Applica Presenter User manual

User ManualUser Manual

User Manual

Presenter / Presenter Pro

One PC can display and manage 4 additional remote monitors.

MNAPPR11072005V1.0

Page 2

Notice

The information contained in this document is subject to change without

notice. Applica, Inc. makes no warranty of any kind with regard to this

material, including but not limited to, implied warranties of merchantability

and fitness for any particular purpose.

Applica, Inc. will not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing, performance

or use of this material.

No part of this document may be photocopied, reproduced or translated

into another language without prior written consent from Applica, Inc.

MNAPPR11072005V1.0 Page 3

Table Of ContentsTable Of Contents

Table Of Contents

IntroductionIntroduction

Introduction ................................................................................................................................................................................................................................

................................................................................................................................................................................................................................

................................................................................................................ 44

What‘s in the box..................................................................................................4

Introducing the Presenter..................................................................................5

Peripheral Compatibility .....................................................................................5

Installation and OperationInstallation and Operation

Installation and Operation ..........................................................................................................................................................................

..........................................................................................................................................................................

..................................................................................... 66

Before you install Presenter ........................................................................................................................................................

........................................................................................................................................................

............................................................................ 6

Quick Start ......................................................................................................................................................................................................................

........................................................................................................... 7

Connecting the Presenter PCI Card ................................................................8

Connecting the Remote Monitors (Presenter) ............................................9

Connecting the Remote Monitors (Presenter Pro) ....................................9

System Power Up............................................................................................... 10

Installing the ApplicaXP Software ................................................................ 11

Installing the Presenter2 Software ............................................................... 12

Preparing System CAT5 cable ....................................................................... 12

AppendixAppendix

Appendix ......................................................................................................................................................................................................................................

................................................................................................................... 1313

1313

Specifications ...................................................................................................... 13

Technical Support .............................................................................................. 14

Troubleshooting ................................................................................................ 14

Limited Warranty Statement .......................................................................... 15

MNAPPR11072005V1.0

Page 4

IntroductionIntroduction

Introduction

What‘s in the boxWhat‘s in the box

What‘s in the box

stnetnoCegakcaPretneserP

ytQnoitpircseDrebmuNtraP

1draCICPretneserP101-G-4UPA

4elbaCAGVot5TAC100-VC-BCPA

1)DC(er

awtfoSretneserP&PXacilppARP-PX-SPA

stnetnoCegakcaPORPretneserP

ytQnoitpircseDrebmuNtraP

1draCICPretneserP101-G-4UPA

1rettimsnarToiduA/AGXUtroP400

4XT-XLS

4revieceRoiduA/AGXU001XR-XLS

1)DC(erawtfoSretneserP/PXacilppARP-PX-SPA

1retpadArewoPV21SU-A2D21-SP

MNAPPR11072005V1.0 Page 5

IntroductionIntroduction

Introduction

Introducing the PresenterIntroducing the Presenter

Introducing the Presenter

When you need to create that special presentation, The Presenter from Applica

can help make it a succes. When you need to have multiple screens and need to

control them from a central location, The Presenter can help. You can manage

and control four additional screens. You can even manage and control up to 16

remote screens by using multiple Presenter Cards.

The Presente Pro adds the functionality of having those remote screens at extremely

remote locations. This is done by combining Applica with SmartAVI. Using the

combination of transmitter and receiver units, SLX-TX400 & SLX-RX100, you can

have those remote screens up to 1000 ft. away.

There are many applications for the Presenter. Some of these include:

•Dynamic Digital Advertising such as malls, airports, hotels, convention centers,

and Sports arenas.

•Education and Entertainment such as information walls, booths, program

information and updates.

•Special Events and Demonstrations such as Vendor booths, product

presentations, and special speaker events.

Peripheral CompatibilityPeripheral Compatibility

Peripheral Compatibility

Start installation process by ensuring that all video displays and audio devices are

compatible with the computers. This is accomplished by connecting the devices

directly to the computer (bypassing the presenter card and/or SLX-100 receivers)

and checking that the devices operate as desired.

