UltraCare Helpers
Cold Iron & HiddenHelpers™
UltraCare InOne
Washer/Dryer Combination Laundry System
UltraCare Drying Systems
Drying Cabinets, Vented & Ventless Dryer
UltraCare XXL
Laundry System
UltraCare Fully Integrated
Laundry System
UltraCare Family
Laundry System

UltraCare
Laundry Solutions
No matter what life throws at you, ASKO has the perfect
UltraCare system to make short work of your laundry.
From the high-efficiency, high-performance UltraCare
Family to the supersized UltraCare XXL workhorse,
ASKO has the right-sized laundry system for any family,
large or small.
Perhaps you want a truly functional, truly beautiful
laundry room with your appliances built into your
cabinetryand complete with countertops? UltraCare
washers and dryers areavailable with plenty of
features to configureyour perfect laundry room.
Maybe you want to conceal your appliances? The
UltraCareIntegrated system with custom cabinet
fronts blends right into your cabinetry. You can
choose from wood, white or black, or you can opt
for our TouchProof™stainless steel panels that will
complement virtually any room.
If you need an extreme space-saving solution, the
UltraCare InOne system combines a washer and dryer
in one standard-sized appliance.
If you have a large home, you may want to install
multiple laundry centers. You’ll love the flexible
installation options of ASKO UltraCare Laundry
Solutions.
If that weren’t enough, the UltraCare Drying Cabinet,
Cold Iron and HiddenHelpers all make life easier by
solving some of the most nagging laundry issues.
Got laundry problems? Simple. Solve them with an
ASKO UltraCare Laundry Solution.

UltraCare Family
Laundry System
Our solutions extend beyond the laundry room,
providing tremendous environmental benefits as well as
fresh, clean clothes. ENERGY STAR qualified UltraCare
Family washers are some of the world’s most efficient,
getting your clothes clean and fresh with less detergent,
less water and less electricity. With a spin speed of up
to 2000 rpm, they extract more moisture than other
washers, which makes the drying process more
energy-efficient.
With the simple and sophisticated EasyControl™
technology,you manage the high performance of
your UltraCare Family washer and dryer by simply
pressing a few buttons.
With less hand-washing, less ironing, less wear on your
clothes, less impact on the environment, less complicated
programming – and more performance – the ASKO
UltraCareFamily LaundrySystem is, in the simplest
terms, the laundry solution for simpler living.
Thanks to its Butterfly Drying System™,the ASKO
UltraCareFamily dryer tumbles clothes in a figure-eight
instead of just round and round in a circle. This keeps
clothes from bundling and creasing and reduces your
need for ironing. Precisely tuned temperature and
moisture sensors work together to end the drying
cycle at just the right time. This prevents overdrying,
which can wrinkle, shrink and even damage your
family’s clothing.
No matter whereyou choose to install your UltraCare
Family LaundrySystem, it’sgoing to look great –
with a variety of finishes, white, black, titanium and
T
ouchProof™stainless, to match any room in your home.
The ASKO UltraCare Family Laundry System makes
life better by simply working better.
For starters, UltraCare Family washers treat your clothes
with TLC – even items labeled for hand-washing.
However, don’t let this gentle action fool you. UltraCare
Family washers provide superior cleaning performance
and a complete range of temperature settings from cold
to 205º to get your family’s clothes ultra-clean and
looking new longer – and without one drop of harsh
chlorine bleach. When it comes to the rinse cycle, many
washers fail to remove all detergent residues. Not
so with UltraCare Family washers – with a unique
seven-rinse process, they remove all traces of detergent,
making them a welcome addition for family members
with allergies or sensitive skin.

UltraCare
Fully Integrated
Laundry System
Now, ASKO gives you a wonderful way to simplify
the look of your laundry room or to install laundry
appliances in a different room altogether – thanks to the
world’s only fully integrated laundry system. With the
UltraCare Fully Integrated Laundry System, the fronts of
your UltraCare washer and dryer come prepared for your
cabinetmaker to easily install wooden panels that match
your other cabinetry. Or if you choose a finish other than
wood, your UltraCare Integrated Laundry System is
available with white, black or TouchProof™stainless steel
panels. Custom-matched to your room, the Fully
Integrated Laundry System can be concealed virtually
anywhere in your home – the bathroom, bedroom,
mudroom or kitchen. Because of the optional ventless
dryer design, you can install your UltraCareFully
Integrated System wherever it makes your life easiest.
Speaking of making life easy, the UltraCare Fully
Integrated Laundry System is not just another pretty
face. It’spacked with the same advanced features and
hard-working performance as the UltraCare Family
LaundrySystem, so it makes doing the laundryasnap.
All this performance is under your command with the
sophisticated, easy-to-use LineConcept™control system
with left-to-right logic and intuitive LCD displays that
seem to program your washer and dryer for you.
Did you ever imagine that laundry could be so
beautiful, so simple, so simply beautiful?
At ASKO, we wouldn’t have it any other way.
Problem solved.

