Ariens 936031 - 2048 User manual

Parts Manual
Models
936031 - 2048
936032 - 1742
936033 - 1542
936034 - 1540
936035 - 1742
936036 - 2548
936320 - 1742
936330 - 1742
03684600D 4/02
Supercedes 03684600, A-C
Printed in USA
Yard Tractor

3
M
ODELS
Model 936031
20.0 HP Briggs & Stratton Intek Twin
with 48" pan
Serial No. 000101 and up
Model 936032
17.0 HP Briggs and Stratton Intek Twin
with 42" pan
Serial No. 000101 and up
Model 936033
15.0 HP Briggs & Stratton Intek Single
with 42" pan
Serial No. 000101 and up
Model 936034
15.0 HP Briggs & Stratton Intek Single
with 40" pan
Serial No. 000101 and up
Model 936035
17.0 HP Briggs and Stratton Intek Single
with 42" pan
Serial No. 000101 and up
Model 936036
25.0 HP Briggs & Stratton Intek Twin
with 48" pan
Serial No. 000101 and up
International
Model 936320
17.0 HP Briggs and Stratton Intek Twin
with 42" pan
Serial No. 000101 and up
Model 936330
17.0 HP Briggs & Stratton Intek Single
with 42" pan
Serial No. 000101 and up
T
ABLE
O
F
C
ONTENTS
D
ECALS
Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
M
AIN
F
RAME
, S
EAT
& C
ONTROLS
Frame and Rear Deck . . . . . . . . . . . . . . . . . . . . . . . . 6
Rear Wheel and Hydro Drive . . . . . . . . . . . . . . . . . . . 8
Hydro Transaxle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Clutch and Brake - Hydro. . . . . . . . . . . . . . . . . . . . . 15
Hood, Dash and Battery. . . . . . . . . . . . . . . . . . . . . . 16
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Attachment Lift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
P
OWER
P
LANT
Engine, Fuel Tank and Belt Drive . . . . . . . . . . . . . . 22
Exhaust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
M
OWER
D
ECK
40" Mower Spindle . . . . . . . . . . . . . . . . . . . . . . . . . . 26
42" Mower Deck. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
42” Deck Front Mount. . . . . . . . . . . . . . . . . . . . . . . . 29
42" Mower Spindle . . . . . . . . . . . . . . . . . . . . . . . . . . 30
42" Mower Brackets and Rollers . . . . . . . . . . . . . . . 32
40" & 48" Hanger Arm . . . . . . . . . . . . . . . . . . . . . . . 33
48" Mower Deck and Rollers . . . . . . . . . . . . . . . . . . 34
48" Mower Spindle . . . . . . . . . . . . . . . . . . . . . . . . . . 36
E
LECTRICAL
Continuity Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . 38
Wiring Diagrams. . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
© Copyright 2000, 2002 Ariens Company

