Aqua-Marina TURBO EP-T20 User manual

EP-T20
Electric Pump Instructions
TURBO
Please read the operation instructions
carefully before using this product.

8
10
PSI/BAR
①Deflation Port
②Inflation Port
③ Pressure Pre-setting Up (+)
④ Pressure Pre-setting Down (-)
⑤ Unit Selection (PSI/BAR)
⑥Power Switch
⑦Display Screen
⑧ Power Socket
⑨ Power Plug
⑩ Cigarette Socket Plug
⑪Hose to Pump Connection Side
⑫Hose
⑬Hose to Nozzle Connection Side
⑭Nozzles
⑮Battery Clamp
11 12 13
14
15
Save your energy for the water! Our ultra compact TURBO electric pump is easy to carry on the go to
inflate with ease.
TURBO (EP-T20) is a smart DC electric air pump that can be used for most inflatable products such as
inflatable SUP boards, kayaks, canoes, speed boats, etc. It has a smart LED display and an intelligent
pressure control system that presets a target pressure value and automatically shuts off when the
pressure reaches the preset target pressure value. The pump also provides an air deflation function to
empty the air for easy folding and storing the inflatable products after use.
2
TURBO Electric Pump EP-T20 DC12V

1. The power supply must be 12V DC power.
2. Do not block the inflation port and deflation port. Make sure the inflation port and deflation port are
unobstructed at all times.
3. Comply with local garbage disposal regulations and do not dispose of air pumps at will. When the
hose is damaged, do not operate this product, please replace the hose immediately.
4. Do not remove the hose while inflating. High air pressure may harm the body.
5. Do not keep the air pump working for more than 30 minutes.
6. Motor overheating may cause internal damage. Please fully cool for 20-30 minutes after
continuous operation for more than 30 minutes.
7. If any components are damaged, please do not use this pump. Please contact a professional for
repair.
8. This product shall not be exposed to rain or water.
9. To avoid danger, the pump outlet or hose should not be aimed at the face or the body while the
pump is working.
10. Please do not leave while inflating or deflating.
11. During the use of the product, please keep the vehicle ignition on to avoid unnecessary damage.
3
SAFETY PRECAUTION
1. To reduce the risk of injury, do not allow children to use it. Children and those who are
incapacitated are frequently monitored. Children must be kept away from the product and the cord.
2. This product is not intended for persons with physical, sensory or mental disabilities, or persons
lacking skills or mental disabilities, unless their safety is protected and supervised and directed by
a guardian.
3. To remove, maintain, repair, or adjust this product, unplug it from the socket.
4. Do not bury the wires in the soil. Keep them in a safe place where they will not be damaged by
lawn mowers or other equipment.
5. If the power cord is damaged, it must be replaced by the manufacturer or its service agent or
similar authorized personnel to avoid danger.
6. Do not unplug if you are standing in water or your hands are wet.
7. Please check the maximum atmospheric pressure of the inflatable product before inflating.
Exceeding the maximum allowable pressure can damage the airbag.
8. Please check the cigarette lighter socket before use to ensure that there is no rust or residue
inside. Poor electrical conductivity cigarette lighter socket may cause the product or power to
overheat and damage the product.
9. The purpose of using the product is limited to those described in the instructions.
WARNING

9. During inflation, the target pressure value can be increased or decreased by pressing the
pressurization button “+” or the pressure relieves button “-” ; the pressure unit switch button “PSI /
BAR” can be pressed to change the unit, but will cause the pump to cease inflation to avoid over
inflation by misoperation. Press the On / Off power switch to restart the inflation after you confirm
the target pressure.
1. Select a suitable nozzle and screw it onto the hose. (FIG1)
2. Place a suitable washer with the groove facing out. (FIG2)
3. Put the end ⑬ of the hose into the air nozzle matching the airbag, turn clockwise and tighten it,
then insert the air charging valve of the airbag, and fix it by turning clockwise. (FIG3)
4. Connect the other end ⑪ of the hose to the air pump inflation port and tighten it clockwise. (FIG4)
5. Insert the car plug into a 12V DC socket. (FIG5)
6. Press the pressure unit switch button “PSI / BAR” to select the unit you want.
7. Press the Pressurization button “+” or the pressure relieves button “-” to set the target pressure you
want, which ranges from 0 to 20PSI (1PSI=0.0689BAR=6.89KPA). (FIG6)
8. After completing the above steps, press the power switch button to start inflating. (FIG7)
INFLATION OPERATION
4
TURBO Electric Pump EP-T20 DC12V
FIG1
FIG5
FIG2
FIG6
FIG3
FIG7
FIG4

