User’s Manual
Aegis Padlock 3.0

Table of Contents
About the Aegis Padlock Portable Secure Hard Drive 4
Package contents 4
Aegis Padlock button panel 5
Aegis Padlock - Getting Started 6
Before you begin 6
Connecting the Aegis Padlock 6
Connecting the Aegis Padlock with USB Y-Cable 7
How do I use the Aegis Padlock the rst time? 7
What if I forget the User Password? 7
Using the Aegis Padlock 8
Entering the Standby Mode 8
Entering the User Mode 8
Exiting the User Mode 8
Entering the Admin Mode 9
Exiting the Admin Mode 9
Password Management 10
Changing the Admin Password 10
Adding a new User Password 11
Deleting the User Passwords 11
Changing the User Password 11
Setting the Unattended Auto Lock Feature 12
Aegis Padlock Brute Force Protection 13
What is Brute Force Attack? 13
How does the Aegis Padlock protect against brute force attack? 13
Setting a Self Destruct Password 14
Completely resetting the Aegis Padlock 15
Initializing and formatting the Aegis Padlock after a complete reset 15

Copyright © Apricorn, Inc 2012. All rights reserved.
Windows is a registered trademark of Microsoft Corporation.
All other trademarks and copyrights referred to are the property of their
respective owners.
Distribution of modied versions of this document is prohibited without the explicit
permission of the copyright holder.
Distribution of the work or derivative work in any standard (paper) book form for
commercial purposes is prohibited unless prior permission is obtained from the
copyright holder.
DOCUMENTATION IS PROVIDEDAS IS AND ALL EXPRESS OR IMPLIED
CONDITIONS, REPRESENTATIONSAND WARRANTIES, INCLUDINGANY
IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FORA PARTICULAR
PURPOSE OR NON-INFRINGEMENT,ARE DISCLAIMED, EXCEPT TO THE
EXTENT THAT SUCH DISCLAIMERSARE HELD TO BE LEGALLY INVALID
Hibernating, Suspending, or Logging off 17
Troubleshooting 18
Technical Support 20
Warranty and RMA information 20

www.apricorn.com
4
About the Aegis Padlock Portable
Secure Hard Drive
Package contents
• Aegis Padlock drive with
integrated USB cable
• Travel pouch
• USB Y-cable
• Quick Start Guide
Looking for an effortless way to secure your
data? The Aegis Padlock Secure Drive is
the ultimate portable hard drive and secure
storage system. With an easy-to-use
keypad design and software free setup, the
Aegis Padlock Secure Drive enables you
to access the drive with your own unique
pin. Featuring 256 bit hardware encryption
and a super-fast USB 3.0 connection, the
Aegis Padlock provides seamless real-time
encryption, keeping your data safe even if
the hard drive is removed from its enclosure.
Quick Start Guide
0
cancel
2
abc
5
jkl
6
mno
9
wxyz
8
tuv
7
pqrs
4
ghi
3
def
1
12
33
1
2
Cancel button
button
LED Indicator light
Remember to save your password in a safe place. If
lost or forgotten, there is no way to access the drive.
If you are having difculty please refer to the com-
plete user’s manual which is loaded on your Aegis
Padlock drive and is also available at Apricorn’s
website at: www.apricorn.com/support
YourAegis Padlock is preformatted in NTFS for Windows®and is ready for use. For the Mac
OS please refer to the directions on the reverse to reformat your drive to a compatible format.
To access theAegis Padlock plug your drive into a powered USB port, enter the default PIN
number of 123456 and press .
The indicator light will change from RED to GREEN indicating the drive is unlocked and can be
accessed.
Changing the ADMIN PIN number to your own unique PIN number
You are the “administrator” of this drive. The rst thing you will want to do is change the
Administrator PIN number from the default 123456 to a unique, secure PIN number that you
will remember.
To change theAdmin PIN number follow the instructions below:
To enter Admin Mode, rst plug the drive into the USB port and wait until the LED light 1. turns RED.
Next, press and hold 0 + for 5 seconds until the LED light ashes RED.2. Enter the Admin PIN number (default is 123456) and press . The LED light will3. turn BLUE indicating you are in Admin Mode.
While in Admin Mode, press and hold 9 + until the LED light ashes BLUE.4.
Enter the new PIN number (minimum 6 digits) and press . The LED light will ash 5. GREEN 3 times if successful.
Re-enter the new PIN number and press . The LED light will stay solid GREEN for
6. 2 seconds then solid BLUE indicating you have successfully changed the Admin PIN.
To exit admin mode and begin using your Aegis Padlock drive, press the CANCEL 7. button until the LED turns RED. Now enter your new PIN number and press .
Aegis Padlock 3.0

