Arbitron 1000-1135 Series User manual

Encoding Monitor
Operations Manual


2007 Arbitron Inc
Date: June 2007
Document #: 1050-1081
Revision J
For Arbitron Encoding onitor odels:
1000-1135-xx Encoding onitor
1000-1162-xx Encoding onitor, RoHS Compliant

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 2
Table of Contents
1. CONTACTS .........................................................................................................................................
1.1. UNITED STATES .................................................................................................................................3
1.2. INTERNATIONAL.................................................................................................................................3
2. NOTICE................................................................................................................................................4
. DISCLAIMER......................................................................................................................................5
4. WARNINGS .........................................................................................................................................6
5. INTRODUCTION/OVERVIEW ........................................................................................................7
5.1. SUGGESTED PLACE ENT IN AUDIO CHAIN ........................................................................................7
6. INSTALLATION .................................................................................................................................8
6.1. INSTALLING THE ONITOR .............................................................................................................8
7. OPERATION .......................................................................................................................................9
7.1. USING THE ONITOR ......................................................................................................................9
7.2. CONNECTOR DESCRIPTIONS .............................................................................................................11
7.3. EXECUTING HYPER TER INAL ON THE PC.................................................................................14
7.4. HYPER TER INAL SETTINGS ......................................................................................................14
7.5. STATUS ESSAGE FOR ATS ............................................................................................................15
7.6. NO ENCODING ESSAGES................................................................................................................16
8. ELECTRICAL SPECIFICATIONS ................................................................................................17
8.1. ANALOG INPUT SPECIFICATIONS......................................................................................................17
8.2. ALAR (RELAY) SPECIFICATIONS ....................................................................................................17
8.3. STATUS (RS-232) SPECIFICATIONS ..................................................................................................17
8.4. POWER SPECIFICATIONS...................................................................................................................18
9. GENERAL SPECIFICATIONS .......................................................................................................19
9.1. PHYSICAL SPECIFICATIONS ..............................................................................................................19
9.2. ENVIRON ENTAL SPECIFICATIONS ..................................................................................................19
FCC DISCLAIMER ....................................................................................................................................20

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 3
1. CONTACTS
If you need assistance or have any questions, please contact or call:
1.1. U NITED S TATES
[e-mail]
• For any questions regarding this manual, please call 410.312. 123.
• For any URGENT Encoding Equipment Issues, please contact our 24/7 Encoding Issues
Hotline [phone]
Arbitron Inc.
9705 Patuxent Woods Drive
Columbia, D 21046-1572
1.2. I NTERNATIONAL
[e-mail]
Arbitron Inc.
9705 Patuxent Woods Drive
Columbia, D 21046-1572

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 4
2. NOTICE
For the 1000-11 5-xx Encoding Monitor:
The two cylindrical ferrite cores, Fair Rite part #0431164281 or its functional equivalent,
supplied as part of the package, must be installed on the two audio cables in close
proximity to the Neutrik XLR connector, close to the connection point at the rear of this
Encoding onitor. (See Figure 1)
To install these devices, simply open the core’s hinged case and fit the sectioned cores
over the cables; once the case is snapped closed, the cores will be firmly secured (see
picture on next page).
The installation of these ferrite cores is not necessary for the 1000-1162-xx Encoding
onitor, RoHS Compliant.
Figure 1: Ferrite Cores

