Arestech MEGA 3110 Series User manual

User Manual
MEGA-3110 Series
High-Performance GPU Computer
with Intel® 9th / 8th LGA1151 Processors

2
User Manual
Record of Revisions
Version
Issue Date
Descriptions
Made By
1.0
2021/10/18
First Release
Jerry

3
User Manual
Copyright
The documentation and the software included with this product are copyrighted by Arestech
Cooperation Co., Ltd. All rights are reserved. No part of this manual may be reproduced, copied,
translated, or transmitted in any form or by any means without the prior written permission of
Arestech Cooperation Co., Ltd. Information provided in this manual is intended to be accurate and
reliable.
Trademark Acknowledgement
Brand and product names are registered trademarks of their respective owners.
Disclaimer
Arestech reserves the right to make changes, without notice, to any product described or contained
in this manual to improve design and/or performance. Applications that are described in this
manual are for illustration purposes only. Arestech makes no representation or guarantee that such
application will be suitable for the specified use without further testing or modification. This
manual might include unintentional typographical or technical errors. Arestech will periodically
correct such erroneous files and incorporate these corrections into the new version of the manual.
Technical Support and Assistance
If there is a problem with your product and you are unable to get a solution from the user’s manual,
please contact the local distributor.
Product Warranty (2 Years)
Arestech warrants to you, the original purchaser, that each of its products will be free from defects
in materials and workmanship for two years from the invoice date. This warranty does not apply to
any products which have been repaired or altered by persons other than repair personnel authorized
by Arestech, or which have been subject to misuse, abuse, accident, or improper installation.
Arestech assumes no liability under the terms of this warranty as a consequence of such events.
When a defect is discovered, please obtain an RMA (return merchandize authorization) from our
website, which allows us to process your return more quickly. The returned product must be properly
packaged in its original packaging to obtain warranty service.

4
User Manual
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use
liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equipment and must
be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting it fall may
cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment from
overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the equipment to the
power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything over the
power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. For safety reasons, the equipment should be opened only by qualified service personnel. If one
of the following situations arises, get the equipment checked by service personnel:
◼The power cord or plug is damaged.
◼Liquid has penetrated into the equipment.
◼The equipment has been exposed to moisture.
◼The equipment does not work well, or you cannot get it to work according to the user
manual.
◼The equipment has been dropped and damaged.
◼The equipment has obvious signs of breakage.
14. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE STORAGE TEMPERATURE
MAY GO BELOW -20°C (-4°F) OR ABOVE 55°C (131°F). THIS COULD DAMAGE THE
EQUIPMENT. THE EQUIPMENT SHOULD BE IN A CONTROLLED ENVIRONMENT.
15. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD
USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

5
User Manual
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from damage:
1. To avoid electrical shock, always disconnect the power from your PC chassis before you work on
it. Don't touch any components on the CPU card or other cards while the PC is on.
2. Disconnect power before making any configuration changes. The sudden rush of power as you
connect a jumper or install a card may damage sensitive electronic components.

6
User Manual
Contents
Chapter 1. Product Introductions ..................................................................................8
1.1 Overview..................................................................................................................8
1.2 MEGA-3110 Series Specifications............................................................................9
1.3 Panel I/O ................................................................................................................11
1.3.1 Front Panel..................................................................................................11
1.3.2 Top Panel ....................................................................................................13
1.4 Mechanical Dimensions.........................................................................................15
1.4.1 MEGA-3112.................................................................................................15
1.4.2 MEGA-3113.................................................................................................16
Chapter 2. Switches and Connectors ...........................................................................18
2.1 Switches and Connectors ......................................................................................18
2.1.1 Front View ..................................................................................................18
2.1.2 Top View.....................................................................................................18
2.2 Switches, LEDs and Connectors Definitions ..........................................................19
2.3 Switch Definitions..................................................................................................20
2.4 Connector Definitions............................................................................................23
Chapter 3. System Setup .............................................................................................32
3.1 Removing CPU Heat Sink Cover.............................................................................32
3.2 Installing CPU.........................................................................................................33
3.3 Installing A SODIMM..............................................................................................38
3.4 Installing A Mini-PCIe or mSATA Module ..............................................................40
3.5 Installing An Antenna ............................................................................................41
3.6 Installing A Removable SATA HDD Bay..................................................................43
3.7 Installing An Internal SATA HDD Bay.....................................................................44
3.8 Installing A CFast1/2 or SIM1/2 Card ....................................................................47
3.9 Installing An Internal SIM3/4 Card ........................................................................48
3.10 Changing A CMOS Battery ..........................................................................50
3.11 Assembly the CPU Heat Sink Cover ............................................................51
3.12 Installing A PCIe Expansion Card ................................................................52