www.apricorn.com
5
Aegis Padlock button panel
The “Cancel” button can be used to:
• Cancel current operation
• Return to the previous step when you knowingly entered a wrong
password
• Exit the Admin Mode
The button can be used to access the Aegis Padlock and it can also be used
as an OK acknowledgement in the following operations:
• Entering a password
• Conrming a new password
The indicator light displays the following colors to indicate the various modes of
operation:
• RED: Standby Mode
• BLUE: Admin Mode
• GREEN: User Mode
The indicator light has other display methods to indicate different status of the
Aegis Padlock. Details are provided later in this chapter.
0
cancel
2
abc
5
jkl
6
mno
9
wxyz
8
tuv
7
pqrs
4
ghi
3
def
13
1
2
Cancel button
button
Indicator light

www.apricorn.com
6
Aegis Padlock - Getting Started
Before you begin
Be sure to review the following information before you begin to use the Aegis
Padlock.
Attention: Use only the included cables with your Aegis Padlock. You might
damage the drive if you use a cable not included with the Aegis Padlock.
The Aegis Padlock is designed for portable use without an AC power adapter and
in most cases will be able to power on a single USB port. In the event that the
Aegis Padlock is unable to power on a single USB connection, use the included
USB Y-cable.
Connecting the Aegis Padlock
1. Attach the integrated USB cable of theAegis Padlock drive to an available USB
port on your computer, as shown below.
2. TheAegis Padlock indicator light should glow RED.
If the Indicator light
does not power, use the
included USB Y-cable.
Refer to directions on the
following page

www.apricorn.com
7
Connecting the Aegis Padlock with USB Y-Cable
If the indicator light does not power on a single USB connection, use the included
USB Y-cable.
1. Attach theAegis Padlock’s integrated USB cable to the female connector of the
USB Y-cable.
2. Connect the two male USB connectors to two available
USB ports on your computer.
3. TheAegis Padlock indicator light should glow RED.
You can use it in one of the following ways:
• Enter the Admin Mode with 123456 (default administrator password),
and then you are able to change the Admin Password or create a User
Password.
• Directly enter the Secure User Mode with 123456 (default Admin Password)
to use the Aegis Padlock.
How do I use the Aegis Padlock the rst time?
What if I forget the User Password?
Use your Admin Password to enter Admin Mode, and then create another User
Password in Admin Mode.

www.apricorn.com
8
Using the Aegis Padlock
Entering and exiting the Standby Mode, Admin
Mode, and User Mode
Entering the Standby Mode
The Standby Mode is the default working mode of the Aegis Padlock and is the
gateway to other working modes.
To enter the Standby Mode, attach theAegis Padlock to your computer. The drive
automatically goes into Standby Mode and the indicator light turns RED. In this
mode, the Aegis Padlock is locked. It cannot be recognized by My Computer and it
does not provide either the regular functions or the encryption function. However, it
enables you to enter and switch between the Admin Mode and the User Mode.
Attention: To switch between theAdmin Mode and the User Mode, you are
required to switch to the Standby Mode rst, and then you can enter the
mode of your choice.
Entering the User Mode
To enter the User Mode, do the following:
1. Attach the Secure Hard Drive to your computer. It enters the Standby Mode.
2. Enter the User Password or the Admin Password (the default Admin Password
is 123456) and press . The indicator light turns GREEN indicating that the
drive is in the User Mode. If the indicator light ashes RED, you need to re-enter
the correct password.
Exiting the User Mode
To exit the User Mode, double-click the Safely Remove Hardware icon from
the Microsoft®Windows®desktop, and then remove the Aegis Padlock from your
computer.
Attach the Aegis Padlock to your computer again and the indicator light turns RED.
This indicates that you are in the Standby Mode.

