Ardo DWI10L6 User manual

DWI)10L6 (GB

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
(On models with water softener system only.)
Electric indicator on control panel (if provided).
If there is no salt warning light in the control panel
(for some models), you can estimate when to fill the salt into
the softener by the number of cycles the dishwasher has run.
Check the regeneration
salt level
Load the baskets
Select a programme
Turnonthewatertap,closethedoor.Themachinewillstartworkingafterabout10seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes(about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will alsodry better.Unload the appliance, starting from the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme Button until the selected programme lights up.
( See the section entitled Operationg instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the On/Off Button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hotsteammay escape
when thedooris opened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Open the door,press the On/Off button to switch on the appliance .
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding content onthe instruction manual.
1. Arunning cycle can only be modified ifit has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the for more than 3 seconds to cancel the running programme.
3. Select a new programme.
4. Restart the dishwasher.
Programme Button

To review the section on troubleshooting Tips
will help you to solve some common problems
by yourself .
Dear Customer,
Please carefully read thismanualbefore usingthe
dishwasher,it will help you touseand maintain the
dishwasher properly.
Pass it on toanysubsequent owner ofthe appliance.
Thismanual contains sections on safety Instructions,
Operating Instructions, InstallationInstructions and
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
developmentandupdating of the product, may
make modifications without giving prior notice.
Keep it as arefer in the later days.
If you can not solvethe problems by yourself ,
please ask for the help of professional technicians.
This appliance is intended tobe used in household
andsimilarapplications suchas:
-staff kitchen areas in shops,offices and other
working environments;
-farm houses;
-byclients inhotels, motels and otherresidential
type environments;
-bed and breakfast type environments.
DishwasherFeatures.................................... ...3
A WaterSoftener...........................................4、
Attention before or after loading the Dishwasher
Baskets..........................................................9
Filtering System.............................................13
Caring for the Dishwasher..................... .........14.
B Loading the Salt into the Softener.................5、
C Fill the Rinse Aid Dispenser.........................5、
D Function of Detergent .................................6 、
Loadingthe upper ...............................10Basket
Loading the Lower ...............................10Basket
Wash CycleTable...........................................11
Turning on theAppliance................................11
Change the Programme.............. ................12....
At the Ene of the Wash Cycle...........................12
Before callingfor service........................... .....22.
Errorcodes.................................... ..............23.
Technical information.............................. .....24..
ControlPanel...................................................3
.................................. 15Installationpreparation ...16Aesthetic panel's dimensions and installation
..............18Tensionadjustment of the door spring
.............................. 18Connectionof drain hoses ......................... 19Dishwasher installation steps
About Electricity Connecting...........................20
ColdWater Connection.................................. 21
Hot ............. 21Water Connection.....................

1
This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of anelectric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren
Donotabuse,siton,orstandonthedoorordish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not place any heavy objects the
door when it is open. The appliance could tip
forward.
on or stand on
When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2 Warning: Knives and other utensils with
sharp points must be loadedin the basket
with their pointsdown or placed in a
horizontal position.
)
When using your dishwasher, youshould
prevent plastic items from coming into contact
with the heating element.(This instruction is only
applicable to machines with a visual heating
element.)
Ifthesupplycordis damaged, it must bereplaced
bythemanufactureroritsserviceagentora
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremelydangerous if swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent comparment isempty
after completion of thewash cycle.
The appliance is to be connected to the water
mains using new hose sets and that old hose-sets
should not be reused.
The maximum number of place settings to be
washed is10.
The maximum permissible inlet water pressure is
1MPa.
The minimum permissible inlet water pressure is
0.04MPa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
The door should not be left open,
since this could increasethe riskof tripping.
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.

2
Dispose of the dishwasher packaging material correctly.
All packaging materialscanbe recycled.
Plastic parts aremarked with thestandard international abbreviations:
PE for polyethylene, e.g. sheet wrapping material
PS for polystyrene,e.g.padding material
POM polyoxymethylene, e.g. plastic clips
PP polypropylene, e.g. Salt filler
ABS Acrylonitrile Butadiene Styrene, e.g.Control Panel .
Packaging material couldbe dangerous for children!
Fordisposing ofpackage and theappliance please goto arecycling centre. Thereforecut
off the powersupplycable and makethe doorclosingdevice unusable.
Cardboard packaging is manufactured from recycled paper and shouldbe disposed in the
waste paper collection for recycling.
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused
by inappropriatewaste handling of this product.
Formoredetailed informationabout recyclingof this product, please contact your local
city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such
waste separately for special treatment is necessary.






