60 Hz FUSION SERIES INSTRUCTION MANUAL
Unit Serial Nu ber:
UNIT IDENTIFICATION
Distributor:
Light Set Serial Nu ber: Install Date:

2 Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
Parts Included
• Aerating Fountain (1)
• Standard Nozzle Package (1)
• Motor Cord or Quick Disconnect (1)
• Control Box / Panel (1)
• Mooring Rope (100’)
• Mooring Stakes (2)
Optional Accessories
 LED Lig ting
 Extended Nozzle Package
 Twister Nozzle Package
SAFETY INSTRUCTIONS
IMPORTANT: Reading and understanding the instructions and warranty disclaimer are
necessary prior to product installation and operation.
• Under NO circumstances s ould anyone enter t e water wit t e electrical equipment plugged in.
• NEVER run t e unit out of t e water. It may damage t e motor seals.
• NEVER lift or drag t e fountain by t e power or lig t cord.
• Suitable for FRESHWATER applications only.
• T e fountain suction screen s ould be inspected for clogging on a mont ly basis. If matted weeds,
leaves, or plastic bags are present, remove t em wit a bristle brus . Failure to keep t e suction screen
clear of blockages will cause low water flow and may cause premature motor failure. This type of failure
is NOT covered under the Aqua Control®, Inc. Manufacturer’s Warranty.
• In freezing conditions, t e fountain must be removed from t e water body and stored in an area
above 32°F.
• Neit er Aqua Control®, Inc. nor its distributors are liable for electrician’s fees incurred for
troubles ooting electrical issues.
TABLE OF CONTENTS
Steps to prep Fusion for water 3
• Nozzle Build
 Individual Nozzle Instructions in
Appendix A
 Mooring & Lig t Installation
Control Box Setup 5
• 0.5HP – 1HP Timer Programming
• 1.5HP – 2HP Timer Programming
Fusion Parts List 7
Stationary Fusion Parts List 8
Troubleshooting Guide 9
Appendix A 10
 CLUSTER ARCH A1
 DAFFODIL A3
 FLARE A5
 LILY A7
 SUPER LILY A9
 TORNADO A11
 DELMAR A13
 DOUBLE ARCH A15
 DOUBLE ARCH LILY A17
 PENTALATOR A19
 QUAD A21
 SPIDER & ARCH A23
 TIARA A25
 TRILLIUM A27
 WEEPING WILLOW A29
 Twister Module A30

Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
NOZZLE BUILD TIPS AND WARNINGS
 All nozzle builds are in Appendix A
 W en building t e Nozzle, it is best to work from inside out to provide room to work.
 Center Nozzle will always be installed last.
I portant Notice on the FUSION Series Multi-Nozzle
Components Carry No Warranty When Assembled Improperly
T is Innovative Multi-Nozzle Casting was designed to offer you t e flexibility to switc spray patterns as
desired. T e screws provided can be inserted multiple times in various locations wit out damaging t e
oles. Extra parts ave been included as spares in t e event t ey are needed.
Nozzles s ould be assembled using even and gradual tig tening. T e screws s ould be tig tened snuggly
using and tools only and opposing sides s ould be tig tened evenly. Over-torqueing t e screws may result
in damages not covered under t e manufacturer’s warranty. Power tools are not allowed.
T e assembled nozzle s ould be andled by t e base. Transporting t e assembly using t e individual tube
assemblies or components may result in damages not covered under warranty. Nozzle components are
warranted for 30 days and solely replaced due to manufacturing defects. All ot er damages caused by
improper andling and/or assembly will require replacement parts purc ased t roug your Aqua Control®
Distributor.
T ere is a separate instruction s eet to use w en installing t e Optional Twister Module. If you experience
difficulty implementing t e build for your preferred spray pattern based upon t e instructions provided,
please contact Aqua Control® Tec nical Support or your local distributor for assistance.
TWISTER MODULE REMINDER
Unlike t e pump itself, t e Twister Module carries a one (1) year manufacturer’s warranty against defects.
Due to t e intricate bearing design, t e Twister Module s ould not be continuously submerged. T is also
means t at your Fusion cannot be sunk for the winter onths without first re oving the Module for off-
season storage in a clean, dry, te perature-controlled environ ent. Please do not esitate to contact
Aqua Control® Tec nical Support or your local distributor if you ave any additional questions or concerns.

