Arbor Technology GT-500 User manual

I
2016.09
GT-500
5” Rugged Android™ Handheld
Device with LTE solution
User's Manual
Version 1.0

- II -
This page is intentionally left blank.

- i -
Revision History
Version Release Time Description
1.0 2016.09 Initial release

- ii -
Preface
Contents
Copyright
Copyright © 2016 ARBOR Technology Corp. All Rights Reserved.
This document contains proprietary information protected by copyright. No
part of this manual may be reproduced by any mechanical, electronic, or other
means in any form without prior written permission of the manufacturer.
Disclaimer
The information in this document is subject to change without prior notice in
order to improve the reliability, design and function. It does not represent a
commitment on the part of the manufacturer.
Under no circumstances will the manufacturer be liable for any direct, indirect,
special, incidental, or consequential damages arising from the use or inability
to use the product or documentation, even if advised of the possibility of such
damages.
About This Manual
This user’s manual provides the general information and installation
instructions for the product. The manual is meant for the experienced users
and integrators with hardware knowledge of personal computers. If you are not
sure about any description in this manual, consult your vendor before further
handling.
We recommend that you keep one copy of this manual for the quick reference
for any necessary maintenance in the future. Thank you for choosing ARBOR
products.

- iii -
Contents
Revision History ............................................................................................i
Contents........................................................................................................ii
Preface...........................................................................................................v
Declaration of Conformity.....................................................................................v
CE ................................................................................................................v
FCC Class B ................................................................................................v
RoHS...........................................................................................................vi
SVHC / REACH...........................................................................................vi
Symbols Description .......................................................................................... vii
Important Safety Instructions ............................................................................. vii
Rechargeable Battery Pack Safety .....................................................................ix
General Cleaning Tips..........................................................................................x
Cleaning Tools.............................................................................................xi
Recommended Cleaning Procedures .........................................................xi
Disposing of the Equipment ............................................................................... xii
Additional Information & Technical Support ....................................................... xii
Warranty............................................................................................................ xiii
Chapter 1. Introduction................................................................................1
1.1. Product Highlights.........................................................................................2
1.2 Package Contents..........................................................................................2
1.3 Parts of the Device.........................................................................................4
1.4 Dimensions ....................................................................................................5
1.5 Specications.................................................................................................6
Chapter 2. Getting Started...........................................................................9
2.1 Installing microSD and SIM Card.................................................................10
2.2 Charging the Battery ....................................................................................13
2.2.1 Charging the Battery .........................................................................13
2.2.2 Checking the Battery Level ...............................................................13
2.3 Installing/Replacing the Battery....................................................................15
2.4 Optimizing Battery Life.................................................................................17
Chapter 3. Using the Rugged Handheld Deivce ......................................19
3.1 Using Touch Screen .....................................................................................20
3.1.1 Basic Operations...............................................................................20
3.1.2 Text Input...........................................................................................21
3.1.3 Sleep Mode.......................................................................................21
3.2 Home Screen ...............................................................................................22

- iv -
Contents
3.2.1 Extending Home Screen ...................................................................24
3.3 Using Cellular Network.................................................................................25
3.3.1 Making/Receiving Calls.....................................................................25
3.3.2 Conguring Your SIM Cards..............................................................26
3.4 Using the Wi-Fi Feature ...............................................................................26
3.4.1 Enabling Wi-Fi and Connecting to a WLAN ......................................27
3.4.2 Adding a Wi-Fi Network.....................................................................28
3.4.3 Connecting to a Wi-Fi Network by WPS ..........................................29
3.4.4 Forgetting/Modifying a Wi-Fi Network...............................................30
3.4.5 Making Your Device a Wi-Fi Hotspot.................................................31
3.5 Using the Bluetooth Feature ........................................................................32
3.5.1 Enabling Bluetooth and Pairing with Bluetooth Device .....................32
3.5.2 Conguring Bluetooth Features to Use.............................................34
3.5.3 Disconnect from a Bluetooth Device.................................................34
3.5.4 Conguring Your Bluetooth Device ...................................................34
3.6 Using the Location Feature..........................................................................35
3.6.1 Enabling/Disabling Location Service.................................................35
3.6.2 Location Mode...................................................................................36
3.7 Using the Camera ........................................................................................37
3.8 Using the NFC Feature ................................................................................39
3.8.1 Enabling/Disabling NFC ...................................................................39
3.8.2 Conguring NFC Modes....................................................................39
3.8.3 Exchanging Data with NFC-Enabled Device.....................................40
3.8.4 Using Tap & Pay................................................................................41
3.9 Using the Barcode Scanner .........................................................................42
3.9.1 Using the BarcodeScanWizard (Optional) ........................................42
3.9.2 Supported Barcode Formats.............................................................43

