidity 10%~95% RH, non condensing
Dimension L15*W8*H3cm
Package contents One 11g wireless AP Router
One CD-ROM with user Guide
One Power adapter
Receiver Sensitivity
Spectifications