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 5
3. DISCLAIMER
It is the responsibility of the Installer to scrupulously adhere to the above-cited
instructions; Arbitron cannot be held accountable for any infringement.
All the information contained within is copyrighted by Arbitron and may not be
reproduced, copied or distributed to any third party without written consent of Arbitron.
NOTWITHSTANDING ANYTHING CONTAINED IN THIS ANUAL OR ANY
OTHER AGREE ENT, THE SOLE AND EXCLUSIVE RE EDY, AT LAW OR IN
EQUITY, FOR ARBITRON’S AND/OR ANY THIRD PARTY’S BREACH OF ANY
WARRANTY, EXPRESS OR I PLIED, INCLUDING WITHOUT LI ITATION
ANY WARRANTY OF ERCHANTABILITY OR FITNESS, AND THE SOLE AND
EXCLUSIVE RE EDY FOR ARBITRON’S AND/OR ANY THIRD PARTY’S
LIABILITY OF ANY KIND, INCLUDING WITHOUT LI ITATION LIABILITY
FOR NEGLIGENCE OR DELAY WITH RESPECT TO THE ENCODING ONITOR,
SHALL BE LI ITED TO $100 IN THE AGGREGATE. IN NO EVENT SHALL
ARBITRON AND/OR ANY THIRD PARTY BE LIABLE FOR SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DA AGES.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 6
4. WARNINGS
To reduce the risk of personal injury, electrical shock, fire, or damage to the ONITOR,
DO NOT expose this unit to rain or moisture. Due to the danger of personal injury,
electrical shock, or damage to the instrument, ONLY Arbitron authorized service
personnel shall gain access to the inside of the ONITOR. DO NOT disconnect the
earth ground from the power cord since this is a very important safety feature. The
ONITOR should be mounted securely in a rack. The sides must be free of obstructions
to provide adequate airflow through the instrument.
The installation of the ferrite cores is of paramount importance for maintenance of
compliance to the FCC part 15 and CISPR 22 Radiated Emission Class “B” Normative.
CAUTION: FAILURE TO INSTALL THE ENCODING MONITOR IN
ACCORDANCE WITH THE SPECIFICATION IN THIS MANUAL AND/OR
FAILURE TO MAINTAIN BROADCAST SIGNALS IN ACCORDANCE WITH
GENERAL INDUSTRY STANDARDS AND SPECIFICATIONS MAY RESULT
IN THE ENCODING MONITOR NOT OPERATING PROPERLY.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 7
5. INTRODUCTION/OVERVIEW
The Arbitron Studio Grade Encoder (SGE) inserts inaudible symbols into the audio of
broadcasts according to Arbitron patented algorithms. The instrument described in this
document, the Encoding onitor ( ONITOR), is used to detect encoded audio program
material. The station engineer can use this instrument to validate that their station is
transmitting encoded program material. Arbitron strongly advises the station engineer to
use air return audio when connecting to the ONITOR, to detect cases where the SGE
has been accidentally ‘patched out’ of the audio stream.
RoHS Compliance (Restriction of Hazardous Substances) is the nickname given to the
European Union's directive 2002/95/EC on the restriction of the use of certain hazardous
substances in electrical and electronic equipment. RoHS seeks to reduce the amount of
hazardous materials entering electronic products.
The Arbitron “1000-1162-xx Encoding onitor, RoHS Compliant” is designed to meet
the requirements of the European Union's directive 2002/95/EC.
All of the other Arbitron Encoding onitors listed on the title page of this manual have
not been designed to meet the requirements of the European Union's directive
2002/95/EC.
5.1. S UGGESTED P LACEMENT IN A UDIO C HAIN
Arbitron recommends that the ONITOR be installed such that it receives program
material that has exited the transmitter or ‘over-the-air’ broadcasts. This will insure that
your media consumers are exposed to encoded program material.
The ONITOR operates optimally with a nominal average audio input level of +8 dBu.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc
6. INSTALLATION
6.1. I NSTALLING THE MONITOR
6.1.1. Place instrument into a 19” rack in an indoor environment.
6.1.2. Install securely using screws in each of the four front panel corners.
6.1.3. See Figure 2. Slide switch ‘S1’ to ‘600’ if 600 ohm input termination is desired or to
‘HI’ if a 12k ohm input bridging impedance is desired.
6.1.4. Connect the power cord to the ONITOR and to the same plug strip that supplies power
to the instruments that will be connected to the input of the ONITOR. The ONITOR
has no power switch. The ‘POWER’ indicator LED will be lit green.
6.1.5. DO NOT block or otherwise impede airflow through the sides of the instrument.
6.1.6. Connect the received program material signals into the connectors marked ‘IN’ on the
ONITOR.
If the program material is always mono and only one audio cable is used (single
channel mode), then the MONITOR can be configured for single channel operation.
In single channel mode, the channel A analog input must be used. The default
decoding mode is dual channel.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 9
Figure 2: Rear-View, onitor
7. OPERATION
7.1. U SING THE MONITOR
The station engineer has been provided several monitoring options:
If desired, they can monitor the front panel LED. When the ONITOR is receiving the
correct encoded material, the front panel LED will be a CONSTANT GREEN. When
incorrectly encoded material is presented to the audio inputs, the front panel LED will
FLASH RED (see notes below).