4
D
ECALS
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
1 07843200 1 Decal-Hot Surface
2 08086600 1 Decal-Operating Instructions Yard Tractor
3 05237900 1 Decal, Belt Diagram (032, 033, 035, 320, 330)
4 07731400 2 Decal, Mower Pan Head Danger
5 07742300 1 Decal, Warning
6 05226300 4 Decal, Blade Alignment (032, 033, 035, 320, 330)
DANGER / PELIGRO
PARA EVITAR DAÑOS SERIOS
O LA MUERTE
TO AVOID SERIOUS INJURY
OR DEATH
• Read the operator's manual.
• Keep children and others away from unit
while operating.
• Look down and behind before and while
backing.
• Never carry children.
• Never direct discharge toward other
people. Thrown objects can cause injury.
• Go up and down slopes, not across.
• If machine stops going uphill, stop blade
and back down slowly.
• Avoid sudden turns.
• Keep safety devices (guards, shields,
switches, etc.) in place and working.
• Check interlock system per manual
before use.
• Understand location and function of all
controls.
POUR EVITER LES BLESSURES
GRAVES OU LA MORT
10°
08086600
• Lire le manuel d'utilisation.
• Éloigner les enfants et toute autre personne pendant le
fonctionnement de la machine.
• Regardez derriere et sur les cotes lorsque vous reculez.
• Ne transportez jamais dénfant.
• Ne jamais décharger directement en direction de
quelqu’un. Des particules projetées peuvent provoquer
des blessures.
• Tondez toujours de haut en bas et inversement jamais le
long des pentes.
• Si la machine sárrete en montee. Debrayez la lame et
redescendez doucement.
• Evitez les virages brusques.
• Maintenez
toujours en place tous les elements de securite
(protecteurs, interupteurs, etc.).
• Controlez le bon fonctionnement des interrupteurs de securité
avant utilisation tel q'uindiqué dans le manuel d'utilisation.
• Comprenez bien la fonction et la situation de chacun des leviers
et boutons de commande.
• Leer el manual del operador.
• Mantenga la unidad alejada de los niños u otras
personas cuando esté en funcionamiento.
• Antes y durante retroceso mirar hacia abajo y
detras.
• Nunca monten niños.
• Nunca dirija la descarga hacia otras personas, ya
que los objetos lanzados pueden provocar lesiones.
• Suba y baje pendientes, no transversalmente.
• Si la maquina se detiene subiendo cuesta, desactive la
cuchilla y baje lentamente.
• Evite viradas subitas.
• Mantenga artefactos de seguridad (defensas,
protectores, interruptores, etc.) en su lugar y trabajando.
• Verifique en el manual el sistema de engranar antes de
usar.
• Tenga conocimiento de funciones y localizaciones de todos
los controles.
After proper belt installation:
1. Marks must align as shown.
2. Distance must be 3/4”(19mm).
3. These three nuts must be tightened.
05237900
Après la pose correcte de la courroie :
1. Les repères doivent être alignées (voir schéma).
2. La distance doit être de 19 mm (3/4 in.).
3. Ces trois écrous doivent être serrés.
Después de la instalación adecuada de la correa:
1. Las marcas deben alinearse como se muestra.
2. La distancia debe ser de 19 mm (3/4 pulg.).
3. Estas tres tuercas deben apretarse.
2
3
1
1
3
After proper belt installation:
1. Marks must align as shown.
2. Distance must be 5/8"–3/4”(16–19mm).
3. These three nuts must be tightened.
05237900
Après la pose correcte de la courroie :
1. Les repères doivent être alignées (voir schéma).
2. La distance doit être de 16–19 mm (5/8–3/4 in.).
3. Ces trois écrous doivent être serrés.
Después de la instalación adecuada de la correa:
1. Las marcas deben alinearse como se muestra.
2. La distancia debe ser de 16–19 mm (5/8–3/4 in.).
3. Estas tres tuercas deben apretarse.
(16 –19mm)
5/8"–3/4"
PE0656
4
1
3
2
6
4
5

5
D
ECALS
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
1 07737100 1 Decal, Dash with Lights
2 08082800 1 Decal, Indicator 5 Pos
3 05236200 2 Decal-Hood Yard Tractor 1540 (034)
08086500 2 Decal-Hood Yard Tractor 1542 (033)
08091300 2 Decal-Hood Yard Tractor 1742 (032, 035, 320, 330)
08091200 2 Decal-Hood Yard Tractor 2048 (031
05236100 2 Decal-Hood Yard Tractor 2548 (036)
4 08086400 1 Decal, Hood Yard Tractor
5 63615100 1 Decal, Set-Yard Tractor Controls
6 07719800 1 Decal, Ignition
08088400
07719600A
07719700A
PE0662
1
3
4
936033
936034
936035
936330
936031
936032
936036
936320
2
6
5
5
5
5
5

6
F
RAME AND
R
EAR
D
ECK
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
1 03650300 1 Insert-Lift
2 03652500 1 Holder-Beverage
3 07521000 1 Snap Bushing
PT0014
1
2
3
4 5
6
7
8
9
10
11
12
6
6 14
15 16
17
6
4
17
16 18
4
19 6
6
4
4
19
20
21
6
22
23
24
25
26
27
29
32
33
30
34
28
35
13
37
38
39
36 13
31
31