- v -
Preface
Declaration of Conformity
CE
The CE symbol on your product indicates that it is in compliance with the
directives of the Union European (EU). A Certicate of Compliance is available
by contacting Technical Support.
This product has passed the CE test for environmental specications when
shielded cables are used for external wiring. We recommend the use of
shielded cables. This kind of cable is available from ARBOR. Please contact
your local supplier for ordering information.
FCC Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference
that may cause undesired operation.
Any changes or modications not expressly approved by the guarantee of this
device could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
Preface

- vi -
Preface
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
RoHS
ARBOR Technology Corp. certies that all components in its products are
in compliance and conform to the European Union’s Restriction of Use
of Hazardous Substances in Electrical and Electronic Equipment (RoHS)
Directive 2002/95/EC.
The above mentioned directive was published on 2/13/2003. The main purpose
of the directive is to prohibit the use of lead, mercury, cadmium, hexavalent
chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl
ethers (PBDE) in electrical and electronic products. Member states of the EU
are to enforce by 7/1/2006.
ARBOR Technology Corp. hereby states that the listed products do not contain
unintentional additions of lead, mercury, hex chrome, PBB or PBDB that
exceed a maximum concentration value of 0.1% by weight or for cadmium
exceed 0.01% by weight, per homogenous material. Homogenous material
is dened as a substance or mixture of substances with uniform composition
(such as solders, resins, plating, etc.). Lead-free solder is used for all
terminations (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)).
SVHC / REACH
To minimize the environmental impact and take more responsibility to the
earth we live, ARBOR hereby conrms all products comply with the restriction
of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH
--Registration, Evaluation, Authorization, and Restriction of Chemicals)
regulated by the European Union.
All substances listed in SVHC < 0.1 % by weight (1000 ppm)

- vii -
Preface
Symbols Description
This symbol of “CAUTION” indicates that there is a danger of
injury to the user or a risk of damage to the product, should
warning notices be disregarded.
Battery Recycle
This symbol indicates electrical warning.
Important Safety Instructions
Read these safety instructions carefully:
1. Read all cautions and warnings on the equipment.
2. Place this equipment on a reliable surface when installing. Dropping it or
letting it fall may cause damage
3. Make sure the correct voltage is connected to the equipment.
4. For pluggable equipment, the socket outlet should be near the equipment
and should be easily accessible.
5. Keep this equipment away from humidity.
6. Disconnect this equipment from the A/C outlet before cleaning it. Use a
moist cloth. Do not use liquid or sprayed detergent for cleaning.
7. To fully disengage the power to the unit, please disconnect the power from
the AC outlet.
8. Do not scratch or rub the screen with a hard object.
9. Never use any of the solvents, such as Thinner Spray-type cleaner, Wax,
Benzene, Abrasive cleaner, Acid or Alkaline solvent, on the display. Harsh
chemicals may cause damage to the cabinet and the touch sensor.
10. Remove dirt with a lightly moistened cloth and a mild solvent detergent.
Then wipe the cabinet with a soft dry cloth.
11. The openings on the enclosure are for air convection and protect the
equipment from overheating. DO NOT COVER THE OPENINGS.

- viii -
Preface
12. Position the power cord so that people cannot step on it. Do not place
anything over the power cord.
13. If the equipment will not be used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
14. Never pour any liquid into openings. This may cause re or electrical
shock.
15. Never open the equipment. For safety reasons, the equipment should be
opened only by qualied service personnel.
16. If one of the following situations arises, get the equipment checked by
service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to work
according to the user’s manual.
e. The equipment has been dropped or damaged.
f. The equipment has obvious signs of breakage.
17. The sound pressure level at the operator’s position, according to IEC 704-
1:1982, is no more than 70dB(A).
18. Keep this User’s Manual for later reference.
19. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW
-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE
EQUIPMENT.
Do not use the power adapter that isn’t made for the equipment.
Supplying the equipment with inappropriate voltage may cause harm
to the battery or, even worse, burn the equipment.
To prevent possible hearing damage, do not listen at high volume
levels for long periods