Back ViewFront view
3
beforeusing it forthe first time.
To getthe best performance from your dishwasher, read all operating instructions
11 12
1
2
3
4
5
7
8
910
Lower basket
Salt container
Dispenser
Cupshelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Upperbasket
Cutlery rack
Top spray arm
1
Innerpipe
5
6
7
8
9
10
12
11
3
24
6
1.On/Off Button:To turnon/off the power supply.
2.ProgramButton : To Press the buttonto select a
wash Program.
5.Delay indicators: to show the delay time
7.Delay Button:ToPress the button to delay;
4.Programindicators: to show whichprogram
you have chose;
3.Power indicator:To show when thepoweron.
6.Saltandrinseaidwarning lights:Toshow
when the salt containeror dispenser need to be
refilled
1h
1177 2233445566

The water softener must be set manually, using the water hardness dial.
The water softeneris designed to remove mineralsandsalts from the water, which would have
a detrimentalor adverse effect on the operation of the appliance.
The higher the content of these minerals and salts,the harder your water is.
The softener should be adjusted accordingto the hardness ofthe water in your area. Your local WaterAuthority
can advise you onthehardnessofthewaterinyourarea.
Adjusting Salt Consumption
The dishwasher isdesigned toallow for adjustment in the amount of salt consumed based onthe hardness of
thewater used.This is intended tooptimise and customisethelevelo f salt consumption.
1. Open the door ,Switch on the appliance;
2. Press the Program button formore than 5seconds to start the water softener
set model within 60seconds after theappliance was switched on(The Salt and
Rinse aid warninglights will be on periodically when it get in the set model );
3. Press the Program button to select the proper set according toyour local environment,
the sets will change in the following sequence: H1->H2->H3->H4->H5->H6;
4. Press the Powerbutton to end the set up model.
WATER SOFTENER
Thehardness ofthe watervariesfrom place to place.If hardwater is used inthedishwasher, deposits will
form on the dishesand utensils.
The appliance is equipped with a special softener that uses a salt container specifically designed to eliminate
lime and minerals from the water.
Contact your local water board for information on the hardnessof your water supply.
dH mmol/l
0~90~5 0~0.94 H1(Rapid ) 0/
10-20
6-11 1.0-2.0 H2(1Hour) 20 60
21-30
12-17 2.1-3.0
H3(1Hour Rapid)、
30 50
H4(Glass) 40
40
fH
0~6
7-14
15-21
Clarke
WATER HARDNESS
Selector Position Salt consumption
(gram/cycle) Auto nomy
(cycles/1kgs)
Please followthe steps belowforadjustment insaltconsumption.
18-22 31-40 22-28 3.1-4.0
4
If your model does not have any water softener, you mayskip this section.
Clark:British degree
fH: French degree
DH: German degree
dH=1.25Clarke=1.78fH=0.178mmol/l
1
41-60
23-34 4.1-6.0 H5(Glass Rapid)、50 30
H6(Glass 1Hour)、60 20
29-42
35-55 61-98 43-69 6.1-9.8
The manufactory setting: H4 (EN 50242)
Before using your dishwasherfor the first time:
A. Set the water softener
B. Add 1.5Kgdishwasher salt and then full fill the salt container with water
C. Filltherinseaiddispenser
D. Fill in detergent

