ArcVision ARC-1493DR User manual

USER MANUAL
HI-RES. OSD CAMERA

Contents
1. SAFETY PRECAUTIONS.................................................................................. 2
2. INTRODUCTION............................................................................................... 3
3. FEATURES ......................................................................................................... 4
4. PACKAGE LIST ................................................................................................. 5
5. NAME and FUNCTION of EACH PART .......................................................... 6
6. INSTALLATION................................................................................................. 8
6.1 Native Keyboard Installation................................................................... 9
6.2 PELCO Keyboard (or compatible) Installation....................................... 9
7. OPERATION..................................................................................................... 10
7.1 Operating Procedure.............................................................................. 10
7.2 Native Keyboard Operation................................................................... 10
7.3 PELCO Keyboard (or compatible) Operation....................................... 11
8. SYSTEM SETUP .............................................................................................. 12
8.1 OSD (On Screen Display) Main Menu Description................................... 12
8.2 Sub Menu Description........................................................................... 13
9. CAMERA CONTROL PROTOCOL ................................................................ 19
10. SPECIFICATION ............................................................................................ 22
The author assumes no responsibility for any errors or omissions that may appear in this
document nor does the author make a commitment to update the information herein.
1
VER.: 1.0, P/N: 040117/2

1. SAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN!
CAUTION :
TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT OPEN COVERS (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
It is advised to read the Safety Precaution Guide through carefully before operating the
product, to prevent any possible danger.
WARNING: Alert the user to the presence of un-insulated “dangerous voltage”.
CAUTION: Alert the user the presence of important operating and maintenance
(Servicing) instructions in the literature accompanying the appliance.
Please be extra careful not to shake the product.
Please avoid places where frequent vibrations or shocks.
Do not install the product in extreme temperature conditions.
Only use the camera under conditions where temperatures are between -10℃and +50℃.
Be especially careful to provide ventilation when operating under high temperatures.
Do not install the product in an environment where the humidity is high.
Unless the product is waterproof or weatherproof, otherwise it can cause the image quality
to be poor.
Never keep the product to direct strong light or sunlight.
It can damage the product.
Do not spill liquid of any kind on the product.
If it gets wet, wipe it dry immediately. Alcohol or beverage can contain minerals that
corrode the electronic components.
When any abnormal occurs, make sure to unplug the unit, and contact your local dealer.
2

2. INTRODUCTION
This digital image camera uses a high sensitive color 1/3” interline transfer Charge
Coupled Device (CCD) image sensor, featuring approx.: NTSC = 380,000/ PAL = 440,000
effective pixels, producing pictures reaching 550 TVL of horizontal resolution.
Built-in ICR module provides excellent low lux effect. Remote control is available via
RS-485/ RS-422 or RS-232 (optional) interface.
3

3. FEATURES
 High sensitivity, low smear, high anti-blooming, and high S/N ratio.
 Mechanic IR cut-filter driving unit with AE/ Illumination Detector (sensor),
provides change from color to B&W mode automatically for day and night
24-hour surveillance.
 OSD (On Screen Display) Setup Menu.
 Camera tile setup of up to 16 alphanumeric letters.
 Privacy image masking with free position.
 Camera control via either RS-422/RS485 or RS232 interface.
 Supports PELCO (D and P) Protocol/ NATIVE Protocol/ LG Protocol.
 Supports AES (Automatic Electronic Shutter), AI ( Auto Iris), GC (Gain
Control), WB (White Balance), and BLC (Back Light Compensation).
 Provides flickerless mode, color rolling suppression, and line-lock function.
 The camera accepts 2 types of auto iris lenses Video type (Video-Drive) and DC
type (DC-Drive).
 Performance: Positive/ negative image, mirror function (left/ right).
 Under low lux environment camera with Hi-Res.+ Ex-view function has better
ability to work in low-light conditions (more sensitive to light) than camera
with Hi-Res. function.
4

4. PACKAGE LIST
Check and make sure all the items shown below are included in your product package.
If something is missing, contact your dealer as soon as possible.
No. Item Picture Quantity
1 Camera
1
2 Manual
1
3
Auto Iris Lens Plug
Mounting Block
Fixed Screws
L-Wrench
1
5

