AR SMOOTH FLITE 16 RRS User manual

Smooth Flite 16
RRS
Version User Guide

2
Table Of Contents
Introducon ---------------------------------------------------------------------------------------------------------------------4
Important Points ---------------------------------------------------------------------------------------------------------------4
Features --------------------------------------------------------------------------------------------------------------------------5
Installaon and Mounng Instrucons ----------------------------------------------------------------------------------6
Mounng the Smart Display ------------------------------------------------------------------------------------------------7
General Usage and Screen Informaon ----------------------------------------------------------------------------------8
Main Menu ----------------------------------------------------------------------------------------------------------------------9
Input to Output Roung---------------------------------------------------------------------------------------------------- 10
Channel Monitor Screen --------------------------------------------------------------------------------------------------- 11
Sub Trim and End Point Menu -------------------------------------------------------------------------------------------- 11
15 Point Servo Matching -------------------------------------------------------------------------------------------------- 12
Fail Safe Screen -------------------------------------------------------------------------------------------------------------- 12
First Time Baery Setup------------------------------------------------------------------------------------------------13,14
Protocol Selecon ARXL Version----------------------------------------------------------------------------------------- 15
Installing the Receivers ARXL Version ---------------------------------------------------------------------------------- 16
System Specic Receiver installaon ----------------------------------------------------------------------------------- 17
Installing Satellites Spektrum Version---------------------------------------------------------------------------------- 18
Input Channel to Servo Output Roung----------------------------------------------------------------------------19,20
Servo Sub-trim, Reversing Method 1 ----------------------------------------------------------------------------------- 21
Servo Sub-trim, Reversing Method 2 ----------------------------------------------------------------------------------- 22
15 Point Matching ----------------------------------------------------------------------------------------------------------- 23
Receiver Menu---------------------------------------------------------------------------------------------------------------- 24
Seng Fail Safe--------------------------------------------------------------------------------------------------------------- 25
Telemetry with Spektrum TM1000-------------------------------------------------------------------------------------- 26
Telemetry with SBUS2 Receivers----------------------------------------------------------------------------------------- 27
Factory Reset------------------------------------------------------------------------------------------------------------------ 28
Addional Screens----------------------------------------------------------------------------------------------------------- 29
Smooth Flite Gyro Menus-------------------------------------------------------------------------------------------------- 30
Smooth Flite Gyro Setup Wizard -----------------------------------------------------------------------------------31—34
Smooth Flite Gyro Pre Flight Checks --------------------------------------------------------------------------------35,36
Smooth Flite Advanced Stabilisaon Features -------------------------------------------------------------------36,37

3
Table Of Contents connued.
Smooth Flite Advanced Stabilisaon Features (Auto Gain Control AGC) -------------------------------------- 36
(Variable Gain Control VGC) Proporonal Mode & Aerobac Mode ------------------------------------------- 37
Smooth Flite Advanced Stabilisaon Features ( Variable Gain Control VGC)--------------------------------- 37
Smooth Flite Detailed Funcons—Channel Assignment-------------------------------------------------------38,39
Smooth Flite Detailed Funcons—Aileron ------------------------------------------------------------------------40,41
Smooth Flite Detailed Funcons—Elevator ----------------------------------------------------------------------42,43
Smooth Flite Detailed Funcons—Rudder ------------------------------------------------------------------------44,45
Smooth Flite Trim------------------------------------------------------------------------------------------------------------ 46
Smooth Flite Advanced Mixing Funcons—Crow and Flaperons, Aileron Dierenal--------------------- 47
Elevon Mixing ----------------------------------------------------------------------------------------------------------------- 48
V-Tail Mixing ------------------------------------------------------------------------------------------------------------------ 49
Gyro Assisted Steer Trim, Dual Rudder Speed Brakes -------------------------------------------------------------- 50
Vectored Thrust Switching------------------------------------------------------------------------------------------------- 51
Setup Hints—Gyro controlled Rudder and ground steering ------------------------------------------------------ 52
Setup Hints—Seng up Flaps with a single TX channel ----------------------------------------------------------- 53
Setup Hints—Elevons, Thrust Vectoring and Canards setup--------------------------------------------------54,55
Frequently Asked Quesons ---------------------------------------------------------------------------------------------- 56
Smooth Flite Specicaons------------------------------------------------------------------------------------------------ 57
Channel Roung Sheet ----------------------------------------------------------------------------------------------------- 58
Usage Statement------------------------------------------------------------------------------------------------------------- 60
Warranty and Contact Informaon ------------------------------------------------------------------------------------- 61