UltraCare XXL
Laundry System
Do you suffer from Big Laundry? You know – load after
load after load – the kind of laundry that never ends?
Finally,Big Laundry has met its match. The ultra-high
capacity of the ASKO UltraCareXXL LaundrySystem
will help you do fewer loads everyweek. Built to gently
clean the most delicate items and still tackle the toughest
stains, the UltraCareXXL Washer has 5 temperature
settings – from cold to extra-hot – and 5 soil level
settings. Likewise, the UltraCareXXL Dryer features
5dryness levels and 5 temperature settings in addition
to anti-crease capability, delay start and more.
In spite of all the features packed into the UltraCare XXL
Laundry System, both the washer and the dryer are
incredibly easy to use. With EasyControl™LineConcept
programming and a clear LED display, operation is a
snap. For the perfect laundry performance for each load,
you simply choose from among 10 different programs
on each unit.
Full of additional solutions, the ASKO UltraCare XXL
Laundry System is available with an exclusive reversible
washer door, an optional pedestal with built-in drawer
and your choice of electric or gas dryers. In other words,
it’s the simple way to finally put an end to Big Laundry.

UltraCare
Drying Systems
ASKO offers a complete range of drying solutions
from traditional vented dryers to condensor-equipped,
ventless dryers to an incredible appliance, the
UltraCare Drying Cabinet.
UltraCare vented dryers use traditional exhaust venting
systems but are otherwise anything but traditional. With
state-of-the-art technology, easy-to-operate controls,
precise moisture sensors, wrinkle-reducing features
and more, UltraCare vented dryers are some of the
world’s most advanced.
Thanks to a unique, built-in condenser, ASKO
UltraCare ventless dryers require no external exhaust
or ductwork. This non-venting, ductless design means
easier, less expensive installation virtually anywhere in
your home. In fact, rooms that were never able to
accommodate a dryer before can have an UltraCare
ventless dryer. With no external exhaust or ductwork,
your home will be more airtight for more efficient
heating and cooling.
An ingenious solution for almost any home, the
UltraCare Drying Cabinet gently dries items that
shouldn’t go into a traditional tumble dryer – knit
sweaters, fine shirts, delicates, even umbrellas.
Consider all the rainy and snowy days when you
need to dry your kids’ clothes. What about special
care instructions such as “dry flat” or “hang to dry?”
The UltraCareDrying Cabinet solves all of these
problems. Tucked away in this energy-efficient
cabinet, wet gloves, hats, shoes, boots, sweaters,
silks and other delicates will be dryin no time –
and your home will stay nice and neat.

UltraCare InOne
Laundry System
Perfect for homes without the space for a washer and
dryer, this hardworking appliance does the job of both.
And with loads of features and automatic transition
from the wash cycle to the dry cycle, the ASKO
UltraCare InOne Laundry System takes nearly all
the work out of doing the laundry.
Installation is simple and inexpensive. Thanks to an
internal moisture condenser, the UltraCare InOne does
not require ductwork or an exterior vent for the dryer
exhaust. Combined with the unit’s space-saving design,
the no-hassle installation makes it ideal for apartments
and townhomes. Just hook up the water connection and
plug it into a regular 110V outlet. That’s all there is to it.
UltraCareCold Iron
In the past, freshly pressed sheets, tablecloths and drapes
were a luxury reserved for fine restaurants and hotels.
Not any longer. The ASKO UltraCare Cold Iron takes
all the work out of pressing “difficult-to-iron” linens.
Pressed linens not only feel and look great; they collect
up to 60 times less dust. To enhance the lives of people
with allergies, asthma and other respiratory concerns, the
ASKO UltraCare Cold Iron improves indoor air quality.
The UltraCare Cold Iron – a solution for better health, for
amore luxurious home and, better yet, for a simpler life.