7
User Manual
3.13 Connecting The Expansion Module with The PC Module ..........................55
3.14 Installing A Stand / Wall Mount .................................................................56
Chapter 4. BIOS Setup.................................................................................................57
4.1 BIOS Introduction ..................................................................................................57
4.2 Main Setup.............................................................................................................58
4.3 Advanced Setup.....................................................................................................59
4.3.1 CPU Configuration ......................................................................................59
4.3.2 PCH-FW Configuration................................................................................60
4.3.3 SATA & RST Configuration ..........................................................................61
4.3.4 Trusted Computing.....................................................................................62
4.3.5 ACPI Settings...............................................................................................64
4.3.6 Super IO Configuration...............................................................................65
4.3.7 Serial Port Console Redirection..................................................................69
4.3.8 Hardware Monitor......................................................................................71
4.3.9 USB Configuration ......................................................................................72
4.3.10 CSM Configuration....................................................................................73
4.4 Chipset...................................................................................................................75
4.4.1 System Agent (SA) Configuration ...............................................................75
4.4.2 PCH-IO Configuration .................................................................................78
4.5 Security ..................................................................................................................81
4.6 Boot 82
4.7 Save & Exit .............................................................................................................83
Main Menu.......................................................................

8
User Manual
Chapter 1. Product Introductions
1.1 Overview
MEGA-3110 series is a high-spec GPU system equipped with convertible expansion module
technology (CEM technology). It supports PCIe modular expansion functions and can be used with
nVIDIA RTX-2080 or higher GPU graphics cards or accelerator cards. It can reduce CPU loading and
increase the speed and ability of image processing.
What’s more, MEGA-3110 series uses Intel® 9th/8th CFL-R/S platform, which can support up to
octa-core processors. The configuration of 4x SATA and 2x CFast/ mSATA in the system is more
suitable for the storage and backup of large amounts of data. This series is ideal for image
recognition, security monitoring, unmanned intelligent vehicles, factory automation, machine
vision, and other fields.

9
User Manual
1.2 MEGA-3110 Series Specifications

10
User Manual

11
User Manual
1.3 Panel I/O
1.3.1 Front Panel
◼Power On/Off Button
Press to turn on or off the system
◼AT/ATX Mode Select Switch
Used to select AT or ATX power mode
◼Reset Button
Used to reset the system
◼COM Port
COM1 ~ COM2 support RS232/422/485
serial device
◼LAN Port
Used to connect the system to a local
area network
◼USB 3.0 Port
Used to connect a USB 3.0 device
◼DisplayPort
Used to connect a DisplayPort monitor
◼DVI-D Port
Used to connect a DVI monitor
◼VGA Port
Used to connect a VGA monitor
◼Line-out
Used to connect a speaker
◼Mic-in
Used to connect a microphone
◼Remote Power On/Off Terminal Block
Used to plug in a remote power on/off
terminal block
◼DC IN
Used to plug in a DC power input with
terminal block
◼Earthing Screw Hole
Used to connect the ground wire
◼Antenna Hole
Used to connect an antenna for optional
Mini-PCIe Wi-Fi module
◼Removable HDD Port
Removable 2.5" SATA HDD Area
◼Expansion Slot
Used to plug in a PCI or PCIe card.
◼Power LED
Indicates the power status of the system
◼IGN LED
Indicates the status of the active ignition
◼GPIO LED
Indicates the status of the GPIO defined
by customer