7
F
RAME AND
R
EAR
D
ECK
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
4 06212200 17 Bolt-Round Head Square Neck .31-18 x .62
5 03649453 1 Rear Deck
6 06543100 28 Nut-Locking-Top-Flange .31-18
7 07008000 4 Nut-Self-Threading Fits .25 Stud
8 03655600 1 Seat-V1400 Med Weltless (032, 033, 034, 035, 320, 330)
03670500 1 Seat-V1500 Hi Weltless (031, 036)
9 03650400 1 Seat Pivot Plate
10 06307400 4 Washer-Lock .31 x .097
11 05947000 4 Bolt-Hex .31-18 x .75 Grade 5
12 07521600 2 Tube Cap
13 06542000 6 Nut-Locking-Top-Flange .38-16
14 08328200 2 Spring-Compression .148 x 1.23 x 2.4
15 03618100 1 Seat Box
16 05947000 3 Bolt-Hex .31-18 x .75 Grade 5
17 05516200 2 Bushing-Flange .325 x .465 x .333 x .685
18 03600800 1 Seat Slides
19 06212200 2 Bolt-Round Head Square Neck .31-18 x .62
20 07008100 4 Screw-Cap Button Head .31-18 x .50 Grade 5
21 06301800 4 Washer-Lock External .313 x .030
22 08800600 6 Pad-Battery
23 06219600 2 Bolt-Round Head Square Neck .38-16 x .75 Grade 5
24 03601600 1 Draw Bar
25 07414400 2 Screw-Tapping .31-18 x .75
26 07411500 2 Screw-Tapping .31-18 x .50
27 03649359 1 Footrest-Left Hand
28 03649559 1 Footrest-Right Hand
29 03689351 1 Limiter, Mower Height Left Hand (031, 034, 036)
30 03689251 1 Limiter, Mower Height Right Hand (031, 034, 036)
31 03688151 2 Bracket, Deck Stop (032, 033, 034, 035, 320, 330)
32 03649800 1 Brace-Foot Rest Left Hand
33 03649900 1 Brace-Foot Rest Right Hand
34 05521100 2 Bushing-Flange .515 x .750 x .745 x 1.00
35 03673551 1 Main Frame
36 05959400 4 Bolt-Hex .38-16 x .75 Grade 5
37 07008400 1 Clip-Harness
38 03674200 1 Plate, Frame-Reinforcing
39 03680951 1 Weldment, Lift Link Mount Right Hand (032, 033, 034, 035, 320, 330)
03681051 1 Weldment, Lift Link Mount Left Hand (032, 033, 034, 035, 320, 330)

8
R
EAR
WHEEL AND HYDRO DRIVE
Model 936031, 032, 033, 036, 320
Item Part No. Qty. Description
1 03678951 1 Mount-Transmission Left Hand
2 03678851 1 Mount-Transmission Right Hand
3 06543100 6 Nut-Locking-Top-Flange .31-18
4 06713500 6 Pin-Hair .08 x .18 x 1.18
5 07414100 6 Screw-Tapping .375-16 x .75
6 06539500 1 Nut-Jam .50-20 Grade 2
7 06307300 1 Washer-Lock .50 x .125 Reg.
8 07321400 1 Sheave-Transaxle
9 03570000 1 Fan-Black Nylon
10 07406900 4 Screw-Tapping 10-24 x .484
11 03648800 1 Transaxle - Hydro
PT0077
1
2
3
5
6
7
8 9
10 11
12
4
14
15
16
17
18
19
20
21
22
21
23
24
25
26
27 5
4
28
19
29
30
4 19
30
31
28
32
33
34
35
3
3
36
37
38
39
40
41
42
43
44
45 46 4
47
48
49
50
51
52
53
54
50
55
56
57
43
50
52
45
13
5

9
R
EAR
W
HEEL AND
H
YDRO
D
RIVE
Model 936031, 032, 033, 036, 320
Item Part No. Qty. Description
12 03677200 1 Rod-Transmission Disconnect
13 00211100 1 Spacer .50 x .75 x .321
14 07026400 1 Cap-Vent .5 Hydro-Gear
15 03635100 1 Hose-Vent .50 ID x 7.50 Long
16 07026300 1 Fitting-Straight 1/2" O-Ring Hydro-Gear
17 05952600 4 Bolt-Hex .31-18 x 2.50 Grade 5
18 05947000 1 Bolt-Hex .31-18 x .75 Grade 5
19 06529800 2 Nut-Locking-Center .31-18
20 03672500 1 Mount, Magnet
21 06441500 4 Washer-Flat-Steel .755 x 1.375 x .062
22 05510400 4 Bushing-Sleeve .750 x 1.125 x 1.062 (031, 032, 033, 320)
03694300 2 Spacer, Wheel (036)
23 07153500 2 Assembly, Tire 20 x 8.00-8 (031, 032, 033, 320)
07157100 2 Assembly, 22” Tire/Wheel (036)
07153600 2 Rim, 20” Tire (031, 032, 033, 320)
07157000 2 Rim, 22” Tire (036)
07133200 2 Tire 20 x 8.00-8 (031, 032, 033, 320)
07136900 2 Tire/Wheel Assembly 18 x 8.50-8 (036)
24 03516900 2 Spindle Cup
25 05707400 2 Ring-Retaining-External .750 x .050
26 00337700 2 Hub Cap
27 03652100 1 Damper-Hydraulic
28 03652200 2 Stud-Ball
29 03650900 1 Anchor-Spring-Top
30 08320200 2 Spring-Tension .085 x .60 x 5.13
31 03678000 1 Support - Shift Arm
32 03664700 1 Mount-Magnet
33 03359700 1 Magnet-HS
34 03677300 1 Strap-Torque Left Hand
35 05952400 1 Bolt-Hex .31-18 x 1.50 Grade 5
36 05963700 1 Bolt-Hex .31-18 x 2.25 Grade 5
37 03677400 1 Strap-Torque Right Hand
38 07413400 2 Screw-Tapping .31-18 x .50
39 03677600 1 Rod-Shift
40 03677900 1 Arm-Shift
41 06436200 1 Washer-Flat-Steel .406 x .812 x .065
42 03665100 1 Pivot-Reverse
43 05518000 3 Bushing-Flange .508 x .645 x .459 x .75
44 03652300 1 Anchor-Spring-Bottom
45 05947000 2 Bolt-Hex .31-18 x .75 Grade 5
46 07014700 1 Yoke .31-24 x 2.250
47 06444300 1 Washer-Flat-Steel .390 x .750 x .125
48 06811800 1 Pin-Clevis .31 x .822
49 06707100 1 Pin-Cotter .12 x 1.0
50 06441100 1 Washer-Flat-Steel .520 x .827 x .062
51 05521100 1 Bushing-Flange .515 x .750 x .745 x 1.00
52 05804500 2 Pin-Groove .188 x 1.25
53 03651700 1 Arm & Hub
54 05520600 1 Bushing-Flange .502 x 1 x .750
55 03684400 1 Shaft-Pedal (Single)
56 03687251 1 Pedal-Forward
57 07524000 1 Cover-Pedal-Forward

