Aquaphile Eazydive Air compressor Owner's manual

AIR COMPRESSOR FOR EAZYDIVE
FEATURES AND INSTRUCTION MANUAL
Compressor
Compressor & hookah
Compressor plugged on
EAZYDIVE for inflation
65 l/mn (from
0 à 12 bars in 5
mn)
Data table of the compressor:
Device
name
Low
Max
pressure
EAZYDIVE
inflation
time
Maximum
Time of
use
Nominal
tension
Maximum
tension
Maximum
amperage
Length of
the
inflating
hose
Length of
the
electric
wire
Connection
on batteries
65
l/mn
65
l/mn
12 b
5 mn
60 mn
12 V
13,8 V
31 A
7,6 m
2,5 m
Battery
clamps
Device
name
Dimension of the
compressor in its fabric
bag L x l x h
Dimension of
the compressor
L x l x h
Weight
Thermal
security
Fuse
Overpressure
valve
Compressor
cooling
Type of
compressor
65 l/mn
35 x 25 x 22
35 x 14 x 18
6,4 kg
No
40 A
No
Wings in
aluminium
Cylinder
and piston.
Oil free.
The compressor is equipped with a pressure gauge and delivered in a fabric bag with an inflation hose, adapters for
inflating inflatable boats (tender, canoe, stand up paddle, etc) and spare fuse.
Air quality :
The compressor has an elementary air filter, only for dust,
located at the side, see picture:
The compressor being oil free, filtering oil is unnecessary.
Spare filters are provided.
To check the air filter and change it: unscrew the cartridge.
made by

The ambient air should be as pure as possible. Absolutely avoid the proximity of an engine exhaust, smoke and suspicious
odors. Preferably inflate in the open air or in a ventilated place. If the intake air is of good quality, the air contained in
EAZYDIVE will be of good quality and will easily check the standard in this matter: European Standard EN 12021.
The compressor is not lubricated with oil, so there is NO trace of oil in the air breathed.
Instructions for inflation :
Do you know how to inflate your car tires? Then you know how to inflate EAZYDIVE!
Connect the compressor clamps to the battery terminals. If your battery is normally charged, you do not need to
start the engine. Electric consumption of an EAZYDIVE inflation: 2 Ah.
Connect the compressor hose onto the compressor (quick release “push-pull”).
Connect the compressor hose onto the tire type valve at the top of the bottle.
Push on the handle and insert the pin (lower handle position: valve open).
Start the compressor (switch on).
Check the manometer (pressure gauge) during inflation.
At 12 bars, stop it. Beware not to leave it in operation once this pressure is reached.
Remove the pin (handle in the upper position: valve closed)
Remove the hose from the valve. It is normal that there is a slight leak before the valve shell is completely closed.
The inflation time (about 5 mn) is indicative, they depend on the battery charge.
If you go diving directly, don’t forget to put the pin again (valve open) for the air supply of the regulator.
Follow the EAZYDIVE instructions.
How many times can EAZYDIVE be inflated with the compressor on a boat's batteries without starting the engine ?
The compressor will consume an average of 25 Amperes during 5 minutes ie about 2 Ah.
Most medium-sized boat batteries have a capacity of 60 to 110 Ah.
You could perform a tenth or so re-inflations without worries, while keeping more than two third potential of the battery,
but everything depends on the other consumptions on board and the state of your battery.
Caution: The primary role of the battery is to start the engine and power the on-board circuits.
If you have two 12 V batteries in parallel, common case on boats, it would be good to:
Isolate one of them,
Make the EAZYDIVE refills on one of the two, the second remaining in reserve,
Reconnect both batteries after recharging.
Air supply for hookah diving:
The use is the same as for tank inflation, but clamp the hookah hose to the compressor inflation hose. Please refer to the
hookah's instructions for use.
The battery consumption for a 60 mn dive is about 25 Ah.
Maintenance :
The compressors require no maintenance. Store them in their bag, avoid shocks and sea water, in this case clean it with a
damp sponge, never with a lot of water.
Once a year, check the air filter. If necessary, flush the hose to clean it or change it.
Precaution of use :
After several consecutive refills or in hookah use, the metal parts of the compressor can be very hot. Don’t touch them
with bare hands an wait until it cool down. Grasp the compressor only by its handle.
