EQUIUM 7300D Series Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2000 TAIS Equium 7300D.doc Rev. 11 03/22/00 nmm. Page 1 of 4
PLATFORM
SERIES NAME EQUIUM 7300D
PART NUMBER PV1052U-xxxx: See Configuration Page
PROCESSOR
Intel Celeron

Yes
Available processor speeds 433, 466, 500MHz
ZIF socket Yes
Integrated Coprocessor Yes
MMX support Yes
ECC support Yes
Processor Cache (L1) Capacity 32KB: (16KB code; 16KB data)
Bus Speed 66MHz Front Side Bus
LEVEL 2 (L2) CACHE Yes: 128KB Pipeline Burst SRAM Integrated into CPU
Data Bus Width/Address Bus Width 64-bit/64-bit
Local Clock Bus Speed Half of the Processor clock
SYSTEM BOARD
Form Factor NLX (8.25" x 10")
Chipset Intel 810
Down Components
I/O Controller Yes
Graphics Controller Integrated into Intel 810 chipset
Audio Controller Software Audio (AC'97)
SYSTEM ARCHITECTURE
PCI BUS (V2.1): (32-bit, 33mhz) Yes: 4-Half-length slot
Form Factor NLX Riser Adapter
AGP BUS Yes
HARDWARE MONITORING (DMI ASIC) Yes
MEMORY: SDRAM (PC100)
Type 168-pin SDRAM DIMM’s with gold-plated contacts, unbuffered
Available Standard Configurations (x*64MB) 64MB, 128MB or 256MB (As Listed: See Configuration Page)
Maximum 512MB
Local Clock Bus Speed 100 MHz
Socket type: (2) 168-pin gold plated DIMM sockets: Accepts 64/128/256MB memory
BIOS (FLASH EEPROM, 4MB) Yes
Plug & Play BIOS Yes
DMI Compliant Yes
Setup Support Yes
USB (v.1.0) Yes
Advanced Power Management 1.2 (APM) Yes
PnP Support (v.1.0a) Yes
VESA support Yes
DPMS Support Yes
DDC Support Yes
DMI (v.2.0) support Yes
UDMA - 33 Yes
UDMA – 66 Yes
POST Yes
ACPI Yes
Machine ID Yes

EQUIUM 7300D Series Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2000 TAIS Equium 7300D.doc Rev. 11 03/22/00 nmm. Page 2 of 4
SERIES NAME EQUIUM 7300D
PART NUMBER PV1052U-xxxx: See Configuration Page
EXTERNAL INTERFACES
One RJ-45 port As Listed: See Configuration Page
One 9-Pin Serial (16550 UART compliant) Yes
Universal Serial Bus ports1Supports 2 USB peripherals without external hub
One 25-Pin Parallel Yes: Supports EPP, ECP
One 15-Pin RGB (SVGA video) Yes
One (PS/2) Mouse Port Yes
One (PS/2) Windows 95 104 Keyboard Yes
Microphone (3.5mm mini jack, monaural) Yes
Line-out (3.5mm mini jack, stereo, 0.7V rms) Yes
AC IN (Standard 3 prong ) Yes
VIDEO (SDRAM)
Video Memory Intel Dynamic System Memory (Shares System Main Memory)
Data Bus Width 64-bit
Clock Speed 100 MHz
Graphic Controller
Standards Supported DPMS Power Managment, PnP compliant
Controller Chip Integrated into Intel 810 chipset (Intel 752 graphics compatible)
Connected Bus type CPU System Bus
64-bit BitBLT Engine Yes
2D Supported Features BitBLT, Hardware Cursor, DirectDraw
3D Supported Features Yes
Triangle Setup Yes
Modeling Fogging, lighting
Shading Gouraud shading
Rendering Texture mapping: Nearest, Linear, MIP Nearest, MIP Linear, Anisotropic,
Z-Buffering
Alpha-blending Yes
Direct3D support Yes
Digital Video Accelerator
YUV Color Space Conversion Yes: Off-loads conversion from CPU for higher performance full motion video
Without compromising picture quality or frame rate.
Scaling Yes: Bilinear Interpolation
Motion Compensation Yes
SUPPORTED VIDEO RESOLUTIONS Colors/ Refresh Rate
(Non-interlaced unless otherwise specified) 4MB Memory
640 x 480 24-bit (16.7M) 85 Hz
800 x 600 24-bit (16.7M) 85 Hz
1024 x 768 24-bit (16.7M) 85 Hz
1280 x 1024 24-bit (16.7M) 85 Hz
1600 x 1200 8-bit (256) 75 Hz
SOUND SYSTEM
Chipsets: Integrated into Intel 810 chipset (Audio-Codec 97 )
Compatibility Sound Blaster Pro & Windows Sound System
FM Synthesis Yes
16-bit stereo audio full duplexed Yes
3D sound support Yes
DirectSound Yes
Built-in microphone No
1. Both ports operate from a single controller allowing 128 devices total, not per port. Throughput for the Universal Serial Bus (USB)
12mb/sec.

