Aputure amaran P60x User manual

Product Manual
English
amaran P60x

Foreword
Thank you for purchasing the amaran series LED photography light -
amaran P60x.
The amaran P60 series is creators' best choice because of its feature of
lightweight and flexibility.
The amaran P60x is a panel photography light with adjustable temperature
(3200 K - 6500 K), power of 60 W, and maximum illuminance of 5070 lux@1 m
(5600 K). The P60x is also excellent in terms of light quality, with a color
rendering index of up to CRI 95+, TLCI 97, and no flicker at all.
IMPORTANT SAFETY INSTRUCTIONS
When using this unit, basic safety precautions should always be followed,
including the following:
Read and understand all instructions before using.
Close supervision is necessary when any fixture is used by or near
children. Do not leave the fixture unattended while in use.
Care must be taken as burns can occur from touching hot surfaces.
Do not operate the fixture if a cord is damaged, or if the fixture has
been dropped or damaged, until it has been examined by quali fied
service personnel.
Position any power cables such that they will not be tripped over,
pulled, or put into contact with hot surfaces.
If an extension cord is necessary, a cord with an amperage rating at
least equal to that of the fixture should be used. Cordsrated for less
amperage than the fixture may overheat.
Always unplug the lighting fixture from the electrical outlet before
cleaning and servicing, or when not in use. Never yank the cord to
remove the plug from the outlet.
Let the lighting fixture cool completely before storing.
To reduce the risk of electric shock, do not immerse this fixture in
water or any other liquids.
To reduce the risk of re or electric shock, do not disassemble this
fixture. Contact [email protected] or take it to qualified service
personnel when service or repair work is required. Incorrect
reassembly may cause electric shock when the lighting fxture is
in use.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
- 1 -

The use of an accessory attachment not recommended by the
manufacturer may increase the risk ofre, electric shock, or injury to
any persons operating the fixture.
Power this fixture by connecting it to a grounded outlet.
Please do not place the LED lighting fixture near any flammable object.
Only use a dry microfiber cloth to clean the product.
Please have the product checked by an authorized service personnel
agent if your product has a problem.
The malfunctions caused by unauthorized disassembly are not covered
under the warranty.
We recommend only using the original Aputure cable accessories.
Please note that our warranty for this product does not apply to any
repairs required due toany malfunctions of unauthorized Aputure
accessories, although you may request such repairs for a fee.
This product is certified by RoHS, CE, KC, PSE, and FCC. Please
operate the product in full compliance with the operation
standards. Please note that this warranty does not apply to repairs
arising from malfunctions, although you may request such repairs on
a chargeable basis.
The instructions and information in this manual are based on thorough,
controlled company testing procedures. Further notice will not be given
if the design or specifi cations change.
SAVE THESE INSTRUCTIONS
11.
12.
13.
14.
15.
16.
17.
18.
19.
- 2 -

FCC compliance statement
This device complies with Part 15 of the FCC rules. The operating
equipment must meet the following two conditions:
(1) This device will not cause harmful interference;
(2) This device can withstand any external interference, including
interference that may cause unintended operation.
[Warning] If the user makes changes or modifications without the express
permission of Aitus, he may lose the right to continue to operate the device.
[Note] This device has been tested and determined to comply with the limits
of a Class B digital device (in accordance with Part 15 of the FCC rules).
These limits are designed to provide reasonable protection from harmful
interference in residential installations. This device generates, uses, and
can radiate radio frequency energy. If it is not installed and used in
accordance with the instructions, it may cause harmful interference to
radio communications. However, under certain installation conditions,
there is no guarantee that such interference will not occur. If this
equipment does cause harmful interference to radio or television
reception, and this can be determined by turning off and on the
equipment, it is recommended that the user try one or more of the
following measures to eliminate the interference:
Increase the distance between the equipment and the receiver.
Connect the equipment to an outlet on another circuit, not the
outlet on the circuit to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
FCC radiation exposure statement
This device complies with FCC radiation exposure limits for uncontrolled
environments.
- 3 -

Componets List
amaran P60x
Carrying case
Adapter
AC Power cable
1/4 - 20 in & 3/8 - 16 in
Spigot
Softbox
Grid
- 4 -

Product Details
LED chips
Transparent
protective baffle
Softbox
support
handle
1/4 screw hole
OLED Display
Power Button
DC Input
Menu
Button
INT Wheel
CCT Wheel
NP-F battery
slot
LIGHTING Mode
Button
EFFECTS Mode
Button
- 5 -

Installation
1. The lamp fixing
2. Softbox installation
Screw the 1/4’’ to 3/8’’ screw clockwise into the 1/4’’ copper nut at the
bottom (or side) of the LED lamp, and tighten it;Connect the 1/4’’ to 3/8’’
screw and the lamp holder through the lamp holder support column,
adjust the appropriate angle and tighten it.
The light soft box can be installed according to the needs of use.
1. Stretch soft box 2. Straighten the two support
rodson both sides of the soft
box to become a support rod
3. Install the soft box to the
lamp body
4. The grid can be installed
according to the requirements
- 6 -

Power supply
1. Adapter power supply
AC 100 V - 240 V
Remaining
Operating time
Brightness
CCT
Bluetooth Mode
When disassembling the power cable, please rotate the spring lock button
on the power cable before disassembling, do not pull it hard.
- 7 -

2. Lithium battery power supply
Battery Installation: Slide the lithium
battery into the battery slot.
Battery Removing: Press the battery
lock button while gently pushing up
the battery to remove the battery.
* This product uses a lithium battery model Sony NP-F Series: NP - F 960 / F 970.
3. V-mount battery or Anton Bauer battery power supply
Through the "D-tap to DC" connection cable, the lamp body can be
connected to the V-mount battery or Anton Bauer battery for power
supply.
- 8 -
* D-tap to DC cable needs to be purchased separately.

