NEC MultiSync E1100 User manual

MultiSync E1100
User’s Manual

Declaration of the Importer
We hereby certify that the color monitor
MultiSync E1100 JC-2144UMB
are in compliance with
Council Directive 73/23/EEC:
- EN 60950
Council Directive 89/336/EEC:
- EN 55022
- EN 60555-2
- EN 60555-3
- EN 50082-1
(IEC 801-2)
(IEC 801-3)
(IEC 801-4)
and marked with
NEC Europe Ltd. Ismaning Office
Steinheilstraße 4-6
D-85737 Ismaning, Germany

Safety Instruction
Caution:
When operating the JC-2144UMB with a 220-240V AC power source
in Europe except UK, use the power cord provided with the monitor.
In UK, a BS approved power cord with moulded plug has a Black (five
Amps) fuse installed for use with this equipment. If a power cord is not
supplied with this equipment please contact your supplier.
When operating the JC-2144UMR with a 220-240V AC Power source
in Australia, use the power cord provided with the monitor.
For all other cases, use a power cord that matches the AC voltage of the
power outlet and has been approved by and complies with the safety
standard of your particular country.
IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of
International Business Machines Corporation.
Apple and Macintosh are registered trademarks of Apple Computer Inc.
Microsoft and Windows are registered trademarks of the Microsoft Corporation.
NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,
OptiClear and Advanced Digital Control System are trademarks of NEC Home Electronics,
Ltd.
MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home
Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,
Switzerland, Denmark, Finland, Norway and Saudi Arabia.
All other trademarks or registered trademarks are property of their respective owners.

English
Deutsch
Français
Italiano
Español
Appendix

English

Introduction
Congratulations on your purchase of the MultiSync E1100 colour
Monitor!
The MultiSync E1100 monitor includes Microsoft’s Plug and Play,
NEC’s ErgoDesign properties, the On Screen Manager (OSM), as well
as all the unique features you expect from MultiSync Monitors.
The MultiSync technology provides you with automatic compatibility
with multiple operating platforms and a vast array of graphics standards
allowing resolution upgrades without upgrading the monitor.
The MultiSync E1100 monitor strictly follows ErgoDesign guidelines
featuring enhanced human ergonomics (human and earth condition).
The goal of ErgoDesign is to maximise the comfort and productivity of
the end user. ErgoDesign parallels the strict European standards of
power management and reduced emissions. In addition our monitor is
designed to be recyclable.
Screen Technology
The OptiClear Surface of the E1100 CRT dramatically reduces the
reflection of ambient illumination and glare resulting in greatly
improved user comfort and productivity. This multilayered screen
coating increases the contrast without sacrificing the focus level, clarity
or brightness.
A 0.28 mm dot pitch in conjunction with the Invar Shadow Mask
increases the clarity and displays greater detail. Good clarity allows
your eyes to flow over the screen image and more easily view the
on-screen information.
The flat square CRT technology reduces image distortion and glare.
Plug and Play
Plug and Play is the new Microsoft®solution with Windows®95 to
provide automatic peripheral connections without confusing and
time-consuming setup. When used with a Plug and Play compatible system
and video card, the MultiSync E1100 monitor automatically tells the
Introduction E - 1

system its identification and capabilities. The system will then select its
highest resolution and refresh rate to take advantage of your MultiSync
monitor.
GlobalSync
The GlobalSync control of the MultiSync E1100 also minimises any
effects of the earths magnetic field on screen performance.
ErgoDesign
The MultiSync ErgoDesign features enhance human ergonomics
(human and earth conditions). MultiSync monitor’s ErgoDesign will
improve the working environment, protect the health of the user and
save money. ErgoDesign parallels the strict European standards of
power management and reduced emissions:
–automatic display power-down (also known as NUTEK
specification 803299)
–emission characteristics (stricter than those referred to as
reduced electromagnetic fields as recommended by MPR II
and, for JC-2144UMB, also by TCO)
–safety (EN 60950)
MultiSync monitors comply with these standards by offering IPM
System power management and Reduced Magnetic Field technology.
Power Manager
IPM (Intelligent Power Manager) System is an innovative power-saving
utility that complies with both the EPA’s Energy Star requirements and
Europe’s TCO NUTEK’s power management requirements. Energy Star
products use less than 30 watts when in the main power saving mode. The
NUTEK specification 803299 requires automatic power down to less than
30 watts in the suspend mode and less than 8 watts in the off mode.
When in the maximum power-down mode, the MultiSync E1100
monitor will consume less than 10% of the total power drawn under
normal operation. This innovation adds up to more than 90% energy
savings, longer monitor life, environmental protection, reduced
E - 2 Introduction

