Tomahawk IC3 User manual

ENGDEUESP
MANUFACTURED BY:
Indoorcycling Group GmbH
Happurger Str. 86
90482 Nuremberg | Germany
[email protected]om
www.indoorcycling.com
Phone: +49(0)911 / 54 44 50
ENG
CAUTION!
READ ALL PRECAUTIONS AND INSTRUCTIONS IN THIS MANUAL BEFORE YOU START
USING THIS EQUIPMENT. PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE.
IMPROPER ASSEMBLY, USE OR MAINTENANCE CAN VOID THE WARRANTY TERMS.
IC3
MODEL NO:IC-TKIC3B-01
Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
TECHNICAL SPECIFICATIONS:
The Tomahawk IC3 Bike is, according to EN 957, a Class S product for professional
and / or commercial use. Such training equipment is intended for use in training areas
of organizations such as tness clubs or sport associations, where access and control are
specically regulated by the individual with legal responsibility.
WARNING!
The bike is designed to accommodate most users from
150 cm to 205 cm (4’11’’to 6’9“) body height.
TABLE OF CONTENTS
IMPORTANT PRECAUTIONS P.3
GETTING STARTED P.4
HOW TO ASSEMBLE THE INDOOR CYCLE P.5-7
INITIAL INSTALLATION CHECKS P.8-9
HOW TO ADJUST THE INDOOR CYCLE P.10-12
RESISTANCE ADJUSTMENT P.13
HOW TO MOVE THE INDOOR CYCLE P.13
PREVENTIVE MAINTENANCE P.14-18
MAINTENANCE ACTIVITY PLAN P.19
SPARE PARTS P.20-25
LIMITED WARRANTY P.26-27
FOOT PRINT: 52 X 120 CM / 20.5 X 47.2 INCH
WEIGHT OF BIKE: 57KG / 126,66 LBS
MAX SADDLE HEIGHT: 115 CM / 45.3 IN
MAX HANDLEBAR HEIGHT: 115 CM / 45.3 IN
MAX USER WEIGHT: 130 KG / 287 LBS

3
ENG
1. It is the sole responsibility of the owner to
ensure that all users of the indoor cycle are
informed and aware of all warnings
and precautions.
2. Operate and maintain the indoor cycle
only as described in this manual and after
proper assembly and functionality check as
described in this manual.
3. Keep the indoor cycle indoors, away from
moisture and dust. Do not place the indoor
cycle in a garage or covered patio or near
water or pools.
4. Place the indoor cycle on a level surface.
To protect the oor or carpet from damage,
place a mat beneath the indoor cycle.
Make sure that there is adequate room (20
inches/0,5m) around the indoor cycle to
assemble, disassemble and operate it.
5. Regularly inspect and properly tighten all
parts of the indoor cycle as recommended in
this manual. Please replace defective parts
immediately and do not use the Bike until
repair is performed. Only use original parts
from the manufacturer.
6. Children under the age of 14 should
only be allowed use of the indoor cycle
with parental approval and supervision. If
the indoor cycle is not in use, please make
sure the brake resistance is fully engaged
to prevent drive gear components from
movement and to avoid the potential risk of
injury due to improper use.
7. The indoor cycle should not be used by
persons exceeding weight of 287 lbs/130 kg.
8. Always wear appropriate riding gear and
shoes for cycling while operating the indoor
cycle. Do not wear loose clothes or shoes
with loose laces which could become caught
on the indoor cycle.
9. Before using the indoor cycle, make sure
you are familiar with the setup/operation of
the indoor cycle.
10. The indoor cycle does have a direct
driven ywheel (wheel); the pedals will
continue to move along with the ywheel
until the ywheel stops.
11. Always adjust the ywheel resistance so
that your pedalling motion is controlled.
12. Keep your back straight while using the
indoor cycle; do not arch your back.
13. If you feel pain or dizziness while
exercising, stop immediately, rest and cool
down and consult a physician.
14. If replacement parts are needed, use only
manufacturer supplied parts.
IMPORTANT
PRECAUTIONS
WARNING!
To reduce the risk of serious injury, read the following
precautions and information carefully before
operating the indoor cycle.
WARNING!
Before beginning any exercise program, consult
your physician.This is especially important for
persons over the age of 35 or persons with pre-
existing health problems. Read all instructions
before using. Be aware that incorrect or extensive
training may result in serious health injuries.
The manufacturer assumes no responsibility for personal injury or
property damage related by or through the use of this product.

