Aqua Creek water rider 3 User manual

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
PART #: F-WXF
330 LB. [150 kg]
MAXIMUM WEIGHT CAPACITY
MANDATORY – LEAVE THIS MANUAL
WITH THE BIKE OWNER
Water Rider 3
SAVE a copy of these instructions
9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | [phone]
aquacreek.com
• To assemble your equipment read entire manual and follow all instructions.
• Consult your doctor before beginning any sports or exercise program. Patients with
hypertension use extreme caution and consult your doctor prior to using this equipment.
• It is important to stretch and warm up prior to using this equipment.
• Check contents of all packages against the parts diagrams and report any damaged and/or
missing parts immediately.
• This device is designed for individual, adult use only. Children using this device should be
supervised.
• This product is to be used in a pool environment where the pH level of the water is maintained
between 6.7ppm and 7.6ppm.
1

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Water Rider 3 Pool Bike
PAGE DESCRIPTION
3 EXPLODED VIEW
3 TOOLS
4 PARTS LIST
5-6 INSTALLATION
7 USING THE POOL BIKE
8 POOL BIKE MAINTENANCE
9 WARRANTY
2

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Exploded View
Tools
• Note: The use of these tools is reserved for the assembly of the pool bike
• Warning: Keep tools out of reach of children
3

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Parts List
ITEM # QTY DESCRIPTION
14 FOOT MAT
22 WHEEL
32 BOLT M8X40MM
44 PROTECTIVE CAP
51 FRONT TUBE
62 HEIGHT ADJUSTMENT KNOB
71 MAIN FRAME
84 CLENCH WASHER
94 HANDLE (CLICK & TURN)
10 4 WELDED NUT
11 2 PROTECTIVE CAP
12 1 HANDLEBAR
13 1 HANDLEBAR TUBE
14 1 COVER
15 1 PEDAL (A-B)
16 1 CRANK LOCKNUT (A-B)
17 1 SEAT SPILE
18 1 SEAT
19 2 BOLT M6X30MM
20 1 STATOR
21 1 BEHIND TUBE
22 1 SEAT TUBE
23 2 LOCK NUT M8
24 2 WASHER ø 8
25 4 WASHER ø 6
26 4 BOLT M6X10MM
4

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Installation
Step 1:
Install two (2) wheels (#2) onto the front tube with
two (2) M8x40MM bolts (#3), two (2) washers (#24)
and two (2) lock nuts (#23). Tighten until snug.
Step 2:
Install the front foot tube (#5) into the main frame
(#7) and then adjust the height using the height
adjustment knob (#6).
Step 3:
Install the back foot tube (#21) into the main frame
(#7) and then adjust the height using the height
adjustment knob (#6).
Step 4:
Install the seat tube (#17) and handlebar tube
(#13) into the main frame (#7) and then adjust their
position using the ‘click-and-turn’ handles (#9).
5

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Installation
Step 5:
Install the handlebar (#12) into the handlebar tube
(#13) and then adjust the position using the ‘click-
and-turn’ handle (#9).
Step 6:
Install the seat (#18) onto the seat tube (#22). Slide
the seat tube (#22) onto the seat support tube (#17)
and adjust its position using the ‘click-and-turn’
knob (#9).
Step 7:
Thread the pedals (#15) onto the pedal crank and
secure with the crank locknut (#16).
Step 8:
Install the cover (#14) onto the main frame (#7).
Secure it in place with the bolts and washers (#25 &
#26).
6

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Using the Pool Bike
Warm Up Phase:
Cool Down Phase:
The warm up phase is important because it helps your blood ow and will
reduce the risk of cramps and muscle injury. It is advisable to stretch during
this phase. Do not force your muscles. If you feel pain, stop exercising
immediately.
The cool down phase helps your cardiovascular system and muscles
relax. Repeat the movements performed during the warm up without
traumatizing your muscles. Be sure to reduce speed and resistance during
this phase. Once you have gained experience, increase the duration and
intensity of your regular workout.
Height Adjustment Knob:
To adjust the height of the bike, simply
pull the adjustment knob straight up
and adjust the height by pulling the leg
of the bike down or pushing it up into
the frame. Release the knob and tighten
at the height that is comfortable.
Consult with a physician before starting any exercise regimen
7