4
Thank you for your purchase of the Advance Radio Smooth Flite System.
The Advanced Radio Smooth Flite system was designed with Giant Scale Models in mind
and combines Power Distribuon, Flite Stabilisaon and a 16 Channel Servo control
system in the lightest package in it’s class (less than 50 grams).
In the past trimming and matching servos would take place via the transmier. This old
school thought would limit you to the number of channels available from the
transmier. With Smooth Flite these funcons have been moved to the Smooth Flite
system and in doing so brings you much more funconality and exibility in model
setup. You gain at the touch of a buon as many as 16 servo outputs that can all be
mixed, matched, sub trimmed, reversed and endpoint adjusted. The power of this new
system and thought process will become obvious as you start to use the Smooth Flite
System.
To add to this we have created much more than just a simple Gyroscope based system.
We decided to include a 3 axis gyro, accelerometer, compass and barometer into the
hardware. The combinaon of these sensors gives you much more exibility in ight
stabilisaon and that is why we called it Smooth Flite!
LETS GET STARTED — in this guide we will show you how to connect your new
Smooth Flite system, General use and setup as well as how to get the most out of the
Smooth Flite stabilisaon system. Please take the me to read & understand this guide
before installaon.
TOUCH SCREEN—The touch screen display supplied with the Smooth Flite should be
protected from vibraon. We don’t recommend mounng the Smart Screen in models
with gas powered engines.
BATTERIES—Before installaon please ensure that your baeries are fully charged. The
Smooth Flite System relies on this to know how much your model has consumed from
each pack. Smooth Flite collects this informaon and displays this as a set of baery cells
indicators on the Smart Screen. NEVER FLY WITH BATTERY PACKS THAT HAVE 35% OR
LESS CAPACITY (RED ZONE ON THE BATTERY INDICATOR). Doing so may put your model
at risk.
RECEIVER INSTALLATION—Some receivers don’t oer protecon against incorrect
polarity or pin oset. IT IS IMPORTANT that you observe correct polarity and pins when
connecng the receivers to the Smooth Flite system.

5
Features:
• Built-in Baery Guard Technology. The Smooth Flite constantly monitors baery
voltage and current draw and displays this on the Smart Screen display.
• Works with single or dual baery conguraon. *Recommended with dual baery.
• Works with all major baery chemistries. LiFe. LiPo, Lion, NiMh, NiCD. Baery voltage
range can be from 6volts to 8.4volts.
• Full Dual Baery Redundancy - If one baery fails the other baery takes full control.
• Dual receiver redundancy
• Up to 16 input channels (depending on transmier capability)
• 16 fully assignable and programmable servo outputs.
• Easy-to-use pre-routed servo roung.
• Independent servo reverse on all channels.
• Sub Trim and end point (3 point) matching on all channels.
• Advanced 15 point matching on all channels
• Maximum Baery Power Balancing – Using dual baery perfect diode technology.
• Proprietary Smooth Flite System with 3 axis Gyro, Accelerometer and Barometer.
Included Items:
1 x Live feedback touch screen Smart display
1 x Smooth Flite power distribuon module.
1 x Power LED
3 x Receiver cables
Oponal Items:
Pin Flag switch with Advance Radio Flag
Remote FOB Switch with Advance Radio Flag
Magnec Switch with Advance Radio Flag
2 x Receivers