10
REAR WHEEL AND HYDRO DRIVE
Model 936034, 035, 330
Item Part No. Qty. Description
1 03678951 1 Mount-Transmission Left Hand
2 03678851 1 Mount-Transmission Right Hand
3 06529800 6 Nut-Locking-Center .31-18
4 06439400 2 Washer-Flat-Steel .328 x .875 x .062
5 07414100 6 Screw-Tapping .375-16 x .75
6 06539500 1 Nut-Jam .50-20 Grade 2
7 06307300 1 Washer-Lock .50 x .125 Reg.
8 07321400 1 Sheave-Transaxle
9 03693700 1 Fan, Transmission
10 07406900 4 Screw-Tapping 10-24 x .484
PT1080
1
2
3 4
5
6
7
8 9
10
11
12
13
14
15
16
17
16
18
19
20
21
5
13
13
22
23
24
25
27 28 13
29
30
31
32
33
34
35
36
32
37
38
39
34
26
42
5
40
41
13
41

11
REAR WHEEL AND HYDRO DRIVE
Model 936034, 035, 330
Item Part No. Qty. Description
11 03693200 1 Transaxle, Hydro
12 03693300 1 Rod-Transmission Disconnect
13 06713500 4 Pin-Hair .08 x .18 x 1.18
14 05960600 4 Bolt-Hex .31-18 x 2.75 Grade 5
15 06601900 2 Key-Square .188 x 2.0 x .188
16 06441500 4 Washer-Flat-Steel .755 x 1.375 x .062
17 03693600 2 Spacer, Wheel
18 07153500 2 Tire/Wheel Assembly 20 x 8.00-8 2 Ply
07153600 2 Rim-Sierra
07133200 2 Tire 20 x 8.00-8
19 03516900 2 Spindle Cup
20 05707400 2 Ring-Retaining-External .750 x .050
21 00337700 2 Hub Cap
22 03664700 1 Mount-Magnet
23 03359700 1 Magnet-HS
24 06437200 1 Washer-Flat-Steel .344 x .688 x 065
25 03693500 1 Rod-Shift
26 03693000 1 Bracket, Shiftrod
27 06436200 1 Washer-Flat-Steel .406 x .812 x .065
28 07014700 1 Yoke .31-24 x 2.250
29 06444300 1 Washer-Flat-Steel .390 x .750 x .125
30 06811800 1 Pin-Clevis .31 x .822
31 06707100 1 Pin-Cotter .12 x 1.0
32 06441100 7 Washer-Flat-Steel .520 x .827 x .062
33 05521100 1 Bushing-Flange .515 x .750 x .745 x 1.00
34 05804500 2 Pin-Groove .188 x 1.25
35 03651700 1 Arm & Hub
36 05520600 1 Bushing-Flange .502 x 1 x .750
37 03684400 1 Shaft-Pedal (Single)
38 03687251 1 Pedal-Forward
39 07524000 1 Cover-Pedal-Forward
40 07411500 4 Screw-Tapping .31-18 x .50 Hex Washer Head
41 07415400 2 Screw-Tapping .38-16 x .75 Hex Washer Head
42 03692900 1 Bracket, Transmission Support