emissions and reduced air conditioning costs of the work environment.
The IPM System increases the monitor’s life and saves energy and costs
by powering down when not in use.
MultiSync monitors follow the Video Electronics Standard Association
(VESA) approved DPMS power-down signalling method. VESA’s
Display Power Management Signalling (DPMS) method, which is
endorsed by the EPA, is the power-down process a system should use to
communicate to the monitor to save power. Power-down functions can
be utilised only with an Energy Star system or video card which adheres
to the VESA DPMS standard. By using the monitor’s horizontal and
vertical SYNC signals, the monitor can be prompted into the different
IPM modes. The following is the description of the LED indicator for
the IPM power-saving modes:
Mode LED Indicator Power Saving
On Green None
Stand By Green Minimum (Quickest Recovery)
Suspend Yellow Moderate (< 15 Watts, Moderate
Recovery)
Off (IPM Mode) Orange Maximum (< 5 Watts, Slow Recovery)
Off (Power
Switch, Off) No Light No Power Used (Fully Off)
Reduced Emissions
The E1100 monitor incorporates Reduced Magnetic Field technology
designed to reduce magnetic and alternating electric field emissions and static
electricity. NEC’s monitors follow the strictest magnetic field, alternating
electric field, and electrostatic recommendations of the Swedish Board for
Technical Accreditation, or SWEDAC (previously known as MPR, National
Board for Measurement and Testing). The JC-2144UMB follows the
recommendations of the TCO which specify maximum recommended values
of electric and magnetic fields.
Introduction E - 3

Multiple Frequency Technology
Multiple Frequency Technology automatically adjusts the monitor to
the video card’s scanning frequency, displaying the resolution you
desire. The MultiSync E1100 color monitor also supports multiple
operating platforms such as PC compatible, Macintosh family and
workstation systems.
Increased refresh rates at all resolutions provide a flicker-free image.
The clearer image is easier on your eyes and extends your viewing time.
A wide range of graphics standards of PC and Macintosh computers,
including VESA standards, is supported by the MultiSync E1100 color
monitor including:
–640 x 480: 60 - 120 Hz vertical refresh
–800 x 600: 55 - 120 Hz vertical refresh
–832 x 624: 55 - 120 Hz vertical refresh
–1024 x 768: 55 - 100 Hz vertical refresh (non-interlaced, 85 Hz
recommended)*
–1152 x 870: 55 - 90 Hz vertical refresh
–1280 x 1024: 55 - 75 Hz vertical refresh (non-interlaced)**
* NEC cites recommended resolutions for optimal display performance.
** Maximum resolution based on horizontal and vertical frequencies only.
NOTE: Some system may not support all modes listed.
Horizontal and vertical FullScan capability can increase the display size
of a variety of video modes to the edges of the monitor bezel. The
FullScan capability allows you to use the entire screen area in most
resolutions, significantly expanding image size.
E - 4 Introduction

Contents of the Package
Included with your MultiSync E1100 color monitor are the following
items:
–MultiSync E1100 (JC-2144UMB/R)
–Power cord
–User’s manual
Recommended use
For optimum performance when setting up and using the MultiSync
E1100 colour monitor, please note the following:
–The optimum monitor position is away from direct sunlight.
–Place the monitor just below eye level for the ideal viewing
angle.
–Allow adequate ventilation around the monitor so that heat can
properly dissipate.
–Do not place any heavy objects on the power cord. Damage of
the cable may cause shock or fire.
Contents of the Package E - 5