www.apricorn.com
9
Entering the Admin Mode
Note: The Aegis Padlock cannot be recognized by the operating system in the
Admin Mode.
To enter theAdmin Mode, do the following:
1. Attach the USB cable to an available USB port on your computer. TheAegis
Padlock goes into the Standby Mode, and the indicator light turns RED.
2. Press and hold + 0 for ve seconds until the indicator light ashes RED.
This indicates that you can enter the Admin Password.
3. Enter the Admin Password and press . The defaultAdmin Password is
123456. The Secure Hard Drive is inAdmin Mode when the indicator light has
changed to BLUE.
Note: If the indicator light ashes RED for a few seconds, indicating the
Aegis Padlock has returned to the Standby Mode, go back to Step 2. This
is due to one of the following conditions:
• You entered an incorrect Admin Password in Step 3.
• No activity was detected within two minutes in the Admin Mode.
Exiting the Admin Mode
To exit the Admin Mode, press the “Cancel” button in theAdmin Mode until the
indicator light turns RED. This indicates that you are in the Standby Mode.

www.apricorn.com
10
Password Management
Changing the Admin Password
This section provides information about managing your password in the Admin
Mode and User Mode.
You can change the Admin Password by doing the following:
1. Enter Admin Mode (refer to page 9 for details).
2. Press and hold + 9 until the indicator light ashes BLUE.
3. Enter the new password and press (The Password must be a minimum of
6 digits and a maximum of 16 digits). The indicator light ashes GREEN three
times. See note below.
4. Re-enter the new Admin Password and press . The indicator light stays
solid GREEN for two seconds and then solid BLUE indicating that the Admin
Password has been changed successfully.
Note: If the indicator light ashes RED three times, this indicates that the
password is less than 6 digits or more than 16 digits. Enter a
password that contains 6 – 16 digits after the indicator light ashes
BLUE intermittently.
1. If the indicator light ashes RED intermittently and then BLUE
intermittently, go back to step 3. This is due to one of the following
conditions:
• You waited longer than 10 seconds before entering a password.
• The new password was entered incorrectly.
2. If no activity is detected within two minutes in theAdmin Mode, theAegis
Padlock will return to the Standby Mode.

www.apricorn.com
11
Adding a new User Password
You can add a new User Password by doing the following:
1. Enter the Admin Mode (refer to page 9 for details).
2. Press and hold + 1 until the indicator light ashes BLUE intermittently.
3. Enter a User Password and press (a minimum of 6 digits and a maximum
of 16 digits) The indicator light ashes GREEN three times.
4. Re-enter the new User Password and press . If the indicator light stays
solid GREEN for two seconds and then solid BLUE, the User Password was
added successfully.
Deleting the User Passwords
You can delete all User Passwords by doing the following:
1. Enter the Admin Mode (refer to page 9 for details).
2. Press and hold 7 + 8 + for ve seconds until the indicator light ashes BLUE
intermittently. After the indicator light ashes GREEN three times and then
BLUE intermittently.
3. Press and hold 7 + 8 + a second time for ve seconds until the indicator
light goes on solid GREEN for two seconds and then back to solid BLUE, this
indicates that the User Passwords were deleted successfully.
Changing the User Password
You can change the User Password by doing the following:
1. Enter User Mode (refer to page 8 for details).
2. Press and hold + 1 until the indicator light ashes RED.
3. Enter your old password and press . The indicator light will turn GREEN,
then change to ashing BLUE.
4. Enter the new password and press (The Password must be a minimum of
6 digits and a maximum of 16 digits). The indicator light will ash GREEN three
times.
5. Re-enter the new User Password and press . The indicator light stays solid
GREEN indicating that the User Password has been changed successfully.