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Pool Bike Maintenance
1. Remove the bike once a week and rinse it thoroughly with soft water, not
pool water.
2. Regularly check the pH of your swimming pool.
3. Remove the bike during manual dosages of chemical products or chlorine
stock treatments. Keep the bike away from chemicals to avoid any splashing
which can stain or cause deposits.
4. Deposits of powder, salt, and other corrosive products will speed up the
corrsion process.
5. When cleaning the surfaces of the swimming pool it is advised to remove
the bike from the pool in order to avoid any risk of stains or deposits.
6. When you are not using the bike, it must be rinsed thoroughly with soft
water, then dried and stored in a location away from chemical products.
7. If there are lime-scale deposits or stains, they can be removed with a
polishing cleaner for stainless steel and a non-abrasive soft cloth. Then wash
the bike with clean water and dry it completely.
The WR3 is made of marine quality AISI 316L stainless steel. Its anti-corrosion
treatment makes it suitable for chlorinated water, seawater and thermal waters.
It does not require any special care in pH-controlled water (6.7 / 7.6).
8

Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 5/1/2015
Revised: 5/1/2015
AQUA CREEK PRODUCTS, LLC LIMITED TWO (2) YEAR WARRANTY:
WATER RIDER AQUATIC EXERCISE EQUIPMENT
(ITEM #’s F-WXF, F-WX4S, F-WX5, F-WXEL, F-WXAQJG)
Aqua Creek Products, LLC (a.k.a. Aqua Creek) warrants to the original end user purchaser that products manufactured by Aqua Creek
when properly installed in accordance with assembly and installation instructions, and properly used and maintained, shall be free from
defects in material and workmanship for a period of two (2) years from the date of original purchase, provided that Aqua Creek receives
prompt notice in writing of any defect or failure and satisfactory proof thereof, with the following exception(s):
Exception(s):
• All non-frame components, i.e. plastic feet, etc… shall be warrantied for six (6) months from the date of original purchase.
IMPORTANT: User is not to exceed the rated weight capacity of this product. It is the responsibility of the product owner to verify the
weight of the patron for warranty claim purposes and to ensure that the product is not overloaded.
This warranty specically excludes reimbursement for labor to remove, repair, or install the product and any return freight charges.
These warranties do not cover any damages due to accident, misuse, abuse, negligence or failure to properly maintain any products,
or normal wear and tear from day to day operations. In the event that any products are altered, repaired, or improperly installed or
improperly used by anyone without the prior written approval by Aqua Creek, all warranties are void. Non-payment for product to Aqua
Creek may void warranty.
To initiate a warranty claim, the owner of an Aqua Creek product must provide the place of purchase, in writing, with a full description
of the product, its serial number, the dates of purchase and installation, and the exact nature of the defect. Within thirty (30) days after
receipt of a written warranty claim by Aqua Creek, and barring any unforeseen delays, the place of purchase will be notied of Aqua
Creek’s decision regarding the claim.
If requested by Aqua Creek, any defective product must be returned, freight prepaid, to Aqua Creek’s designated factory location or duly
appointed distributor for inspection and/or repair. Aqua Creek will, at its option, repair or replace the failed or defective item, and deliver
the repaired product or replacement to the buyer of the product, freight prepaid to the destination provided for in the original order.
Products returned to Aqua Creek for which Aqua Creek provides replacement under this limited warranty shall become the property of
Aqua Creek. A new warranty period shall NOT be established for the repaired or replaced products. Such products shall remain under
warranty only for the remainder of the original warranty period on the original products purchased.
This written limited warranty constitutes the nal, complete and exclusive statement of warranty terms. No person or organization is
authorized to make any other specic or implied warranties or representations on behalf of Aqua Creek.
THE WARRANTIES SET FORTH HEREIN ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, WHICH ARE HEREBY DISCLAIMED
AND EXCLUDED, INCLUDING WITHOUT LIMITATION ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR
USE.
THE SOLE AND EXCLUSIVE REMEDIES FOR BREACH OF ANY AND ALL WARRANTIES WITH RESPECT TO THE PRODUCTS SHALL BE LIMITED
TO REPAIR OR REPLACEMENT AT AQUA CREEK’S DESIGNATED FACTORY LOCATION, OR DULY APPOINTED DISTRIBUTOR, OR IN PLACE
AT AQUA CREEK’S OPTION. IN NO EVENT SHALL AQUA CREEK’S LIABILITY EXCEED THE ENTIRE AMOUNT PAID TO AQUA CREEK BY THE
ORIGINAL PURCHASER FOR THE FAILED OR DEFECTIVE PRODUCT.
IN NO EVENT SHALL AQUA CREEK PRODUCTS, LLC BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT, PUNITIVE OR
EXEMPLARY DAMAGES OR LOST PROFITS FROM ANY BREACH OF THIS LIMITED WARRANTY OR OTHERWISE.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH MAY VARY FROM STATE TO STATE.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, SO SOME OF
THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