4 Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
MOORING ROPE & LIGHT SET INSTALLATION
Step #1
Fasten mooring rope to t e large
oles on two opposing sides of t e
float. Make sure to place t e knot on
t e bottom side of t e float as to not
interfere wit t e lig t bracket.
Step #2
Mount t e lig t bracket to t e float
making sure t at t e power cable is
away from t e float. Place bracket in
t e corner using t e provided
ardware in t e two outer oles as
s own. Bracket will contour over t e
mooring rope.
Step #3
For t e 0.5 p and 1 p unit, plug t e
lig t set cord into t e outlet labeled
Lights in t e control box.
For t e 1.5 p and 2 p unit, place t e
individual wires of t e lig t cable in
t e corresponding lig t set terminal
block.
Mooring
Rope Hole
Light Bracket
Mounting bolts
Cord Away from Float

5 Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
0.5HP – 1HP TIMER PROGRAMMING
Step #1
Plug fountain motor cord
& lig t set cord (optional)
into t e control box.
Receptacles in t e control
box are labeled ‘LIGHTS’
& ‘FOUNTAIN’. Do not
reverse the plugs. The
photocell controls the
light receptacle.
Lig t Set Cord
GFCI Reset
P otocell
Timer wit Pins
Control Box Cord Fountain Motor Cord
ON
GREEN
OFF
RED
Step #2
Set ON/OFF times using
tripper pins. Insert ON
(Green) and OFF (Red)
trippers into dial at desired
times. Turn dial clockwise and
align arrow wit Time- of-Day
(AM or PM) in window.
Step #3
Plug control box cord into
standard 115V ouse old
outlet.
Step #4
Turn on control and test
GFCI (Pus ‘TEST’ button
and t en Pus ‘RESET’).
NOTE: Install control box in an area with nat ral light. Placing the control box in a shaded area
or an area that is lit at night will not allow the photocell to properly operate the light circ it.

6 Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
1.5HP – 2HP TIMER PROGRAMMING
Step #1
Press and old t e CLOCK button.
Single press t e DAY button until
t e correct day is annotated.
Single press t e HO R button until
t e correct our (AM/PM) is
annotated. Single press MIN until
t e correct minute is annotated.
Once t e time and day is set,
release t e CLOCK button.
Step #2
Single press TIMER and 1 ON will
display. Single press DAY, HO R,
and MIN to set t e day or days you
want t e unit to turn on at a
certain time. Single press TIMER
and 1 OFF will Display. Single press
DAY, HO R, and MIN to set t e
day or days you want t e unit to
turn off at a certain time. Repeat
until desired on/off times are set.
Single press clock to get back to
main screen.
Note: Timer has 8 on/off
times that can be set. If unit is
to be turned on and off the same
time each day, you will only
need to set the on time for
1-ON and off time for 1-OFF.
(Mo = Monday, Tu = Tuesday, We =
Wednesday, T = T ursday, Fr = Friday, Sa =
Saturday,
Su = Sunday); (ON, OFF)
Eit er individual days “Mo”, “Tu”, “We”,
“T ”, “Fr”, “Sa”, “Su”, or different groups
1. Group “Mo – Tu – We – T – Fr”,
2. Group “Sa – Su”,
3. Group “Mo – Tu – We – T – Fr – Sa”,
4. Group “Mo, Tu, We”,
5. Group “T , Fr, Sa”
6. Group “Mo, We, Fr”,
7. Group “Tu, T , Sa”,
8. Group “Mo – Tu – We – T – Fr – Sa –
Su”,
Step #3
Single press t e MANUAL button
until t e line is over AUTO. T is
sets t e timer to turn on/off at
specified times.
Note: When line is above on
the unit will continue to run
until set to auto or off. When
turning unit from ON to A TO,
unit will stay on until next OFF
time. When turning unit from
OFF to A TO, unit will stay off
until next ON time
1. AM/PM
2. ON / AUTO / OFF indicator
3. Clock Button
4. Timer Button
5. Power Lig t – w en timer is on
6. Reset Button – press to reset to factory
defaults
7. Day of t e week display
8. Time Display
9. Day Button
10. Hour Button
11. Minute Button
12. Manual Button
NOTE: Install control box in an area with nat ral light. Placing the control box in a shaded area
or an area that is lit at night will not allow the photocell to properly operate the light circ it.
1
2
7
8
9
12
11
10
6
5
4
3

