Ariens Path-Pro SS21 Owner's manual

04535815C •7/14
Printed in USA
Path-Pro
E10
Owner/Operator Manual
Ръководство за работа на
ползвателя/оператора
Návod k obsluze
Betriebsanleitung
Manual del propietario/operador
Käyttöohjekirja
Manuel du propriétaire/utilisateur
Tulajdonosi/kezelői útmutató
Manuale del proprietario/operatore
Gebruikshandleiding
Brukerhåndbok
Instrukcja obslugi / operatora
Manualul proprietarului /
operatorului
Руководство владельца/
пользователя
Navodila za uporabo
Príručka majiteľa/obsluhy
Instruktionsbok
Kullanım Kılavuzu
Models
938310 – SS21
(SN 000101 +)
938313 – SS21EC
(SN 000101 +)
®

2
Ariens Company
655 West Ryan
Street
Brillion, Wisconsin
54110-1072 USA
Telephone
[phone]
Facsimile
[phone]
EC DECLARATION OF CONFORMITY ISSUED BY THE MANUFACTURER – ЕО ДЕКЛАРАЦИЯ
ЗА СЪОТВЕТСТВИЕ, ИЗДАВАНА ОТ ПРОИЗВОДИТЕЛЯ
– ES PROHLÁŠENÍ O SHODĚ,
VYDANÉ VÝROBCEM –
VOM HERSTELLER HERAUSGEGEBENE EG-KONFORMITÄT-
SERKLÄRUNG – DECLARACIÓN DE CONFORMIDAD CE EMITIDA POR EL FABRICANTE –
VALMISTAJAN ANTAMA EY-VAATIMUSTENMUKAISUUSVAKUUTUS – DÉCLARATION DE CON-
FORMITÉ CE ÉMISE PAR LE FABRICANT – A GYÁRTÓ ÁLTAL KIÁLLÍTOTT EK
MEGFELELŐSÉGI NYILATKOZAT – DICHIARAZIONE DI CONFORMITÀ CE DEL
PRODOTTO RILASCIATA DAL PRODUTTORE – EG- CONFORMITEITSVERKLARING,
UITGEGEVEN DOOR DE FABRIKANT– EF-SAMSVARSERKLÆRING FRA PRO-
DUSENTEN – DEKLARACJA ZGODNOŒCI Z PRZEPISAMI EC WYDANA PRZEZ PRO-
DUCENTA – DECLARAŢIE DE CONFORMITATE CE EMISĂDE PRODUCĂTOR –
СОСТАВЛЕННОЕ ПРОИЗВОДИТЕЛЕМ ЗАЯВЛЕНИЕ ОСООТВЕТСТВИИ
СТАНДАРТАМ ИНОРМАМ ЕС – ES-IZJAVA O SKLADNOSTI, KI JO JEG-DEKLARA-
TIONEN OM ÖVERENSSTÄMMELSE UTFÄRDAD AV TILLVERKAREN – E IZDAL
PROIZVAJALEC – ES VYHLÁSENIE O ZHODE, VYDANÉ VÝROBCOM – ÜRETİCİ
TARAFINDAN DÜZENLENEN EC UYGUNLUK BEYANI
We the undersigned, ARIENS COMPANY, certify that: Ние, долуподписаните от фирма ARIENS, удостоверяваме,
че: My, nížepodepsaní, ARIENS COMPANY, prohlašujeme, že: Der Unterzeichnete, ARIENS COMPANY,
bescheinigt, dass: Nosotros, los abajo firmantes, ARIENS COMPANY, certificamos que: Allekirjoittanut, ARIENS
COMPANY, vakuuttaa, että: Nous, soussignés ARIENS COMPANY, certifions que:Alulírott, ARIENS COMPANY,
tanúsítja, hogy: La sottoscritta società ARIENS COMPANY certifica che: Wij, de ondergetekenden, ARIENS
COMPANY, verklaren dat: Undertegnede, ARIENS COMPANY, bekrefter at: My, niżej podpisani, ARIENS
COMPANY, oświadczamy, że: Subsemnata ARIENS COMPANY, certifică: Мы (фирма ARIENS),
нижеподписавшиеся, настоящим заявляем, что: Spodaj podpisani ARIENS COMPANY potrjujemo, da je: My,
spoločnosťARIENS COMPANY vyhlasujeme, že: Undertecknad, ARIENS COMPANY, intygar att: Biz altta
imzasıbulunan, ARIENS COMPANY olarak tasdik ederiz ki:
Type: Тип: Typ: Typ:
Tipo:Tyyppi:Type:
Típus:Tipo: Type:
Typen: Typ: Tip:
Тип: Tip: Typ: Typ:
Tip:
Walk-Behind Snow Thrower – Cнегорин сръчно управление – Sněhová fréza s pojezdem
– Handgeführte Schneefräse – Caminar por detrás de la lanzadora de nieve –
Käsinohjailtava Lumilinko – Les Chasse-neige Autotractés – Tologatós hómaró –
Spazzaneve Semovente – aan de sneeuwruimer – Snøfreser – Odgarniacz śniegu do
prowadzenia przed sobą – Frezăde zăpadă – Cнегоочиститель, управляемый идущим
сзади оператором – Ročno vodljiva snežna freza – Snehová fréza s kráčajúcou obsluhou
– Gå bakom snöslungan – Kar küreme makinesi
Trade Name: Търговско название: Obchodní název: Handelsbezeichnung:
Nombre comercial: Kauppanimi: Appellation commerciale: Kereskedelmi név:
Nome commerciale: Handelsnaam: Handelsnavn: Nazwa handlowa: Nume
comercial: Название фирмы: Trgovsko ime: Názov výrobku:
Handelsbeteckning: Ticaret Unvanı:
Ariens
Model , Model Name, Serial Number:
Модел, Име на модела, Сериен номер:
Model, název modelu, výrobní číslo: Modell, Modellname und Seriennummer:
Modelo, Nombre, Nº de Serie: Malli, mallin nimi, sarjanumero: Modèle, nom du
modèle, numéro de série: Modell, Modellnév, Sorozatszám: Modello, Nome
modello, Numero di serie : Model, Model Naam, Volgnummer : Modell,
modellnavn, serienummer : Model, nazwa modelu, numer seryjny: Model, nume
model, număr serie: Модель, наименование модели, серийный номер:
Model, ime modela, serijska številka: Model, nModel, Model Adı, Seri
Numarası : ázov modelu, výrobné číslo: Modell, modellnamn, serienummer:
938310, Path-Pro SS21, 101+
938313, Path-Pro SS21EC,
101+
Conforms to: Съответства на: Odpovídá normě: mit den Anforderungen der folgenden Richtlinien übereinstimmt:
Cumple con: Täyttää seuraavat vaatimukset: Est conforme à: Megfelel: È conforme a: Voldoet aan: Er i samsvar
med: Jest zgodny z: În conformitate cu: Соответствует: V skladu z: Je v zhode s: Överensstämmer med:
Uygundur:
2006/42/EC, 2004/108/EC, 2002/88/EC
2000/14/EC amended by 2005/88/EC Conformity Assessment Annex V. 2000/14/EC изменена от 2005/88/EC
за оценка на съответствието приложение V. 2000/14/EC ve znění 2005/88/ES o posuzování shody příloze V.
2000/14/EC geändert durch 2005/88/EG Konformitätsbewertung Anhang V. 2000/14/EC modificada por
2005/88/CE evaluación de la conformidad del anexo V. 2000/14/EY muutettuna 2005/88/EY
vaatimustenmukaisuuden arviointi Liite V. 2000/14/CE modifiée par 2005/88/CE évaluation de la conformité aux
annexes V. 2000/14/EC módosított 2005/88/EK megfelelőség-értékelés V. mellékletének. 2000/14/EC
modificata dalla 2005/88/CE Valutazione Conformità, Allegato V. 2000/14/EG gewijzigd bij 2005/88/EG
conformiteitsbeoordeling bijlage V. 2000/14/EC endret ved 2005/88/EC konformitetsvurdering anneks V.
2000/14/EC zmieniona przez 2005/88/WE oceny zgodności załączniku V. 2000/14/EC modificatăprin
2005/88/EC evaluarea conformităii anexa V. 2000/14/EC amended by 2005/88/EC Conformity Assessment
Annex V. 2000/14/EC spremenjena z 2005/88/ES ocenjevanja skladnosti v Prilogi V. 2000/14/EC v znení
2005/88/ES o posudzovaní zhody prílohe V. 2000/14/EC ändrat genom 2005/88/EG
Överensstämmelseutvärdering Bilaga V. 2000/14/EC 2005/88/EC Uygunluk Değerlendirme Ek V ile değiştirilen.
688300 