If they operate as desired, they should function properly when connected to the

Presenter unit.

If the device does not operate as desired when connected directly to the computer,

something is wrong with the device, NOT the Presenter unit since it is not yet

connected.

MNAPPR11072005V1.0

Page 6

Before you install PresenterBefore you install Presenter

Before you install Presenter

There are several steps you should take in preparation for the installation of

your Presenter unit. These steps are to ensure proper installation so that your

product may run smoothly and trouble free.

We have attempted to make the installation procedure as simple as possible.

Variations in computer systems might make your installation procedure unique

but please try to follow these steps as closely as possible.

Please check the following:

•Make sure to logon with a username and password that has Administrator

privileges.

•Install and register Windows XP and all normal applications that you will

run on this PC.

•Make sure that you have installed current drivers for your normal video

adapter.

•If your PC supports Hyperthreading (HT), make sure that it is disabled in the

BIOS/CMOS.

•Make sure that any Remote Control Host software is uninstalled.

•Verify that Windows XP Service Pack 1 (SP1 or SP1a) is installed. (Start >

Control Panel > System > General. Or Windows Key+Pause/BreakKey).

•Make sure that you have at least 256MB of Ram.

•It might later be useful to determine wether your computer uses an AGP or

PCI Graphics Card. You may write it down or remember it.

•Disable any screen savers. Go to Control Panel > Display > Screen Saver Tab

and select (None) for the screen saver. Here you will also want to adjust

the Power settings by clicking the Power button at the bottom of the

Screen Saver tab. You will want to select the Always On power scheme and

“Turn Off Monitor” should be set to “Never”.

•Make sure that any AntiVirus software is disabled as this may interrupt or

interfere with installation. Note: You may reenable this software after

Presenter is installed.

After any settings might have been made it might be neccessary to restart your

computer. If you have not done so already please do so no to ensure that all

changes have been finalized.

Installation and OperationInstallation and Operation

Installation and Operation

MNAPPR11072005V1.0 Page 7

Installation and OperationInstallation and Operation

Installation and Operation

Quick StartQuick Start

Quick Start

Before beginning installation ensure that your PC is turned off. Follow the Steps

indicated for the Presenter Package you have.

1. Install the Presenter PCI card into an available PCI slot in your computer.

2. (Presenter) Connect the CAT5 to VGA adapters to the 4 CAT5 connectors

on the Presenter Card.

(Presenter Pro) Use 4 CAT5 cables to Connect the Presenter Card to the

inputs on the SLX-TX400.

3. (Presenter Pro) Run a CAT5 cable from the transmitter to the remote

location of your screen. Connect a remote station (SLX-RX100) into each

end of those CAT5 cables that you will be using.

4. (Presenter)Connect remote monitors to the ends of the CAT5/VGA cables.

(Presenter Pro) Connect monitors and/or speakers to SLX-RX100 units.

Then connect the external power supply to the AC IN connection of the

SLX-X400 unit. (Optional) Connect power adapters to the SLX-RX100 units.

5. Power on your PC.

6. Windows will now recognize that new hardware has been installed. Allow

it to detect all of the hardware. This could take a few minutes.

7. Install the provided ApplicaXP software (includes drivers) and the Presenter

Software.

8. Reboot your computer.

Presenter

Presenter Pro

MNAPPR11072005V1.0

Page 8

Connecting the Presenter PCI card (Detailed)Connecting the Presenter PCI card (Detailed)

Connecting the Presenter PCI card (Detailed)

1. Open up the computer so the inside is exposed. Usually this is a side panel.

2. Find an available PCI slot. Remove the filler bracket from the slot you have

selected.

3. Ground yourself by briefly touching something metal, such as the

computer chassis, with your fingers, and then remove the PCI board from

its shielded plastic envelope.

4. Carefully insert the Presenter card making sure that it is properly and

completely inserted. This is done by firmly applying pressure across the top.

You will feel the card slide into place. If you do not know how to do this

find someone who is qualified to do so. Verify that no other PCI cards have

been accidentally lifted from their slots.

