Distinguishing features.
A thought for our future
“Efficiency”
Means being able to provide your family unbelievable clean clothes and
in the process providing the future generation precious natural
resources, saving you money and protecting the environment, without
sacrificing comfort. Through its horizontal axis wash system using
dramatically less water and less energy than conventional laundry pairs
combined with high spin speeds extracting water, superior to that of a
conventional machine, orchestrated in concert with the sensor control
dryer preventing any damage to your clothes caused by high heat and
over-drying.
Laundry
Award winning softness
Stains from A to Z
“Super Wash”
The claim that your washing will be truly super with Ariston’s new
washing machine is more than just a promise. Ariston’s new washing
machine features an electronic control module which means that it is
able to process the quantity and type of wash and decide the right
combination of water, temperature and spin speed with a high level of
precision to offer you a better performance and great results –
attacking all of the stains requiring particular attention to defeat.
Thanks to its Dynamic Wash System involving specific action of the
calibrated drum allows the detergent to wash better than ever and
helps get rid of all traces of dirt.
As soothing as a lullaby
“Super Silent”
Helps your family spend time together without being disturbed,
enjoying maximum freedom all the time. So you can switch on the
washing machine whenever you want, even while asleep. Freedom that
satisfies all needs. This is possible thanks to special sound-absorbing
materials, and a new tri-phase motor never used before in washing
machines. This laundry is designed to achieve an outstanding
performance without any noisy mechanical interference.
Ariston’s washing machines are able to ensure outstandingly ultra-low
noise levels, similar to a whisper or a lullaby.
“Woolmark Platinum Care”
Ariston is the only brand worldwide which, has obtained
"Woolmark Platinum Care". This is the highest certification awarded
by “The Woolmark Company“ to the brand with such a high standard of
washing quality that you can now wash those garments in a washing
machine which once upon a time could only be hand washed.
And so from now on if you own a new Ariston washing machine, it is
a real delight to find the words “hand wash only” on your favorite
garments – this means that they can go in your Ariston washing
machine and you can be certain of obtaining truly outstanding results.
A unique design makes
your house unique too.
The central philosophy of M. Hasuike’s design is essentiality and
harmony combined in a totally distinctive style.
The elegant, rounded, soft lines of the new laundry line, is a clear
example of this philosophy displayed in the unique door and detergent
drawer design, in the shape of the control panel and in the other
exclusive features.
Particular attention to product design is aimed at obtaining structures
which are solid, innovative, functional: an Ariston tradition.
The new collection is dedicated to those who wish to be surrounded by
distinctive, beautiful objects which add warmth and beauty to the home.
ARI_ FS_LVB_USA _2-15_b3 28-03-2008 11:46 Pagina 4

76
170º Sanitary Cycle
Cleaning without additives is a nice
option you can choose with Ariston.
Its internal heating element boost the
water temperature for sanitizing
results.
Detergent loss
prevention
100% detergent
cleaning power is
captured thanks to the
pressure system which
keeps the active soap
in the washer and not
down the drain. So it is
nice to know your
washing machine is not
wasting a drop of
detergent providing the
maximum in cleaning
efficiency.
7
8
No more pain,
no more stains
Even the most stubborn stains
disappear without any pre-wash thanks
to the special Bleach compartment
which integrates the selected program
increasing the additive’s cleaning
power. And above all there is no need
to pre-wash by hand when
combined with the
Soaking Option.
9
You choose when
to wash
The Delay Timer lets you program the
wash start time for any time of the day
even if you are not at home, up to
24 hours in advance. This includes the
dryers which gives you a delay time of
up to 12 hours. Now you can really
react to your schedule.
11 Crease Care
In each drying
program the special
final Crease Care option,
periodically tumbles the
clothes until you come
back eliminating chance
of wrinkles.
Post Crease Care can
be combined with the
delay dry on the dryers
eliminating any wrinkling
of clothes prior to the
start of the cycle.
12
10
1
Your daily wash
If you want fresh, clean
laundry every day, the
Daily Wash program lets
you freshen up garmets
of different fabrics in no
time at all – 30 minutes
for a 7.5 pounds load
washing in tempertures
up to 120˚F.