12
HYDRO TRANSAXLE
Model 936034, 035, 330
PT1090

13
HYDRO TRANSAXLE
Model 936034, 035, 330
Item Part No. Qty. Description
1 70467 1 Main Housing, Assembly
2 70483 1 Side Housing, Assembly
3 70477 1 Center Section, Assembly
4 51048 1 Swashplate, trunnion Machined
5 70331 2 Block, Assembly
6 50928 10.5 oz Sealant
7 51190 14 Hex Flange Screw .25-20 x 1.25
9 51062 1 Shaft, Input
10 2000022 1 Ring, Retaining
11 50581 1 Spacer
12 50329 3 Ring, Retaining
13 51161 1 Seal, Lip .67 x 1.58 x .276
14 50315 1 Ball Bearing 17MM I.D. x 40MM O.D. 12MM
16 51064 1 Hex Flange Head Screw .313-24 x .75
17 51140 1 Lip Seal .18 x .32 x 7
18 51420 1 Arm Control
19 50551 2 Bearing , Thrust .30 x .52 x .13
23 51207 1 Washer, Check Plug Assembly
24 50966 1 Shaft, Motor
27 51130 1 Gear, Pinnion 13T
28 51129 1 10T/48T Gear
29 51043 1 Gear, 10T Jackshaft
30 51044 1 60T Bull Gear
31 51088 2 Sleeve Bearing .75 x 1.75 x .825
32 51089 2 Sleave Bearing (Outboard) .75 x 1.575 x .625
33 44875 2 Washer .75 x 1.50 13 THK
34 51066 2 Lip Seal Axle Seal
35 51354 1 Shaft, Axle .75 x 11.39 (Key Right Hand)
36 51353 1 Shaft, Axle .75 x 11.39 (Key Left Hand)
37 44096 2 Miter Gear (Splined)
38 44097 2 Miter Gear 15T
39 50146 1 Shaft
40 44871 2 Ring, Spiral Retaining
41 51083 1 Pin, Jackshaft
42 51100 1 Magnet, Ring
43 51136 1 Spring, Bypass
44 50016 2 Hydro Mounting Screw .38-24 x 2.5 Ling
45 51132 1 Filter
46 51133 1 Base, Filter
47 51091 1 Actuator, Bypass
48 51098 1 Rod, Bypass Actuator
49 51099 1 Arm, Bypass
50 51116 1 Retaing Ring .25 External
51 51081 1 Seal, Lip .741 x .25 x .25 TC
52 44371 1 Washer, Flat .625 I.D. x 1.00 O.D. x .05 THK
53 44145 1 Retaining Ring
54 51071 1 Bearing, Center Block
55 2003014 1 Spring, Helical Compression
56 2003017 1 Washer
57 78.5 oz 20W-50 Oil
58 44092 1 Brake Yoke
59 51072 1 Rotor, Brake
60 44132 2 Brake Puck
61 44134 1 Puck Plate
62 44127 2 Brake Actuating Pin
63 51146 2 HFHCS .25-20 x with Patch, Special Flange

14
HYDRO TRANSAXLE
Model 936034, 035, 330
Item Part No. Qty. Description
65 23711 1 Spacer
66 50884 1 Spring, Brake Arm Bias
67 44138 1 Square Head Bolt .313-24 Ribbed
68 51142 1 Arm Brake
69 44142 1 Slotted Hex Nut .313-24
70 44101 1 Cotter Pin .094 x .75
71 50819 1 Compression Spring Brake Anti-Drag
72 50132 3 Washer, HT .50 I.D. x 1.00 O.D. x .032
73 44130 2 Washer, Flat .34 I.D. x .875 O.D.
74 44761 1 Oil Seal .825 x 1.00 x .25
75 51084 1 Check Plug Assembly, .027 Washer
83 9004800-2506 2 Pin, Standard Headless
84 51143 1 Fitting, .316 SAE .157 Tube
85 41147 1 Hose, Expansion Tank
87 51251 1 Cap, Vent
88 50583 1 Bolt, Self tapping 10-32 x .50
93 51118 2 Spring Clip, Housing Thrust
94 44147 1 Bearing, Ball .62 x I.D. x 1.38 x .44
95 50837 1 Screw Socket Head Cap .313-24 x 1.50
96 51200 1 Spacer, Location
97 50870 1 Screw SFHCS .313-18 x 1.00
98 51365 1 Arm, Return
99 51097 1 Puck, Adjusting
100 51122 1 Washer .24 I.D. x 1.80 O.D. x .239
101 51131 1 Spring, Extension
102 51123 1 Spacer .25 I.D. .55 O.D. x .87
103 51223 1 Bracket, Torque
107 51134 1 Deflector
108 51069 1 Washer, Motor Shaft .71 I.D. x 1.15 O.D. x .03
109 9005110-5600 1 Plug SAE #6
110 50868 1 Screw, Torx Head .313-18
111 51144 1 O-Ring .103 x .299 I.D.
113 51179 1 Bracket, Support Expansion Tank
114 51184 1 Spring Guid
117 51124 1 Pin, Spring
119 51230 1 Fan, 7 inch
120 51231 1 Pulley
121 51244 1 Hex Lock Nut .50-20 (Nylon Insert)
122 51523 1 Washer, O.D. Slotted .53 x 1.63 x .06
123 51229 1 Bracket, Belt Keeper
124 70484 1 Center Section, Filter, Bypass Assembly
125 70488 1 Filter Assembly
126 70460 1 Kit, Fan/Pulley (Includes 119 - 122)
127 70483 1 Seal, O-Ring Kit
128 70503 1 Kit, Expansion Tank
129 51252 1 Cap, Expansion tank Shipping
130 51426 2 Stud, Ball
131 51421 1 Bracket, Crusie Damper
132 43083 2 Hex Nut .313-18
133 51425 1 Damper
134 51430 2 Washer, Helical Spring Lock .313, Regular