–Keep the monitor away from high capacity transformers,
electric motors and other devices which may create strong
magnetic fields.
–Use the monitor in a clean, dry area.
–Handle with care when transporting.
–We recommend to adjust the brightness in a way that the
background raster disappears.
–For ergonomical reasons we recommend not to use the
position of the maximum contrast control.
–For ergonomical reasons the preset size and position is
recommended with the standard signals.
–For ergonomical reasons preset side-pincushion setting is
recommended.
–For ergonomical reasons we recommend using
non-interlaced signals with a vertical refresh rate between
75 and 120 Hz.
–For ergonomical reasons we recommend not to use the primary
colour blue on dark background ( it is difficult to recognise and
produces eye fatigue due to insufficient contrast).
–To separate the equipment from the power source you have
to remove the plug from the inlet socket.
–The power outlet socket should be installed as near to the
equipment as possible, and should be easily accessible.
–We recommend using the power cord supplied with the
monitor. However, if another type of power cord is
required, power cord H05VV-F should be used except in
U.K.
–To clean the CRT surface use a lint-free, non-abrasive cloth
and a neutral cleaner based, non-abrasive cleaning solution
or glass cleaner for best results.
E - 6 Recommended use

Quick Start
The following chart summarises the connection process for the
MultiSync E1100.
For more details please turn to the following pages if you are connecting
to an IBM compatible, Macintosh compatible or other systems.
Is the computer a Macintosh
Computer? Use the optional MultiSync Mac adapter to attach the
monitors signal cable to the
Macintosh video output.
Attach the signal cable of the moni-
tor to the video board/Mac adapter.
Connect the power cord of the
monitor to the power outlet and to
the monitor itself.
Turn monitor and computer on.
If necessary, use the OSM controls
for personal preference of the image.
Is the image correct?
Enjoy your monitor.
Problem solved?
Call your NEC-Dealer
Yes
No
Yes No
No
Yes
See the Trouble Shooting section
Quick Start E - 7

Connection to Your Personal Computer
The MultiSync E1100 color monitor complements NEC computers, PC
compatibles, Macintosh and Macintosh compatibles.
For the PC:
Your system has one of two configurations:
–the video controller is built into the computer
–the video controller is in the form of a display card (sometimes
referred to as the graphics card, video adapter or graphics board)
Both configurations have a video connector (or a CRT PORT on laptop
computers). If you are not sure which port is the video connector, please
consult your computer or display card manual.
For the Mac:
With the optional MultiSync E1100 Macintosh Cable Adapter, the
MultiSync E1100 color monitor is compatible with Macintosh
computers, as well as Macintosh clones.
NOTE: Power Macintosh 6100/60 users need to use the Apple HDI-45
cable adapter in conjunction with the appropriate MultiSync Cable
Adapter when connecting a MultiSync monitor.
The MultiSync E1100 Macintosh Cable Adapter allows you to change
between 640 x 480, 832 x 624, 1024 x 768 and 1152 x 870 screen
resolutions without restarting your system, if the video port supports
these modes. You will connect your MultiSync E1100 monitor one of
two ways to your Macintosh computer:
–On-board video port
–NuBus, PDS or PCI display card
Both configurations should have the same style video connector. If you
are not sure which port is the video connector, please consult your
computer or display card manual.
Please contact your local dealer for information about the Mac Adapter.
E - 8 Connection to Your Personal Computer

To attach the MultiSync E1100 monitor to your system, follow these
instructions:
1. Turn off the power to your computer and MultiSync monitor.
2. If necessary, install the display card. For more information,
refer to the display card manual.
3. For the PC: Connect the MultiSync E1100 monitor’s video
cable to the display card’s connector on the computer.
Tighten screws on all connectors.
For the Mac: Connect the MultiSync E1100 Macintosh
Cable Adapter to the monitor’s connector on your computer.
Connect the MultiSync E1100 monitor’s signal cable to the
other end of the cable adapter. Tighten screws on all
connectors.
4. Connect one end of the power cable to the MultiSync E1100
monitor and the other end to the power outlet.
5. Turn on your MultiSync monitor and computer.
6. This completes the installation.
NOTE: If you have any problems, please refer to the
Troubleshooting section of this manual.
Connection to Your Personal Computer E - 9

