User Manual
User Manual
BPC-3022
Fanless Embedded Box PC
with Intel Celeron N2930 Processor
and Multiple Video Outputs
Version : v1.0
Released date : 2014.11.27

User Manual
Copyright
The documentation and the software included with this product are copyrighted 2014
by Arestech Co., Ltd. All rights are reserved. Arestech Co., Ltd. reserves the right to
make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted in
any form or by any means without the prior written permission of Arestech Co., Ltd.
Information provided in this manual is intended to be accurate and reliable. However,
Arestech Co., Ltd. assumes no responsibility for its use, nor for any infringements of
the rights of third parties, which may result from its use.
Acknowledgements
Intel and Pentium are trademarks of Intel Corporation.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Product Warranty
Arestech warrants to you, the original purchaser, that each of its products will be free
from defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by
persons other than repair personnel authorized by Arestech, or which have been
subject to misuse, abuse, accident or improper installation. Arestech assumes no
liability under the terms of this warranty as a consequence of such events. Because of
Arestech’s high quality-control standards and rigorous testing, most of our customers
never need to use our repair service. If an Arestech product is defective, it will be
repaired or replaced at no charge during the warranty period. For outof- warranty
repairs, you will be billed according to the cost of replacement materials, service time
and freight. Please consult your dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU
speed, Arestech products used, other hardware and software used, etc.) Note
anything abnormal and list any onscreen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA (return merchandize

User Manual
authorization) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a fully-completed Repair and Replacement
Order Card and a photocopy proof of purchase date (such as your sales receipt)
in a shippable container. A product returned without proof of the purchase date is
not eligible for warranty service.
5. Write the RMA number visibly on the outside of the package and ship it prepaid
to your dealer.

User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth.
Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the
equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it
fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be opened
only by qualified service personnel.
If one of the following situations arises, get the equipment checked by service
personnel:
The power cord or plug is damaged.
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to
the user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
14. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE
THESTORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE
60° C(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT

User Manual
SHOULD BE IN A CONTROLLED ENVIRONMENT.
15. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive
electronic components.

User Manual
Contents
Chapter 1: General Introduction.................................................................................1
1.1 Overview..............................................................................................1
1.2 Key Features................................................................................................3
1.3 Hardware Specification...............................................................3
1.4 I/O Arrangement...........................................................................5
1.5 Mechanical Dimensions.................................................................................10
Chapter 2: System Setup .............................................................12
2.1 Installation Procedure....................................................................12
2.2 Installing Change 2.5" HDD/SSD..............................................................13
2.3 Installing Memory / mSATA SSD/ PCIe Module OSD Function.................15
2.4 Installing Mounting Bracket...........................................................................16
Chapter 3: BIOS Setting................................................................17
3.1 Main Menu...........................................................................17
3.2 Advanced Menu..........................................................................18
3.3 Chipset Menu...........................................................................28
3.4 Security Menu.............................................................................32
3.5 Boot Menu.............................................................................34
3.6 Exit Menu..................................................... .........................35

User Manual
Page 1
Chapter1. General Introduction
1.1 Overview
The BPC-3022 fanless Box PC is designed with an Intel®Celeron®N2930
processor, the first Celeron processor to support DDR3L SDRAM that runs at
1.83 GHz while maintaining low power consumption and an attractive price
point, making this embedded hardware platform ideal for embedded and
automation applications. The BPC-3022's compact size and multiple display
ports offer the highest degree of flexibility for many kinds of industrial solutions.
Its rugged case is designed to protect against electromagnetic interference,
extremes of cold and heat, and highlights a passive cooling design for quiet,
fanless operation suitable for digital signage, or the medical and automation
industries.
( Front Cover )

User Manual
Page 2
(Back Cover )

User Manual
Page 3
1.2 Key Features
Intel Celeron Processor N2930 Quad-Core
Compact Size and Light Weight
1 GbE, HD Audio, 5 USB, 1 COM, DVI-I, HDMI,
2 mini PCIe (for WLAN & 3G module)
Support 1 SATA HDD/SSD (2.5”), 1 mSATA
-20~60°C operating temperature
1.3 Hardware Specification
Model
BPC-3022
Processor
System
CPU
Intel Celeron Processor N2930 Quad-Core
Frequency
Quad-Core up to 1.83 GHz
L2 Cache
2 MB
System Chipset
N/A
BIOS
UEFI
Memory
Technology
DDR3L 1333 MHz SDRAM (1.35 V only
Max. Capacity
8 GB
Socket
1, 204-pin SO-DIMM
Display
Graphics Engine
Intel HD Graphics
DVI-I
Up to 1920 x 1080
HDMI
Supports 1920 x 1080, Max data rate: up to 1.65 Gb/s
Supports HDMI v1.3 up to 1080p
Dual Display
DVI-I + HDMI
I/O Interface
USB
1 USB 3.0, 4 USB 2.0
Serial Port
1 COM (RS-232)
Ethernet
Controller
1 GbE LAN, Realtek RTL8111G, 10/100/1000 Mbps
Audio
Chipset
Realtek ALC662, High Definition Audio (HD)
Connector
Line out, Mic in
Expansion
Mini PCIe
1 Half-size slot / WIFI module(optional)
1 Full-size slot(only USB and mSATA signal)/3G
module(option)
Storage
SATA II
2.5” HDD / SSD (Max data transfer rate 300 MB/s)
mSATA
1 (mSATA shared with full-size mini PCIe slot)
Power
Power Type
AT /ATX
Power Connector
DC Jack