Need it in a pinch?
3
Detergent free too
You will not find any traces of
detergent which may ruin your
garments or irritate sensitive skin. The
special Extra Rinse option lets you add
a further rinse level to the selected
program in order to get rid of all traces
of detergent.
4
Controlled results
Your washing machine is
constantly monitored in order
to ensure best washing results thanks to
Sensor System – a series of control
systems. Your dryer is equipped with
Moisture sensor constantly monitoring
the dryness level you desire. Just set and
forget and your clothes will come out at
the dryness level you desire.
2
As soft as silk
Thanks to the Silk
program, machine washing a silk
garment as if it were a cotton item will
become a completely normal action.
5
Laundry
6
Air Fluff
Air Fluff option is a
10 minute cycle for
you dryer that helps
refresh the clothes
that have been in your
closet for a long time:
eliminating any bad
smells.
Better than ever
Improve the efficiency of your home with
a washer that holds the lowest
operating cost of any washer available;
exceeding the requirements of
Energy Star and still allowing you
to handle big loads up to 15lbs.
Less time spent
ironing, more free time
Ariston’s new washing machine’s special
Easy Iron option provides the ability to
eliminate wrinkling caused when clothes
are left in the drum. Just press the easy
iron option button and the clothes will be
held in water until you press the Easy
Iron button again. This means no
wrinkles. Now it will not only
be a pleasure to do your
laundry but ironing will be
quicker and easier.
ARI_ FS_LVB_USA _2-15_b3 28-03-2008 11:46 Pagina 6

8
Pretty efficient
The platinum line of laundry from Ariston is not only efficient in their
operation, lowest energy rating in its class, but also provides an
opportunity to create an efficient laundry room even if space is an
obstacle. Stack them as shown and enjoy the high class platinum finish
coupled with the elegantly rounded style of the control panel, large and
unique door design, in addition to it having capacity up to 15lbs of laundry
will make the least favorite room in your home a pleasure to visit.
9
Washers
AW 125 NA
AW 129 NA
AW 149 NA
1200 rpm spin speed
Electronic / Smart Controls
Multiple spin speed adjustments
Multiple Temperature settings
Energy Star certified
11 wash settings
Super Silent Triphase Motor
Woolmark Platinum Care
Super Wash option
Easy Iron option
Pre-wash option
Extra Rinse option
Daily Wash
Silk program
Stain Removal / Bleach program
13 lbs maximum load capacity
12 lbs Energy test washing capacity
Stainless Steel Drum / Tub
Dimensions (HxWxD): 33.5''x23.4''x21.1''
Stainless Steel Look / Platinum Color
1200 rpm spin speed
Electronic / Smart Controls
Multiple spin speed adjustments
Multiple Temperature settings
Energy Star certified
11 wash settings
Super Silent Triphase Motor
Woolmark Platinum Care
Super Wash option
Easy Iron option
Pre-wash option
Extra Rinse option
Daily Wash
Silk program
Sanitary Cycle (internal heating element)
Soaking option
16 lbs maximum load capacity
15 lbs Energy test washing capacity
Stainless Steel Drum
Dimensions (HxWxD): 33.5''x23.4''x22.8''
Stainless Steel Look / Platinum Color
1400 rpm spin speed
Electronic Display / Smart Controls
Multiple spin speed adjustments
Multiple Temperature settings
Energy Star certified
11 wash settings
Super Silent Triphase Motor
Woolmark Platinum Care
Super Wash option
Easy Iron option
Pre-wash option
Delay Timer (up to 24 hs)
Daily Wash
Silk program
Sanitary Cycle (internal heating element)
Soaking option
16 lbs maximum load capacity
15 lbs Energy test washing capacity
Stainless Steel Drum
Dimensions (HxWxD): 33.5''x23.4''x22.8''
Stainless Steel Look / Platinum Color
ARI_ FS_LVB_USA _2-15_b3 28-03-2008 11:46 Pagina 8

10
Elegant Applications
Increase you work top and build your Aristons Platinum Series laundry
undercounter. If ventilation is an issue look to utilizing the largest
condensor dryer on the market. Now you can dry your clothes anywhere
without the need of external venting/duct work. If it is time to refresh
your laundry room, check out this new line and enjoy the many features
that come inside this pretty wrapper.