On-Screen Manager (OSM )
Now, On-Screen Manager (OSM ) Controls have made the MultiSync
monitor’s Advanced Digital Control System easier to use by providing
menus on screen. A touch of the up front controls turns on OSM,
allowing you to easily navigate through menus and adjust controls.
OSM allows you to control Brightness, Contrast, Size, Position,
Geometry and other OSM Utilities. User adjustments are saved
automatically when you change menus. Controls can be reset to factory
settings by pressing the reset button.
The enhanced Color Control System allow you to adjust the colours on
your screen and customise the color accuracy of your monitor. Through
the OSM’s enhanced Color Control System, you can better match your
image color to a variety of standards, such as:
–Your personal preference (depending upon the application
used).
–Another monitor.
–Your printer or Service Bureau output.
You can also access five industry standard color temperature settings
and customise and store up to five personal settings.
OSM buttons on the front of the monitor function as follows:
E - 10 On-Screen Manager (OSM )

Main Menu Sub-Menu
EXIT Exits the OSM Controls. Exits to the OSM main
menu.
CONTROL ▼/▲Moves the highlighted
area up/down to select
one of the controls
Moves the highlighted
area up/down to select
one of the controls.
CONTROL+/- Moves the highlighted
area left/right to select
one of the controls
Moves the bar in the +
or – direction to increase
or decrease the
adjustment.
PROCEED Has no function Only executes control or
enters sub, sub-menu
RESET Resets all the controls
within the highlighted
menu to the factory
setting
Resets the highlighted
control to the factory
setting.
NOTE: When RESET is pressed in the main and sub-menu, a warning
window will appear allowing you to cancel the reset function.
OSM Elements:
On-Screen Manager windows typically have the following elements:
Highlight: Indicates the selected menu or control in green. Inactive tab
is indicated in yellow.
Scroll Bar: Indicates direction of adjustment.
Accessing OSM: Press any of the control buttons +/-,▼/▲or the
PROCEED or EXIT button to view the current settings.
Turning off OSM:
–When in the main menu: Press the EXIT button.
–When in the sub-menu: Press the EXIT button twice.
–When in the sub, sub-menu: Press the EXIT button three times.
On-Screen Manager (OSM ) E - 11

OSM Menus
Main Menu
OSM’s main menu of control icons gives you an overview of the
selection of controls available. When OSM is activated, icons are
displayed at the top of the menu.
If an arrow button is displayed (⇒), it indicates further choices are
available.
The icons control the following:
Brightness/Contrast Control
BRIGHTNESS: Adjusts the overall image and background screen
brightness.
CONTRAST: Adjusts the image brightness in relation to the
background.
DEGAUSS: Eliminates the build-up of stray magnetic fields which
alter the correct scan of the electron beams and affect the purity of the
screen colours, focus, and convergence. When activated, your screen
image will jump and waver a bit as the screen is demagnetised.
Caution: Please allow a minimum of 20 minutes to elapse between uses
of the Degauss function.
BRIGHTNESS
CONTRAST
DEGAUSS
E - 12 OSM Menus