15
CLUTCH AND BRAKE-HYDRO
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
1 06537200 1 Nut-Locking-Jam .38-16
2 06436200 4 Washer-Flat-Steel .406 x .812 x .065
3 08310400 1 Spring-Compression .048 x .59 x 2.06
4 08327000 1 Spring-Compression .125 x .78 x 1.00
5 06535900 1 Nut-Jam .375-16
6 03689700 1 Rod-Brake (031, 032, 033, 036, 320)
7 03693400 1 Rod, Brake (034, 035, 330)
8 01582300 1 Trunnion (034, 035, 330)
9 03652453 1 Knob-Park Brake
10 03357400 1 Rod
11 06700300 1 Pin-Cotter .06 x .50
12 08325200 1 Spring-Tension .051 x .60 x 2.25
13 05717600 2 Ring-Retaining-External .250 x .010
14 03357300 1 Bellcrank-Parking Brake
15 07411900 2 Screw-Tapping 12-24 x .50
16 08828100 1 Switch, Interlock
17 06713500 2 Pin-Hair Internal .08 x .18 x 1.18
18 03357200 1 Rod-Parking Brake
19 07523600 1 Cover-Pedal-Brake
20 03651000 1 Pedal-Brake
21 05804500 3 Pin-Groove .188 x 1.25
22 03650500 1 Lever-Brake Switch
23 03686700 1 Weldment, Brake Arm
24 03357100 1 Lever-Parking Brake
25 06529800 1 Nut-Locking-Center .31-18
26 01305900 1 Shoulder Spacer
27 06214100 1 Bolt-Round Head Square Neck .31-18 x .75
28 07526700 1 Grip .062 x .375 x .750
29 08333200 1 Spring-Tension .095 x .85 x 4.38
30 06416800 5 Washer-Plastic .390 x .875 x .062
1
3 4
2
5
6
9
10
11
12
13
14
15
13 16
17
18
19
20
21
21
21
22
23
2
17
24
25
26
27
28
29
30
PT0034
5
2
7
8

16
HOOD, DASH AND BATTERY
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
1 03679300 1 Dash
2 06004600 2 Screw-Set 10-24 x .38
3 03653253 1 Knob-Throttle
4 06938800 1 Throttle Control-Tec/B & S
5 06436700 2 Washer-Flat-Steel .323 x .625 x .062
6 06529700 2 Nut-Locking-Center .25-20
7 03489900 1 Ignition Switch Key
8 07517700 1 Cap- Ignition Switch
9 06517400 1 Nut-Panel .562-24
10 06306900 1 Washer-Lock Internal .563 x .040
11 53606900 1 PTO Knob/Switch Assembly
12 06918300 1 Choke Cable (031, 032, 036, 320)
13 07406900 5 Screw-Tapping 10-24 x .484
14 06215700 2 Bolt-Round Head Square Neck .31-18 x .75
15 03651400 1 Holddown-Battery
16 03357600 1 Support-Dash-Top
PT0104
1
2 3
4
5
6
7 8 9
10
11
12 13 14
15
16
17
18
19
20
21
22
23
24
25
26
27 20 28
29
30
31
31
32
33
23
34
35
36
37
38
39
40
41
42
43
44
45
44
46
47
48
49
50
51
52
53
54
55
56
57
58
59
59
60
60
61
61
62
63
64
65
66
67
68
68
69
70
70
71
59
20