EQUIUM 7300D Series Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2000 TAIS Equium 7300D.doc Rev. 11 03/22/00 nmm. Page 3 of 4
SERIES NAME EQUIUM 7300D
PART NUMBER PV1052U-xxxx: See Configuration Page
CHASSIS "DESKTOP DESIGN"
EXPANSION BAY TOTAL AVAILABLE CONFIGURED
Internal 3.5” 2 1 1 (HDD)
5.25” 0 0 0
External 3.5” 1 0 1 (FDD)
5.25” 2 1 1 (CD-ROM)
EXPANSION SLOTS TOTAL AVAILABLE CONFIGURED
PCI: Half-Length 4 4 0
POWER SUPPLY (200Watts )
Input (Voltage/Frequency) 115-230V; 47-63Hz
Cord Length 6 feet
SUPPORTED SAFETY STANDARDS
US/Canada UL 1950 – CSA 950-95, 3rd Edition, 7/28/95
CSA C22.2 No. 950-95
ISO9241-3/8
ICES-003, Issue 2
FCC Class B
Europe EN 60950: A1-A4, EN55022
CE Mark
EN 50082-1 (1992)
IEC 801-4 (European harmonized standard)
IEC 801-2 ESD testing
IEC 801-3 Radiated Field susceptibility
TUV/GS Mark, Blue Angel
International CISPR 22, 1995
IEC 950, 2nd Edition, 1995 (w/amendments 1, 2 &3 & 4)
AS/NZS 3548 Class B (1995)
CERTIFICATIONS: Windows 95 & Windows NT logo, Novell Client, Energy Star
HARDWARE COMPLIANT: PC98, PC99, Wired For Management (WfM), Year 2000
SECURITY
Hardware Security Lock Loop (Secures chassis internals) – lock not included
Miscellaneous Chassis Intrusion Alert
Password Support Supervisor/Administrator, User, Sleep
DIMENSIONS 17.32”L x 16.34”W x 5.12”D
WEIGHT 24.5 lbs.
BUNDLED SOFTWARE OPTIONS: Windows 95, Windows 98 Second Edition or Windows NT Workstation v4.0
w/NT Service Pack 4 & SystemSoft Card Wizard, Intel LANDeskClient Manager 6.0 and Toshiba SMS Connection
CD’s Included: Toshiba Configuration Builder CD & Toshiba Companion disk
WARRANTY: 3 Yr. Limited Warranty: 1st Year on-site, 2nd and 3rd year parts
ENVIRONMENTAL SPECIFICATIONS Operating Non-operating
Temperature: 50°F (10°C) to 95°F (35°C) -4°F (-20°C) to 140°F (60°C)
Packaged: -30°C to 70°C -- --
Relative Humidity: 30%to 80%non-condensing 10%to 90%non-condensing
Shock: 10G; 1.5G w/CD-ROM installed 60G; 10G w/CD-ROM installed
Vibration (5~150Hz f/30 minutes, each axis) 0.3G 0.6G
Packaged: 1.0G -- --

EQUIUM 7300D Series Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2000 TAIS Equium 7300D.doc Rev. 11 03/22/00 nmm. Page 4 of 4
SERIES NAME EQUIUM 7300D
PART NUMBER PV1052U-xxxx: See Configuration Page
COMPONENT
STORAGE
FDD 3.5” 1.44MB Floppy Disk Drive
HDD (3.5” Half-height Enhanced IDE) As Listed: See Configuration Page
Type SMART, Ultra-DMA66
Capacity options 6.4GB, 10.2GB, 13.6GB, 17.2GB, 20.5GB ( GB = 1billion bytes)
RPM 5400
Buffer 512KB
Access Time <9.7 msec
Ultra DMA Yes
Burst Data Transfer Rate Ultra DMA Mode4 (66.0MB/sec); Ultra DMA Mode2 (33.0MB/sec);
PIO Mode 4/Multi-word DMA mode2 (16.7MB/sec)
Certifications SMART, UDMA-33, UDMA-66, Energy Star
Controller Enhanced IDE
CD-ROM:As Listed: See Configuration Page
Available options None, 40X CD-ROM or 8X DVD-ROM (DVD-ROM is for storage only)
CD-ROM speed 40X
Interface ATAPI ( Enhanced IDE )
Modes supported PIO mode 4, DMA mode 2, and Ultra DMA
Random Access Time < 80 ms(typical)
Sustained Data Transfer Rate 2550~6000KB/Sec(17X~40X), average over 30X
Disk Formats supported ISO9660 Data Discs, CD-ROM(Mode 1 & Mode 2), Mixed Mode (Audio Combined
CD-ROM Disc), CD-ROM/XA(Mode 2, Form 1 & Form 2), CD-I/FMV, Video CD,
CD-DA, Photo-CD(Single & Multisession), Karaoke CD, CD Extra, CD-RW (read
Only)
DVD-ROM (Toshiba SD-M1202) 8X speed, Region 1 (DVD-ROM is for storage only)
Interface ATAPI ( Enhanced IDE ) with 256KB Buffer
Random Access Time 105ms (DVD mode); 80ms (CD-ROM mode)
Sustained Data Transfer Rate (DVD) 4,460KB/sec to 10,800KB/sec
Sustained Data Transfer Rate (CD) 2,595KB/sec to 6,000KB/sec
Supported Disk Formats Multisession Photo-CD, CD-Extra, CD-ROM XA, CD-I, Video CD, CD-G,
CD-I Ready, MPC-3 Compliant, DVD, DVD-R, CD-DA, CD-R, CD-RW (read only)
OTHER OPTIONAL DEVICES PCMCIA card reader (ISA based) or 100MB Iomega® Zip® (IDE)
ETHERNET SUPPORT As Listed: See Configuration Page
Available options Intel EtherExpress PRO/100B PCI or None
Chipset i82559
Support Network 100Base-TX, 10Base T
Port RJ 45 (with Connection Status LED and Ethernet Speed LED)
Wake on LAN Yes
KEYBOARD (PS/2)
Choice of Two Keyboard Options Value Keyboard
Enhanced 104-key keyboard Yes
Windows 95 support Yes
3.5mm Travel Yes
12 dedicated function keys Yes
Numeric keypad Yes
Keyboard tilt Yes
Scroll Lock, CapsLock, NumLock Indicators Yes
POINTING DEVICE Choice of
2 Button with PS/2 connector
2 Button Scroller mouse with PS/2 connector and wheel for scroll function