11
Dryers
AS 65 VXS NA
ASL 65 VXS NA
ASL 75 CXS NA
Vented - Electromechanical Controls
Bidirectional Rotation
Bull-eye see-through door
Removable lint filter
Stacking Kit included
Sensor Controls
Timed Dry
Easy Iron Option
Air Fluff Option
15 lbs maximum load capacity
Stainless Steel Tub / Drum
Dimensions (HxWxD): 33.5''x23.4''x21.7''
Stainless Steel Look / Platinum Color
Vented - Electronic Controls
Bidirectional Rotation
Bull-eye see-through door
Removable lint filter
Stacking Kit included
End noise signal
Sensor Controls
Timed Dry
Easy Iron Option
Air Fluff Option
Delay Timer (up to 18 hs)
Pre and Post Creasecare
Wool Program
15 lbs maximum load capacity
Stainless Steel Tub / Drum
Dimensions (HxWxD): 33.5''x23.4''x21.7''
Stainless Steel Look / Platinum Color
Condenser - Electronic Controls
Bidirectional Rotation
180º (reversible) full metal door
Removable lint filter
Stacking Kit included
End noise signal
Sensor Controls
Timed Dry
Easy Iron Option
Air Fluff Option
Delay Timer (up to 12 hs)
Pre and Post Creasecare
16 lbs maximum load capacity
Stainless Steel Tub / Drum
Dimensions (HxWxD): 33.5''x23.4''x23.0''
Stainless Steel Look / Platinum Color
ARI_ FS_LVB_USA _2-15_b3 28-03-2008 11:46 Pagina 10

12
Problem Solved
A conventional dryer not an option in your home?
Check out the Ariston line up of combination washer-dryers. Offered in both
the new Platinum Series as well as the traditional white, fitting your design
needs. So if the connections are not available consider this all in one unit
boasting up to a 13lb washing capacity or an efficient 6-8 pounds washing
and drying load without having to remove the clothes. Of course these
machines offer all of the needed features from a daily cycle to a sanitary wash.
13
Combination washer-dryers
AWD 129 NA
1200 rpm spin speed
Electronic / Smart Controls
Multiple Drying time adjustments
Multiple Temperature settings
Energy Star certified
9 wash settings
Stain Removal / Bleach option
Delay Timer (up to 12 hs)
Easy Iron option
Extra Rinse option
Throttle down spin speed regulation
Pre-wash option
13 lbs maximum load capacity
12 lbs Energy test washing capacity
8 lbs dryer capacity
Stainless Steel Drum / Tub
Dimensions (HxWxD): 33.5''x23.4''x21.1''
Stainless Steel Look / Platinum Color
AWD 121 NA
1200 rpm spin speed
Electronic / Smart Controls
Multiple Drying time adjustments
Multiple Temperature settings
Energy Star certified
9 wash settings
Stain Removal / Bleach option
Delay Timer (up to 12 hs)
Easy Iron option
Extra Rinse option
Throttle down spin speed regulation
Pre-wash option
13 lbs maximum load capacity
12 lbs Energy test washing capacity
8 lbs dryer capacity
Stainless Steel Drum / Tu b
Dimensions (HxWxD): 33.5''x23.4''x21.1''
White Color
ARI_ FS_LVB_USA _2-15_b3 28-03-2008 11:46 Pagina 12

14 15
Technical Charts Washers and Combination washer-dryers Technical Charts Dryers
(*) Certain limitation apply, see manufacturers limited warranty for details
Ariston reserves the right to bring changes to the products without notice.