3
Representative Measured Sound Power Level (Lwa) –
Представително измерено ниво на акустична
мощност (Lwa) – Representativní hodnota změřené
hladiny hlučnosti
(Lwa) – Repräsentativer gemessener
Geräuschpegel
(Lwa) – Nivel de potencia acústica rep-
resentativo medido (Lwa) – Tyypillinen mitattu äänite-
hotaso
(Lwa) – Niveau de puissance acoustique
représentatif mesuré
(Lwa) – Tipikus mért hangteljesít-
mény (Lwa) – Livello di potenza sonora rappresentativo
rilevato
(Lwa) – Representatief gemeten geluidsniveau
(Lwa) – Representativt målt lydeffektnivå (Lwa) – Zmier-
zony reprezentatywny poziom mocy akustycznej (Lwa) –
Nivel reprezentativ măsurat putere acustică (Lwa) –
Репрезентативный измеренный уровень звуковой
мощности (Lwa) – Tipična izmerjena raven zvočne moči
(Lwa) – Charakteristická zmeraná hladina akustického
výkonu (Lwa) – Representativ uppmätt ljudnivå (Lwa) –
Örnek ÖlçülmüşSes Güç Seviyesi (Lwa)
Guaranteed Sound Power Level (Lwa) – Гарантирано
ниво на акустична мощност
(Lwa) – Zaručovaná hod-
nota hladiny hlučnosti
(Lwa) – Garantierter Geräus-
chpegel
(Lwa) – Nivel de potencia acústica garantizado
(Lwa) – Taattu äänitehotaso (Lwa) – Niveau de puis-
sance acoustique garanti
(Lwa) – Garantált hangteljesít-
mény
(Lwa) – Livello di potenza sonora garantito (Lwa) –
Gegarandeerd geluidsniveau (Lwa) – Garantert lydef-
fektnivå
(Lwa) – Gwarantowany reprezentatywny
poziom mocy akustycznej
(Lwa) – Nivel garantat putere
acustică
(Lwa) – Гарантированный уровень звуковой
мощности
(Lwa) – Zajamčena raven zvočne moči (Lwa)
–
Zaručená hladina akustického výkonu (Lwa) –
Garanterad uppmätt ljudnivå
(Lwa) – Garanti Edilmiş
Ses Güç Seviyesi (Lwa)
938310, 938313: 100 dBA938310, 938313: 104 dBA
Engine Power (Kw @ RPM): Мощност на двигателя (Kw @ RPM): Výkon motoru při
regulovaných otáčkách (kW při ot./min): Motorleistung (kW bei U/Min): Potencia del
motor (Kw a RPM): Enimmäisteho (Kw @ RPM): Puissance moteur (kW au régime
max.): Motorteljesítmény (Kw @ RPM): Potenza max. del motore (kW a giri/min.):
Motor Vermogen (Kw @ RPM): Motoreffekt (Kw @ RPM): Moc silnika (kW przy
obr./min): Putere motor (Kw la RPM): Мощность двигателя (кВт при об/мин): Moč
motorja (kW pri vrt./min.): Výkon motora (Kw @ RPM) (kW / ot./min.): Motoreffekt (kW
@ varvtal): Motor Gücü (Kw @ RPM):
938310 3.0 @ 3650
938313 4.8 @ 3650
Fred J. Moreaux:
Director Product Conformance & Warranty (Keeper of
Technical File) / Началник Съответствие на продукта
иГаранция (Пазител на техническото досие) /
Správce shody výrobku a záruky (správce technické
dokumentace) / Director Product Conformance & War-
ranty (Archivar der technischen Akte) / Director de con-
formidad de los productos y de garantía (Conservador
de los archivos técnicos) / Tuotteen vaatimustenmu-
kaisuudesta vastaava johtaja (teknisen tiedoston
haltija) / Responsable de la conformité des produits et
de la garantie (dépositaire de la fiche technique) / Ter-
mék megfelelőségi és garanciális igazgató (műszaki
dokumentáció tárolásának felelőse) / Responsabile di
conformità del prodotto e garanzia (depositario del fas-
cicolo tecnico) / Directeur technische produktstandardi-
satie & garantie (Houder van het technische bestand) /
Ansvarlig for produktsamsvar (innehaver av teknisk fil) /
Dyrektor ds. zgodności produktów i gwarancji
(przechowujący dokumentacjętechniczną) / Director
conformitate şi garanţie produs (responsabil fişă
tehnică) / Директор по гарантии на изделия иих
соответствию стандартам (Хранитель технического
файла) / Direktor za skladnost in garancijo izdelka
(skrbnik tehnične dokumentacije) / Vedúci pre zhodu a
záruku výrobku (udržiavateľsúboru technickej doku-
mentácie) / Chef för produktöverensstämmelse och
garanti (innehavare av tekniska data) / Ürün Uygunluk
ve Garanti Müdürü (Teknik Dosya Saklayıcısı)
Ariens Company
Brillion, WI 54110-1072 USA
Signature – Подпис – Podpis
– Unterschrift – Firma –
Allekirjoitus – Signature –
Aláírás – Firma –
Handtekening – Signatur –
Podpis – Semnătură –
Подпись – Podpis – Podpis
– Namnteckning – Imza
07/25/2014
Date – дата – Datum –
Datum – Fecha –
Päivämäärä – Date –
Dátum – Data – Datum –
Dato – Data – Data –
дата – Datum – Dátum –
Datum – Tarih
David Sturges:
Authorized to Compile the Technical File / Упълномощен
да състави Техническото досие / Oprávněný vytvořit
technickou dokumentaci / ZAutorizado para compilar
los archivos técnicos / ur Anlage der technischen Akte
ermächtigt / Valtuutettu laatimaan teknisen tiedoston /
Autorisé à remplir la fiche technique / A műszaki doku-
mentáció összeállítására jogosult / Autorizzato alla
compilazione del fascicolo tecnico / Geautoriseerd om
het technische bestand samen te stellen / Autorisert til
å produsere den tekniske filen / Uprawniony do przy-
gotowania dokumentacji technicznej / Autorizat pentru
prelucrarea fişei tehnice / Уполномочен на
составление технического файла / Pooblaščenec za
pripravo tehnične dokumentacije / Oprávnený na zos-
tavenie súboru technickej dokumentácie / Auktoriserad
att kompilera den tekniska filen / Teknik DosyayıDerle-
meye Yetkili
Ariens Company
Great Haseley
Oxford
OX44 7PF UK
Signature – Подпис – Podpis
– Unterschrift – Firma –
Allekirjoitus – Signature –
Aláírás – Firma –
Handtekening – Signatur –
Podpis – Semnătură –
Подпись – Podpis – Podpis
– Namnteckning – Imza
07/25/2014
Date –
дата – Datum –
Datum – Fecha –
Päivämäärä – Date –
Dátum – Data – Datum –
Dato – Data – Data –
дата – Datum – Dátum –
Datum – Tarih
688300 