UltraCare
HiddenHelpers™
Neatly out of sight but ready to assist with storage,
folding and ironing, you’ll find optional, time-saving
tools called HiddenHelpers, little conveniences that
make life so easy you’ll never want to do without
them. Designed to make doing your laundry as fast,
simple and organized as possible, ASKO UltraCare
HiddenHelpers include space-saving features such
as a concealed, removable basket, a handy ironing
board, pull-out shelves for sorting and folding clothes
and pedestals for easy loading and unloading.
Available for the UltraCareXXL System, the pedestal
includes a storage drawer.Located under the washer,
it’sthe ideal hiding spot for detergents, fabric softeners,
coat hangers and other clutter.Elevating the washer,
this pedestal/drawer combination simplifies loading
and unloading your clothes.
Outfitted with practical features like these HiddenHelpers,
your UltraCare Laundry System takes much of the work
out of laundering your family’s clothes.

DC7171 DC7181
Clothes Line Equivalent 521/2'52
1/2'
Drying Time, Normal 150 min 150 min
Programs Normal Normal
Medium, Low Medium, Low
Timer Up to 4 hrs Up to 4 hrs
Element 1200 W 1200 W
CFM 26 26
Voltage 120V/60 Hz 120V/60 Hz
Bar for Hangers • •
Door Hanger • •
Glove Hanger • •
Colors White, Titanium White, Titanium
Shoe Rack (Accessory) Optional Optional
Height 67" to 69" 713/8"to 733/8"
Width 237/16"23
7/16"
Depth 251/4"25
1/4"
Depth with Door Open 461/4"461/4"
Weight 132 lbs 143 lbs
WD6442
Washer
Average Water Consumption (Gallons) 18.4
Low Discharge Rate (GPM) 4.5 (1 DFU)
Spin Speeds 550/800/1200
Detergent & Fabric Softener Dispenser •
Overfill Protection •
Pre-Wash Option •
Maximum Number of Rinses 5
Dryer
Drying Times (Minutes) 40–140
Cool Down Cycle •
Wrinkle-Reducing Auto-Reversing Action •
End-of-Program Light •
Internal Moisture-Condensing Drying •
Regular Program: Heavy Stain, White, Colorfast, Color •
Synthetic Program: Heavy Stain, Colorfast, Color •
Delicate Program: Wool/Hand Wash, Quick Wash •
Stainless Steel Inner and Outer Tanks •
Four-Shock Suspension •
Dryer Heating Element 1300 Watt
Washer Heating Element 1200 Watt
Internal Water Heater Temperature Boost To 140º F
ADA Height Compliant •
Large Capacity Drum •
Every Unit Factory Tested •
Portability Kit (optional) •
Colors White, Titanium
Height 331/4"to 34"
Width 231/2"
Depth with Door Open 39"
Depth with Door Closed 235/8"
Weight 195 lbs
Ironing Board
8080704 - W, T (W6903)
8080705 - W, T,SS (W6903FI, W6222)
Height 515/16"
Width 237/16"
Depth 231/4"
Depth at Max. Reach 621/2"
Ironing BoardDimensions 361/2"long X 125/8"wide
Sleeve Insert Width (Optional) 163/4"added to
width when installed
Double Shelf
8080443 - W,T(W6903)
8080407 - W,T, SS (W6903FI, W6222)
Height 515/16"
Width 237/16"
Depth 231/4"
Depth at Max. Reach 511/4"
Shelf Working Surface 29" long X 21" wide
Basket Work Area 189/16"long X
193/16"wide
Single Shelf
8079977 - W, T (W6903, W6903FI)
8061907 - W, B, T (W6222)
Height 515/16"
Width 237/16"
Depth 231/4"
Depth at Max. Reach 81/2"
Shelf Working Surface 141/2"long X 21" wide
XXL Steel Laundry Platform
8052005-1 – W
8052005-3 – T
Height 16"- 17"
Width 27"
Depth 281/2"
Depth w/Drawer Open 44"
Weight 63 lbs
CI700
Roller Cloth 215/8" X 551/8"
Roller Pressure 750 lbs - 882 lbs
Motor Output 90 Watt
Colors White, Titanium
Height 113/8"