www.apricorn.com
12
Setting the Unattended Auto Lock Feature
To protect against unauthorized access if the drive is unlocked and unattended, the
Aegis Padlock can be set to automatically lock after a pre-set amount of time.
In its default state, the Aegis Padlock Unattended Auto Lock feature is turned off.
The Unattended Auto Lock can be set to activate after 5, 10 or 20 minutes.
To set the UnattendedAuto Lock please use the following steps:
1. Enter the Admin mode by pressing and holding + 0 for ve seconds until
the indicator light ashes RED. This indicates that you can enter the Admin
Password.
2. Enter the Admin Password and press . The drive is inAdmin Mode when the
indicator light has changed to BLUE.
3. Once in Admin mode, press + 6. The indicator light should start ashing
RED and BLUE intermittently.
4. Press one of the numbers below that corresponds to amount of time you would
like the drive to lock after no activity:
5. After you have input the number, the indicator light should ash GREEN 3
times to indicate that you have successfully set the Unattended Auto Lock
feature.
Auto Lock Timeout Table:
1 = 5 min
2 = 10 min
3 = 20 min
0 = OFF
The default is 0 (OFF)

www.apricorn.com
13
Aegis Padlock Brute Force Protection
What is Brute Force Attack?
A brute force attack is a method of defeating a cryptographic scheme by
systematically trying a large number of possibilities; for example, a large number
of the possible keys in a key space in order to decrypt a message. In most
schemes, the theoretical possibility of a brute force attack is recognized, but it
is set up in such a way that it would be computationally infeasible to carry out.
Accordingly, one denition of “breaking” a cryptographic scheme is to nd a
method faster than a brute force attack.
1. With the drive locked and in the standby state the indicator light is solid RED.
2. After six tries to enter the correct user or admin password the keypad will not
respond and indicator light will turn off. The drive will need to be unplugged
from the USB port and replugged. This will be repeated for each six
unsuccessful attempts.
3. If the user, unsuccessfully tries to unlock the drive on his 10th try the
keypad will lock and the indicator light will begin blinking quickly. Even after
unplugging and replugging in the unit, the drive will remain locked and the
indicator light will continue to blink rapidly.
4. Here are the steps to allow the user to unlock the keypad for 10 more
attempts to unlock this drive.
a. Unplug the device from the computer
b. Push and hold the number ve key and plug-in the drive
c. The indicator light will be blinking alternating RED and GREEN rapidly
d. Enter the code 5278879 and press
e. The keypad will unlock and will be in the standby state with the
indicator light solid RED, this will allow only 10 more attempts
g. After a total of 20 Attempts the drive will remain locked with the indicator
light ashing RED quickly. You must now go through the reset process and
reformat the drive to be able to use the drive again. (see page 15)
How does the Aegis Padlock protect against
brute force attack?

www.apricorn.com
14
Setting a Self Destruct Password
The Aegis Padlock has the ability to set a password that will reset the encryption
key if needed. By resetting the encryption key all data on the drive will be lost and
cannot be recovered.
After initiating the Self Destruct sequence, the PIN used to initiate the self
destruct sequence will become the default Admin password. The drive
will need to be initialized and reformatted. For directions see page 15.
To set a Self Destruct password please use the following steps:
1. Enter the Admin mode by pressing and holding + 0 for ve seconds until
the indicator light ashes RED. This indicates that you can enter the Admin
Password.
2. Enter the Admin Password and press . The drive is inAdmin Mode when the
indicator light has changed to BLUE.
3. Once in Admin mode, press + 3. The indicator light should start ashing
RED and BLUE intermittently.
4. Input in the PIN that you would like to use as the Self Destruct password and
press .
5. The Aegis Padlock will then check against known PINs to make sure that it is
not already in use. If in use the indicator light will ash RED 3 times and the
drive will go into Standby mode. If this happens please re-enter the Admin
mode (step 1) and repeat the process with a new code.
6. If the Self Destruct password is accepted the indicator light ashes GREEN
three times.
7. Immediately re-enter the new PIN and press . If the indicator light stays
solid GREEN for two seconds and then goes to solid BLUE, the Self Destruct
PIN was added successfully.
8. To delete the Self Destruct password, you will need to delete all of the User
Passwords. Please refer to the instructions on page 11 - Deleting User Passwords.
Note: The PIN must be a minimum of 6 digits in the length (16 max) and
cannot match any Admin or User codes already used by the drive.
In the future, a User or Admin code can not be set to the same number
as used by the Self Destruct password.