1. The salt container must only be refilled when the salt warning light in the control panel comes on.
Depending on how well thesalt dissolves, thesalt warninglight maystill be on even though the
salt container is filled.
If there is no salt warning light in the control panel (forsome Models),you can estimate when to fill
the salt into the softener by the cycles that the dishwasherhas run.
2. If thereare spills ofthe salt,a soakor a rapid program should be runto removethe excessive salt.
Always use the salt intended for use with dishwasher.
The salt container is located beneath the lower basket and should be filled as explained
inthe following:
Attention!
Only use salt specifically designed for the use indishwashers! Every other type of
salt not specifically designed for the use in adishwasher, especially table salt, will
damage thewater softener. In case of damages caused by the use of unsuitable
salt the manufacturerdoes not give anywarranty nor is liable for any damagescaused.
Only fill withsalt just before starting one of thecomplete washingprograms.
This will prevent any grains of salt or salty water, which may have been spilled,
remaining on the bottomofthe machinefor any period oftime, which maycause
corrosion.
5
The rinse aid isreleasedduring the final rinse to prevent water from forming droplets onyour dishes, which can
leave spots and streaks. It also improvesdryingby allowing watertoroll offthe dishes. Your dishwasher is
designed touse liquid rinseaids.The rinseaid dispenser islocated inside thedoor next to the detergentdispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume ofthe rinseaidcontaineris about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during thelastrinse, ensuring thorough rinsing, and spotandstreakfree drying.
Attention!
Only use branded rinse aid for dishwasher. Neverfill therinse aid dispenser withanyother substances
(e.g. Dishwasher cleaning agent, liquid detergent).This would damage the appliance.
Full fill the salt container with water,It is normal for a small amount of water to come out of the
saltcontainer.
AAfter the lower basket has been removed, unscrew and remove the cap from the salt container.
BPlace the end ofthefunnel (supplied)into the hole and introduce about 1.5kg of dishwasher salt.
C
DAfter filling the container , screw the cap tightly back clockwise.
EThe saltwarning light will stopbeing after thesaltcontainer hasbeenfilled withsalt.
FImmediately afterfilling the salt into the salt container, a washing program should be started
program Otherwise the filter system, pumpor other important parts of the machine maybe damaged
bysalty water.This is out of warranty.
(Wesuggest to use a short
).

6
To open the dispenser,turn the cap to the "open" (left) arrow and lift it out.
Pourthe rinse aid intothe dispenser, being careful not tooverfill.
Replace the cap by inserting italigned with "open" arrow and turningit to the closed (right) arrow.
Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings.Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amountof rinse
aid dispensedby removing the dispenser lidand rotating the dial to "5". If the
dishes still are not drying properly or are show spots, adjustthe dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory valueis "4".)
Increasethedose if thereare drops of waterorlimespots onthe dishes after washing.
Reduce itif there are sticky whitish stains on your dishes ora bluish film on glassware or
knife blades.
1
2
3
As the rinse aid diminishes, the size of the black dot
onthe rinse aid level indicator changes, as illustratedbelow.
Full
3/4full
1/2full
1/4 full - Should refillto eliminate spotting
Empty
When to Refill the RinseAid Dispenser
Ifthereis no rinse-aid warning lightin thecontrolpanel, you can estimate the amount from thecolour
of the optical level indicator C located next to the cap. Whentherinse-aidcontainer is full, the whole
indicator will be dark .As the rinse-aid diminishes, thesize of the dark dot decreases. You should never let
the rinse aid level fall 1 / 4 full.
during the nextwash. Don'tforget toreplacethe cap before you closedishwasherdoor.
Clean up any rinse aid spilled while during fillingwith an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients arenecessary to remove dirt, crushdirt and transport it outof the dishwasher.
Mostof thecommercialquality detergents are suitableforthispurpose.
""
Proper Use ofDetergent
Useonly detergent specificallymade for the use in dishwashers. Keep your detergent fresh and dry.
Don't putpowdered detergentinto the dispenser untilyou're ready to wash dishes.
Attention!

7
Amount of DetergenttoUse
Dishwasher detergent is corrosive! Take care to keepit out of reach of children.
Based ontheir chemicalcomposition, detergents can besplit in two basic types:
Detergent tabletsofdifferent brandsdissolve at different speeds. For this reasonsome
detergenttablets cannot dissolve and develop theirfullcleaningpower during short
programs. Therefore please use long programs when usingdetergent tablets, to
ensure the complete removal of detergent residuals.
The dispenser mustberefilled before the start of each washcycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinseaid than
Conventional dishwasher.Generally, only one tablespoon of detergent is neededfor
anormal wash load. More heavily soileditems need more detergent.Alwaysaddthe
detergentjust before starting the dishwasher, otherwiseit couldgetdamp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
DetergentDispenser
conventional, alkaline detergents with caustic components
low alkalineconcentrated detergents with natural enzymes
Normally new pulverised detergent is without phosphate.Thus the watersoftenerfunction of
phosphate is not given. In this case we recommend to fill salt in the salt containereven when
the hardness of water is only 6 dH. If detergents without phosphate are used in the case of hard water
often white spots appear on dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine do only bleach a little. Strongand coloured spots will not
be removed completely. Inthiscase pleasechoosea program with a higher temperature.
°
Detergents
Thereare 3 sorts of detergents
1.Withphosphate and withchlorine
2.With phosphate andwithout chlorine
3.Withoutphosphate and without chlorine
Always add the detergent just before starting each wash cycle.
Only use branded detergentaidfor dishwasher.
If the lid isclosed: press release button. The lid will spring open.
Detergent tablet
Detergent powder