6
Installaon and Mounng Instrucons
In this secon we will explain how to mount both the Smooth Flite and the Smart Display.
The Advanced Radio Smart System gives you the choice of mounng the Smart Screen in
the Model or leaving it disconnected for normal ying. The Smooth Flite will operate in
normal ying mode without the Smart Screen Connected.
Smart Screen Mounng
If your model is a gas powered and has a high level of vibraon then we don’t
recommend mounng the screen in the model unless you provide a high level of
vibraon damping when mounng the screen.
If your model provides a low vibraon environment (Turbine, Sail Plane, Electric model)
then hard mounng of the Smart Screen is possible.
The Smooth Flite provides downlink telemetry so it is not necessary to mount the
Smart Screen in the model to view baery data.
Mounng the Smooth Flite System
The Smooth Flite is supplied with 4 rubber shock mounts in the base plate, similar to rubber
mounts on servos, these provide shock mounng for the Smooth Flite.

7
Mounng the Smart Display
To save weight the Smart Screen is not required for normal ying usage. It is only required
for programming the Smooth Flite.
Should you wish to mount the Smart Screen in the model for quick baery checks etc then
we recommend 2 opons of mounng the Smart Screen display.
NOTE: Whichever method of mounng you choose, ensure the cable that comes out of
the Smart Screen Display is not crushed in any way. Doing so will reduce the longevity of
the cables.
Opon 2. For hard mounng. The screen case has 2 eyelet holes on each edge of the screen.
If you are mounng the screen in a scale cockpit, or in a non vibraon model. (e.g. Turbine)
these holes can be used to ax the Smart Display.
Simply place the Smart Display where you wish to mount it. Holding it in place, make a dot
using a pen or pencil in each eyelet hole. Removing the screen, drill a hole where you placed
the dots.
Now simply screw the Smart Display in place.
NOTE: Hard mounng the Smart Display provides lile to NO protecon against vibraon.
Use this method if you are using a non vibraon model or ONLY where there is lile to no
vibraon. AVOID MOUNTING IN HIGH VIBRATION AREAS.
Opon 1. Using 3M Velcro adhesives, you can mount the back of the screen to a surface.
NOTE: This is a semi hard mount, and will provide a good resistance to vibraon. AVOID
MOUNTING IN HIGH VIBRATION AREAS. VIBRATION DAMAGE IS NOT COVERED UNDER
WARRANTY. Clean both the back of the Smart Screen and surface that it is being mounted
on. Place 3M dots/tape each side of the cable. Trimming as necessary.
IMPORTANT: DO NOT APPLY FORCE DIRECTLY ONTO THE SCREEN
Press on the black case around the screen to ensure it is secure.

8
General Usage and Screen Informaon
Important: The Smart Screen Display supplied with the Smooth Flite is a touch screen
display. It is used in both setup and provides feedback to the user about baery voltage and
milliamps used. The screen can be mounted in a model for quick and easy use. However the
Smooth Flite will operate during normal ying mode without the Smart Screen connected.
Main Smart Screen Display
Baery 1 (B1) and Baery 2 (B2)
Shows input voltage of both baery packs.
Servo
Shows Regulated voltage to servos
Total mA
Shows total milliamps since last charge.
Press here to enter the Main Menu
Last mA
Shows milliamps used since model was last powered up
and resets when model is turned o. Press here to reset
ight mer and Last mA.
FL-T
Flight mer since model was turned on. The mer only
operates while on the main screen.
FL-N
Flight number since reset. Gives an indicaon of number
of ights on the models airframe.
Baery Indicators
Shows the remaining capacity in the baeries from 100%
- 0%. NEVER FLY IF THE INDICATORS ARE IN THE RED.
Below is an overview of each screen on the Smooth Flite