EN - 4
SAFETY. . . . . . . . . . . . . . . . . . . . . . . . . . 6
CONTROLS AND FEATURES . . . . . . . 12
OPERATION . . . . . . . . . . . . . . . . . . . . . 13
MAINTENANCE SCHEDULE . . . . . . . . 19
STORAGE . . . . . . . . . . . . . . . . . . . . . . . 20
TROUBLESHOOTING . . . . . . . . . . . . . 21
SERVICE PARTS . . . . . . . . . . . . . . . . . 22
SPECIFICATIONS. . . . . . . . . . . . . . . . . 22
ACCESSORIES. . . . . . . . . . . . . . . . . . . 22
WARRANTY . . . . . . . . . . . . . . . . . . . . . 21
Original Instructions.
THE MANUAL
Before operating unit, carefully and
completely read your manual. The contents
will provide you with an understanding of
safety instructions and controls during normal
operation and maintenance.
ENGINE MANUAL
The engine on this unit is covered by a
separate manual specific to the engine. This
manual is included in the literature package
that shipped with the unit. Refer to this
manual for engine service recommendations.
If the engine manual is not available, contact
the engine manufacturer for a replacement
manual.
MODEL AND SERIAL NUMBERS
When ordering replacement parts or making
service inquiries, know the Model and Serial
numbers of your unit.
Numbers are located on the product
registration form in the unit literature
package. They are also printed on a serial
number label on your unit (see Figure 1).
• Record unit model and serial numbers
here.
• Record engine model and serial
numbers here.
PRODUCT REGISTRATION
The Ariens dealer should register the product
at the time of purchase. Registering the
product helps the company process warranty
claims or contact you with the latest service
information. Claims meeting requirements
during the limited warranty period will be
honored, whether or not the product
registration card is returned with proof of
purchase.
Customer Note: If the Dealer does not
register your product, please fill out, sign and
return the product registration card to Ariens
or go to www.ariens.eu.
UNAUTHORIZED REPLACEMENT
PARTS
Use only Ariens replacement parts. The
replacement of any part on this unit with
anything other than an Ariens authorized
replacement part may adversely affect the
performance, durability and safety of this unit
and may void the warranty. Ariens disclaims
liability for any claims or damages, whether
warranty, property damage, personal injury or
death arising out of the use of unauthorized
replacement parts.
NOTE: A Parts Manual may be downloaded
from www.ariens.eu.
TABLE OF CONTENTS
INTRODUCTION
Figure 1
1. Unit Model & Serial Number Label
1

EN - 5
DELIVERY
Customer Note: If this product was
purchased without complete assembly and
instruction by a retailer, it is your
responsibility to:
• Read and understand all instructions
in this manual. If you do not
understand or have difficulty following
the instructions, contact your nearest
Ariens Dealer for assistance.
NOTE: To locate your nearest Ariens Dealer,
go to www.ariens.eu.
Before Operating Unit
1. Make sure all assembly has been
properly completed.
2. Understand all Safety Precautions
provided in the manuals.
3. Review control functions and operation
of the unit. Do not operate the unit
unless all controls function as described
in this manual.
4. Review recommended maintenance and
adjustments.
5. Review Limited Warranty policy.
6. Fill out a product registration card and
return it to Ariens Company or register
the product at www.ariens.eu.
DISCLAIMER
Ariens reserves the right to discontinue,
change and improve its products at any time
without notice or obligation to the purchaser.
The descriptions and specifications contained
in this manual were in effect at printing.
Equipment described within this manual may
be optional. Some illustrations may not be
applicable to your unit.
WARNING: Improper assembly or
adjustments can cause serious
injury.