5. Insert a screw to secure the chrome bracket of the pci card to the PC case.

Note: If you are connecting more than one Presenter card, completely

install the first card and make sure it is fully operational. This will simply the

installation process and simplify possible troubleshooting later on.

6. Put the cover back on the computer. (If you are connecting multiple cards

you can postpone this step until all of the cards are installed.

Before beginning installation ensure that the PC is turned off.

Installation and OperationInstallation and Operation

Installation and Operation

The Applica Presenter card requires an available full length PCI

slot . The PC case must also be large enough to accommodate

and cool a card of this size.

MNAPPR11072005V1.0 Page 9

Installation and OperationInstallation and Operation

Installation and Operation

Connecting the Trasnmitter, Receivers and RemoteConnecting the Trasnmitter, Receivers and Remote

Connecting the Trasnmitter, Receivers and Remote

Monitors (Presenter Pro)Monitors (Presenter Pro)

Monitors (Presenter Pro)

1. Use four CAT5 cables to connect the outputs on the Presenter card

to the inputs on the SLX-TX400 unit.

2. Optional - Connect audio inputs to the front of the SLX-TX400 or connect a

standard USB 2.0 cable to the SLX-TX400 to use built in audio.

2. Connect additional CAT5 cables to the output connectors on the SLX-

TX400 units and run those cables to the location of your remote monitors.

3. Connect an SLX-RX100 unit to each end of those CAT5 cables.

4. Connect your output monitor and speakers to the SLX-RX100 units.

* Up to four can be connected although only

two are shown.

* Up to four can be connectedalthough only one is

shown

Connecting the Remote Monitors (Presenter)Connecting the Remote Monitors (Presenter)

Connecting the Remote Monitors (Presenter)

1. Use the supplied CAT5 to VGA cables to connect the remote monitors to the

the CAT5 connectors on the Presenter Card.

MNAPPR11072005V1.0

Page 10

System Power UpSystem Power Up

System Power Up

1. Presenter Pro - Connect the 12 Volt power supply to the SLX-TX400 and plug

it into the wall socket.

2. Presenter Pro - (Optional) Connect power adapter to remote units and plug

those into a wall socket. Power on the remote stations.

3. Power on your computer.

4. On boot up, Windows should recognize that new hardware has been

installed. This may take a few minutes as it recognizes the necessary

hardware for the Presenter Card.

Before you power up, ensure that all cables are properly connected as shown in

the diagram below.

Installation and OperationInstallation and Operation

Installation and Operation

Presenter

Presenter Pro

MNAPPR11072005V1.0 Page 11

Installation and OperationInstallation and Operation

Installation and Operation

Installing the ApplicaXP softwareInstalling the ApplicaXP software

Installing the ApplicaXP software

Once your PC has finished booting up and has recognized all of the hardware,

the software is ready to be installed.

Insert the CD that contains the ApplicaXP software into your computer. Locate

the file named “ApplicaXP Setup v.*.exe” (Where * represents the version of the

software). This may vary depending on which version was shipped with your

unit. Double-click the file to initiate the installation process.

1. The first screen that appears is the End User License Agreement (EULA)

page. You must agree to the license agreement in order to install and use the

ApplicaXP software. If you agree to the EULA please click I Agree in order to

continue.

2. On the following screen type in your name, organization, and the serial

number which can be found on the cd sleeve. Please type in the serial number

exactly as you see it including the dashes (-). If this software will be for all

users of this computer, please leave this option selected. Click Next to continue.

3. On the next screen click next if you would like to use the default windows

installation directory. If you would like to choose your own directory please

type it in now.

4. If you wish to have shortcuts for the ApplicaXP software installed in the

Start Menu, click Install. If you do not wish to create the shortcuts please

check the box labeled, “Do not create shortcuts” then Click Install.

Windows will now install the Applica XP software. After the software has

finished copying files, click Next to complete installation.

If you would like to reboot now, leave selections as is, and click Finish. If you

would like to restart later, select “I want to manually reboot later” and then click

Finish.