10. When the pressure reaches the pre-set value, the air pump will automatically stop working.
11. After inflating, pull the plug off from the 12V DC socket.
12. When not in use, remove the hose from the air pump and airbag and store it.
13. The pump will work in 2 stages. Stage 1 for fast air flow air pump unit for low-pressure inflation,
and when the smart pressure control system detects that the pressure of stage 1 is not
increasing, it will automatically switch to stage 2 with a high-pressure compressor until the
pressure reaches the target value.
Note: The air pump has a memory of the last pressure value used. The pressure value for the next use
will display the pressure value set last time by default.
Note: After the air pump is turned on and not running for 2 minutes, it will enter standby mode. You can
press any button to activate the system.
DEFLATION OPERATION
1. Remove the hose from the inflation port, then connect one end of the hose with the air pump
outlet and tighten it clockwise (FIG8). The other end is still connected to the airbag.
2. Press the power switch button of the air pump to start venting until all the gas is discharged, then
turn off the power and stop venting.
MAINTENANCE AND STORAGE
1. After use, or before moving, repairing, or adjusting the product, unplug it from the socket.
2. When not in use, please cool it thoroughly and put it in the box.
3. Please use it indoors and not under direct sunlight or rain.
4. Please store in a dry and ventilated place.
5
FIG8

6
Check whether the hose is
blocked or damaged in any
way.
TROUBLE SHOOTING
Fault Inspection
The Air Pump
cannot be started
normally.
The power source is not
plugged in properly.
The fuse in the DC plug is
faulty or worn out.
Overheating or overload
causes the motor to cease.
Remove any blockages from the
hose, or replace them if damaged.
Pause the inflation, check all
connections are secure, and
reinstall if necessary.
If the problem persists, please
contact the manufacturer or an
authorized technician for immediate
repair.
The connection between the
hose / Air Pump/inflation
valve is not secure.
Solution
Make sure that the power cable is in
the 12V DC socket.
Change the fuse.
Allow the motor to cool down
and restart the pump.
If the problem persists, please contact
the manufacturer or an authorized
technician for immediate repair.
Slow or abnormal
inflation.
TURBO Electric Pump EP-T20 DC12V
/
/

7
AM warrants this product to be free from major defects in material or workmanship to the original
purchaser for below specified period from the date of purchase. This warranty is subject to the
following limitations:
• This product has a limited TWELVE (12) months warranty.
1. AM will make the final warranty determination, which may require inspection and/or photos of the
equipment, which clearly show the defect(s). If necessary, this information must be sent to the
AM distributor in your country with prepaid postage. Product can be returned only if a return
authorization number is given in advance by the AM distributor. The return authorization number
must be clearly labelled on the outside of the package, or it will be refused.
2. If a product is deemed to be defective by AM, the warranty covers the repair or replacement of
the defective product only. AM will not be responsible for any costs, losses, or damages incurred
as a result of loss or misuse of this product.
3. This warranty does not cover damage caused by misuse, abuse, neglect, normal wear and tear
including, but not limited to, punctures, damage due to excessive heat exposure, damage
caused by improper handling and storage, or damage caused by anything other than defects in
material and workmanship.
4. This warranty is void if any unauthorized repair, change or modification has been made to any
part of the equipment.
5. The warranty for any repaired or replacement equipment is good from the date of the original
purchase only.
6. The original purchase receipt must accompany all warranty claims. The name of the retailer and
date of purchase must be clear and legible.
7. There are no warranties that extend beyond the warranty specified here in.
This product is designed in accordance with standards for a specific
use. Any modifications or transformations higher than that indicated by
the manufacturer could result in serious risks for the user and will void
the warranty.
WARNING
WARRANTY