EN - 6
Read these safety rules and follow them
closely. Failure to follow these rules could
lead to loss of control of unit, severe personal
injury or death to you or bystanders or result
in damage to property or the machine.
Safety Alert Symbols
SIGNAL WORDS
The safety alert symbols above and signal
words below are used on decals and in this
manual.
Read and understand all safety messages.
1. Danger
2. Warning
3. Caution
4. Notice
NOTICE: Indicates information or procedures
that are considered important but not hazard
related. If not followed property damage
could result.
5. Important
IMPORTANT: Indicates general reference
information worthy of special attention.
SAFETY DECALS
This snow thrower is capable of crushing or
amputating body parts. Failure to observe the
following safety instructions could result in
serious injury or death.
The safety decals on your machine are visual
reminders of the important safety information
found in this manual. All messages found on
your unit must be fully understood and
carefully followed. Safety decals found on the
machine are explained below.
Always replace missing or damaged safety
decals. Replacement decal information is in
the Parts Manual for your machine. Decals
can be ordered from your dealer.
See Figure 2 for safety decal locations.
SAFETY
WARNING: This snow thrower is
capable of crushing or amputating
body parts. Failure to observe the
safety instructions in the manuals
and on decals could result in serious
injury or death.
Tragic accidents can occur if the
operator is not alert to the presence
of children. Never assume that
children will remain where you last
saw them.
Gasoline is extremely flammable
and the vapors are explosive;
handle with care.
Stop engine and allow moving parts
to stop before leaving operator’s
position.
These are safety alert
symbols. They mean:
• ATTENTION!
• YOUR SAFETY IS
INVOLVED!
When you see this symbol:
• BECOME ALERT!
•OBEYTHE
MESSAGE!
DANGER: Indicates an
IMMINENTLY HAZARDOUS
SITUATION! If not avoided, WILL
RESULT in death or serious injury.
WARNING: Indicates a
POTENTIALLY HAZARDOUS
SITUATION! If not avoided, COULD
RESULT in death or serious injury.
CAUTION: Indicates a
POTENTIALLY HAZARDOUS
SITUATION! If not avoided, MAY
RESULT in minor or moderate injury.
It may also be used to alert against
unsafe practices.

EN - 7
1. Safety Decal Identification
2. Safety Decal Description
1. DANGER!
Danger!
ROTATING PARTS.
Keep clear of auger while
engine is running.
• Read Operator’s
Manual.
• Allow operation only by
properly trained adult,
never children.
• Stop engine and
remove ignition key
prior to leaving the
operator’s position for
any reason.
• Keep all controls,
guards and safety
devices properly
serviced and functional.
• Never direct discharge
towards persons or
property that may be
injured or damaged by
thrown objects.
08000917
Figure 2
4
2
1
3
2. DANGER!
Danger!
ROTATING PARTS! ONLY
use clean-out tool to clear
blockages. NEVER use
your hands. High speed
auger/impeller rotates
below discharge
opening. Wait for all
moving parts to stop
before removing clogs or
servicing.
3. DANGER!
Danger!
Read Owner/Operator
Manual.
Do not operate in rain.

EN - 8
RULES FOR SAFE OPERATION
This snow thrower is capable of amputating
hands and feet and throwing objects. Failure
to observe the following safety instructions
could result in serious injury.
The following safety instructions are based
on the B71.3 specifications of the American
National Standards Institute in effect at the
time of production.
4. DANGER!
Danger!
ONLY use clean-out tool to
clear blockages. NEVER
use your hands.
Never direct discharge
towards persons or
property that may be
injured or damaged by
thrown objects.
Keep people away from
unit while operating. Keep
children out of work area
and under watchful care of
a responsible adult.
Stop engine, remove key,
read manual before
making any repairs or
adjustments.
Read Owner/Operator
Manual.
Wear appropriate hearing
protection.
Training
Read, understand and follow all instructions
on the machine and in the manual(s) before
operating this unit. Be thoroughly familiar
with the controls and the proper use of the
equipment. Know how to stop the unit and
disengage the controls quickly.
Never allow children to operate the
equipment. Never allow adults to operate
the equipment without proper instruction,
including actual operation.
Keep the area of operation clear of all
persons, particularly small children. Keep
children under watchful care of a
responsible adult. Be alert and shut off unit if
children enter area.
Exercise caution to avoid slipping or falling,
especially when operating the snow thrower
in reverse.
Always remove key and/or wire from spark
plug before assembly, maintenance or
service. Unintentional engine start up can
cause death or serious injury.
Complete a walk-around inspection of the
unit to understand the unit, your work area,
and all safety decals.
Preparation
Always check overhead and side clearances
carefully before operation.
Always be aware of traffic when operating
along streets or curbs.
Thoroughly inspect the area where the
equipment is to be used and remove all
pets, doormats, sleds, boards, toys, wires,
debris and other foreign objects.
Disengage all clutches and shift into neutral
before starting the engine (motor).
Use only approved extension cords and
receptacles when starting units equipped
with electric starter. Do not connect electric
starter cord to any wiring system that is not a
three-wire grounded system.