Size and Position
LEFT/RIGHT: Moves the image horizontally (left or right).
DOWN/UP: Moves the image vertically (up or down).
NARROW/WIDE: Increases or decreases the horizontal size of the
image.
SHORT/TALL: Increases or decreases the vertical size of the image.
Color Control
Presets 1 through 5, selects the desired color setting. The bar is replaced
by the color setting choice from 1 to 5. Each color setting is adjusted at
the factory to the stated degree Kelvin. If a setting is adjusted, the name
of the setting will change from degree Kelvin to Custom.
RED, GREEN, BLUE: Increases or decreases red, green, or blue
depending upon which is selected. The change in color will appear on
screen and the direction (increase or decrease) will be shown by the
bars.
Note on Controls in Color Control Menu:
EXIT: Exits to the main menu.
Cursor ▼/▲: Moves the highlighted area up/down to select one of the
choices.
Cursor +/-: Moves the bar in the + or – direction to increase or decrease
the adjustment or selects the color setting (1 through 5).
RESET: Resets the current highlighted color setting to the factory
setting.
The current color settings on your monitor were determined by focus
groups and end users’ panels to be the most popular settings for the
majority of applications. NEC’s Color Control system allows you to
change your on-screen colours by adjusting the monitor’s red, green and
blue color guns individually. You can adjust colours to suit your
individual needs or preferences. You can also access five industry
standard color temperature settings.
OSM Menus E - 13

Geometry Controls
The Geometry controls allow you to adjust the curvature or angle of the
sides of your display.
IN/OUT (pincushion): increases or decreases the curvature of the sides
either inward or outward.
LEFT/RIGHT (pincushion balance): increases or decreases the
curvature of the sides either to the left or right.
TILT (parallelogram): increases or decreases the tilt of the sides either
to the left or right.
ALIGN (trapezoidal): increases or decreases the bottom of the screen
to be the same as the top.
ROTATE (raster rotation): rotates the entire display clockwise or
counter clockwise.
Note on Controls in the Geometry Controls Menu:
EXIT: exits to the main menu.
Cursor ▼/▲:moves the highlighted area up/down to select one of the
choices.
Cursor +/-: moves the bar in the + or – direction to increase or decrease
the adjustment.
RESET: resets the current highlighted control to the factory setting.
Tools 1
Provides a list of optional adjustments which include the following:
LANGUAGE: OSM menus are available in 6 languages.
OSM POSITION: You can choose where you would like the OSM
image to appear on your screen. Selecting OSM location allows you to
manually adjust the OSM menu left, right, up, or down.
OSM TURN OFF: The OSM menu will stay on as long as it is in use.
In the OSM Turn Off sub-menu, you can select how long the monitor
waits after the last touch of a button to shut off the OSM menu. The
preset choices are 10, 20, 30, 60, 120 seconds.
OSM LOCKOUT: This control completely locks out access to all
OSM functions. When attempting to activate OSM while in the lockout
E - 14 OSM Menus

mode, a screen will appear indicating that OSM is locked out. To
activate the OSM Lockout function, press PROCEED, then “▲” and
hold down simultanously. To de-activate the OSM Lockout, press
PROCEED, then “▲” and hold down simultanously.
IPM OFF MODE: Using this function the OFF MODE of the IPM can
be disabled.
–ENABLE: The IPM works normally, all four stages of the
energy saving are used.
–DISABLE: The OFF MODE of the IPM is not used.
For standard computers and graphics boards you should keep the factory
setting ENABLE.
FACTORY PRESET: Selecting Factory Preset allows you to reset all
OSM settings back to the factory settings. A warning statement will
appear to confirm that you do want to reset ALL settings. Individual
settings can be reset by highlighting the control to be reset and pressing
the RESET button.
Tools 2
Provides a list of optional adjustments which include the following:
MOIRE CANCELER: Moiré can be visible if large areas of dithered
colour are displayed (overall colour made from alternating pixels of
different colours). The Moiré Canceller allows you to minimize this
phenomenon, using the +/- CONTROL buttons.
LINEARITY: The Linearity selection allows you to adjust the spacing
of the areas on the screen. The purpose of this control is to ensure that a
2 cm circle is a true 2 cm circle wherever it is drawn on the screen. The
best way to determine the vertical linearity is as follows:
–Draw equally spaced horizontal lines using a drawing
application that has a ruler.
–Use the Vertical control to adjust the spacing between the lines
near the centre of your screen.
–Use the Vertical Ballance control to adjust the lines near the top
and bottom of your screen.
OSM Menus E - 15
