Argos 01OSBP0603-V1 Instruction manual

P 1
01OSBP0603-V1
6x3 Pent Shed
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timer.
**Protim Aquatan T5 (621)**
Protim Aquatan* T5 is a coloured, water-based concentrate which is diluted with water to make a solution
for application to unseasoned timber. Protim Aquatan T5 treated wood is not protected against wood
destroying insects or wood decaying fungi. Further preservative treatment is required to protect against
these organisms.
Contains: Boric Acid, Sodium Hydroxide 32% solution, aqueous mixture of sodium dioctyl sulphosuccinate &
alcohols: 2,4,6-Trichlorophenol.
Hazard Statements:
H315: Causes skin irritation.
H319: Causes serious eye irritation.
H412: Harmful to aquatic life.
Wear gloves when handling freshly treated wood.
Avoid breathing dust when cutting treated or untreated wood.
Dispose of o-cuts responsibly – do not burn.
IF SKIN IRRITATION OCCURS: Get medical advice/attention.
IF IN EYES: Rinse cautiously with water for several minuets. Remove contact lenses, and continue rinsing. If
the irritation persists: Get medical advice/attention.
DO NOT INGEST.
Please retain product label and instructions for future reference
P 1
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied)
including a Phillips screwdriver, Stanley knife, wood saw, step ladder and drill with 2mm
bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
As with all natural materials, timber can be aected during various weather conditions.
For the duration of heavy or extended periods of rain, swelling of the wood panels may
occur. Warping of the wood may also occur during excessive dry spells due to an interior
moisture loss. Unfortunately, these processes cannot be avoided but can be helped. It is
suggested that the outdoor building is sprayed with water during extended periods of
warm sunshine and sheltered as much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to protect
the product during transit and for upto 3 months against mould. To validate your
guarantee and ensure longevity of the product, it is ESSENTIAL the building is treated
with a wood preserver within the rst three months of assembly and thereafter in
accordance with the manufactures recommendations. Care must be taken to ensure
the product is placed on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to
diagrams for the base dimensions, The base should be slightly smaller than the external
measurement of the building, i.e. The cladding should overlap the base, creating a run
o for water. It is also recommended that the oor be at least 25mm above the
surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in
the case of childrens products independently tested to EN71 level, we cannot accept
responsibility for your safety whilst erecting or using this product.
Refer to the instructions pages for you specic product code

12 3 4567
8 9
50mm Screw x30
40mm Screw x15
Felt Tacks x100
30mm Screw x65
P 2
01OSBP0603-V1
Overall Dimensions:
Length = 1804mm
Width = 959mm
Height = 2122mm
Base Dimensions:
Length = 935mm
Width = 1804mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Door
Gable
Plain
Gable
Front
Panel
Rear
Panel
Door Floor Roof
Sheet
Gable Tops
T-Hinge QTY 2
Pad Bolt
Felt
10
11
12
13
14
15
16
17
18
Eave Framing 1828mm
Front Corner Trim 1882mm QTY 2
Rear Corner Trim 2082mm QTY 2
Rear Fascia 1882mm
Side Fascia 1035mm QTY 2
Bolt Block 160mm
Remove transportation
blocks from the bottom
of each panel before
beginning assembly. Each
Panel should have two
Pre Assembly
Step 1
Place the floor on a firm
level base, ensure the
base has suitable
drainage free from areas
where standing water can
collect.
(SEE FRONT PAGE FOR
BASE REQUIREMENTS)
6

3x50mm Screws
Pre drill
hole
P 3
Please retain product label and instructions for future reference
Step 2
Fix the corners with
3x50mm screws as shown
in the diagram.
Do not secure the
building to the floor until
the roof is fitted.
50mm
screw
Step 3
Attach the door gable
and front panel with
9x50mm screws, using
the same method shown
in Step 2.
Step 4
Secure the gable tops
onto the plain and door
gables, ensuring the
panels are flush. Fix in
place using 2x30mm
screws per side.
Step 5
fix the eave framing to
the edge of the roof sheet
using 4x30mm screws.
Place roof into position
ensuring the eave fits
butt against the front
panel cladding. Secure
using 10x30mm screws as
shown in the diagram.
9x50mm Screws
Pre drill
hole
50mm
screw
4x30mm Screws
Pre drill
hole
30mm
screw
4
2
1
3
8
9
14x30mm Screws
Pre drill
hole
30mm
screw
7
10

HANDLE
WITH CARE
12
3
4
P 4
Please retain product label and instructions for future reference
Step 6
Secure the building to the
floor using 14x50mm
screws. Ensure to screw
into the floor bearers.
14x50mm Screws
Pre drill
hole
50mm
screw
100mm
intervals
50mm
Overhang
Step 7
Cut the felt into 2 sheets at
1950mm and fix onto the
roof using felt tacks as
shown in diagram ensuring
there is 50mm overhang
around the sides.
Felt
tacks
100 x Felt Tacks
Step 9
Use 3x30mm screws to fix
each cover trim to the
corners of the building as
shown in diagram.
12x30mm Screws
Pre drill
hole
30mm
screw
17
Step 8
Fix the hinges to the door
with 8 x30mm screws
ensuring they are located
into the door framing.
Attach the door to the
gable using 6x30mm
screws.
Fit the bolt block to the
door using 2x30mm screws,
screwing through the
cladding into the block.
Attach the pad bolt to door,
lining up with the bolt
block and door framing,
with 10x30mm screws.
26x30mm Screws
Pre drill
hole
30mm
screw
5
15
16
18
12
12
11
11
For assistance please contact customer care on: 01636 880514
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk

It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
P 5
Please retain product label and instructions for future reference
Step 10
Fit the fascia boards to the
sides and back of the
building using 3x40mm
screws per board as shown
in the diagram.
9x40mm Screws
Pre drill
hole
40mm
screw
14
14
13