EN - 9
Handle fuel with care; it is highly flammable.
• Use an approved fuel container.
• Never add fuel to a running engine or hot
engine.
• Fill fuel tank outdoors with extreme care.
Never fill fuel tank indoors.
• Never fill containers inside a vehicle or
on a truck or trailer bed with a plastic
liner. Always place containers on the
ground, away from your vehicle, before
filling.
• When practical, remove gas-powered
equipment from the truck or trailer and
refuel it on the ground. If this is not
possible, then refuel such equipment on
a trailer with a portable container, rather
than from a gasoline dispenser nozzle.
• Keep the nozzle in contact with the rim of
the fuel tank or container opening at all
times, until refueling is complete. Do not
use a nozzle lock-open device.
• Replace gasoline cap securely and wipe
up spilled fuel.
• If fuel is spilled on clothing, change
clothing immediately.
Adjust the auger/impeller housing height to
clear gravel or crushed rock surface.
Never attempt to make any adjustments
while the engine (motor) is running (except
when specifically recommended by
manufacturer).
Always allow unit and engine to adjust to
outdoor temperature before clearing snow.
Operation
Never leave a running unit unattended.
Always shut off engine before leaving unit.
Always remove key to prevent unauthorized
use.
Do not put hands or feet near or under
rotating parts. Keep clear of the discharge
opening at all times.
Moving and/or rotating parts can cut off body
parts such as fingers or a hand. Always
keep hands, feet and clothing away from all
rotating parts during operation.
Always keep hands away from all pinch
points.
Do not touch unit parts which might be hot
from operation. Allow parts to cool before
attempting to maintain, adjust or service.
Thrown objects can cause injury. Check for
weak spots on docks, ramps or floors. Avoid
uneven work areas and rough terrain. Stay
alert for hidden hazards.
Exercise extreme caution when operating on
or crossing gravel drives, walks or roads.
Adjust skid shoes so scraper blade does not
contact gravel. Stay alert for hidden hazards
or traffic.
After striking a foreign object, stop the
engine (motor), remove the wire from the
spark plug, thoroughly inspect the snow
thrower for any damage, and repair the
damage before restarting and operating the
snow thrower.
If the unit should start to vibrate abnormally,
stop the engine (motor) and check
immediately for the cause.
Stop the engine (motor) whenever you leave
the operating position, before unclogging the
auger/impeller housing or discharge guide,
and when making any repairs, adjustments
or inspections.
When leaving the machine unattended,
disengage the power take-off, lower the
attachment, set the parking brake, stop the
engine and remove the key.
When cleaning, repairing or inspecting the
snow thrower, make certain the
auger/impeller and all moving parts have
stopped. Disconnect the spark plug wire and
keep the wire away from the plug to prevent
someone from accidentally starting the
machine.
Do not run the engine (motor) indoors,
except when starting the engine and for
transporting the snow thrower in or out of the
building. Open the outside doors; exhaust
fumes are dangerous.
Never operate the snow thrower without
proper guards and other safety protective
devices in place.
Never direct the discharge toward people or
areas where property damage can occur
from thrown objects. Keep children and
others away.
Do not overload the machine capacity by
attempting to clear snow at too fast a rate.
Slow down and turn corners slowly.
Never operate the machine at high transport
speeds on slippery surfaces. Look behind
and use care when backing.

EN - 10
Do not operate in reverse unless absolutely
necessary. Always back up slowly and look
down and behind before and while backing.
Do not carry passengers.
Disengage attachment drive when traveling
from one work area to another.
Disengage power to the auger/impeller
when snow thrower is transported or not in
use.
Use only attachments and accessories
approved by the manufacturer of the snow
thrower (such as wheel weights,
counterweights or cabs).
This product is equipped with an internal
combustion type engine. Do not use unit on
or near any unimproved, forest-covered or
brush-covered land unless exhaust system
is equipped with a spark arrester meeting
applicable local, state or federal laws. A
spark arrester, if it is used, must be
maintained in effective working order by
operator.
Never operate the snow thrower without
good visibility or light. Falling snow, fog, etc.
can reduce vision and cause an accident.
Never operate unit after or during the use of
medication, drugs or alcohol. Safe operation
requires complete and unimpaired attention
at all times.
Never allow anyone to operate this unit
when their alertness or coordination is
impaired.
Avoid sharp edges. Sharp edges can cut.
Do not throw snow any higher than
necessary.
Clearing a Clogged Discharge Chute
Hand contact with the rotating
auger/impeller inside the discharge chute is
the most common cause of injury associated
with snow throwers. Never use your hand to
clean out the discharge chute.
To clear the chute:
1. SHUT THE ENGINE OFF!
2. Wait 10 seconds to be sure the
auger/impeller blades have stopped
rotating.
3. Always use a clean-out tool, not your
hands.
Maintenance and Storage
Secure unit so it will not tip over during
maintenance.
Before cleaning, removing clogs or making
any inspections, repairs, etc., disengage
clutch(es), stop unit and engine, remove
key, allow moving parts to stop. Allow hot
parts to cool.
Make sure the equipment is in safe working
condition. Check shear bolts and other bolts
and hardware at frequent intervals for proper
tightness. If components are worn or
damaged, replace with manufacturer’s
recommended parts.
Check clutch and brake operation
frequently.
Do not change engine governor settings or
over-speed engine.
Adjust and service as required. All motion of
drive wheels and auger/impeller must stop
quickly when control levers are released.
Always maintain unit in safe operating
condition. Damaged or worn out muffler can
cause fire or explosion.
Keep unit free of ice or other debris. Clean
up oil or fuel spills.
Always keep protective structures, guards,
and panels in good repair, in place and
securely fastened. Never modify or remove
safety devices.
Never store the machine with fuel in the fuel
tank inside a building where ignition sources
are present such as hot water heaters,
space heaters or clothes dryers. Allow the
engine to cool before storing in any
enclosure or covering the unit.
Always refer to operator's manual for
important details if the snow thrower is to be
stored for an extended period.
Maintain or replace safety and instruction
labels as necessary.
Run the machine a few minutes after
throwing snow to prevent freeze-up of the
auger/impeller.