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
GETTING STARTED
DEAR CUSTOMER,
Congratulations on selecting the Tomahawk IC3 Indoor Cycle. The Tomahawk IC3 Indoor Cycle
oers an impressive array of features designed to enhance cardiovascular tness, tone muscles,
and develop endurance. Whether users are beginners or experienced athletes, the Tomahawk
IC3 Indoor Cycle oers workouts that will help users to reach their individual tness goals.
IMPORTANT: Read this manual carefully before assembling or using the indoor cycle. If you have
questions after reading this manual, please contact your local distributor or refer to the website
www.indoorcycling.com. Before reading further, please familiarize yourself with the parts that
are labeled in the drawing below.
YOU WILL FIND THE PRODUCTION CODE ON THE LOWER LEFT SIDE OF THE TOMAHAWK IC3 INDOOR CYCLE FRAME.
PLEASE REFER TO THIS NUMBER IN SERVICING AND MAINTENANCE LISTS.
EMERGENCY BRAKE & RESISTANCE KNOB
SADDLE
LEVER HANDLE
ADJUSTMENT KNOB
PEDAL /TOE CLIP
CHAIN GUARD
MAINTENANCE COVER
HANDLEBAR
ADJUSTMENT KNOB
BRAKE PAD
FLYWHEEL
TRANSPORT WHEEL
LEVELLING FEET

5
ENG
HOW TO ASSEMBLE THE
INDOOR CYCLE
SW 17/19MM
SW 13/15MM 15MM WRENCH
1X 1X
3MM
6MM HAND
TIGHT
1. 2.
4.3.

PLEASE ASSURE THAT NUTS ARE TIGHTENED WITH
SIGNIFICANT FORCE TO MINIMIZE LOOSENING.
DURING USE.
SEAT CLAMP MUST BE TIGHTENED SECURELY FROM
BOTH SIDES TO MINIMIZE LOOSENING DURING USE.
PLEASE ASSURE THAT NUTS ARE TIGHTENED WITH
SIGNIFICANT FORCE TO MINIMIZE LOOSENING.
DURING USE.
SEAT CLAMP MUST BE TIGHTENED SECURELY FROM
BOTH SIDES TO MINIMIZE LOOSENING DURING USE.
A
A (1 : 2)
STOP MARK STOP MARK

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
HOW TO ASSEMBLE THE
INDOOR CYCLE
WARNING!
Make sure the seat is xed properly in a
LEVEL HORIZONTAL position and seat clamp
must be tightened securely from both sides
to minimize loosening during use!
5.
13MM
SW 17/19MM
SW 13/15MM 15MM WRENCH 3MM 6MM HAND
TIGHT
1X 1X
6.

7
ENG
HOW TO ASSEMBLE THE
INDOOR CYCLE


7. 8.
SW 17/19MM
SW 13/15MM 15MM WRENCH
1X 1X
3MM
6MM HAND
TIGHT
10.
9.
WARNING!
Pedal marked Rinstalled on right crank (clockwise). Pedal marked Linstalled on left crank (counter-
clockwise) Pedals must be fastened with signicant strength to avoid loosening with use of the indoor cycle.
PLEASE FOLLOW
INSTRUCTIONS!