5. NAME and FUNCTION of EACH PART
Side View
Front View
Rear View
6

1. Video Output: Composite Video 1Vp-p, 75 Ohms, BNC.
Function
2. Key Control:
No. Name
1 SUp (S)
2 T(T)Down
3 (+)/►Increase Value (＋)
4 (-)/◄Decrease Value (－)
5 Menu Enter or Exit Setup Menu
3. rotocol / NATIVE/ PELCO
e Function
P : AUTO / LG
4. Baud Rates: 2.4K/ 4.8K/ 9.6K/ 19.2K BPS
RS-232:
No. Nam
1 RX RS-232 Interface RX
2 GND GND
3 TX RS-232 Interface TX
4 GND GND
S-485/ RS-422:
e Function
R
No. Nam
1 R+ RS-485/RS-422 Interface R+
2 R- RS-485/RS-422 Interface R-
3 T+ RS-485/RS-422 Interface T+
4 T- RS-485/RS-422 Interface T-
7

6. INSTALLATION
1
2
3
RD
TD
GND
1
2
3
4
5
6
7
8
9
1 Frame GND
2 RD
3 TD
4 DTR
5 Signal GND
6 DSR
7 RTS
8 CTS
9 RI
Camera
RS-232 Interface
RS-232C D-Sub Connector
4
GND
Figure 6-1
1
2
3
4
R+
T-
T+
R-
R+
R-
T+
T-
Camera
RS-422 Interface 232 to 422 Converter
RD
TD
To PC or
Controller
Figure 6-2
1
2
3
4
R+
T-
T+
R-
D+
D-
Camera
RS-485 Interface 232 to 485 Converter
RD
TD
To PC or
Controller
D-
D+
Figure 6-3
8

6.1 Native Keyboard Installation
 RS-485 interface is used for communicating native keyboard. Refer to Figure
 only be adjusted
tion Setting
6-3; connect R+ and T+ of the camera together; connect R+ and T+ of the
camera to D+ of the native keyboard. Connect R- and T- of the camera together;
connect R- and T- of the camera to D- of the native keyboard.
User may adjust Camera ID, Protocol, Speed and Parity should
via rear panel keys.
Communica
CAMERA ID 1 - 127
PROTOCOL AUT VEO/ NATI
SPEED 9600
PARITY NONE
The speed of native keyboard is fixed (9600), and the adjusted function is only effective,
.2 PELCO Keyboard (or compatible) Installation
gure
 r panel keys or via remote commands.
after exiting the OSD setup menu.
6
 RS-422 interface is used for communicating PELCO keyboard. Refer to Fi
6-2; connect R+ of the camera to T+ of the PELCO keyboard. Connect R- of the
camera to T- of the PELCO keyboard.
User may adjust Camera ID via rea
Protocol, Speed and Parity should only be adjusted via rear panel keys.
Communication Setting
0 - 25 tocol3 for P pro
CAMERA ID 1 - 255 for D protocol
PROTOCOL AUTO/ PELCO
SPEED 2400/ 4800/ 9600/ 19200
PARITY NONE
The speed of c ould be the same as the speed of the keyboard, and the
NOTE: Maximum cable distance for RS-422/ RS-485 communication over 24-gauge
amera sh
adjusted function is only effective, after exiting the OSD setup menu.
wire is 4,000 feet (1,219 m). Recommend using shielded twisted pair cable that meets
the basic requirements for EIA RS-422 / RS-485 applications.
9

7. OPERATION
7.1 Operating Procedure
1. Mount the camera on the mounting bracket, secure the camera (find the hole on the top
or bottom of the camera) to the bracket with the supplied mounting block and 2 screws.
2. Connect the video output to the monitor or other video device via a 75 Ohms type
coaxial cable.
3. Power Input Terminal (Dual Power): the camera accepts both AC 24V and DC 12 V
power sources (non-polarity).
7.2 Native Keyboard Operation
Normal Display Mode
Native Keyboard Camera Function
BRIGHTNESS+ Brightness +
BRIGHTNESS- Brightness -
Zoom TELE None
Zoom WIDE None
NEAR None
FAR None
Move Joystick Left None
Move Joystick Right None
Move Joystick Up None
Move Joystick Down None
MENU key Accessing OSD Main Menu
OSD Setup Menu Mode
Native Keyboard Camera Function
eDecrease (-)
fIncrease (+)
cCursor Up
dCursor Down
BRIGHTNESS+ None
BRIGHTNESS- None
Zoom TELE None
Zoom WIDE None
NEAR None
FAR None
Please refer to the native keyboard manual for more information.
10