EN - 11
OPERATOR ZONE
This unit is designed to be operated by one
person located in the operator zone (see
Figure 3).
Personal Protection
Do not operate the equipment without
wearing adequate winter garments. Avoid
loose fitting clothing that can get caught in
moving parts. Wear footwear that will
improve footing on slippery surfaces.
Wear adequate safety gear, including safety
glasses with side shields, and protective
gloves.
Do not wear loose clothing or jewelry, and tie
back hair that may get caught in rotating
parts.
Protect eyes, face and head from objects
that may be thrown from unit. Wear
appropriate hearing protection.
Slope Operation
Operate the snow thrower on level surfaces.
Stay off slopes and slippery surfaces.
Do not clear snow across the face of slopes;
go up and down. Exercise extreme caution
when operating on slopes. Do not attempt to
clear steep slopes.
Use a slow speed to avoid stops or shifts on
slopes. Avoid starting or stopping on a
slope.
Do not park unit on a slope unless
absolutely necessary. When parking on a
slope always block the wheels.
Do not operate near drop-offs, ditches, or
embankments. Unit can suddenly turn over if
a wheel is over the edge of a cliff or ditch, or
if an edge caves in.
Fuel
Do not run engine in an enclosed area.
Always provide good ventilation. Fumes
from engine exhaust can cause injury or
death.
Fuel is highly flammable and its vapors are
explosive. Handle with care. Use only an
approved gasoline container with an
appropriately sized dispensing spout.
No smoking, No sparks, No flames. Always
allow engine to cool before servicing.
Never fill fuel tank when engine is running or
hot from operation.
Never fill or drain fuel tank indoors.
Replace fuel cap securely and clean up
spilled fuel.
Never fill fuel containers inside a vehicle or
on a truck or trailer bed with a plastic liner.
Always place containers on the ground away
from your vehicle before filling.
When practical, remove gas-powered
equipment from the truck or trailer and refuel it
on the ground. If this is not possible, then
refuel on a trailer with a portable container,
rather than from a gasoline dispenser nozzle.
Keep the nozzle in contact with the rim of
the fuel tank or container opening at all
times until fueling is complete. Do not use a
nozzle lock-open device.
If fuel is spilled on clothing, change clothing
immediately.
Properly remove fuel before tipping unit up
onto housing, so no spills will occur.
Towing/Transporting
Always shut off engine, remove key and
close fuel shut-off valve or drain fuel when
transporting unit on a truck or trailer.
Use extra care when loading or unloading
unit onto trailer or truck. Secure unit chassis
to transport vehicle. Never secure from rods
or linkages that could be damaged. Do not
transport machine while engine is running.
Accessories
Use only Ariens Company-recommended
attachments that are appropriate to your use
and can be used safely in your application.
Operator Zone
Figure 3

EN - 12
1. Handlebar
2. Auger Control Bar
3. Auger Control Cable Assembly
4. Remote Discharge Chute Handle
Assembly (Model 938313)
5. Recoil Starter Handle
6. Discharge Chute Handle
(Model 938310)
7. Discharge Chute Deflector Handle
8. Discharge Chute
9. Wing Knob
10. Auger Paddle
11. Oil Fill (Models 938310)
12. Oil Fill (Model 938313)
13. Oil Drain Plug
14. Fuel Cap & Tank
15. Choke Control Knob
16. Engine Switch
17. Primer Bulb
18. Electric Start Button
(Model 938313)
19. Power Cord Receptacle
(Model 938313)
20. Fuel Shut-off Valve
21. Engine Guard
22. Fuel & Oil Door
CONTROLS AND FEATURES
11
13
1
2
3
5
4
67
10
8
9
16
19
18
15
17
12 14 20
21
22
Figure 4

EN - 13
CONTROLS AND FEATURES
See Figure 4 for all controls and features
locations.
Engine Switch
(Item 16)
The engine switch has
two positions:
1. OFF
Engine will not start or
run.
2. ON
Engine will start and run.
Choke Control Knob
(Item 15)
1. START
(Choke Closed):
Chokes off air to
engine for easier
starting.
2. RUN
(Choke Open):
Allows for normal
operation.
IMPORTANT: Gradually open choke after
engine starts.
Fuel Shut-off Valve
(Item 20)
IMPORTANT: The fuel shut-off valve MUST
be in the closed (off) position before
transporting the unit. The valve is closed
when it is narrow and vertical when viewed
from above.
The fuel shut-off
valve has two
positions:
1. OFF
Use this position
to service,
transport or store
the unit.
2. ON
Use this position
to run the unit.
Primer Bulb
(Item 17)
Pushing primer bulb adds fuel to engine for
easier start. See Start Engine (Recoil Start)
on page 15.
Recoil Starter Handle
(Item 5)
When pulled, handle will start engine. See
Start Engine (Recoil Start) on page 15.
IMPORTANT: Do not let handle snap back
against handlebar.
Electric Start Button
Model 938313
(Item 18)
When pushed, button will start a properly
choked and cranked engine. See Start
Engine (Electric Start) on page 15.
Discharge Chute
(Item 8)
Turn discharge chute handle (Item 6) to
control direction of snow discharge.
Remote Discharge Chute Handle
Assembly
(Item 4)
Model 938313
Move remote discharge chute handle forward
or backward to control direction of snow
discharge.
OPERATION
WARNING: AVOID INJURY. Read
and understand the entire Safety
section before proceeding.
1
2
2
1
1
2

EN - 14
GASOLINE
IMPORTANT: Always use gasoline that
meets the following guidelines:
• Clean, fresh gasoline.
• A minimum of 87 octane/87 AKI (91
RON). High altitude use may require a
different octane. Consult your Engine
Manual.
• Gasoline with up to 10% ethanol
(gasohol) or up to 10% MTBE (methyl
tertiary butyl ether) is acceptable.
• Use of any gasoline other than those
approved above may void the engine
warranty. If gas pumps are not marked
for the content of alcohol or ethers,
check ethanol and MTBE levels with
the fuel supplier.
• Do not modify the fuel system to use
different fuels.
• Never mix oil and gasoline.
NOTICE: All gasoline is not the same. If the
engine experiences starting or performance
problems after using a new gasoline, switch
to a different fuel provider or fuel brand.
IMPORTANT: Excessively oxygenated or
reformulated fuels (fuels blended with
alcohols or ethers) can damage the fuel
system or cause performance problems. If
any undesirable operating problems occur,
use a gasoline with a lower percentage of
alcohol or ether.
Fuel Tank
To add fuel:
1. Turn engine off and let cool for at least
three minutes.
2. Open fuel and oil door (Item 22) and
clean fuel cap and surrounding area to
prevent moisture and debris from
entering fuel tank.
3. Remove fuel cap.
IMPORTANT: Refer to Engine Manual for
correct type and grade of fuel.
4. Fill fuel tank to bottom of filler neck. See
SPECIFICATIONS on page 22 for fuel
tank capacity.
IMPORTANT: Do not overfill! This equipment
and/or its engine may include evaporative
emissions control system components,
required to meet EPA and/or CARB
regulations, that will only function properly
when the fuel tank has been filled to the
recommended level. Overfilling may cause
permanent damage to evaporative emissions
control system components. Filling to the
recommended level ensures a vapor gap
required to allow for fuel expansion. Pay
close attention while filling the fuel tank to
ensure that the recommended fuel level
inside the tank is not exceeded. Use a
portable gasoline container with an
appropriately sized dispensing spout when
filling the tank. Do not use a funnel or other
device that obstructs the view of the tank
filling process.
5. Replace fuel cap and tighten.
6. Clean up any spilled fuel and close fuel
and oil door.
Fuel Stabilizer
Gasoline left in the fuel system for extended
periods without a stabilizer will deteriorate,
resulting in gum deposits in the system.
These deposits can damage the carburetor
and the fuel hoses, filter and tank. Prevent
deposits from forming in the fuel system
during storage by adding a quality fuel
stabilizer to the fuel. Follow the
recommended mix ratio found on the fuel
stabilizer container.
ENGINE OIL
Model 938313
To check oil level:
1. Turn engine off and let cool for at least
three minutes.
2. Open fuel and oil door (Item 22) and
remove cap from oil fill.
3. Check oil level on dipstick. Oil level must
be maintained at safe operating level.
See SPECIFICATIONS on page 22. See
Engine Manual for detailed information.
4. Replace cap and close door.
To add oil:
1. Turn engine off and let cool for at least
three minutes.
2. Open fuel and oil door (Item 22) and
remove cap from oil fill.
3. Add 5W-30 oil and replace cap. Do not
overfill.
4. Clean up any spilled oil and close door.
Model 938310
To check oil level:
1. Turn engine off and let cool for at least
three minutes.
2. Remove cap from oil fill (Item 11).
3. Check oil level on dipstick. Oil level must
be maintained at safe operating level.
See SPECIFICATIONS on page 22. See
Engine Manual for detailed information.
4. Replace cap.