7 Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
FUSION PUMP PARTS LIST
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 62MC2-2.021-L2 2.00HP 60HZ 1PH 230V MOTOR
ASSEMBLY FINISHED 1
EV-H-ZIPTIE ZIP TIE 2
2 41-SRR SHAFT RETAINING RING 1
3 41-RS .188 X .250 X 0.75 LONG
RECTANGULAR EY 1
4 40-PH PUMP HOUSING 1
5 40-F-1 S2 INLET FAIRING 1
6 80BS-06X1.0 #6-18 X 1 SELF TAP SCREW 2
7 41-SW EXTENDED SHAFT WASHER 1
8 80S-0.005 .625 X .005 SHIM 59
Qty Varies by unit
9 40-SH-1 PRIMARY SHROUD 1
10 80BSC-0.31X0.63 5/16-18 X 5/8 BUTTONHEAD SC 43 3
80WF-0.31 5/16" FLAT WASHER 67 3
80WL-0.31 5/16" LOC WASHER 76 3
11 PROP
(.5hp) 40-P-04.5-W PROP - 4.5 DEGREE - 3 BLADE 1
(1hp) 40-P-08.0 PROP - 8 DEGREE - 3 BLADE 1
(1.5hp) 40-P-07. PROP - 7 DEGREE - 3 BLADE 2
(2hp) 40-P-08.0 PROP - 8 DEGREE - 3 BLADE 2
12 40-P-00 PROP SPACER(ONLY FOR 2-STAGE) 1
13 40-IFS-2 INTERNAL FLOW STRAIGHTENER 18-
35 2
14 40-SH-2 SECONDARY SHROUD 1
15 80BT-0.25X0.63 1/4-20 X 5/8 TRUSS HEAD 30 3
80WL-0.25 1/4" LOC WASHER 75 3
80WF-0.25 1/4" FLAT WASHER 64 3
16 80WB-0.31 5/16" BELLVILLE WASHER 1
17 80BR-0.31X0.75 5/16-18x3/4" PHIL RH SCREW 87 1
80WF-0.31 5/16" FLAT WASHER 67 1
80WL-0.31 5/16" LOC WASHER 76 1
18 41-OF OUTFLOW 1
19 BOLT
1-STAGE 80BH-0.25X3.50 1/4-20 X 3 1/2 HEX HEAD 14 3
2-STAGE 80BH-0.25X6.00 1/4-20 X 6 HEX HEAD 16 3
80WL-0.25 1/4" LOC WASHER 75 3
80WF-0.25-N 1/4" NARROW WASHER - 1/2" OD 64 3
20 41-BASE MULTI NOZZLE BASE 1
21 80BH-0.38X3.00 .375-16X3.000 FHPCS 18-8 S.S. 1

8 Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
FUSION UNIT BREAKDOWN LIST
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 41-BASE MULTI NOZZLE BASE 1
2 41-OF OUTFLOW 1
3 FLOAT FUSION FLOAT
0.5HP - 1HP
41-FLOAT-S FUSION FLOAT - SMALL 1
1.5HP -2HP
41-FLOAT-L FUSION FLOAT - LARGE 1
4 PUMP ASSEMBLY - SEE PAGE 7 1
5 MOTOR ASSEBMLY
0.5HP
62MA2-0.511-L2 0.5, 115, 1 2W MTR ASSY 1
1HP
62MA2-1.011-L2 0.5, 115, 1 2W MTR ASSY 1
1.5HP
62MA2-1.511-L2 0.5, 115, 1 2W MTR ASSY 1
5HP
62MA2-2.011-L2 0.5, 115, 1 2W MTR ASSY 1
6 40-SCR MOLDED SUCTION SCREEN 1
7 40-SCR-EC MOLDED SUCTION SCREEN END
CAP 1

9 Aqua Control®, Inc. 60Hz Fusion Series Owner’s Manual
FUSION SERIES TROUBLESHOOTING GUIDE
TROUBLE CHECK POSSIBLE SOLUTIONS
Fusion does not operate
-OR-
Starts t en stops
Not plugged in
Cord must be plugged into a 3-wire outlet
t at is protected by a GFCI or t e supplied
Fusion Control Box.
GFCI Tripped
Reset GFCI. If GFCI will not reset or trips
immediately, unplug t e pump & lig ts and
reset GFCI. If GFCI will still not reset, t ere
may be a problem wit t e Fusion Control
Box or t e incoming power. If t e GFCI
resets, plug t e pump in t e Fusion Control
Box. If t e GFCI trips, t ere may be a
problem wit t e pump cord. If t e GFCI
olds, plug in t e optional lig t kit. If t e
GFCI trips, t ere may be a problem wit t e
lig ts.
Contact Aqua Control® Tec nical Support to
troubles oot lig ts or pump
GFCI not tripped,
not running.
Disconnect power. C eck propeller for
obstruction. T ese motors ave internal
overloads. If t e propeller is jammed, t e
internal overload may trip. T is overload
may require up to 10 minutes to cool
down & reset. If t e motor
does not restart, t ere may be ot er
motor problems. Contact Aqua Control®
Tec nical Support to troubles oot t e
pump.
Fusion spray pattern is not
reac ing full size
Fusion intake clogged
Disconnect power. C eck suction screen for
obstruction & remove debris.
Nozzle clogged
Disconnect power. Remove nozzle &
c eck for obstruction & remove debris.
Aqua Control® Technical Support
Available Monday t ru Friday, 7:30AM – 5:00PM CST
P one: 1-800-377-0019 or 1-815-664-4900
Email: [e-mail]
-OR-
Contact Your Local Aqua Control® Distributor