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
INITIAL
INSTALLATION CHECKS
The cycle tune-up must be performed at initial installation of the indoor cycle for optimal
performance and longevity. Please read and follow all instructions below. If the indoor cycle is
not installed and tuned as described, components may wear excessively and the indoor cycle
may become damaged. If you have questions about the installation, please contact Tomahawk
customer service www.indoorcycling.com
Note: Some maintenance procedures require acid-, silicone- and solvent free spray
lubricant (for example BRUNOX), and white lithium grease.
1. Make sure that the indoor cycle is level. If the indoor cycle rocks on the oor, turn the
leveling feet underneath the front and/or rear stabilizer until the rocking motion is eliminated.
2. Verify emergency brake function to assure that emergency brake functions correctly.
3. Brake pad calibration: Turn resistance knob counterclockwise as far as possible (minimum
braking eect). Verify that there is a slight separation of the brake pad from ywheel. Brake pad
should barely touch the ywheel when resistance knob is turned counterclockwise as far as it
can go.
4. Apply spray lubricant to the brake pad using the lubrication holes on the plastic part or the
brake pad and externally on the felt pad. Make sure brake pad is thoroughly soaked from end
to end with lubricant spray. Wipe the excess from the ywheel.
* Best Practice: Use a rellable spray bottle lled with non-aerosol acid-, silicone- and
solvent- free spray lubricant purchased by the gallon (3.7 L) at the local hardware store.
5. Apply Lithium grease to the threads on the lower end of the brake rod. First, turn the resistance
knob clockwise until it stops. Apply a small amount of white lithium grease to the threads on the
brake rod above the two lock nuts.Then, turn the resistance knob counterclockwise until it stops.

9
ENG
INITIAL
INSTALLATION CHECKS
6. Apply Lithium grease on the metal threads of all the adjustment knobs.
7. Check four (4) Allen bolts on RS pulley for tightness. If loose, apply LocTite Threadlocker
Blue-242 and retighten.
8. Verify R and L crank arm Allen bolts for tightness. If loose, apply LocTite Threadlocker
Blue-242 and retighten.
9. Wipe down bike frame with rag moistened with solvent-free spray lubricant
10. Some parts of the indoor cycle may become loose during shipment. Check crank arms and
check all exposed screws, bolts and nuts, and make sure that they are properly tightened.
CUSTOMER SERVICE
1. Provide basic maintenance instructions for clients and direct them to detailed maintenance
instructions (page 13-18).
2. Provide sign-o sheet for clients to conrm explanation of maintenance procedures/manual
and verication of condition of bikes.

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
HOW TO ADJUST THE
INDOOR CYCLE
The Tomahawk IC3 Indoor Cycle can be adjusted for maximum comfort and exercise
eectiveness. The instructions below describe one approach to adjusting the Tomahawk IC3
Indoor Cycle to ensure optimal user comfort and ideal body positioning. You may choose to
adjust the Tomahawk IC3 Indoor Cycle dierently.
PEDAL STRAP ADJUSTMENT:
Sit on the saddle and position your feet on the pedals, with the balls of your feet directly above
the spindles of the pedals (see the drawing below). Adjust the pedal straps so the toe clips (cages)
are snug but not too tight. Note: When tting a bike with combi-pedals, the pedals feature toe
clips on one surface and SPD cleats on the opposite surface. If desired, use the SPD cleats with
cycling shoes instead of the toe clips.
Please do not adjust
saddle height beyond
the STOP mark on the
stem and ensure the pop
pin is fully engaged and
securely tightened
WARNING!
Please avoid overtightening the pop pin adjustment knob as this may cause damage to the
vertical aluminum stems.
SADDLE HEIGHT ADJUSTMENT:
Sit on the saddle and slowly pedal until the right pedal is in the lowest position. Your knees
should be slightly bent with no dropping of the hips. To avoid hyperextending your knees, make
sure that your legs are not completely straight.
Please do not adjust
saddle height beyond
the STOP mark on the
stem. Also ensure the pop
pin is fully engaged and
securely tightened

11
ENG
HOW TO ADJUST THE
INDOOR CYCLE
SADDLE HORIZONTAL ADJUSTMENT:
Proper horizontal adjustment of the saddle is very important in avoiding injury to the knees. Sit
on the saddle and move the pedals until the crank arms are in horizontal position.
Using your forward leg as a marker, your kneecap should be directly above the center of the pedal so that a straight line
is created between knee and center of the pedal (see the dotted line in image below).To adjust the horizontal position of
the saddle, rst dismount the Tomahawk IC3 Indoor Cycle. Next, loosen the rear lever handle, slide the saddle forward or
backward as required, and then retighten the lever handle.
horizontal adjustment
with lever handle