If you selected Reboot Now, your computer will automatically restart. After your

computer has restarted the remote stations should be ready to use. You will

notice a small icon located on your taskbar in the system tray. This will be a

small yellow A.

This is one of the shortcuts to access the Applica XP software. The other will be

located in your start menu unless you decided during the installation process

not to create shortcuts.

Note: To see a more detailed installation manual for both Applica Xp and the Presenter

software, please refer to the Help Files located in the Help section of the software.

MNAPPR11072005V1.0

Page 12

Installing the Presenter2 softwareInstalling the Presenter2 software

Installing the Presenter2 software

On the same CD that has the ApplicaXP software, locate the file named “Presenter2

Setup v.*.exe” (Where * represents the version of the software). This may vary

depending on which version was shipped with your unit. Double-click the file to

initiate the installation process.

1. The first screen that appears the introduction followed by the License

Agreement page.You must agree to the license agreement in order to install

and use the Presenter software. If you agree, please click I Agree in order to

continue.

2. On the following screen type in your name, organization, and the serial

number which can be found on the cd sleeve. Click Next to continue.

3. On the next screen click next if you would like to use the default windows

installation directory. If you would like to choose your own directory please

type it in now.

4. If you wish to have shortcuts for the Presenter software installed in the Start

Menu, click Install. If you do not wish to create the shortcuts please check

the box labeled, “Do not create shortcuts” then Click Install.

Windows will now install the Presenter software. After the software has finished

copying files, click Next to complete installation.

Please select “Reboot Now” and click Finish to restart your computer.

Preparing System CAT5 CablePreparing System CAT5 Cable

Preparing System CAT5 Cable

The U4TX utilizes category 5 (CAT5), shielded twisted pair (STP) cable to transport

signal between transmitter and receiver.

This cable is used for LAN applications and is found in abundance, already installed,

in many buildings. The category 5 is a standard which establishes minimum

requirements for telecommunications cabling within a commercial building. The

standard covers various aspects of wiring including telecommunications outlets.

Following is the wiring standard for terminating CAT 5 cable using RJ 45 connector:

Pair 1 Pins 1 & 2

Pair 2 Pins 3 & 6

Pair 3 Pins 4 & 5

Pair 4 Pins 7 & 8

Connectors:Connectors:

Connectors: RJ-45

Capacitance:Capacitance:

Capacitance: 14 pf/ft (46.2 pf/m)

Conductor Gauge:Conductor Gauge:

Conductor Gauge: 24 AWG

Impedance:Impedance:

Impedance: 100 +/- 15 ohms

4 - Pair, (stranded) Foil Shielded

Installation and OperationInstallation and Operation

Installation and Operation

MNAPPR11072005V1.0 Page 13

AppendixAppendix

Appendix

SpecificationsSpecifications

Specifications

snoitacificepSdraCICPretneserP

ecafretnIsuBecafretnIsuB ecafretnIsuB ecafretnIsuBecafretnIsuBzhM33,tib23,V5

1.2VsubICPstroP4

oediVoediV oediV oediVoediV

pihCoediVITArosiS

@noituloseRdetroppuS

zH58

eurT867x4201;roloCeurT

006x008;roloCeurT084x046

roloChgiH0021x0061;roloC

ataDataD ataD ataDataD

etaRrefsnarTces/BM231otpU

rotcennoC)54

JR(5TAC

ecnatsiDnoissimsarT .tf0001otpU:orPretneserPtf05otpU:retneserP

lacisyhPlacisyhP lacisyhP lacisyhPlac

isyhP

DxWxHsnoisnemiDmm062x411x12

thgieW)sbl24.(gk91.