Height with Safety Guard Raised 165/8"
Width 283/4"
Depth 131/2"
Weight 44 lbs
A79002002 - T
A79002001 - W
Height 275/8"
Width 283/4"
Depth 251/4"
ASKO retains the right to vary the model specifications at any time. All facts were accurate at time of printing. Before purchasing any appliance, read energy cost and efficiency information at your retailer.
For complete product specifications please refer to the ASKO Product & Design Guide or visit www.askousa.com.
Washers Drying Cabinet
InOne Washer/Dryer HiddenHelpers™
Cold Iron
Cold Iron Stand
Dryers
Features & Specifications
W6222 W6903 W6903FI WL6511
Minimum Water Consumption (Gallons) 5.7 5.7 5.7 13
Automatic Load Balancing System • • • •
Spin Speeds 800/1200 400-2000 400-2000 550-1150
Sensor Level Control™System • • • •
Internal Water Heater • • • •
Wash Temperature Options Cold, 85-205 Cold, 85-205 Cold, 85-205 Cold, 155
Maximum Number of Rinses 7 7 7 4
Six-Way, Aqua Block Water Containment System • • • •
Stainless Steel Inner and Outer Tank • • • Inner Only
Solid Rubber SmartSeal™Door Gasket • • •
Quattro™ Suspension • • • QuatroPlus™
Electronic Door Latch • • • •
Finger Guard Between Inner and Outer Cases • • •
Drop-Down Outer Door •
Side Swing Door • • Reversible
No-Spin Option • • • •
EasyControl™/SmoothDial Controls •
EasyControl™/Line Concept Controls • • •
Adjustable Programs 10 13 13 10
Program Interrupt, Add An Item • • • •
Delay Start 1-24 Hours 1-24 Hours 1-12 Hours
Quick Wash Program (Typically 35 Minutes) • • • •
Anti-Crease Program • •
Easy-To-Reach, Out-Front Controls • • •
Complies With ADA Height Accessibility Guidelines • • •
220 V, 20 Amp Cord and Plug Included • • • 110V
Every Unit Factory Tested • • • •
Colors: White, Black, Titanium or TouchProof™Stainless Steel W, B, T W, SS W,T
Requires Optional, One-Piece Door Panel (see “Individual Doors”) •
Height 331/2"to 341/2"33
1/2"to 341/2"33 1/2"to 341/2"40 1/4" to 411/4"
Width 237/16" 231/2" 231/2" 27"
Depth with Door Open 4217/32" 461/8" 477/8" 511/4"
Depth with Door Closed 247/16"23
13/16"23 1/16" 31"
Butterfly Drying™System
Internal MoistureCondenser/Collector (Ventless)
Three-Way Venting
Reversible Door
Cool Down
Drying Temperatures (Air,Low and Normal)
SensiDry™
Anti-Crease Program
Four-Way Water Containment System
Stainless Steel Drum
Double Lint Filter
Cleanable Fan
Stacking Kit Included
End-Of-Cycle Tone
EasyControl™/SmoothDial Controls
EasyControl™/Line Concept Controls
Number Of Programs
Timed Dry Program (Minutes)
Air (Fluff) Drying Program
Delay Start
Includes 220 V, 20 Amp Receptacle For ASKO Washer
Available in Gas
Every Unit Factory Tested
Colors: White, Black, Titanium or TouchProof™Stainless Steel
Requires Optional, One-Piece Door Panel
(See “Individual Doors”)
Height
Width
Depth with Door Open
Depth with Door Closed
T712
•
•
•
•
•
•
•
•
•
•
•
•
•
6
60
•
5Hrs
•
•
W, B, T
331/2"
to 341/2"
237/16"
461/16"
247/16"
T712C
•
•
•
•
•
•
•
•
•
•
•
•
•
•
6
60
•
5Hrs
•
•
W, T
331/2"
to 341/2"
237/16"
461/16"
247/16"
T793
•
•
•
•
•
•
•
•
•
•
•
•
•
6
5-180
•
1-24 Hrs
•
•
W, SS
•
331/2"
to 341/2"
231/2"
461/8"
2313/16"
T793C
•
•
•
•
•
•
•
•
•
•
•
•
•
•
6
5-180
•
1-24 Hrs
•
•
W
331/2"
to 341/2"
231/2"
467/8"
2313/16"
T793FI
•
•
•
•
•
•
•
•
•
•
•
•
•
6
5-180
•
1-24 Hrs
•
•
331/2"
to 341/2"
231/2"
47 7/8"
231/8"
TL75I
•
•
5
•
•
•
•
•
10
20-60
•
1-12 Hrs
•
W, T
401/4"
to 411/4"
27"
521/2"
311/2"