7.3 PELCO Keyboard (or compatible) Operation
Normal Display Mode
PELCO Keyboard Camera Function
OPEN Brightness +
CLOSE Brightness -
Twist Joystick clockwise or Zoom In None
Twist Joystick counterclockwise or Zoom Out None
NEAR None
FAR None
Move Joystick Left None
Move Joystick Right None
Move Joystick Up None
Move Joystick Down None
Enter 95; Hold the PRESET key (approximately five
seconds) until the main menu appears on the screen. Accessing OSD Main Menu
OSD Setup Menu Mode
PELCO Keyboard Camera Function
OPEN Sub Menu Enter
CLOSE Sub Menu Exit
NEAR Cursor Up
FAR Cursor Down
Move Joystick Left Decrease (-)
Move Joystick Right Increase (+)
Move Joystick Up Cursor Up
Move Joystick Down Cursor Down
Twist Joystick clockwise or Zoom In None
Twist Joystick counterclockwise or Zoom Out None
Please refer to PELCO Keyboard (or compatible) manual for more information.
11

8. SYSTEM SETUP
8.1 OSD (On Screen Display) Main Menu Description
Main Menu Display
MAIN MENU VER.xxxx
EXPOSURE
BLC
DAY/NIGHT
WHITE BALANCE
PRIVACY MASK
EFFECT
DISPLAY
COMMUNICATION
DEFAULT
EXIT
st
st
st
st
st
st
st
st
ON
st
Main Menu Setup
 In order to display the setup menu on the screen, set the menu command or press the
button panel.
 Use S/ Tcontrol buttons to select each item.
 Use ◄(－)/ ►(＋) control buttons to change the data.
 Use MENU control button to ENTER/ EXIT the menu display.
12

8.2 Sub Menu Description
Exposure Setup
EXPOSURE
LENS TYPE
BRIGHTNESS
AGC MODE
AGC MAX
AGC ADJ
FLICKERLESS
SHUTTER SPD
DEFAULT
RETURN
DC/ VIDEO
30
AUTO
100
NA
OFF
NORMAL
ON
st
Note:
1. Lens type can be switched to DC/ VIDEO or MANUAL. When the system is set to
DC/ VIDEO, please put the switch (situated on the back of the camera) in “DC” or
“VIDEO” position respectively according to the type of the lens used (Different lens
types used will influence the image brightness, please adjust according to actual
condition.).
2. Brightness setup range: 0~36.
3. AGC MODE: AUTO/ MANUAL selectable.
(1) AGC MAX: Set AGC MODE to AUTO (AGC MAX setup range = 0~255).
When AGC MAX < 100 is setup, AE function of Day/ Night Mode
becomes an ineffective function (data value “---” for D/N Mode will
be shown on the display).
Set to MANUAL, AGC MAX becomes an NA (Not Available)
item.
(2) AGC ADJ: Set AGC MODE to AUTO, AGC ADJ becomes an NA (Not
Available) item.
(3) AGC MODE: Set to MANUAL, AGC ADJ can be set to fixed GAIN value
(0~255).
4. SHUTTER SPD mode (NTSC: 1/100 and PAL: 1/120) is fixed, when
FLICKERLESS mode is set to “ON”.
5. Nine types of SHUTTER SPD Mode: AUTO, NORMAL (NTSC: 1/60 and PAL: 1/50),
1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, and 1/100000.
6. AGC MODE auto switches to manual, when SHUTTER SPD is set to 1/250,
1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/100000 or FLICKERLESS (set to
“ON”).
7. DEFAULT: Return to the factory-default configuration.
8. RETURN: Return to previous page.
13

BLC Setup:
BLC
BLC MODE
BLC LEVEL
BLC AREA
DEFAULT
RETURN
OFF
15
CENTER
ON
st
Note:
1. BLC MODE: BLC MODE can be set to “ON/ OFF”.
2. BLC LEVEL (1~15): The higher the value, the higher the backlight compensation
level.
3. Seven Types of BLC AREA Mode:
(1) CENTER (2) TOPS (3) TOPL (4) BOTTOMS (5) BOTTOML (6) LEFT (7) RIGHT
(1)CENTER (2)TOPS (3)TOPL
(4)BOTTOMS (5)BOTTOML (6)LEFT
(7)RIGHT
14