Fill the detergent dispenser with detergent.
The marking indicates the dosing levels , as
illustrated on the right:
Theplace of main wash cycle detergent placed.
Theplace of pre-wash cycle detergent placed.
Please observe the manufacturers dosing and storage
Recommendations asstatedonthedetergent packaging.
Close thelid and press untilit locks in place.
If the dishes are heavily soiled, place anadditional
detergent dose in the pre-wash detergent chamber. This detergent will take effectduring the pre-washphase.
A
B
Fill in Detergent
You find information about the amount ofdetergent for thesingle programme on the last page.
Pleaseaware, that according tothe levelsoiling and the specific hardnessof waterdifferencesare possible.
Pleaseobserve themanufacturer's recommendations onthe detergentpackaging.
8

Cutlery with wooden,horn china or
mother-of-pearl handles
Plasticitems that arenotheat resistant
Older cutlerywith glued partsthatarenot
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made fromsynthetic fibres
Some types of glassescan become
dull aftera large number of washes
Silver and aluminum parts have a
tendency to discolourduring washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are oflimited suitability
Dishes and itemsofcutlery mustnotlie insideoneanother, orcover each other.
To avoiddamage to glasses,theymust not touch.
Load large itemswhich are most difficult to clean intothe lower basket.
The upper basket is designed to holdmoredelicate and lighterdishware such as glasses, coffee
andtea cups
Long bladed knives stored in an uprightposition are a potential hazard!
Long and/or sharp itemsof cutlery such as carving knives must be positioned
horizontallyin the upperbasket.
Please do not overload your dishwasher. This is important forgood results and for
reasonable consumption of energy.
Load hollow items such as cups,glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deepbase.
Consider buying utensilswhich are identifiedasdishwasher-proof.
Usea mild detergentthatisdescribedas 'kind to dishes'. Ifnecessary, seek further
information from the detergent manufacturers.
Forparticular items, select aprogramwithaslow atemperature aspossible.
To prevent damage, do not take glassandcutlery out of the dishwasher immediately
after the programmehas ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlerybasketsmay vary from your model.)
Scrape off any largeamounts ofleftover food.Soften remnants ofburnt food in pans.
It is not necessary to rinse the dishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tipover.
4.All utensils are placed in the way thatthe spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.
9

10
Theupper basket is designed to holdmore delicate
and lighter dishware such as glasses, coffee and
teacups and saucers, aswell asplates,small bowls
andshallowpans (as long astheyarenot toodirty).
Position thedishes andcookware sothatthey will
notgetmoved bythespray of water.
We suggest that you place large items and the most
difficultto cleanitemsare tobe placedintothelower
basket: suchaspots, pans, lids, serving dishes and
bowls, as shown in the figure below. It is preferable to
place serving dishes and lids on the side of the racks
in order to avoid blocking the rotation of the top spray
arm.
Pots,servingbowls,etc,mustalwaysbeplacedtopdown.
Deep pots should be slanted to allow water to flow out.
Please bereminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
Folding Spikes of Lower Basket
Forbetter stacking of pots and pans,
the spikescan be folded down as
show in the picture right.
Adjusting the Upper Basket
The heightof the upperbasketcan be adjusted in order to
create morespace for largeutensilsbothfor the upper
/lowerbasket. The height of the upper basket can be
adjusted byplacingthewheels on differentheight of the
rails. Long items, serving cutlery, salad servers and knives
shouldbeplacedontheshelfsothat theydonotobstruct
therotationofthesprayarms..
Folding back the cup shelives
For better stacking of pots andpans,
the spikes can be folded down as
show in the picture right.
Cutlery should be placedin the cutlery basket withthe handlesat the bottom. If therackhas side baskets, the
spoons should be loaded separately into the appropriate slots, especially long utensilsshould be placed in the
horizontal position at the front of the upper basket as shown in the picture.
Do not let any item extend through the bottom.
Always loadsharp utensils with the sharp point down!

