Arboria Seat and Back User manual

3” screw (12)
Arbor Seat and Back
PLEASE READ COMPLETELY BEFORE BEGINNING ASSEMBLY
ASSEMBLY INSTRUCTIONS
SEAT AND BACK INSTALLED IN ARBOR
TOOLS YOU WILL NEED
• Philips screwdriver (electric driver recommended)
• Small hammer
• Tape measure
• Pencil
• Four 2” nails
STEP 2
SEAT AND BACK TO ARBOR ASSEMBLY
• Determine the height you prefer for the bench seat, usually from 16” to 18” above
ground.
• Deduct 4 3/4” from the height and mark that height on each “leg” of the arbor, this
will locate the bottom of the seat support.
• Drive nails in each of the arbor posts at the marked places.
• Rest the seat on the projecting nails, line it up front and back with the arbor posts.
• Hold the seat firmly to the arbor post and drive 3” screws into all four posts.
• Position back 4” above seat, use books or blocks to support the back and
steady in place
• Position outer edge of back blocks flush with the arbor post.
• Secure the back to arbor using 3” screws.
STEP 3
1 5/8” screw (6)
HARDWARE
CHECK BOX FOR THESE CONTENTS
Made in USA 2003
• Seat assembly
• Back rails (total 3)
• Back mounting block (total 2)
• Screws (total 18)
STEP 1
• Line up the outer rails to the edge of the back block with the narrow
end pointing upward.
• Secure the outer back rails using the 1 5/8” screws. Center the middle
rail and secure using 1 5/8” screws.
BACK ASSEMBLY
Block narrow end Back rails
4 3/4”
4”
LWO Corporation, 3841 N. Columbia Blvd., Portland, OR 97217 [phone] [phone] www.arboria.com