DAY/ NIGHT Setup:
DAY/ NIGHT
D/N MODE
DAY→NIGHT
NIGHT→DAY
SENSOR LEVEL
FILTER DELAY
DEFAULT
RETURN
AE VALUE
SENSOR VALUE
AE
50
200
NA
NA
ON
st
???
???
Note:
1. D/N MODE: Four types of setup (AE*/ SENSOR/ DAY/ NIGHT).
(1) AE: Setup according to DAY→NIGHT and NIGHT→DAY (threshold value),
auto switches to Color or B/ W. When AGC MAX < 100 is setup, AE function of
Day/ Night Mode becomes an ineffective function (data value “---” for D/N Mode
will be shown on the display).
(2) SENSOR: Auto switches to Color or B/ W according to SENSOR LEVEL
and FILTER DELAY setup.
(3) DAY: Fixed to Color mode.
(4) NIGHT: Fixed to B/ W mode.
2. DAY→NIGHT: The threshold value of color change (from color to B/ W) under
AE mode. Switches to B/W when “Day→Night” ≧“AE Value”.
3. NIGHT→DAY: The threshold value of color change (from B/ W to color) under
AE mode. Switches to Color when “Night→Day” ≦“AE Value”.
4. SENSOR LEVEL
(1) Higher the value: When the environment illumination is insufficient the process of
switching to B/ W will be delayed.
(2) Lower the value: When the environment illumination is insufficient advanced
switching process from Color to B/ W will quickened.
5. FILTER DELAY: The delay time of the system switching from color to B&W mode
when environment illumination change occurs (Filter Delay Time: 0~15 Sec.).
6. When D/N MODE is set to “AE/ DAY/ NIGHT” mode, SENSOR LEVEL and
FILTER DELAY become an NA (Not Available) item.
7. AE VALUE: When D/ N is set to AE, it will reflect the illumination degree of the current scene.
8. SENSOR VALUE: When D/ N is set to SENSOR, it will reflect the illumination
degree of the current scene.
9. The table shown below are reference values, please setup according to the current scene.
CCD Type Lens Type Shutter Speed BLC DAY→NIGHT NIGHT→DAY
EX-View DC Drive Video Drive
Manual IRIS On / Off 50 200
DC drive On / Off 50 200
Video drive On / Off 50 150
Non EX-View Manual drive
Normal
On / Off 50 180
On 20 100
EX-View
Non EX-View Manual IRIS Auto Off 20 110
15

WHITE BALANCE Setup:
WHITE BALANCE
WB MODE
RED GAIN
BLUE GAIN
PUSH AUTO
DEFAULT
RETURN
AUTO
NA
NA
NA
ON
st
Note:
1. Five Types of WB MODE: AUTO, INDOOR, OUTDOOR, MANUAL, and PUSH
AUTO.
2. RED GAIN/ BLUE GAIN operates only when WB MODE is set to MANUAL, otherwise
it is an NA (Not Available) item.
3. When WB MODE is set to PUSH AUTO:
 PUSH AUTO ON: Enable auto tracing white balance.
 PUSH AUTO OFF: Disable auto tracing white balance.
PRIVACY MASK Setup:
PRIVACY MASK
AREA
MASK
START X
END X
START Y
END Y
DEFAULT
RETURN
1
OFF
50
100
30
40
ON
st
Note:
1. AREA: PRIVACY MASK (Maximum 8 mask area setups).
2. MASK: Select “ON/ OFF” to enable or disable mask area.
3. START X: Horizontal start position (2~225).
4. END X: Horizontal end position (2~225).
5. START Y: Vertical start position (0~225).
6. END Y: Vertical end position (0~225).
16

EFFECT Setup:
EFFECT
SHARPNESS
POSI/NEGA
MIRROR
SYNC
V PHASE
DEFAULT
RETURN
10
POSI
OFF
INT
NA
ON
st
Note:
1. SHARPNESS: Video sharpness level setup (0 ~15).
2. POSI/ NEGA: Images can be set to POSI (Positive Image ) or NEGA (Negative
Image).
3. Two Types of MIRROR Mode: OFF/ ON (HORIZONTAL).
4. SYNC: When using a DC 12V adaptor, the sync setting is set to internal sync.
5. V PHASE: When L/L mode is selected, you can adjust the desired phase (0 ~ 358),
otherwise it is an NA (Not Available) item.
17