UL and CUL listed
For planning purposes only,
for details see care & use manual
Staked installation Height 67”
For planning purposes only,
for details see care & use manual
Stacked installation Height 67”
AW 129 NA
washing machine
platinum
15 lbs / 7.0 kgs
16 lbs / 7.5 kgs
189 kWh/year
1000 W
UL / CUL
•
Heavy, Regular, Light
Heavy, Regular, Light
Delicates, Silk, Wool
•
•
Up to 1200 rpm
•
•
•
•
•
850mm x 595mm x 580mm
33.47'' x 23.43'' x 22.84''
910mm x 635mm x 615mm
35.83'' x 25.00'' x 24.22''
13”
158.7 lbs / 72.0 kg
162.1 lbs / 73.5 kg
120 volts / 60 hz
11 Amps / 3 prong plug
6 ft. / 1.8 mts
Triphase (quiet)
•
•
•
Poliplex / Stainless Steel
4
2 springs / 2 dampers
English, Spanish, French
included
AW 125 NA
washing machine
platinum
12 lbs / 5.5 kgs
13 lbs / 6.0 kgs
176 kWh/year
UL / CUL
Heavy, Regular, Light
Heavy, Regular, Light
Delicates, Silk, Wool
•
•
Up to 1200 rpm
•
•
•
•
•
850mm x 595mm x 535mm
33.47'' x 23.43'' x 21.07''
910mm x 635mm x 595mm
35.83'' x 25.00'' x 23.43''
13”
145.5 lbs / 66.0 kg
149.7 lbs / 67.9 kg
120 volts / 60 hz
11 Amps / 3 prong plug
6 ft. / 1.8 mts
Triphase (quiet)
•
•
•
Stainless Steel
4
2 springs / 2 dampers
English, Spanish, French
included
AWD 129 NA
combo washer/dryer
platinum
12 lbs / 5.5 kgs
8 lbs / 3.6 kgs
13 lbs / 6.0 kgs
176 kWh/year
1300 W
UL / CUL
Heavy, Regular, Light
Heavy, Regular, Light
Delicates, Silk, Wool
•
•
Up to 1200 rpm
•
•
•
•
•
850mm x 595mm x 535mm
33.47'' x 23.43'' x 21.07''
910mm x 635mm x 595mm
35.83'' x 25.00'' x 23.43''
13”
137.3 lbs / 62.3 kg
141.5 lbs / 64.2 kg
120 volts / 60 hz
13 Amps / 3 prong plug
6 ft. / 1.8 mts
Collector
•
•
•
Stainless Steel
4
2 springs / 2 dampers
English, Spanish, French
included
AWD 121 NA
combo washer/dryer
white
12 lbs / 5.5 kgs
8 lbs / 3.6 kgs
13 lbs / 6.0 kgs
176 kWh/year
1300 W
UL / CUL
Heavy, Regular, Light
Heavy, Regular, Light
Delicates, Silk, Wool
•
•
Up to 1200 rpm
•
•
•
•
•
850mm x 595mm x 535mm
33.47'' x 23.43'' x 21.07''
910mm x 635mm x 595mm
35.83'' x 25.00'' x 23.43''
13”
137.3 lbs / 62.3 kg
141.5 lbs / 64.2 kg
120 volts / 60 hz
13 Amps / 3 prong plug
6 ft. / 1.8 mts
Collector
•
•
•
Stainless Steel
4
2 springs / 2 dampers
English, Spanish, French
included
23.43"
22.84"
33.47"
23.43"
21.07"
33.47"
AW 149 NA - AW 129 NA AW 125 NA - AWD 129 NA - AWD 121 NA
23.43"
23.00"
33.47"
ASL 75 CXS NA
23.43"
21.66"
33.47"
ASL 65 VXS NA - AS 65 VXS NA
AW 149 NA
washing machine
platinum
15 lbs / 7.0 kgs
16 lbs / 7.5 kgs
189 kWh/year
1000 W
UL / CUL
•
Heavy, Regular, Light
Heavy, Regular, Light
Delicates, Silk, Wool
•
•
Up to 1400 rpm
•
•
•
•
•
850mm x 595mm x 580mm
33.47'' x 23.43'' x 22.84''
910mm x 635mm x 615mm
35.83'' x 25.00'' x 24.22''
13”
158.7 lbs / 72.0 kg
162.1 lbs / 73.5 kg
120 volts / 60 hz
11 Amps / 3 prong plug
6 ft. / 1.8 mts
Triphase (quiet)
•
•
•
Poliplex / Stainless Steel
4
2 springs / 2 dampers
English, Spanish, French
included
Model
Product Line
Color
Performances
Energy test washing capacity
Energy test drying capacity
Maximum washing load
Energyguide
Heating Element
Aproval
Primary Functions
Sanitary Wash
Cotton Wash
Permanent Press Wash
Delicates Wash
Daily Wash
Variable temperature
Variable drying time
Variable spin speed
Additional Options
Super Wash
Pre-Wash
Easy Iron
Delay Timer
Extra Rinse
Soaking
Bleach Stain Removal Program
Dimensions
Product only (HxWxD)
Product with packaging (HxWxD)
Door opening
Weight
Product only
Product with packaging
Technical Data
Voltage / Frequency
Amperage / Wire
Cable length
Motor
Detergent recovery system
Antifoam protection
Overflow / Flood protection
Tub & Drum
Adjustable feet
Suspension System
Accessories
Instruction Manual
Connection hoses
(*) Certain limitation apply, see manufacturers limited warranty for details
Ariston reserves the right to bring changes to the products without notice.