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
HOW TO ADJUST THE
INDOOR CYCLE
Next, the horizontal position of the handlebar should be adjusted. If the handlebar is too close
to the saddle, your breathing may feel restricted. If the handlebar is too far from the saddle,
you may experience back discomfort. To adjust the horizontal position of the handlebar, rst
dismount the Tomahawk IC3 Indoor Cycle.
Check for proper handlebar position by positioning your elbow so that it touches the front tip of the saddle at a
90- degree angle and checking that the ngertip of your middle nger is touching the handlebar at the mid-point. If it is
not as described, loosen the fore/aft lever handle and slide the handlebar forward or backward until your middle nger is
touching the handlebar at the mid-point. Retighten the lever handle.The handlebar oers a wide variety of hand positions
for personal preferences. Changing your hand position can change the angle of your back, neck, and arms. To minimize
the stress on your muscles during your workouts, change your hand position frequently.
HANDLEBAR ADJUSTMENT:
Begin with the top of the handlebar at relatively the same height as, or just slightly higher than,
the top of the saddle (dotted horizontal line A in the drawing below) and at a neutral fore/
aft position (see dotted vertical line B in drawing below). If your knees touch the handlebars,
or if you experience back discomfort while pedaling for extended periods of time, the height of
the handlebars can be adjusted. First, dismount the Tomahawk IC3 Indoor Cycle. Next, turn the
front adjustment knob counterclockwise, slide the handlebar post up or down, and retighten
the adjustment knob.
A.
B.
handlebar
fore/aft
lever handle:
handlebar up/down
adjustment knob

13
ENG
HOW TO OPERATE THE
INDOOR CYCLE
RESISTANCE ADJUSTMENT:
The preferred level of diculty in pedaling (resistance) can be regulated in ne increments by
use of the resistance knob. To increase the resistance, turn the resistance knob clockwise.
To decrease the resistance, turn the knob counterclockwise.
IMPORTANT: To stop the ywheel (wheel) while pedaling, pull up the red emergency handle. The ywheel should
quickly come to a complete stop. Please make sure your shoes are xed into the toe clip or, in case cycling shoes are
used, your shoe cleat is connected to the pedal binding while riding.
HOW TO MOVE THE TOMAHAWK IC3 INDOOR CYCLE:
Due to the weight of the Tomahawk IC3 Indoor Cycle, it is recommended that two people
move it. While one person lifts the back of the Tomahawk IC3 Indoor Cycle, the second person
rmly holds the handlebar and tips the Tomahawk IC3 Indoor Cycle forward until it rolls on the
wheels. Carefully move the Indoor Cycle to the desired location and then lower it. CAUTION:
To reduce the risk of injury, use extreme caution while moving the Indoor Cycle. Do not
attempt to move it over uneven surfaces. Make sure to allow a minimum safety space of
20 inches to the nearest equipment.
If the Tomahawk IC3 Indoor Cycle rocks on the oor after
being set down, turn the leveling feet (see diagram)
underneath the front or rear stabilizer until the
rocking motion is eliminated.
Important:
Please do not unscrew the leveling feet more than ½ inch!
LEVELLING FEET
TheTomahawk IC3 Indoor Cycle does not have a free-moving flywheel (wheel).The pedals will continue to move
with the flywheel until the flywheel stops. Reducing speed in a controlled manner is required. To stop the flywheel
immediately, pull up the red emergency break handle. Always pedal in a controlled manner and adjust
your desired cadence according to your own abilities.
PULL THE RED EMERGENCY HANDLE UP = EMERGENCY STOP
RESISTANCE KNOB (TURN)
EMERGENCY BRAKE HANDLE (PULL)