EN - 15
To add oil:
1. Turn engine off and let cool for at least
three minutes.
2. Remove cap from oil fill (Item 11) and
add 5W-30 oil. Do not overfill.
3. Replace cap.
4. Clean up any spilled oil.
TRANSPORTING UNIT
1. Always shut off engine, remove key and
close fuel shut-off valve when
transporting on a truck or trailer.
2. Use extra care when loading or
unloading onto truck or trailer. Do not lift
using discharge chute handle (Item 6).
3. Secure unit chassis to transport vehicle.
Never secure from rods or linkages that
could be damaged.
4. Do not transport unit while engine is
running.
OPERATION
Start Engine (Recoil Start)
1. Check oil level. See Engine Oil on
page 14.
2. Position discharge chute (Item 8) in a
safe direction.
3. Move engine switch (Item 16) to ON
position.
4. Open fuel shut-off valve (Item 20).
5. If engine is cold, turn choke (Item 15) to
CLOSED position.
NOTICE: Do not apply choke to a warm
engine.
6. Push primer bulb (Item 17) twice.
NOTICE: Do not push primer bulb to start a
warm engine.
7. Slowly pull recoil starter handle (Item 5)
until engine compression makes pulling
difficult. Let starter rewind a little, and
then pull smoothly and quickly to start
engine.
8. Repeat step 7 as needed.
9. Gradually open choke after engine
starts.
IMPORTANT: If engine does not start after
three attempts, see TROUBLESHOOTING
on page 21.
10. Pull auger control bar (Item 2) back to
handlebar to start auger; release bar to
stop auger.
Start Engine (Electric Start)
Model 938313
1. Check oil level. See Engine Oil on
page 14.
2. Position discharge chute (Item 8) in a
safe direction.
3. Connect a power cord to power cord
recepticle (Item 19) and then plug cord
into a wall outlet.
CAUTION: Use cord that is minimum of
13 amp, 16 Gauge, 3 wire grounded plug, UL
listed, CSA Certified. Cord must be labeled
suitable for outdoor use.
4. Move engine switch (Item 16) to ON
position.
5. Open fuel shut-off valve (Item 20).
6. If engine is cold, turn choke (Item 15) to
CLOSED position.
NOTICE: Do not apply choke to a warm
engine.
7. Push primer bulb (Item 17) twice and
then press electric start button (Item 18).
NOTICE: Do not push primer bulb to start a
warm engine.
8. When engine starts, disconnect power
cord from wall outlet, then disconnect
cord from power cord recepticle.
IMPORTANT: If engine does not start after
three attempts, see TROUBLESHOOTING
on page 21.
9. Pull auger control bar (Item 2) back to
handlebar to start auger; release bar to
stop auger.
Discharge Chute
(Item 8)
Model 938310
IMPORTANT: Always throw snow in a safe
direction, away from people and windows.
To control the discharge of snow:
1. Turn discharge chute handle (Item 6) in
the direction you want to throw snow.
2. Loosen wing knob (Item 9) and move
discharge chute deflector handle
(Item 7) up or down to control snow
throw height.
3. Tighten wing knob in desired position.
If chute becomes frozen and does not turn
correctly, take unit into warm area until
controls are unfrozen.
CAUTION: Do not use chute handle to lift the
unit.

EN - 16
Remote Discharge Chute Handle
Assembly
(Item 4)
Model 938313
IMPORTANT: Always throw snow in a safe
direction, away from people and windows.
Move remote discharge chute handle forward
or backward to choose the direction to throw
snow.
If chute becomes frozen and does not turn
correctly, take unit into warm area until
controls are unfrozen.
Stop Engine
1. Release auger control bar (Item 2).
2. Turn engine switch (Item 16) to OFF
position.
3. If finished with unit, close fuel shut-off
valve (Item 20).
MAINTENANCE
Replace Auger Paddles
Replace auger paddles when paddles are
worn down to wear indicator holes. See
Figure 5.
IMPORTANT: Always replace auger paddles
in pairs. Do not replace one paddle only.
See MAINTENANCE SCHEDULE on
page 19.
1. Move engine switch (Item 16) to OFF
position and remove key. Allow unit to
cool.
2. Tip unit back onto engine guard. Do not
tip further than engine guard allows or oil
may leak out of engine.
3. Remove six hex bolts and nuts per
paddle. Discard hardware, spacers and
paddles. See Figure 6.
NOTICE: Do not remove center plate.
4. Position new paddles with wear indicator
holes on the left side as you face the
unit.
5. Install spacers into paddle holes and
secure paddle with new hex bolts and
nuts.
6. Tighten nuts to 5.6 – 10.2 N•m. Do not
overtighten.
7. When both paddles are installed, rotate
auger paddles by hand. Ensure that
paddles do not rub on housing and are
tightly attached.
8. Return unit to operating position.
9. Remove slack from auger cable. See
Adjust Auger Cable on page 17.
Figure 5
1
1
1. Wear Indicator Hole
Figure 6
1
1. Bolt and Nut Locations
2. Paddle
3. Center Plate
2
1
3