www.apricorn.com
15
Completely resetting the Aegis Padlock
If you forget all the User Passwords or Admin Passwords, you can perform a
complete reset to remove all the User Passwords, and restore the Admin Password
to the default 123456.
Attention: Completely resetting theAegis Padlock will reset the encryption
key, in effect making all the data on the drive unrecoverable. You will need to
partition and format theAegis Padlock with disk management applications.
To perform a complete reset of the drive, do the following:
1. Press and hold the “Cancel” button while you attach the Aegis Padlock to an
available USB port on your computer. The indicator light will ash BLUE and
RED alternately.
2. Press and hold “Cancel” + + 2 for 10 seconds until the indicator light
ashes RED and BLUE intermittently, and then stops on a solid color. The
indicator light will then turn solid GREEN for two seconds, followed by solid
RED. You have successfully reset the Aegis Padlock.
Note: If no activity is detected for 30 seconds in this step, the Aegis Padlock
will go into the Standby Mode.
Initializing and formatting the Aegis Padlock after
a complete reset
A complete reset of the Aegis Padlock will erase all information and partition
settings. You will need to initialize and format the Aegis Padlock.
To initialize your Aegis Padlock, do the following:
1. After a complete reset, attach the Aegis Padlock to the computer.
2. Wait 5 seconds for the computer to recognize the device.
3. Enter the default User Password 123456 and press to enter the User
Mode.
4. Right-click My Computer, and then click Manage from the Windows
desktop.

www.apricorn.com
16
5. In the Computer Manage window, click Disk Management. In the Disk
Management window, the Aegis Padlock is recognized as an unknown device
that is uninitialized and unallocated.
6. Do the following to make the drive recognized as a basic drive.
• If the Initialize and Convert Disk Wizard window opens, click Cancel,
then initialize the disk manually using the following steps.
a. Right-click Unknown Disk, and then select Initialize Disk.
b. In the Initialize Disk window, click OK.
7. Right-click in the blank area under the Unallocated section, and then select
New Partition. The Welcome to the New Partition Wizard window opens.
8. Click Next.
9. Select Primary partition and click Next.
10. If you need only one partition, accept the default partition size and click
Next.
11. Click Next.
12. Create a volume label, select Perform a quick format, and then click Next.
13. Click Finish.
14. Wait until the format process is complete. The Aegis Padlock will be
recognized and it is available for use.

www.apricorn.com
17
Hibernating, Suspending, or Logging off
from the Operating System
Be sure to save and close all the les on your Aegis Padlock before hibernating,
suspending, or logging off from the Windows operating system.
It is recommended that you log off the Aegis Padlock manually before
hibernating, suspending, or logging off from your system.
To log off the Aegis Padlock, double-click Safely Remove Hardware on the
Windows desktop and remove the Aegis Padlock from your computer.
Attention: To ensure the data integrity of yourAegis Padlock, be sure to
lock or log off your Aegis Padlock if you are:
• away from your computer
• using the switching user function by sharing a computer with others

www.apricorn.com
18
Troubleshooting
This section contains troubleshooting information for the Aegis Padlock. If
you encounter any of the following problems when using the Aegis Padlock, refer to
the corresponding answers.
Q: How do I use the Aegis Padlock the rst time?
A: You can use it in one of the following ways:
• Enter the Admin Mode with 123456 (default administrator password),
and then you are able to change the Admin Password or create a User
Password
• Directly enter the Secure User Mode with 123456 (default Admin Password)
to use the Aegis Padlock
Q: What can I do if I forget the User Password?
A: Use your Admin Password to enter Admin Mode, and then create another
User Password in Admin Mode.
Q: What can I do if I forget the Admin Password?
A: There is no other way to retrieve the Admin Password except a complete reset
of the Aegis Padlock. After a complete reset, all data will be lost and you will need
to initialize, allocate and format the Aegis Padlock manually. Then you will be able
to use the default Admin Password 123456.
Q: Why did the operating system not recognize the Aegis Padlock after I
enter the User Mode and completely reset the computer?
A: You need to initialize, allocate and format the Aegis Padlock manually. For
more information, refer to Initializing and formatting the Hard Drive after a
complete reset in this manual.