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 10
If the engineer cannot always visually monitor the ONITOR front panel, the engineer
can use the rear panel ALAR connection. This connection provides both a normally
open and normally closed relays which will energize when indicating a loss of encoding.
This connection can be made externally to either an audible or visual indicator, or both.
It is highly recommended that the monitor’s ALAR connection should be used in
conjunction with your station’s current Air Fault Alarm system (or similar).
Provision has also been made for connection to a remote monitor device via RS232. See
below for specification of connection to both the ALAR and RS232 connections.
Note: The MONITOR has been configured with a nominal alarm delay of approximately
3 minutes. In other words the MONITOR will not assert an alarm condition until it fails
to detect the specified code for approximately 3 minutes. At that time the alarm relay
will close (or open) the LED will turn RED and a statement will be issued via the RS232
connection. When an encoded signal is applied to the input the MONITOR will release
the alarm condition immediately. Please see below for information on the specifics of the
alarm assertion.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 11
7.2. C ONNECTOR D ESCRIPTIONS
7.2.1. Analog Input Connector Description
Input connectors on the ONITOR are female; thus, the mating XLR cable connector is
required to be male. Balanced XLR pin-out for the Arbitron ONITOR is as follows:
Pin 1- Shell or ground
Pin 2- High
Pin 3- Low

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 12
7.2.2. Alarm Connection Description
On the rear panel of the ONITOR is a DB9 male connector labeled, “ALAR
CONNECTION”. This connector provides a normally open and normally closed contact
switch to monitor the presence of encoded program material and to monitor the status of
the ONITOR itself. To allow remote monitoring of the ONITOR status, the
following connections are detailed:
CODE STATUS
Status = CODES Status = NO CODES
Pin 2 Open to pin 3 Shorted to pin 3
Pin 4 Shorted to pin 3 Open to pin 3
OPERATIONAL STATUS
Status = MONITOR
Normal
Status = MONITOR
Failure
Pin 7 Open to pin 8 Shorted to pin 8
Pin 9 Shorted to pin 8 Open to pin 8
The pins are connected to an internal relay of the ONITOR whose relay contacts are
rated at 0.3A max, 24VDC. If the front panel LED is SOLID RED and the onitor
failure alarm is asserted, then a system failure has occurred.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 13
7.2. . STATUS (RS-2 2) Description
On the rear panel of the ONITOR is a DB9 female connector labeled, “STATUS RS-
232”. This is an RS-232 serial port that is output only. To allow remote monitoring of
this ONITOR, the following connections are detailed:
a. Pin 3 – Transmit Data (TD)
b. Pin 5 – Chassis ground (Common)
To communicate with the ONITOR, the following hardware is required.
• PC (Desktop or Laptop) running Windows 95 or later software, and that has a 9 pin
‘D’ serial port. (Other computers/software configurations may work, but have not
been tested.)
• RS-232 DB-9 Cable with a Null- odem adapter
Plug one end of the RS-232 DB-9 cable with a Null- odem adapter into the ‘STATUS
PORT’ in the rear of the Encoding onitor and the other end into the CO Port of the
PC to allow remote monitoring.
On the front panel of the ONITOR is a DB9 female connector labeled “Service Port”.
THE SERVICE PORT CONNECTOR IS FOR AUTHORIZED USERS ONLY. Do
not use this port unless authorized to do so by Arbitron.
A RS-232 DB-9 Cable and a special adaptor/connector (per Arbitron drawing number
1002-0610) are required to use the features of the service port.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 14
7.3. E XECUTING HYPER TERMINAL ON THE PC
• Go to Start/Programs/Accessories/Communications/HyperTerminal to start the program.
• It will then ask for a name on the Connection Description window.
• Type “Local” for the name to begin.
7.4. HYPER TERMINAL S ETTINGS
• 8 data bits
• 1 stop bit
• no parity
• 9600 baud rate
• xon/xoff flow control
• Choose the serial port, CO 1 – CO 4, where the Encoding onitor is connected.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 15
7.5. S TATUS MESSAGE F ORMATS
7.5.1. Boot-up Messages
System boot-up starts when power is applied to the ONITOR. If the HyperTerminal is
active during system power on, as the system is booted up the rear panel ‘STATUS’
serial port sends out the following messages:
<NOTE@P[Encoding Monitor Boot Loader][Vx.xx]>
<NOTE@P[Main program checksum][Valid]> to indicate self test pass
or
<NOTE@P[Main program checksum][Invalid]> to indicate self test fail.
<NOTE@P[Encoding Monitor Main][Vx.xx]>
7.5.2. Encoding Present Messages
When the onitor has determined that a valid code is present in the program material, the
status port sends out the following messages:
<NOTE@P[000x][station_name]>
where x = 0 - 9.
A new output line is displayed every 20 seconds. (Note: This is not indicative of the
detection rate.) The number of each line ( e.g., 0001, 0002) is output to show activity on
the line, since the first portion of this message may not change.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 16
7.6. N O E NCODING M ESSAGES
If a valid code is not detected in the program material, the status port sends out the no
code message:
<NOTE@P[000x][Encoding not detected]>
where x = 0 - 9.
A new output line is displayed every 20 seconds. The number of each line ( i.e. 0001,
0002) is output to show activity on the line, since the first portion of this message may
not change.
If a code is detected in the program material, but the detected code is not one of the
identification codes programmed into the unit, the status port sends out the unknown
station message:
<NOTE@P[000x][Unknown Station]>
where x = 0 - 9.
A new output line is displayed every 20 seconds. The number of each line ( i.e. 0001,
0002) is output to show activity on the line, since the first portion of this message may
not change.