EN - 17
Adjust Auger Cable
See Figure 7.
1. Move engine switch (Item 16) to OFF
position and remove key. Allow unit to
cool.
2. Slide plastic sleeve up to auger control
bar.
3. Insert Z-hook into appropriate hole in
adjustment bracket. When auger control
bar is disengaged, there should minor
slack in cable and no tension.
4. Engage auger control bar to ensure
proper operation. There should be no
excessive tension on cable.
5. Lower plastic sleeve.
Replace Belt
See MAINTENANCE SCHEDULE on
page 19.
1. Move engine switch (Item 16) to OFF
position and remove key. Allow unit to
cool.
2. Remove five tapping screws from belt
cover and remove belt cover. Retain all
parts.
3. Disconnect extension spring from idler
bracket. See Figure 8.
4. Remove belt from drive pulley, idler and
engine sheave.
5. Install new belt on engine sheave, idler
and drive pulley. Route belt between
idler and belt finger on idler bracket.
6. Reinstall extension spring.
7. Reinstall belt cover.
Replace Scraper Blade
See MAINTENANCE SCHEDULE on
page 19.
1. Move engine switch (Item 16) to OFF
position and remove key. Allow unit to
cool.
2. Tip unit back onto engine guard.
3. Remove nuts, bolts, scraper support and
scraper blade. Retain hardware. Discard
scraper blade.
4. Check condition of scraper support.
Replace if worn or damaged.
5. Insert scraper support into new scraper
blade. The D-shaped cutout must be on
the left (drive belt side). See Figure 9.
Figure 7
2
3
1. Auger Control Bar
2. Plastic Sleeve
3. Z-hook
4. Adjustment Bracket
1
4
1
2
36
4
Figure 8
1. Extension Spring
2. Drive Pulley
3. Idler
4. Idler Bracket
5. Belt Finger
6. Engine Sheave
5

EN - 18
6. Position scraper assembly under
housing. See Figure 10.
• D-shaped cutout must be on the left.
• Edge must point down and forward.
• Scraper assembly bolt holes must
align with square bolt holes in auger
housing.
7. Move scraper assembly backward and
up until small lip on top of scraper blade
contacts bottom lip of housing.
8. Install bolts and nuts. Tighten nuts to
4.52 – 5.65 N•m. Threads must protrude
beyond the nut.
9. Return unit to operating position.
IMPORTANT: If auger paddles are pulling too
strongly or scraper blade is not clearing
completely, loosen nuts (do not remove) and
slide scraper assembly down slightly. Tighten
nuts.
Adjust Remote Chute Rotation
Cables
Model 938313
1. Move engine switch (Item 16) to OFF
position and remove key. Allow unit to
cool.
2. Open fuel and oil door (Item 22) to
access chute rotation cable adjustment
screws.
3. Loosen chute rotation cable adjustment
screws. See Figure 11.
4. Pull cable covers to the right to remove
slack.
5. Tighten screws and close fuel and oil
door.
IMPORTANT: Remote chute rotation cables
may also be accessed from under unit by
tipping unit forward.
FOR BEST PERFORMANCE
• For complete snow removal, walk slowly
and slightly overlap each path previously
taken.
• Position discharge chute downwind
when possible.
• Do not pick up gravel and rocks. Push
down slightly on handlebar to avoid
picking up debris.
• Inspect auger before each use and
remove any accumulation / debris.
• Check oil level before each use.
• Clean unit after each use.
Figure 9
Figure 10
1. Scraper Blade Edge
1
1. Chute Rotation Cable Adjustment
Screws
1
Figure 11

EN - 19
IMPORTANT: Proper maintenance can
prolong the life of unit. The following chart
shows the recommended service schedule.
MAINTENANCE SCHEDULE
WARNING: AVOID INJURY. Read
and understand the entire Safety
section before proceeding.
Interval Task Action
Each Use
Clean unit. Remove snow and debris with a soft-bristled
brush. Do not use harsh abrasives or cleaners.
NOTICE: Protect painted surfaces with
automotive-type wax.
Check engine oil. See Engine Oil on page 14.
Follow engine
maintenance schedule.
Perform scheduled engine maintenance. Refer
to Engine Manual for detailed instructions.
Every 10 Hours
Check fasteners. Check all fasteners. Replace missing or
damaged fasteners. Tighten all nuts and bolts to
correct torque values.
Check auger paddle
wear.
Replace when auger paddles are worn to wear
indicator holes. See Replace Auger Paddles on
page 16.
Check scraper blade
wear.
Do not allow scraper blade to wear down too far
or auger housing will become damaged. See
Replace Scraper Blade on page 17.
As Needed
Check belt wear. Adjust auger cable as needed. Replace when
damaged or when auger stops or stutters during
operation. See Replace Belt on page 17.
Replace scraper blade. Replace when damaged or when scraper blade
has been adjusted down as far as possible and
does not touch surface or clear properly. See
Replace Scraper Blade on page 17.

EN - 20
SHORT TERM
Never spray unit with high pressure water or
store unit outdoors.
Inspect unit for visible signs of wear,
breakage or damage and repair as needed.
Keep all nuts, bolts and screws properly
tightened and know unit is in safe working
condition.
Store unit in a cool, dry, protected area.
Protect bare-metal areas with a light coat of
oil or anti-rust compound.
LONG TERM
Perform all short term storage items.
Touch up all scratched painted surfaces.
Fuel System
Gasoline left in the fuel system for extended
periods without a stabilizer will deteriorate,
resulting in gum deposits in the system.
These deposits can damage the carburetor
and the fuel hoses, filter and tank. Prevent
deposits from forming in the fuel system
during storage by adding a quality fuel
stabilizer to the fuel. Follow the
recommended mix ratio found on the fuel
stabilizer container.
To treat the fuel system for storage:
1. Add fuel stabilizer (Ariens part number
00592900) according to manufacturer’s
instructions.
2. Run engine for at least 10 minutes after
adding stabilizer to allow it to reach the
carburetor.
Never store the engine with fuel in the fuel
tank inside of a building with potential
sources of ignition.
TO TAKE THE UNIT OUT OF
STORAGE
1. See the Engine Service Manual to
prepare engine for service.
2. Put fresh, clean fuel in the fuel tank.
3. Begin the maintenance schedule.
STORAGE