erutarepmeTgnitarepOerutarepmeTgnitarepO erutarepmeTgn

itarepO erutarepmeTgnitarepOerutarepmeTgnitarepO)Cseerged04ot0(.Fseerged401ot23

erutarepmeTegarotSerutarep

meTegarotS erutarepmeTegarotS erutarepmeTegarotSerutarepmeTegarotS )Cseerged06ot04-(tiehnerhaFseerged041ot04-

ytidimuHytidimuH ytidimuH ytidimuHytidimuHgnisnednocnon%09ot%02

snoitacificepS001XR-XLS/004XT-XLS

AGVAGV AGV AGVAGV

tamroFSBVC,C/Y,VUY,BsGR,VHBGR

rotcennoC51DDH

noituloseR )AGX

S,AGX,AGVS,AGV(0021x0061otpU

oiduAoiduA oiduA oiduAoiduA

epyTlangiSleveLeniLoeretSdecnalabnU

rotcennoCtekcoskc

ajmm5.3dradnatS

rewoPrewoP rewoP rewoPrewoPkcajCDmm1.2A2CD21004XT-XLS

)lanoitpO(kcajCDmm1.2A1CD21001XR-XLS

cisyhPlacisyhP lacisyhP lacisyhPlacisyhP

thgieW gk21.001XR-XLSgk55.004XT-XLS

)DxWxH(snoisnemiD mm59x08x32001X

R-XLSmm89x981x62004XT-XLS

5TAC5TAC 5TAC 5TAC5TAC "elbaC5TACgnitcennoC"noitceseesesaelP

MNAPPR11072005V1.0

Page 14

AppendixAppendix

Appendix

TroubleshootingTroubleshooting

Troubleshooting

motpmyS noitcA

putooB

seodyalpsid

rowohston

noswohs

ehtfoeno

noitats

.srotinom

gniwollofehtfoenood,PGAsiretpadaoedivy

ramirpruoyfI

:evahuoysoibfodniktahwnognidneped

,slarehpirePdetargetnI“tceles,snoitpoputesSOMC/SOIBehtre

dnU

."PGA"noitpoehttcelesneht,"tsriFyalpsiDtinI“retne

serutaeFSOIB“tceles,noitcelesnoitpoputesSOMC/SOIB

ehtrednU

.”PGA“noitpoehttcelesneht,”morftooBAGV“retnedna”puteS

detargetnI“tceles,noitcelessnoitpoputesS

OMC/SOIBehtrednU

.noitpotahtelbanenehtdna,”tsriFyalpsiDtinI“retne,”slarehpireP

unem"O/IDRAOBNO&,ICP,PNP

"ehttceles,SOIBraludoMdrawA

.noitpo"tsriFyalpsiDtinI"ehttcelesnehtdna

:ICPsiretpadaoedivyramirpruoyfI

owmaeTehtybdeipuccositahttolsehtotnidracICPruoyevoM

ffonrutwoN.dracezingocerotcpwolladnaretupmoctoobeR

.drac

dracscihpargICPehterehwdrackrowmaeTehtllatsnidnaCPeht

ebotdesu

etomeR

odsrotinom

yalpsidton

egami

erus

ekamFFOsiDELfI.noitatsetomerehtnosDELrewopehtkcehC

.detcennocsiretpadarewopehttaht

eratinuehtmorfsallew

saretupmocehtmorfselbacehttahtkcehC

.detcennocylreporp

otyltceridmehtgnitcennocyblanoitarepoerasrotinom

tahtyfireV

.retupmoceht

oediVrooP elbac5TACevissecxe,gnilbacroopybdesuacebyamoedivrooP

nacelbac5TACytilau

qwolsemitemoS.spooldnuorgybrohtgnel

.noitcnuflamesuac

ylreporperasdleihsdnaedamylreporpsignilbacllataht

yfireV

.001XR-XLSfomottobehtnosbonkgninuteniftsujdA.dednuorg

Technical SupportTechnical Support

Technical Support

Our technical support staff is ready to assist you with your technical needs

related to our product or its operation in your system. To obtain quick assis-

tance please follow the troubleshooting guidelines below.

1. Review the troubleshooting section of this manual (found in the Appendix)

to ensure that the problem cannot be resolved with information already

provided.

2. Document the nature of your problem as detailed as possible and either

call (818) 565-0011 or e-mail [email protected]

To expedite assistance please provide model number, serial number, date

of purchase and invoice number.