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
PREVENTIVE
MAINTENANCE
WARNING!
REGULAR MAINTENANCE MUST BE PERFORMED ON THE TOMAHAWK IC3 INDOOR CYCLE
FOR OPTIMAL PERFORMANCE AND LONGEVITY.
Please read and follow all instructions below. If the indoor cycle is not maintained as described,
components may wear excessively and the Tomahawk IC3 Indoor Cycle may become
damaged. Improper maintenance will void the warranty terms. If you have questions about
maintenance, contact your local distributor or refer to www.indoorcycling.com.
NOTE: MANY MAINTENANCE PROCEDURES REQUIRE LUBRICANT SPRAY.
MANUFACTURER RECOMMENDS BRUNOX OR ANY OTHER SOLVENT-FREE LUBRICANT.
DAILY MAINTENANCE:
1. Make sure that the Tomahawk IC3 Indoor Cycle is level. If the Tomahawk IC3 Indoor Cycle
rocks on your oor, turn the leveling feet underneath the front or rear stabilizer until the
rocking motion is eliminated (see„How to move the Tomahawk IC3 Indoor Cycle“ on page 12).
2. After each user nishes exercising, the Tomahawk IC3 Indoor Cycle should be disinfected
and cleaned to maintain a hygienic environment. First, apply a disinfectant spray to the
handlebars and the saddle. Using a lint-free cloth, dry the handlebars and the saddle. Next,
apply a small amount of disinfectant to a lint-free cloth and clean the adjustment knobs and
the lock
handles. Avoid using strong detergents on the Tomahawk IC3 Indoor Cycle frame.
WEEKLY MAINTENANCE:
1. Apply a small amount of the lubrication spray to a lint-free cloth. Thoroughly clean the
frame, the handlebar slider, the seat sliders, the ywheel, and the plastic parts of the Tomahawk
IC3 Indoor Cycle.
2. For optimal performance of the resistance
system, and to minimize wear on the brake
pad, the acid-, silicone- and solvent-free
spray lubricant should be applied to the
brake pad using the lubrication holes on the
plastic part of the brake pad. If fuzz or lint
appears on the brake pad, the brake pad has
become too dry. Lubricant spray should be
applied more frequently. Make sure brake
pad is thoroughly soaked from end to end
with lubricant spray. aWipe o any excess.


15
ENG
PREVENTIVE
MAINTENANCE

BI-WEEKLY MAINTENANCE:
1. The Tomahawk IC3 Indoor Cycle should
not be used if the emergency brake system is
not working properly.
While sitting on the saddle and pedaling,
test the brake by pulling upward on the
emergency brake handle. The ywheel
should come to a quick and
complete stop.
2. To maintain the easy adjustability of
the saddle post, the saddle post should
be cleaned and lubricated. Turn the rear
adjustment knob counterclockwise and slide
the saddle post out of the frame. Apply a
small amount of lubricant spray to a lint-free
cloth, and clean the saddle post (A).
Next, loosen the rear lock handle and slide
the saddle carriage as far back as possible. Apply a small
amount of lubricant spray to a lint-free cloth, and clean the
top of the saddle slide (B).Then slide the saddle carriage
as far forward as possible and clean the top of the saddle
slide. Finally, adjust the saddle to the desired position.
A
B
1.
2.

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
PREVENTIVE
MAINTENANCE
3. To maintain the easy adjustability of the
handlebar post, the handlebar post should
be cleaned and lubricated. First, turn the front
adjustment knob counterclockwise and slide
the handlebar post out of the frame. Apply a
small amount of lubricant spray to a lint-free
cloth, and clean the handlebar post (A).
Next, reinsert the handlebar post into the frame and adjust
it to the desired height. Loosen the front lock handle and
slide the handlebar carriage as far back as possible. Apply
a small amount of lubricant spray to a lint-free cloth, and
clean the surface of the handlebar slide (B). Then slide the
handlebar carriage as far forward as possible and clean the
top of the handlebar slide. Finally, adjust the handlebar to
the desired position.
MONTHLY MAINTENANCE:
1. To maintain the smooth function of the
height adjust ment knobs for the handlebar
and saddle, the metal threads on the
adjustment knobs (A) must be lubricated.
Use of white lithium grease is recommended.
G
G (2 : 5)
1.