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 17
. ELECTRICAL SPECIFICATIONS
.1. A NALOG I NPUT S PECIFICATIONS
8.1.1. Input Impedance User Selectable
600Ω, balanced terminated (“600”) or
12kΩ, balanced bridging (“HI”)
8.1.2. Analog Input Level
Average inimum: 0dBu over 20Hz-20kHz
Average Nominal: +8dBu over 20Hz-20kHz
Absolute aximum: +20dBu over 20Hz-20kHz
8.1. . Common Mode Rejection Ratio
Better than –70dB @60Hz
.2. A LARM ( RELAY ) S PECIFICATIONS
8.2.1. Absolute Maximum Voltage Input
24VDC or 24VAC
8.2.2. Absolute Maximum Current Input
300 mA
.3. S TATUS (RS-232) S PECIFICATIONS
8. .1. Standard
TIA/EIA-232-F

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 1
8. .2. Minimum Output Voltage into kohm load
±5V
8. . . Baud Rate
9600
8. .4. Parity
None
8. .5. Number of Data Bits
8
8. .6. Number of Stop Bits
1
8. .7. Recommended Flow Control
XON/XOFF
.4. P OWER S PECIFICATIONS
8.4.1. Voltage
100 – 240 VAC
8.4.2. Current
1.4 Amps maximum
8.4. . Frequency
50/60Hz
8.4.4. Connector Type
IEC

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 19
9. GENERAL SPECIFICATIONS
9.1. P HYSICAL S PECIFICATIONS
9.1.1. Dimensions
48 x 16.5 x 4.5 cm (L x D x H)
9.1.2. Weight
2.7 kg
9.2. E NVIRONMENTAL S PECIFICATIONS
9.2.1. Temperature Range
Operating: 0-45 C
Storage: 0-70 C

Encoding onitor
Operations anual
Document # 1050-1081
Rev. J
 2007 Arbitron Inc 20
FCC DISCLAIMER
This equipment has been tested with the limits for a Class A digital device, pursuant to Part 15 Subpart B of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