9
Main Menu
Return
Returns back to the previous screen.
Power
Press here to go to the baery setup and reset
menu.
Monitor
Press here to go to servo programming menu.
I/O Roung
Pressing here will take you to the channel
roung screen.
Servo Match
Pressing here will take you to the 3 point and 15
point servo matching screen,
Receiver
Pressing here will take you to the receiver and
frame rate monitor screen.
System
Pressing here will take you to the system page
which contains credits and system informaon
Smooth Flite
Pressing here will take you to the Smooth Flite
page.
Power Setup Screen
Return
Takes you back to the previous screen.
RES-mA
Resets total mA used. Please ensure both packs
are FULLY charged before you reset.
RES-FLT
Resets ight counter and mer to zero. Use this
feature mostly when installing in a new airframe
or before the maiden ight.
Bat Capacity mA
Shows the capacity of the baeries you are
using. We will go through how to set this in the
First Time Setup secon on page 10.

10
Servo Matching screen
Return
Takes you back to the previous screen.
S01—S16
Pressing any of these buons will take you
to the servo matching page for the
corresponding servo output on the Smooth
Flite. Here you can match the
servos with the 3 point and 15 point
matching.
I/O Roung Screen
Save
Takes you back to the previous screen and
saves your roung choices.
- and + buons
Changes the input Channel from 1 to 16
Note: you can only assign servos to channels
that are available from your Receiver.
Example: you can not assign a servo to
channel 16 when using a 10 channel radio
S01 to S16
These buons correspond to the outputs on
the Smooth Flite RRS.
They have 3 colours,
Green = they are assigned to the current re-
ceiver channel.
Blue = they are not assigned to any receiver
channel.
Grey = they have been assigned to a dierent
receiver channel and cannot be selected for
this channel

11
Channel Monitor screen
Return
Takes you back to the previous screen.
1/2
Changes the page to higher channels.
Channel Bars
The bars show the current input channels and posion.
Note: The bars have two colours.
Blue = no servo output has been assigned.
Green = one or more servo outputs has been assigned to
this channel.
Tapping any of the green bars will take you to the inputs
to outputs screen and show corresponding assigned
input to output channel(s).
We will expand on this feature in the servo matching
Sub Trim
Return Returns you back to the previous screen.
Servo Live PWM Shows the live PWM value of the
servo output.
Sub Trim Level shis the enre range of the chosen
servo channel.
Servo Travel Are end point adjustment to increase or
reduce servo range relave to sck movement. Also used
in conjuncon to match mulple servos.
Servo ABS Limit Adjusts the absolute maximum and
minimum travel of a servo.
Sub Trim and Servo Match Menu
Return
Returns you back to the previous screen.
Servo Direcon
Reverses the selected servo direcon.
Sub Trim & Servo Match
Takes you to the Sub Trim page for the chosen Servo
15 point Servo Match
Takes you to the Mul-point match page.

12
15 Point Servo Matching
Return
Takes you back to the previous screen.
Reset
Resets the sub trim values back to default.
Vercal Bars
Shows the sub trim applied to the servo. The
sub trim values can be changed using the
DEC, INC buons. Receiver Page
Return
Takes you back to the previous screen.
Reset
Resets the receiver values back to zero.
Frames
Shows good frames received by each receivers.
Drops
Shows frames not used by the receivers.
Fails
Shows frames received by Smooth Flite with an
incorrect checksum value.
Frame Rate
Set the output frame rate of the signal to the
servos.
Fail Safe Buon
Takes the user to the fail safe set up screen.
Fail Safe Screen
Return
Takes you back to the previous screen.
Vercal Bars
Shows the fail safe values based on sck posi-
on from the radio. Fail safe is set by pressing
the corresponding blue bar.
Note: The bars have two colours.
Blue = Fail safe is set to heading hold for that
transmier channel.
Green = Fail safe is set to a specic posion
based on the radio