www.apricorn.com
19
Q: How do I use the Aegis Padlock without a password?
A: As a full disk encryption product, the Aegis Padlock can never be used
without a password.
Q: What encryption algorithm is used in this product?
A: Depending on your model the Aegis Padlock uses either AES 128-bit or 256-bit
algorithm.
Q: Why could I not initialize, partition or format the Aegis Padlock?
A: Ensure that you have administrator privileges. You can use only the
administrator account to initialize, partition or format the Aegis Padlock in
the Admin Mode.

www.apricorn.com
20
One Year Limited Warranty:
Apricorn offers a 3-year limited warranty on the Aegis Padlock against defects in materials and
workmanship under normal use. The warranty period is effective from the date of purchase either
directly from Apricorn or an authorized reseller.
Disclaimer and terms of the warranties:
THE WARRANTY BECOMES EFFECTIVE ON THE DATE OF PURCHASE AND MUST BE VERIFIED WITH
YOUR SALES RECEIPT OR INVOICE DISPLAYING THE DATE OF PRODUCT PURCHASE.
APRICORN WILL, AT NO ADDITIONAL CHARGE, REPAIR OR REPLACE DEFECTIVE PARTS WITH NEW
PARTS OR SERVICEABLE USED PARTS THAT ARE EQUIVALENT TO NEW IN PERFORMANCE. ALL
EXCHANGED PARTS AND PRODUCTS REPLACED UNDER THIS WARRANTY WILL BECOME THE
PROPERTY OF APRICORN.
THIS WARRANTY DOES NOT EXTEND TOANY PRODUCT NOT PURCHASED DIRECTLY FROMAPRICORN
OR AN AUTHORIZED RESELLER OR TO ANY PRODUCT THAT HAS BEEN DAMAGED OR RENDERED
DEFECTIVE: 1. AS A RESULT OF ACCIDENT, MISUSE, NEGLECT, ABUSE OR FAILURE AND/OR INABILITY
TO FOLLOWTHE WRITTEN INSTRUCTIONS PROVIDED IN THIS INSTRUCTION GUIDE: 2. BYTHE USE OF
PARTS NOT MANUFACTURED OR SOLD BY APRICORN; 3. BY MODIFICATION OF THE PRODUCT; OR 4.
AS A RESULT OF SERVICE, ALTERNATION OR REPAIR BY ANYONE OTHER THAN APRICORN AND SHALL
BE VOID. THIS WARRANTY DOES NOT COVER NORMAL WEAR AND TEAR.
NO OTHER WARRANTY, EITHER EXPRESS OR IMPLIED, INCLUDING ANY WARRANTY OR
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, HAS BEEN OR WILL BE MADE BY
OR ON BEHALF OF APRICORN OR BY OPERATION OF LAW WITH RESPECT TO THE PRODUCT OR ITS
INSTALLATION, USE, OPERATION, REPLACEMENT OR REPAIR.
APRICORN SHALL NOT BE LIABLE BY VIRTUE OF THIS WARRANTY, OR OTHERWISE, FOR ANY
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGE INCLUDING ANY LOSS OF DATA RESULTING
FROM THE USE OR OPERATION OF THE PRODUCT, WHETHER OR NOT APRICORN WAS APPRISED OF
THE POSSIBILITY OF SUCH DAMAGES.
Apricorn provides the following helpful resources for you:
1. Apricorn’s Website (http://www.apricorn.com)
This gives you the ability to check for up-to-date information
2. E-mail us at [email protected]
3. Or call the Technical Support Department at 1-800-458-5448
Apricorn’s Technical Support Specialists are available from 8:00 a.m. to
5:00 p.m., Pacic Standard Time Monday through Friday
Technical Support
Warranty and RMA information