17
HOOD, DASH AND BATTERY
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
17 06436700 2 Washer-Flat-Steel .323 x .625 x .062
18 06530200 2 Nut-Locking-Nylon .31-18
19 03656600 1 Rod-Hood Prop
20 07411600 10 Screw-Tapping .250-20 x .37
21 03656700 1 Mount-Prop Rod
22 01320200 1 Wave Washer
23 06435800 5 Washer-Flat-Steel .31 x .734 x .065
24 06529700 1 Nut-Locking-Center .250-20
25 03657000 1 Cover- Switch
26 03656800 1 Switch-Light
27 03656900 1 Switch-Cruise
28 03634400 1 Battery w/Tube
29 02530700 1 Rubber Pad
30 03651200 1 Support-Dash-Base
31 07411500 5 Screw-Tapping .31-18 x .50
32 06529200 4 Nut-Hex .31-18
33 06307400 4 Washer-Lock .31 x .097
34 03651300 1 Brace
35 08314900 1 Spring-Tension .035 x .45 x 2.75
36 03673351 1 Side Panel-Right Hand
37 03673451 1 Side Panel-Left Hand
38 07412500 8 Screw-Tapping 12-16 x .500
39 03679159 1 Hood, Ariens with Slots (031, 032, 036, 320)
03653659 1 Hood, Ariens no Slots (033, 034, 035, 330)
40 03647300 1 Headlight-Left Hand (Includes 59, 60 & 61)
41 03647200 1 Headlight-Right Hand (Includes 59, 60 & 61)
42 06529200 2 Nut-Hex .31-18
43 06307400 2 Washer-Lock .31 x .097
44 06437500 4 Washer .328 x 1.0 x .094
45 06435500 2 Washer-Flat-Nylon .375 x 1.000 x .062
46 05946900 2 Bolt-Hex .31-18 x 1.00 Grade 5
47 03679200 1 Grill
48 00283500 1 Clevis Pin .243/.248 x 1.50
49 07413300 1 Screw-Tapping 12-24 x .50
50 03655000 1 Hood Latch
51 07526700 1 Grip .062 x .375 x .750
52 06440600 1 Washer-Flat-Steel .281 x 1.250 x .048
53 07413400 2 Screw-Tapping .31-18 x .50
54 03679400 1 Baffle-Hood (031, 032, 036, 320)
03657700 1 Baffle-Hood (034, 035, 330)
03670900 1 Baffle-Hood (033)
55 03358200 1 Brace-Throttle Control
56 06706900 1 Pin-Cotter .09 x .75
57 03665900 1 Locator-Hood
58 07406400 1 Screw-Tapping 10-12 x .50
59 07413000 8 Screw-Tapping 10-24 x .75
60 03617500 2 Lamp Socket
61 03420500 2 Headlight Bulb
62 07008400 1 Clip-Harness
63 07505700 1 Insulator
64 05946800 2 Bolt-Hex .25 - 20 x .75 Grade 5
65 06308000 2 Washer-Locking .250 x .077 Heavy
66 06533200 2 Nut-Hex .25-20
67 06445400 2 Washer-Flat-Steel .219 x .500 x .049
68 03673251 2 Bracket-Steering Assembly
69 06530200 4 Nut-Lock-Jam-Center .375-16
70 06437200 4 Washer-Flat-Steel .344 x .688 x .065
71 03673200 2 Bracket-Steering Assembly

18
STEERING
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
1 03600600 1 Steering Wheel 13
2 05803700 1 Pin-Roll .250 x 1.75
3 05947000 2 Bolt-Hex .31-18 x .75 Grade 5
4 06435800 2 Washer-Flat-Steel .31 x .734 x .065
5 05402500 1 Bearing-Flange .751 x 2 Holes x .81
6 06307400 2 Washer-Lock .31 x .097
PT0095
1
2
3
4
5
6
7
8
9
10
11
12
12
13
14
14
15
16
17
17
16
18
19
14
16
14
20 21
20
20
22
23
24
24
22
25
25
16
16
23
20
26 27
28
29
28
29
49
31
32
33
34
33
35
33
34
35
36
37
38
33
34
39
40
41
42
43
44 45
45 38
47
48
47
48
46
30