*EN 50242 : Thisprogramme is the test cycle. The information for comparability test
in accordance with EN 50242,as follows:
Capacity: 10 setting
PositionUpper basket: upper wheels onrails
Rinse aid setting: 6
Pl:0.55w; Po:0.45w.
Starting a cycle wash
Draw out the lower and upper basket, load the dishes and push them back.
Itis commended to load the lower basket first, then the upper one (see the sectionentitled
Loadingthe Dishwasher ).
Pour in the detergent (see the sectionentitled Salt, Detergent and RinseAid ).
Insertthe pluginto the socket.The power supply is 220-240 VAC /50 HZ, the specification
of thesocket is 10A 250VAC. Make sure that the water supply is turned on to full pressure.
Openthe door, press the ON/OFF Button, andthe ON/OFF light will turn on.
Press the program Button , thewash program will be changed asfollows direction:
If a program isselected, the response lightwill light.Then close the door,the dishwasher
begins to start.
“”
“”
Intensive->Normal->Eco->Glass->1Hour ;->Rapid
1
2
3
4
5
Means: need to fill rinse into the Rinse-Aid Dispenser.
()
11
Eco.
Intensive
Normal
(*EN 50242)
(or )3in1
3/22g
Rapid
Pre-wash(50 )
Pre-wash
Wash (65 )
Rinse
Rinse(55 )
Drying
℃
℃
℃
Pre-wash(45 )
Wash (50 )
Rinse
Rinse(60 )
Drying
℃
℃
℃
Wash (50 )
Drying
Pre-wash
Rinse(60 )
℃
℃
Wash (40 )
Rinse
Rinse(45 )
℃
℃
155
165
130
40
1.04
0.83
1.2
0.45
16.8
13.7
9
10
1Hour
Wash(60 )
Rinse (60 )
Drying
Pre-wash(50 )℃
℃
℃
60 9.6
0.87
3/22g
20g
Glass
25g
Rinse
Drying
Pre-wash
wash(40 )
Rinse(60 )
℃
℃
110 0.72
13.7
For normally soiled loads,
such as , plates,glasses
and lightly soiled pans.
pots
For heaviest soiled crockery,
and normally soiled pots
pans dishes etc with dried
on soiling.
、
、
Standard daily cycle for
normally soiled loads, such
as pots plates glasses.、、
For lightly soiled loads that
do not need excellent drying
efficiency.
A shorter wash for lightly
soiled loads and quick wash.
For lightly soiled crockery
and glass
(or )3in1
3/22g
(or )3in1
3/22g
1h

When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button, shut off thewater supply and open the door of thedishwasher.
Wait for afew minutes before unloading thedishwasherto avoidhandlingthe dishes and utensils while they
are still hot and more susceptible to breakage. Theywillalsodry better.
Switch Off the Dishwasher
The program light is on but is not blinking, only in this case the programmehas ended.
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turnoff thewatertap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore beallowed to cool down around 15 minutes
before removing from the appliance.
Open thedishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler andthe drying will be improved.
Unloadingthe dishwasher
It is normal that the dishwasher is wet inside.
Empty thelower basket first and then the upper one.This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
If you open the door , the machine will pause. The program lightwill
stop blinking and the buzzer will mooing every minute unless you close the door .After
you close the door ,the machine will keepon workingafter 10 seconds.
during awash cycle
Premise:
Acycle that is underway can only be modified if it has only been running for a short time. Otherwise, the
detergent may have alreadybeen released, and the appliancemay have already drained the wash water.
If this is the case, the detergent dispenser must be refilled (see the section entitled "Loading the
Detergent " ).
Openthe door ,press the Programbutton , themachine will be in standbystate,
then youcan change the program to the desired cycle setting (see the section entitled " Starting a
wash cycle. . ." ).
more than 3 seconds
1
2
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little .
14
5
The dishwasher will run after 10 seconds.
Wash thearms in soapy and warm water and use a soft brush to
cleanthejets. Replace them afterrinsing them thoroughly.
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
It is dangerousto open the door when washing, because the hot water may scald you.
12

The filter preventslarger remnantsof food or other objects from getting insidethepum.
Theresidues may blockthe filter, in this case they mustbe removed.
The filter system consists of a coarse filter,a flat (Mainfilter)
And a microfilter(Fine filter).
Food and soil particles trapped in thisfilter arepulverizedbya
special jet on the lower spray arm andwasheddown todrain.
Larger items, such as pieces of bonesor glass, that could block
the drainaretrappedin the coarse filter. To remove theitems
caught by the filter, gently squeeze the tap onthetop of this
filterandliftout.
Thisfilter holds soil and food residues in the sump areaand
prevents itfrom beingredepositon the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filterassembly
Thefilter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it isa goodidea to
remove thelarger food particles trapped in the filteraftereach washcycleby rinsing the semicircular filterand
cup under running water. To remove the filter device,pull the cup handle in the upwarddirection.
removes food particles fromthewash water, allowing it to be recycledduring the cycle.
For
The dishwasher must never beused without the filters.
Improper replacementof the filter may reduce the performancelevelofthe appliance
and damage dishesand utensils.
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
13
1
2
Step 1 Turn the filter in anti-clockwisedirection,：
Step 2 lift the filter assy up：

