Aristo 608-4X User manual

Assembly Instruction
Item# 608-4X
Aristo Wooden Pet House End Table
RF40103
Allen Key
Hardware
1/4
LIST OF WOODEN PARTS
x 2
x 2
x 8
RF10052
Screw JCB M6 x 30
RF44013
Washer
RF40002
Spring
x 1
x 2
RF40009
Metal Pin
x 1
RF40258
Metal Handle
A
Top
B
Shelf
C
Left Panel
D
Right Panel
G
Back Panel
E
Bottom
F
Door
x 1 x 1 x 1
x 1 x 1 x 1 x 1
AB
E
C
DFG

2/4
E
D
D
B
G
E
x 2
RF10052
Diagram1.
Diagram2.
Step 1.
Attach Bottom (E) to Right Panel (D) by using
Screws (RF10052) as per diagram 1.
Step 2.
Place the shelf (B) and Back Panel (G) to the unit
as per diagram 2.

3/4
C
E
B
A
x 2
RF10052
x 4
RF10052
Diagram3.
Diagram4.
Step 3.
- Attach the Handle (RF40258) to the Left Panel (C).
- Attach Left Panel (C) to the unit by using Screws (RF10052)
as per diagram 3.
Step 4.
Upright the unit. Attach Top (A) by using Screws (RF10052)
as per diagram 4.
C
x 1
RF40258

4/4
RF40009
x 2
RF44054
x 2
RF40002
x 2
F
Step 5.
Diagram5.
Place Spring (RF40002), Door Pin (RF40009), and Washer (RF44054)
to pre-drilled holes on Door (F) as per diagram.
(Tip: Carefully hold the pins to prevent it from bouncing o). Insert
the pin on top of Door (F) to the hole on Shelf (B) rst, then place
the pin on bottom of Door (F) to Panel (E). Ensure the top and
bottom pins on Door (F) are inserted into the holes on Panel (E).
E
B
Tip:
Carefully hold the pins to
prevent it from bouncing
o.