UL and CUL listed
ASL 65 VXS NA
vented dryer
platinum
•
•
15 lbs / 6.5 kgs
•
electronic
UL / CUL
•
Cotton / Permanent Press
up to 120 min
Delicates / Wool
•
•
up to 18 hrs
•
•
•
850mm x 595mm x 550mm
33.47'' x 23.43'' x 21.66''
890mm x 638mm x 610 mm
35.04'' x 25.12'' x 24.02''
bottom left rear
13''
67.3 lbs / 30.5 kg
70.6 lbs / 32.0 kg
208-240 volts / 60 hz
30 Amps / 4 prong plug
6 ft. / 1.8 mts
2000 - 2600 W
Stainless Steel
3.53 cft / 100 lt
•
English, Spanish, French
included
included
AS 65 VXS NA
vented dryer
platinum
•
•
15 lbs / 6.5 kgs
electromechanic
UL / CUL
Heavy load, Light load
up to 120 min
•
•
•
850mm x 595mm x 550mm
33.47'' x 23.43'' x 21.66''
890mm x 638mm x 610 mm
35.04'' x 25.12'' x 24.02''
bottom left rear
13''
67.3 lbs / 30.5 kg
70.6 lbs / 32.0 kg
208-240 volts / 60 hz
30 Amps / 4 prong plug
6 ft. / 1.8 mts
2000 - 2600 W
Stainless Steel
3.53 cft / 100 lt
•
English, Spanish, French
included
included
ASL 75 CXS NA
condenser dryer
platinum
•
•
16 lbs / 7.5 kgs
•
electronic
UL / CUL
Cotton / Permanent Press
up to 160 min
•
•
up to 12 hrs
•
•
•
850mm x 595mm x 584mm
33.47'' x 23.43'' x 23.00''
890mm x 638mm x 670mm
35.04'' x 25.12'' x 26.38''
17''
70.6 lbs / 32.0 kg
81.6 lbs / 37.0 kg
208-240 volts / 60 hz
30 Amps / 4 prong plug
6 ft. / 1.8 mts
2100 - 2750 W
Stainless Steel
3.96 cft / 112 lt
•
English, Spanish, French
included
included
Model
Product Line
Color
Performances
Bi-directional rotation
Removable filter
Maximum drying load
Alarm at end of cycle
Controls
Aproval
Time to end
Primary Functions
Sensor drying
Automatic drying
Timed drying
Fabric care
Additional Options
Air Fluff
Easy Iron
Time Delay
Pre crease care
Post crease care
High Heat / Low Heat
Dimensions
Product only (HxWxD)
Product with packaging (HxWxD)
Venting hole
Door opening
Weight
Product only
Product with packaging
Technical Data
Voltage / Frequency
Amperage / Wire
Cable length
Maximum abosrved power
Tub & Drum
Volume
Adjustable feet
Accessories
Instruction Manual
Stacking Kit
Adaptor for ventilation kit
ARI_ FS_LVB_USA _2-15_b3 28-03-2008 11:46 Pagina 14