MNAPPR11072005V1.0 Page 15

AppendixAppendix

Appendix

Limited Warranty StatementLimited Warranty Statement

Limited Warranty Statement

A. Extent of limited warrantyA. Extent of limited warranty

A. Extent of limited warranty

1. SmartAVI warrants to the end–user customers that SmartAVI product specified

above will be free from defects in materials and workmanship for the duration of 1

year, which duration begins on the date of purchase by the customer. Customer is

responsible for maintaining proof of date of purchase.

2. SmartAVI limited warranty covers only those defects which arise as a result of nor-

mal use of the product, and do not apply to any:

a. Improper or inadequate maintenance or modifications

b. Operations outside product specifications

c. Mechanical abuse and exposure to severe conditions

3. If SmartAVI receives during applicable warranty period notice of defect SmartAVI

will at its discretion replace or repair defective product. If SmartAVI is unable to

replace or repair defective product covered by the SmartAVI warranty within rea-

sonable period of time SmartAVI shall refund the cost of the product.

4. SmartAVI shall have no obligation to repair, replace or refund unit until customer

returns defective product to SmartAVI.

5. Any replacement product could be new or like new, provided that it has functional-

ity at least equal to that of the product being replaced.

6. SmartAVI’s limited warranty is valid in any country where the covered product is

distributed by SmartAVI.

B. Limitations of warrantyB. Limitations of warranty

B. Limitations of warranty

TO THE EXTENT ALLOWED BY LOCAL LAW, SMARTAVI NOT ITS THIRD PARTY SUPPLIERS

MAKE ANY OTHER WARRANTY OR CONDITION OF ANY KIND WHETHER EXPRESSED OR

IMPLIED, WITH RESPECT TO THE SMARTAVI PRODUCT, AND SPECIFICALLY DISCLAIM IM-

PLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY, SATISFACTORY QUALITY, AND

FITNESS FOR A PARTICULAR PURPOSE.

C. Limitations of liabilityC. Limitations of liability

C. Limitations of liability

To the extent allowed by local law the remedies provided in this warranty statement are the

customer’s sole and exclusive remedies.

TO THE EXTENT ALLOWED BY LOCAL LAW, EXCEPT FOR THE OBLIGATIONS SPECIFICALLY

SET FORTH IN THIS WARRANTY STATEMENT, IN NO EVENT WILL SMARTAVI OR ITS THIRD

PARTY SUPPLIERS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUEN-

TIAL DAMAGES WHETHER BASED ON CONTRACT, TORT OR ANY OTHER LEGAL THEORY

AND WHETHER ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

D. Local lawD. Local law

D. Local law

To the extent that this warranty statement is inconsistent with local law, this warranty state-

ment shall be considered modified to be consistent with such law.

Applica, Inc.

3111 Winona Ave, Suite 101

Burbank, CA 91504

Tel (818) 565-0011 Fax (818) 565-0020

Email: [email protected]

This manual suits for next models

Table of contents

Popular PCI Card manuals by other brands

CSL

CSL 300770 user manual

SIIG

SIIG ID-P40311-S1 Quick installation guide

DAQ system

DAQ system USB3-FRM20 user manual

StarTech.com

StarTech.com PCI2S232485I instruction manual

D-Link

D-Link AirPro DWL-AB520 Quick installation guide

SMC Networks

SMC Networks SMC EZ Connect g SMCWPCI-G user guide

Edimax

Edimax EW-7326Ig user manual

Applistar

Applistar DNPCIe 10G K7 LL QSFP user manual

StarTech.com

StarTech.com ST100SLP Instruction guide

ActionTec

ActionTec 802PAG User & installation manual

SeaLevel

SeaLevel ACB-ULTRA.LPC user manual

AJA

AJA KONA HDMI Installation and operation manual

Brainboxes

Brainboxes CC-618 Hardware guide

Encore

Encore ENL-WI-G datasheet

Lucent Technologies

Lucent Technologies WaveLAN/ISA Card user manual

Unigraf

Unigraf UFG-10 series Programming guide

Supermicro

Supermicro AOC-USAS2-L8i user manual

SIIG

SIIG Low Profile PCI-2S Quick installation guide