DISPLAY Setup:
DISPLAY
TITLE
TITLE DISP
TITLE POS
ID DISP
ID POS
DEFAULT
RETURN
████████
ON
LEFT DOWN
ON
RIGHT DOWN
ON
st
Note:
1. TITLE :You can enter up to 16 characters.
2. TITLE/ ID DISP: Set to ON to display or OFF not to display.
3. TITLE/ ID POS (Four ID Setup Positions):
RIGHT DOWN/ LEFT UP/ RIGHT UP/ LEFT DOWN.
COMMUNICATION Setup:
COMMUNICATION
CAMERA ID
PROTOCOL
SPEED
PARITY
RETURN
1
AUTO
9600
NONE
st
Note:
1. Please refer to “6. INSTALLATION” for more information on Communication.
18

9. CAMERA CONTROL PROTOCOL
Native Protocol Format
Interface Type: RS485
Version: 1.02
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Command
Packet Receiver ID Transmitter
ID OP Code Data 0 Data 1 Check Sum
Definitions: (in Hexadecimal)
Keyboard ID: XX
Camera ID: YY
Check Sum: ZZ (Byte1 xor Byte2 xor Byte3 xor Byte4 xor Byte5).
Note: “xor” means Exclusive OR.
Event Keyboard Send Camera Response Remarks
Linking
step1.01 XX 00 00 00 ZZ
step2.02 XX 00 00 00 ZZ
step3.03 XX 00 00 00 ZZ
…
…
step128.80 XX 00 00 00 ZZ
XX YY 00 00 00 ZZ
The camera will
respond at once
after keyboard sent
correct device ID.
Button
NUM+”ENTER”
or “CH+” or “CH-”
step1.YY XX 4A 00 00 ZZ
step3.YY XX 01 00 00 ZZ
step2.XX YY 4A 00 ## ZZ
step4.XX YY 01 && $$ ZZ
“##”: Device Type
“$$”: Device State
Button “BRIGHTNESS +” step1.YY XX 23 02 00 ZZ
step3.YY XX 23 05 00 ZZ
step2.XX YY 23 02 00 ZZ
step4.XX YY 23 05 00 ZZ
Button “BRIGHTNESS –” step1.YY XX 23 03 00 ZZ
step3.YY XX 23 05 00 ZZ
step2.XX YY 23 03 00 ZZ
step4.XX YY 23 05 00 ZZ
Button “ZOOM TELE” step1.YY XX 24 01 00 ZZ
step3.YY XX 24 04 00 ZZ
step2.XX YY 24 01 00 ZZ
step4.XX YY 24 04 00 ZZ
Button “ZOOM WIDE” step1.YY XX 24 00 00 ZZ
step3.YY XX 24 04 00 ZZ
step2.XX YY 24 00 00 ZZ
step4.XX YY 24 04 00 ZZ
Button “MENU” for call
OSD
step1.YY XX 10 00 00 ZZ
step3.YY XX 28 04 00 ZZ
step5.YY XX 28 FF 00 ZZ
step1.YY XX 10 00 00 ZZ
step3.YY XX 28 04 00 ZZ
step5.YY XX 28 FF 00 ZZ
OSD MODE
OSD MODE Button “►” step1.YY XX 28 03 00 ZZ
step3.YY XX 28 FF 00 ZZ
step2.XX YY 28 03 00 ZZ
step4.XX YY 28 FF 00 ZZ OSD MODE
OSD MODE Button “◄” step1.YY XX 28 02 00 ZZ
step3.YY XX 28 FF 00 ZZ
step2.XX YY 28 02 00 ZZ
step4.XX YY 28 FF 00 ZZ OSD MODE
OSD MODE Button “▲” step1.YY XX 28 00 00 ZZ
step3.YY XX 28 FF 00 ZZ
step2.XX YY 28 00 00 ZZ
step4.XX YY 28 FF 00 ZZ OSD MODE
OSD MODE Button “▼” step1.YY XX 28 01 00 ZZ
step3.YY XX 28 FF 00 ZZ
step2.XX YY 28 01 00 ZZ
step4.XX YY 28 FF 00 ZZ OSD MODE
OSD MODE Button
“ENTER”
step1.YY XX 10 00 00 ZZ
step3.YY XX 28 06 00 ZZ
step2.XX YY 10 20 03 ZZ
step4.XX YY 28 06 ** ZZ
“**”: 11 OSD off
00 OSD on
OSD MODE Button
“ESC”
step1.YY XX 10 00 00 ZZ
step3.YY XX 28 05 00 ZZ
step2.XX YY 10 20 03 ZZ
step4.XX YY 28 05 ** ZZ
“**”: 11 OSD off
00 OSD on
19