19
STEERING
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
7 06529200 2 Nut-Hex .31-18
8 03603100 1 Tube
9 05808400 1 Pin-Roll .250 x 1.000
10 03351700 1 Column, Steering
11 03649600 1 Cone-Steering Column
12 03672951 2 Bracket, Steering Gear
13 05957900 2 Bolt-Hex .38-16 x 1.50 Grade 5
14 05508000 4 Bushing-Flange .750 x 1.093 x .625 x 1.375
15 03493500 1 Gear, Steering
16 05707400 7 Ring-Retaining-External .750 x .050
17 06441500 6 Washer-Flat-Steel .755 x 1.375 x .062
18 05946800 6 Bolt-Hex .25-20 x .75
19 06529700 6 Nut-Locking-Center .25-20
20 06542000 4 Nut-Locking-Top-Flange .38-16
21 03351800 1 Arm, Steering Rod
22 06538000 2 Nut-Locking .563-18-Grade 5
23 03563100 2 Rod End, .38 Right Hand
24 07006300 2 Bolt-Button Head .38-16 x 1.25 Grade 5
25 06534700 4 Nut -Jam .375-24
26 02913300 1 Pin .25 .248 x 1.17 x 1.19
27 02902100 1 Pinion Gear-Steering
28 05958500 2 Bolt-Hex .38-16 x 1.75 Grade 5
29 05522100 2 Bushing-Sleeve .377 x .624 x .370
30 05531900 1 Bushing-.748 x 2.00 Self-Lubricating
31 03668600 1 Link-Drag (Includes 23 & 48)
32 03664300 1 Arm-Steering Spindle
33 06441500 7 Washer-Flat-Steel .755 x 1.375 x .062
34 05505700 4 Bushing-Sleeve .750 x .814 x 1.000
35 03675300 1 Spindle Left Hand
03675500 1 Spindle Right Hand
36 07012600 2 Fitting-Lube .25-28 x .256
37 03646600 1 Axle, Front
38 06529600 3 Nut-Locking-Center .38-16
39 07149400 2 Tire/Wheel Assembly 15 x 6.00-6
07149500 2 Wheel-with Bearings
05520700 4 Bushing-3/4 Bore
07047000 2 Fitting-Lube .25-28 x .97
07109900 2 Tire-Turf Saver 15 x 6.00-6 2 Ply
05434900 2 Bearing-Ball
40 03516900 2 Spindle Cup
41 00337700 2 Hub Cap
42 05522700 1 Bushing-Sleeve .377 x .623 x .775
43 05522000 1 Bushing-Sleeve .626 x 1.000 x .524
44 05958500 1 Bolt-Hex .38-16 x 1.75 Grade 5
45 06443400 2 Washer-Flat-Steel .390 x 1.500 x .125
46 05802100 1 Pin-Roll .188 x 1.13
47 06537400 2 Nut-Jam .375-24, Left Hand
48 03668700 2 Rod End, .38 Left Hand
49 03668500 1 Rod, Tie (Includes 23 & 48)

20
ATTACHMENT LIFT
Model 936031, 032, 033, 034, 035, 036, 320, 330
1
2
30
3
4
5
6
7
8
9
10
11
12
13
14
15 34
12
16
17
18
19
20
21
22
23
24
25
26
27
28
22
23
29
25
27
28
31
32
33
35
PT0114
13

21
ATTACHMENT LIFT
Model 936031, 032, 033, 034, 035, 036, 320, 330
Item Part No. Qty. Description
1 03665500 1 Cover-Lift Right Hand
2 07412600 2 Screw-Tapping 12-16 x 1.125
3 06111100 2 Screw-Machine .10-24 x .625
4 03348351 1 Lift Lever
5 03679500 1 Quadrant-Lift
6 05521600 2 Bushing-Flange .750 x .873
7 03689500 1 Arm-Lift
8 06215700 2 Bolt-Round Head Square Neck .31-18 x .75 Grade 5
9 06543100 2 Nut-Locking-Top-Flange .31-18
10 03665600 1 Cover-Lift Left Hand
11 06529700 1 Nut-Locking-Center .25-20
12 06436200 1 Washer-Flat-Steel .406 x .812 x .065
13 06707100 2 Pin-Cotter .12 x 1.0
14 03653800 1 Pivot-Pin
15 05952500 2 Bolt-Hex .25-20 x 1.50 Grade 5
16 03675000 1 Pin-Lift
17 08330300 1 Spring-Tension .048 x .44 x 2.12
18 03683000 1 Lever-Detent
19 08082800 1 Decal-Indicator 5 Position
20 03676200 1 Indicator-Deck Height
21 06000500 1 Screw-Set .25-20 x .25
22 06211800 4 Bolt-Round Head Square Neck .38-16 x .75
23 03687800 2 Bracket, Center Lift
24 06916000 1 J-Clamp
25 06534900 4 Nut-Flange .375-16
26 03687600 1 Lever, Center Lift
27 06436100 2 Washer, Flat-Steel .630 x 1.005 x .062
28 06711900 2 Pin, Hair External .12 x .31 x 2.37
29 05717600 1 Ring-Retaining-External .250 x .010
30 06541300 2 Nut,10-24 Low Crown, Acorn
31 03694500 1 Spring, Gas (031, 032, 033, 035, 320, 330)
03692100 1 Spring, Gas (034)
32 06435700 1 Washer-Flat-Steel .38 x .875 x .083
33 06713500 1 Pin-Hair Internal .08 x .18 x 1.18
34 06439000 2 Washer-Flat-Steel .812 x 1.50 x .135
35 03352700 1 Link, Lift