13
First Time Baery Setup
We are now going to go proceed with a rst me setup of the Smooth Flite .
Please ensure your baeries are fully charged before you setup the Smooth Flite.
If you need any addional help with what each buon or item does please read the
General Usage and Screen informaon page located on page 7 of this manual.
We recommend you do not have any servos connected to the Smooth Flite during the
rst me setup.
Step 1
Ensure that both baeries are plugged into
the Smooth Flite. You will also need to en-
sure the Smart display is plugged into the
switch as it is used for programming.
Upon power up, you will see the AR logo.
Aer a few seconds the Smart Screen will
be shown.
Step 2
Press the green Total mA text on the Smart
Screen, this will take you to the main menu.
Step 3
You should now see the Main Menu
Screen. Press the POWER buon on
the screen.

14
Step 4
This is the baery setup screen. Using the arrows
(DEC, INC) next to Bat Capacity mA cycle through
unl you see the correct capacity that matches
your baery packs.
Note: Step 4 is extremely important! Please en-
sure the capacity is set correctly to the baery
packs you are using.
The Smooth Flite uses this capacity value to
show the remaining baery capacity on the
main screen. If you set this value incorrectly then
the remaining capacity indicators may not show
the correct remaining baery capacity.
Important
The Smart display main Screen shows how much capacity you have le using
the baery indicators on the le and right of the baery screen It is important
that the capacity you enter is correct and accurate. If you are unsure about the
capacity of your baeries or if your packs are not new we recommend cycling
your packs by discharging them and recharging them to full. This will give you
the best possible result for the baery packs you are using.
Step 5
Once you have setup these parameters, press the RETURN buon to save and return to the main
menu. Press RETURN again to go back to the Smart Screen. You have successfully setup the
Smooth Flite Baery monitoring.

15
Before connecng receivers to the Smooth Flite RRS you will need to select the appropriate protocol to
match to your transmier system. Smooth Flite system supports the following protocols:
SBUS, SBUS2, XBUS, Je EX Bus, FRSKY, HOTT, SRXL, SRXL2
and Core in SBUS mode.
Protocol Selecon
Step 1
From the main Menu tap the “System” buon.
Step 2
From the System Page tap “Receiver Protocol”.
Step 3
Tap the appropriate buon that matches the
protocol of your transmier/receiver system.
Futaba = SBUS2
JR/DFA = X-BUS
Graupner = HOTT
JETI = JETI EX
Spektrum SRXL = AR8010T/ AR9030T receivers.
FRSKY S=Port = SBUS2 with S-Port telemetry
Spektrum SRXL2 or SRXL DX18 Mode = SPM4651T
DO NOT CONNECT 3.3V Spektrum Satellite receiv-
ers to the SF16 version of the Smooth Flite.
Core SBUS = SBUS receiver connecvity.
Mulplex SRXL = Mulplex SRXL
Aer making the selecon you will be asked to conrm.
PLEAES NOTE changing the protocol will reset the
Smooth Flite system to factory defaults erasing all input
to output roung, sub trim and Smooth Flite Gyro
sengs.

16
The Smooth Flite ARXL includes two receiver connecon cables and possible a third telemetry
cable. (For Spektrum SRXL2 receivers you will need to purchase part number BRC857), Standard
receiver cables are generally supplied preconnected to the
Smooth Flite. These can then be connected to the SBUS2, SRXL,
JR XBus, Je EX Bus, HOTT port on your receiver.
PLEASE NOTE the polarity of the receiver signal and ground on
the receiver before connecng to the Smooth Flite.
The Smooth Flite system will work with either a single or dual
receiver setup. The receivers MUST BE capable of 7.4V .
We recommend using two HV (high voltage) receivers or simi-
lar. If you are unsure please contact Advanced Radio for details.
The Smooth Flite System is designed to supply the power to all
the servos. NEVER connect servos directly to the receiver when
using the Smooth Flite System.
Note: For more informaon on how to setup and bind single or
dual receivers, please consult your transmier and receiver
manual supplied by the manufacturer.
Spektrum Receivers = Connect to SRXL/SRXL2 port .
Futaba Receivers = Connect to SBUS2 port.
JR/FDA Receivers = Connect to XBUS port.
JETI Receivers = Connect to EX BUS port.
Graupner Receivers = Connect to SUMD port.
FRSky Receivers = Connect to SBUS port.
Core Receivers = SBUS port.
Redundant Receiver Cable
Installing the Receivers ARXL Version
Please note cable posion on a 7008 receiver.
It is possible to plug into the ground pins of the
receiver and this may damage the receiver and
Smooth Flite system.
Please note cable polarity on a RG812BX