The control panel can be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use agood appliance polish wax.
Never usesharp objects, scouring pads orharsh cleaners on any part of the dishwasher.
ProtectAgainst Freezing
1.Cut off the electrical power to thedishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottomof the tub and use a spongeto soak up water in the sump.
please take frost protection measuresonthe dishwasher in winter. Every fter washingcycles,
please operate as follows time a
：
Cleaning the Filter
CleaningThe Door
To clean the coarsefilter and the fine filter, use a cleaning brush.Reassemble the filter parts as shown in the figures
on thelast page and reinsert the entire assembly in the dishwasher, positioning it in itsseat and pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted andtheperformance ofthe dishwashercouldbe decreased.
To clean theedge around the door,you should use only a soft warm, damp cloth.
To avoid penetrationof waterinto thedoor lock and electrical components,do not
use a spray cleaner of any kind.
Never use a spray cleaner toclean the door panel as it may damage the door lock
and electrical components.
Abrasive agentsor some paper towels should not be used because of the riskof
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly for hard
water chemicalswillclogthesprayarmjetsandbearings.
- Inspect the filtersfor blocking after every timethe dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Removeanyfoodremnants and
cleanthefilters underrunningwater.
Remarks:
The entire filter assembly shouldbe cleaned once a week.
Toremovethelower sprayarm,pull out the spray arm upward.
To remove the upper sprayarm, hold the nut, rotate the arm
clockwise toremoveit.
Wash the arms in soapy andwarm water and use a soft brush to
clean thejets. Replace them after rinsingthem thoroughly.
14

Itis recommend thatyourun awashcycle with the
dishwasher empty andthenremove the plugfrom the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealsto lastlongerandpreventodours fromforming
withinthe appliance.
If the appliance must be moved, tryto keep it in the
verticalposition. Ifabsolutelynecessary,itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food that remainstrappedin the seals.
Periodic cleaning with adamp sponge will preventthis
from occurring.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasive cleaning products.
Only use acloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened withwater ana little
vinegar, ora cleaning product madespecificallyfor
dishwashers.
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
After every wash, turn off the water supply to the
appliance and leave the doorslightly open so that
moisture and odours arenot trapped inside.
After EveryWash
When not in Use for aLongTime
15
Theinstallation of the pipes
and electrical equipments
shouldbedonebyprofessionals.
Electrical Shock Hazard
Disconnect electricalpower before
installingdishwasher.
Failuretodosocanresultindeathor
electrical shock.
The installation position of dishwasher should be near the existing inlet and drain hoses and
powercord.
One side of thecabinetsinkshould be chosen tofacilitatetheconnection of drain hoses of
thedishwasher.
Installation preparation
Note: please check the accompanying installation accessories(hook for aesthetic panel,screw)
●

Please carefully read the installation instruction.
Illustrationsofcabinet dimensionsandinstallation position of thedishwasher
Preparations should bemade before moving the dishwasher to the installationplace.
Choose a placenear the sink to facilitate the installation ofinlet and drain hoses
(see figure1).
If dishwasher is installed atthe cornerof thecabinet, thereshouldbe somespace
(illustratedin figure2) whenthedoor is opened.
2
1
Minimumspace when
the door is opened
【】Figure2
Cabinet dimensions
【】Figure1
Cabinet
Dishwasher
Door of
dishwasher
Minimum space of 50mm
1 The aesthetic wooden panel could beprocessed according tothe Figure 3.
The aesthetic panel should
be processed in accordance
with the illustrateddimensions
【】Figure3
●Aesthetic panel's dimensions and installation
Less than 5mm
between the top
of dishwasher and
cabinetand the
outer door aligned
tocabinet.
90 °
90 °
450 mm
820mm
100
580mm
80
Space between cabinet
bottom and floor
Electrical, drain and
water supply line
entrances
(Unit: mm)
16
dp8
449
416 0.2±
390 0.2±
287.5 0.2±
286
38 8- 2
dp8
4- 2
dp8
2- 2
20 MAX（）
5