User Manual
Page 4
Power Input
Single 12 V DC input
Power
Consumption
0.72 A @ 12 V (9.4 W) , Typical
1.38 A @ 12 V (15.8 W) ,MAX
Environment
Operational Temp
-20~60°C (-4~140° F) w/ 2.5” SSD
(Humidity: 60°C @80% RH non-condensing)
Non-Operational
-40~85°C (-40~185° F) w/ 2.5” SSD
(Humidity: 60°C @ 80% RH non-condensing)
Vibration
5 Grms, IEC 60068-2-64, random, 5~500 Hz, 1 Oct/min.,
1hr/axis, x, y, z 3 axes (w/ SSD )
1 Grms, IEC 60068-2-64, random, 5~500 Hz, 1 Oct/min.,
1hr/axis, x, y, z 3 axes (w/ 2.5” HDD)
Certificate
EMC
CE, FCC Class A
General
Dimensions
172.8 x 46.1 x 112.4 mm (6.80” x 1.81” x 4.43”)
Weight
0.91 kg (2.0 Ib)
OS
Windows 7/8/8.1, WS7P/E, WES8, Fedora 20, Ubuntu
14.04

User Manual
Page 5
1.4 I/O Arrangement
( Front Side )
Power Button
Press this button to turn on the system.
Audio Port
Green connector means LINE OUT / Pink connector MIC IN .
USB 2.0 Port
Pin
Definition
1
+5
2
USB-
3
USB+
4
GND
Basically, USB2.0 supports 0.5A @ 5 V
USB2.0
Audio
Port
Power
Button

User Manual
Page 6
( Back IO Side )
DC 12 V Power Input Connector
This connector must be connected to DC 12 V power adaptor.
DVI-I Port
This port can be connected to the DVI monitor via the external DVI-I
connector.
When connecting VGA monitor, you need an exclusive special DVI to VGA
adapter (only offered by Arestech) .
HDMI Port
This port can be connected to the HDMI monitor. (HDMI v1.3)
Users can connect DVI-I and HDMI in the same time (Dual Display), but
cannot support 3-display because of Intel chipset's constraint.
USB 3.0 Port
Basically, USB2.0 supports 0.5A @ 5 V
Pin
Definition
1
+5
2
USB-
3
USB+
4
GND
5
StdA_SSRX-
6
StdA_SSRX+
7
GND_DRAIN
8
StdA_SSTX-
9
StdA_SSTX+
Power DC
Input
DVI-I
HDMI
USB3.0
COM
Port
USB2.0
LAN
Port
Antenna
SMA Hole

User Manual
Page 7
USB 2.0 Port
Pin
Definition
1
+5
2
USB-
3
USB+
4
GND
Basically, USB2.0 supports 0.5A @ 5 V
COM Port (RS-232 only)
Pin
Definition
Pin
Definition
1
DCD
6
DSR
2
RXD
7
RTS
3
TXD
8
CTS
4
DTR
9
N/A
5
GND

User Manual
Page 8
LAN Port
This port can be connected to the Ethernet via RJ-45 connector .
10/100BASE-T:
Pin
Definition
Pin
Definition
1
TX_D0+
5
NC
2
TX_D0-
6
RX_D1-
3
RX_D1+
7
NC
4
NC
8
NC
1000BASE-T:
Pin
Definition
Pin
Definition
1
TX_D0+
5
BI_D2-
2
TX_D0-
6
RX_D1-
3
RX_D1+
7
BI_D3+
4
BI_D2+
8
BI_D3-
Activity/Link LED
Status
Description
Off
No Link
Blinking
Data Activity
On
Link
SPEED LED
Status
Description
Off
10Mbps connection
Off
100Mbps connection
Green
1Gbps connection

User Manual
Page 9
Antenna SMA Hole
This hole is reserved for antenna SMA connector .
If customer select a 3G or a WIFI module , there will be SMA connectors.
If customer doesn't select any wireless module, this hole will be reserved.

User Manual
Page 10
1.5 Mechanical Dimension
Front Side Dimension
Top Side Dimension

User Manual
Page 11
Back Side Dimension
Bottom Side Dimension

User Manual
Page 12
Chapter2. System Setup
2.1 Installation Procedure
1. Connecting Power Cord
The BOX PC can only be powered through an DC electrical outlet (12 V).
Be sure to handle the power cord by holding the plug end only.
Follow these procedures to connect the power cord:
(1) Connect the male end of the power cord to the DC-In connector of BOX PC.
(2) Connect another male plug of the power cord to an electrical outlet.
2. Connecting Keyboard and Mouse and Monitor
Connect the mouse and keyboard to the USB connector of BOX PC.
Connect the Monitor to the HDMI or DVI-I port.
3. Switching on Power
The power button is located at the left side on the front cover of BO PC.

User Manual
Page 13
2.2 Installing Change 2.5" HDD/SSD
Step 1. Unfasten the screw on the bottom of the BOX PC
Step 2. Open the bottom cover of the BOX PC.
Step 3. Unplug the SATA and SATA power cable.

User Manual
Page 14
Step 4 . Unfasten the 4 screws on the HDD bracket and install a new one.
