APM Video Server AAL - 7910 1CH User manual

APM CO., LTD
AAL - 7910 1CH Video Server
AAL - 7940 4CH Video Serve
r
FEATURES
z1 ch video input (AAL-7910) / 4 ch video inputs (AAL-7940)
zIP filter for advanced security
zRS-485 control interface (PTZ)
z2 sensors inputs / 2 alarm outputs
zSupport TCP/IP, SMTP, FTP, PPPoE , DHCP
zLocal Backup Port: CF memory card
SPECIFICATIONS
Model AAL - 7910 AAL - 7940
Preset Number 16
Power Supply 12VDC/400mA.
Alarm Input 2*In/2*Out
Video Input 1 channel 4 channels
Video Output lVpp / 75 Ohm -
Control Interface RS-485
PTZ Protocol Pelco P, Pelco D, A-Linking
Audio Streaming lch,Linein -
Codec JPEG, 3 levels
Resolution 640*480,352*288,320*240,176*144
Up to 30 fps for all resolutions Up to 30 fps for single channel viewing
Up to 5fps for quad channel mode
Compatibility Windows 2000, XP
LANI/F 10/100M
Notification Email, FTP, Popup Message
Local Backup CF memory card
Operating System Linux
Type of IP Address Static or Dynamic
Viewer Microsoft Internet Explorer 5.0 or later
IP Filtering Yes
Networking Protocol TCP / IP, HTTP , SMTP , FTP, NTP , DNS , DDNS , ARP and DHCP
Communication Protocol PPPoE
O.P Temperature 5°C to 45°C(40°F to 113°F)
Gross Dimension 22cm*30cm*9cm
Gross Weight 1 Kg
Frame Rate
1F, No.49, Alley 24, Lane 75, Sec 3, Kang-Ning Road, Nei-Hu District, Taipei 114, Taiwan, R.O.C
www.apm.com.tw apm.sales @msa.hinet.net Tel:[phone] Fax:[phone]