12
User Manual
MEGA-3112
MEGA-3113

13
User Manual
1.3.2 Top Panel
◼Clear CMOS
Used to clear CMOS
◼PC/Car Mode Select Switch
Used to select PC or Car mode
◼Delay Time Select Switch
Used to select car mode system to turn
off delay time
◼CMOS Battery
Used to change a CMOS battery
◼SIM Card
Used to insert a SIM card
◼CFast Socket
Used to insert a CFast card
◼COM Port
COM1 ~ COM2 support RS232/422/485
serial device
◼Digital I/O Terminal Block
Supports 8 digital inputs and 8 digital
outputs
◼Antenna Hole
Used to connect an antenna for optional
Mini-PCIe WiFi module
◼Flexible I/O Window Slot
Used to customize I/O output
MEGA-3112

14
User Manual
MEGA-3113

15
User Manual
1.4 Mechanical Dimensions
1.4.1 MEGA-3112

16
User Manual
1.4.2 MEGA-3113

17
User Manual

18
User Manual
Chapter 2. Switches and Connectors
2.1 Switches and Connectors
2.1.1 Front View
2.1.2 Top View

19
User Manual
2.2 Switches, LEDs and Connectors Definitions
◼List of Switches and LEDs
Location
Definition
PWR_SW2
Power Button
AT_ATX2
AT / ATX Power Mode Switch
RESET2
Reset Button
CLR_CMOS1
Clear BIOS Switch
CAR_PWR1
PC / Car Mode Switch
DELAY_TIME1
Car mode system turn off delay time
PWR_LED2
Power LED Status
IGN_LED2
Power Ignition LED Status
GPIO_LED4, GPIO_LED5, GPIO_LED6
GPIO LED Status
◼List of Connectors
Location
Definition
PWR_SW3
Remote Power On/Off Connector
USB7_1, USB8_1
USB 2.0 Port
COM1_2_1
RS232 / RS422 / RS485 Connector
COM3_1, COM4_1, COM5_1, COM6_1
RS232 / RS422 / RS485 Connector
CFAST1, CFAST2
CFast Socket
DC_IN2
6-pin DC 24~48V Power Input with Power
Ignition Connector
SIM1_1, SIM2_1, SIM3_1, SIM4_1
SIM Card Socket
LINE_OUT1
Line-out Jack
MIC_IN1
Mic-in Jack
POWER1, POWER2
Power Connector
DIO1_1
8DI / 8DO Connector
VGA1_1
VGA Connector
DVI_D1
DVI-D Connector
DP1
DisplayPort Connector
SODIMM1, SODIMM2
DDR3L SODIMM Socket
CN1, CN2 ,CN3
LAN and USB3.0 Port
MINIPCIE1, MINIPCIE2
Mini PCI-Express Socket
CN4, CN5
Dual Mode Mini PCI-Express / mSATA Socket
SATA1_1, SATA2_1, SATA3_1, SATA4_1
22-pin SATA with Power Connector
FAN1
Internal PWM FAN Connector

20
User Manual
2.3 Switch Definitions
◼PWR_SW2: Power Button
Switch
Definition
Push
Power On/Off System
◼AT_ATX2: AT / ATX Power Mode Switch
Pin
Definition
1-2 (Right)
ATX Power Mode (Default)
2-3 (Left)
AT Power Mode
◼RESET2: Reset Button
Switch
Definition
Push
Reset System
◼CLR_CMOS1: CMOS Clear Switch
Pin
Definition
1-2 (Left)
Normal (Default)
2-3 (Right)
Clear CMOS
◼CAR_PWR1: PC / Car Mode Switch
Pin
Definition
1-2 (Left)
PC Power Mode (Default)
2-3 (Right)
Vehicle Power Ignition Mode