17
Please observe the correct polarity and pin placement when connecng the receivers.
Smooth Flite sends telemetry of baery voltage, current and mAh consumpon downlink to the connected re-
ceivers.
Futaba SBUS2 System.
Smooth Flite supports dual SBUS2 receivers. SBUS2 provides up to 16 channels into the Smooth Flite (depending
on transmier) routed to any of the 16 servo outputs. Connect the two supplied receiver cables to SBUS2 ports.
Please observe the correct polarity and pin placement when connecng the receivers. Telemetry is provided
from port R1. No addional translator accessory is required. Only the rst bound receiver will accept telemetry
in a Futaba system. You MUST connect this receiver to port R1 of the Smooth Flite system to receive telemetry.
Je EX-BUS System.
Smooth Flite supports all Je EX-Bus capable receivers. Je EX provides up to 16 channels (depending on trans-
mier) into the Smooth Flite routed to any of the 16 servo output channels. When using two JETI EX BUS receiv-
ers with Smooth Flite you connect receivers to Smooth Flite ports R1 and R2 and to the EXT port of each receiv-
er. Set the receivers to EX bus mode on the Je Transmier. Please observe the correct polarity and pin place-
ment when connecng the receivers. Telemetry is provided via the EX bus cable on Smooth Flite port R1.
JR/DFA X-BUS System.
Smooth Flite supports all JR/DFA receivers with XBUS-A. XBUS-A protocol supports up to 16 channels into the
Smooth Flite (depending on transmier) routed to any of the 16 servo output channels. Connect the two sup-
plied receiver cables to Smooth Flite ports R1 and R2 and then to the receiver . Please observe the correct polar-
ity and pin placement when connecng the receivers. For Telemetry connect port TEL of the Smooth Flite to
the Baery/Sense port of either receiver.
FRSKY.
Smooth Flite supports S-Port capable receivers. Up to 16 channels are available (depending on transmier) into
the Smooth Flite routed to any of the 16 servo output channels. When using two S-Port receivers with Smooth
Flite you connect receivers to Smooth Flite ports R1 and R2 and to the SBUS. Please observe the correct polarity
and pin placement when connecng the receivers. For Telemetry connect port TEL of the Smooth Flite to the S-
Port of the primary receiver.
Spektrum SRXL2 System.
The current version of Smooth Flite supports the full features of SRXL2 protocol. Smooth Flite will receive 16
channels when using SRXL2 receivers and depending on your radio TX capabilies.Telemetry is sent on all SRXL2
receiver connecons when requested by the receiver. Please use 3 x SPM4651T receivers for full range teleme-
try. The SPM4651T use a new 4 pin connector. You will require adaptor leads SKU BRC857 from AR for the
SPM4651T receivers to connect to SF16.
Spektrum SRXL System.
Connect with the supplied receiver cables one or two SRXL receivers to the SF16 ports marked R1 and R2. Con-
nects to the receiver SRXL port (please not the polarity of the port connecon on the receiver) .
Please Note: Spektrum SRXL does not support downlink telemetry from external devices. Receiver voltage is
however sent from the receiver.
System Specic Receiver Installaon