A
B
A
3.

17
ENG
PREVENTIVE
MAINTENANCE
2. To maintain the easy adjustability of the re-
sistance system, the threads on the lower end
of the brake rod should be lubricated. First,
turn the resistance knob clockwise until it
stops. Next, look under the right or left side of
the frame and locate the brake rod, which has
two lock nuts on its lower end. Apply a small
amount of synthetic grease (white lithium
grease) to the threads on the brake rod above
the two lock nuts. Turn the resistance knob
counterclockwise until it stops.
3. Some parts of the Tomahawk IC3 Indoor
Cycle may become loose as a result of
repeated use. Check pedals, toe clips and
pedal straps, and make sure that they are
properly tightened. Next, check all exposed
screws, bolts, and nuts. Make sure that they
are properly tightened. Finally, check the
saddle to make sure that it is not loose or
damaged. Please use Locktite on loose crank
arm and pulley screws.
4. The brake pad will become worn as a
result of repeated use. The Tomahawk IC3
Indoor Cycle should not be used if the
emergency brake system is not working
properly (see page 14)! Should you feel
that the resistance system’s functions are
decient, it is essential to ne-tune the
resistance system before the bike is used
again! Please check the setting of the brake
system as follows: First turn the resistance
regulator on the brake system as far as it
will go to the left (minimum braking eect).
If the setting is correct, the brake pads
should be ush with the ywheel and barely
touching so that it is possible to cycle with
a barely noticeable amount of resistance.
The brake pad can be adjusted using a 10
mm wrench. Next, check the brake pad for
signs of wear. If the brake pad does show
signs of excessive wear, thoroughly soak the
brake pad with lubricant spray using the 2
lubrication holes (B). Wipe o the excess.
2.
3.
4.
B

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
MAINTENANCE ACTIVITY
REQUIRED SCHEDULE
EXAMPLES OF MAINTENANCE PLAN CHARTS FOR IN HOUSE SERVICE TECHNICIANS:
ACTIVITY ROTATION DETAILS
FEET LEVELLING, DISINFECTION
& CLEANING OF THE BIKE DAILY P 14
SERVICING BRAKE PADS, DETAILED
CLEANING OF THE ENTIRE BIKE WEEKLY P 14
CHECK EMERGENCY BRAKE FUNCTION BI-WEEKLY P 15
CLEAN AND LUBRICATE SADDLE
& HANDLEBAR SLIDERS / POSTS BI-WEEKLY P 15+16
CHECK ADJUSTMENT KNOBS MONTHLY P16
CHECK BRAKE PAD FOR SIGNS OF WEAR MONTHLY P 17
CHECK BRAKE SYSTEM, LUBRICATE MONTHLY P 17
CHECK PEDALS, TOE CLIP & STRAPS MONTHLY P17
FOR SIGNS OF WEAR
CHECK ALL CONNECTIONS AND FIXINGS MONTHLY P17
CHECK BELT DRIVE TRAIN MOTHLY P18
WEEKLY MAINTENANCE CHECKLIST
BIKE NO. PRODUCTION CODE OBSERVATIONS ACTION TAKEN RESULT NAME/DATE

19
ENG
MAINTENANCE ACTIVITY
REQUIRED SCHEDULE
BI-WEEKLY MAINTENANCE CHECKLIST
BIKE NO. PRODUCTION CODE OBSERVATIONS ACTION TAKEN RESULT NAME/DATE
MONTHLY MAINTENANCE CHECKLIST
BIKE NO. PRODUCTION CODE OBSERVATIONS ACTION TAKEN RESULT NAME/DATE

Version 1.1 2014 IC-TKIC3B-01 Copyright by Indoorcycling Group GmbH 2014 | www.indoorcycling.com
SPARE PARTS
DRIVE GEAR PARTS
BRAKE PARTS