Operation Instructions
1. Turning on the Light
After connecting the lamp body to an appropriate power source,
press the power switch to start the P60x.
2. Manual Control
Rotate the Intensity (INT) Wheel
to adjust the intensity of the light
from 0-100%.
Rotate the CCT / HUE wheel to
adjust the CCT of the light from
3200 K- 6500 K.
* The speed at which you rotate the knob will result in different rates
of change.
- 9 -

2.1 Press the LIGHTING button to
enter CCT mode to adjust the CCT
and INT of the light.
2.2 Press the EFFECTS button, the default current light effect mode takes
effect ( a total of four light effects: paparazzi, Strobe, fireworks, Pulsing ).
Paparazzi Strobe
Fireworks Pulsing
2.3 Press the MENU button to enter the menu interface.
- 10 -
MENU

3. Menu introduction
3.1 Fan Mode
Press the MENU button to enter
the menu interface, rotate the INT
wheel to select and press to enter
the Fan mode, rotate the INT wheel
to select the smart/medium mode,
and then short press the INT wheel
to confirm the selection.
3.2 Studio Mode
Press the MENU button to enter
the menu interface, rotate the INT
wheel to select and press to enter
the Studio mode interface. Rotate
the INT wheel to select "Yes", and
the power-on light is on.
3.3 Bluetooth Reset
Press the MENU button to enter
the menu interface, rotate the INT
wheel to select and press to enter
the Bluetooth Reset. Rotate the
wheel to select "YES" to reset the
Bluetooth pairing; If you choose
“NO”, then it will return to the
previous menu.
3.4 Fixture Serial No
Press the MENU button to enter
the menu interface, rotate the INT
wheel to select and press to enter
the Fixture Serial No.and you can
see that device has a unique serial
number.
- 11 -

3.5 Language
Press the MENU button to enter
the menu interface, rotate the INT
wheel to select and press to enter
the Language menu. You can rotate
the INT wheel to select English or
Chinese, and then press the Select
wheel to confirm the selection.
3.6 Firmware Version
Press the MENU button to enter
the menu interface, rotate the INT
wheel to select and press to enter
the Firmware Version, You can
check the firmware version number
of the fixture.
3.7 Custom FX
Press the MENU button to enter the menu interface, rotate the INT wheel
to select and press to enter the Custom FX. You can choose to enter Picker
FX, Music FX, or Touchbar FX interface. Each type can save 10 custom FXs.
In the name of each FX, "NO FX" means unsaved FX, and "Untitled" means
saved FX.
3.8 Exit
Press the MENU button to enter the menu interface, rotate the INT wheel
to select and press to enter the Exit.You can return to the initial interface
of CCT mode.
- 12 -

4. Use of Sidus Link APP
You can download the Sidus Link app from the iOS App Store or Google
Play Store for enhancing the functionality of the light. Please visit sidus.link
/app/help for more details regarding how to use the app to control your
Aputure lights.
Specifications
CCT
CRI
TLCI
CQS
SSI (D56)
SSI (D32)
Beam angle
Power Output
Power Input
Operating Current
Operating Voltage
NP-F Battery Operating Voltage
V/Anton Bauer Mount Battery
Operating Voltage
Operating temperature
Control Methods
Wireless Operating Range
(Bluetooth)
Screen Type
Cooling Method
Head Cable
Power cable
Lamp Head Size
Lamp Head Weight
3200 K - 6500 K
≥ 95
≥ 97
≥ 95
≥ 72
≥ 84
45°
≤ 60 W
≤ 78 W
4.5 A
100 V - 240 V 50 Hz / 60 Hz
6.5 V - 8.4 V
-20 °C - +45 °C / -4 °F - +113 °F
Manual，Sidus Link APP
OLED
Active Cooling
2-Pin DC Head Cable（3 m）
Locking Power cable（1.5 m）
25.10 * 17.40 * 3.95 cm
979 g
- 13 -
12.5 V - 16.8 V
≥ 80 m / 262.5 ft

Photometrics
CCT
3200 K
4300 K
5600 K
6500 K
Distance
Lux
Fc
Lux
Fc
Lux
Fc
Lux
Fc
0.5 m
17570
1632
17670
1642
18120
1683
18410
1710
1 m
4860
452
4940
459
5070
471
5180
481
2 m
1280
119
1283
119
1328
123
1354
126
* This is an averaged result. The luminance of your individual unit may
vary slightly from this data
Trademark statement
Sony is a trademark and product model of Sony Corporation in China or
other countries.
- 14 -

Aputure Imaging Industries Co., Ltd. Add: F/3, Building 21, Longjun industrial estate, HePing West Road, Shenzhen, Guangdong E-MAIL: [email protected] Sales Contact: (86)0755-83285569-613
Aputure Imaging Industries Co., Ltd. warrants the original consumer purchaser from defects in material and workmanship for a period of one (1) year after the date of purchase. For more details of warranty visit www.aputure.com
Serial No. Item Name Purchase Date Buyer Name Buyer Phone Buyer Add Franchiser Seal
Add: F/3, Building 21, Longjun Industrial Estate, Heping West Road, Shenzhen, Guangdong
Aputure Imaging Industries Co.,Ltd.
Inspection: Qualified