18
Graupner HOTT System.
Smooth Flite supports all receivers with HOTT protocol. HOTT receivers provide up to 16 channels (depending
and transmier) into the Smooth Flite routed to any of the 16 servo output channels. Connect receivers to
Smooth Flite ports R1 and R2 to the SUMD port of the HOTT receiver. You will need to set the receiver to SUMD.
Please observe the correct polarity and pin placement when connecng the receivers. For Telemetry connect
port TEL of the Smooth Flite to the telemetry port of either HOTT receiver.
Power Box Core
Smooth Flite supports SBUS capable Core receivers. Up to 16 channels are available (depending on transmier)
into the Smooth Flite 16 routed to any of the 16 servo output channels. Connect receivers to Smooth Flite ports
R1 and R2 and to the SBUS port on the receiver. Please observe the correct polarity and pin placement when
connecng the receivers. Baery telemetry is supplied by the receivers.
Please observe the correct polarity and pin placement when connecng the receivers.
System Specic Receiver installaon

19
Input Channel to Servo Output Roung
During this stage, we will install the receiver and servos.
Important: Check the recommended voltage range of your servos, supplying excessive
voltage to your servos may cause damage to the servos.
Before connecng any servos to the Smooth Flite we recommend reading through the
following steps. This will allow you to familiarise yourself with Smooth Flite in order to
use it to its fullest potenal.
During the setup if you have mulple servos on a control surface (Example: 2 servos on
an aileron). We recommend seng up the master servo before mechanically connecng
the slave.
Step 1
Ensure that both baeries are plugged into
the Smooth Flite. You will need to plug in
the Smart Screen as it is used for program-
ming. Ensure your receiver is plugged into
the Smooth Flite and your transmier is on
and bound to your receiver.
For more informaon see page 6.
Step 2
Press the green Total mA text on the Smart
Screen, this will take you to the main menu.
Step 3
You should now see the Main Menu
Screen. Press the MONITOR buon
on the screen. This will take you to
the receiver input channel monitor.

20
Note: The monitor gives you a visual indicaon of
the assigned input channels from your receiver.
Your new Smooth Flite RRS comes with primary
control surfaces pre-assigned to simplify your
setup.
Hint: Create a new model on your transmier with
dual aileron channels, single elevator and single
rudder channels.
If all is connected correctly, moving the transmier
scks will cause the green bars on the monitor
screen to move.
As you can see, the monitor screen is a good tool
for viewing input channel assignments.
For advance setups, we have included a blank as-
signment sheet at the end of this user guide.
The following steps will show you how you can re-
assign channels from the factory setup.
Press return from the monitor screen to return to
the main menu.
Step 4
From the main menu, tap the I/O Roung
buon. The screen (on the le) should ap-
pear. In this example, transmier input chan-
nel 1 (coloured white) routs to servo outputs
S01, S02, S03 and S04, which are coloured
green.
Lets show how easy it is to assign and de-
assign addional servo outputs to transmier
channel 1.
Tap the Blue S09 buon on the Smart Screen.
The S09 should turn green. We have now add-
ed servo output 19(S09) to transmier input
channel 1. Smooth Flite makes it that simple!
Tapping S09 a second me, will de-assign it
turning it back to blue.
Note: The servo channels are colour coded.
Green = they are assigned to the current transmier input channel.
Blue = they are not assigned to any transmier input channel and are available .
Grey = they have been assigned to a dierent transmier input channel other than the one currently
selected and cannot be selected for this channel.
Step 5
Lets now show you how to move through transmier input channels. With the Stylus, tap the Plus (+)
buon once. You should see the input channel change to 2 (coloured white), and the previously green
servo output channels will become grey (remember these servo outputs were assigned to input channel 1
so they are not available to input channel 2). Depending on the chosen protocol other servo outputs
should show as green i.e. they are assigned to input channel 2. Tapping the Plus (+) sign will move you to
higher input channels. Tapping the Minus (-) sign minus sign will move you to lower input channels and
eventually back to input channel 1.
Note: you must press the SAVE buon in order to conrm any changes to the channel roung. Pressing
save also returns you to the Main Menu.
