Ariston AVSD 109 User manual

1
GB
English, 1
Contents
Installation, 2-3
Unpacking and levelling, 2
Electric and water connections, 2-3
The first wash cycle, 3
Technical details, 3
Washing machine description, 4-5
Control panel, 4
Display, 5
Starting and Programmes,
riefly: how to start a programme, 6
Programme table, 6
Personalisations, 7
Setting the temperature, 7
Setting the spin cycle, 7
Options, 7
Detergents and laundry, 8
Detergent dispenser, 8
leach cycle, 8
Preparing your laundry, 8
Special items, 8
Woolmark Platinum Care, 8
Precautions and advice, 9
General safety, 9
Disposal, 9
Saving energy and respecting the environment, 9
Care and maintenance, 10
Cutting off the water or electricity supply, 10
Cleaning your appliance, 10
Cleaning the detergent dispenser, 10
Caring for your appliance door and drum, 10
Cleaning the pump, 10
Checking the water inlet hose, 10
Troubleshooting, 11
Service, 12
efore calling for Assistance, 12
WASHING MACHINE
AVSD 109
Instructions for use
GB
ÐÓÑÑÊÈÉ, 13
CIS
Deutsch, 25
DE
Èeský, 37
CZ
Românã, 49
RO
Magyar, 61
HU
Slovenský, 73
SK

2
GB
Keep this instruction manual in a safe place for
future reference. Should the appliance be sold,
transferred or moved, make sure the instruction
manual accompanies the washing machine to inform
the new owner as to its operation and features.
Read these instructions carefully: they contain vital
information on installation, use and safety.
Unpacking and levelling
Unpacking
1. Unpack the washing machine.
2. Check whether the washing machine has been
damaged during transport. If this is the case, do not
install it and contact your retailer.
3. Remove the four
protective screws and
the rubber washer with
the respective spacer,
situated on the rear of
the appliance (see
figure).
4. Seal the gaps using the plastic plugs provided.
5. Use the plug provided to seal the three holes
where the plug was housed, situated on the lower
right-hand side on the rear of your appliance.
6. Keep all the parts: you will need them again if the
washing machine needs to be moved to another
location.
Packaging materials are not children's toys.
Levelling
1. Install the washing machine on a flat sturdy floor,
without resting it up against walls, furniture cabinets
or other.
2. If the floor is not
perfectly level, compen-
sate for any unevenness
by tightening or
loosening the adjustable
front feet (see figure);
the angle of inclination,
measured according to
the worktop, must not
exceed 2°.
Levelling your appliance correctly will provide it with
stability and avoid any vibrations, noise and shifting
during operation. If it is placed on a fitted or loose
carpet, adjust the feet in such a way as to allow
enough room for ventilation beneath the washing
machine.
Electric and water connections
Connecting the water inlet hose
1. Insert seal A into the
end of the inlet hose
and screw the latter
onto a cold water tap
with a 3/4 gas threaded
mouth (see figure).
efore making the
connection, allow the
water to run freely until
it is perfectly clear.
2. Connect the other end
of the water inlet hose to
the washing machine,
screwing it onto the
appliance's cold water
inlet, situated on the top
right-hand side on the
rear of the appliance
(see figure).
3. Make sure there are no kinks or bends in the
hose.
The water pressure at the tap must be within the
values indicated in the Technical details table
(on the next page).
If the water inlet hose is not long enough, contact
a specialist store or an authorised serviceman.
Installation
A

3
GB
Connecting the drain hose
Connect the drain hose,
without bending it, to a
draining duct or a wall
drain situated between
65 and 100 cm from the
floor;
alternatively, place it
over the edge of a
basin, sink or tub,
fastening the duct
supplied to the tap (see
figure). The free end of
the hose should not be
underwater.
 We advise against the use of hose extensions; in
case of absolute need, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Electric connection
efore plugging the appliance into the mains socket,
make sure that:
 the socket is earthed and in compliance with the
applicable law;
 the socket is able to sustain the appliance's
maximum power load indicated in the Technical
details table (on the right);
 the supply voltage is included within the values i
ndicated on the Technical details table
(on the right);
 the socket is compatible with the washing
machine's plug. If this is not the case, replace the
socket or the plug.
 The washing machine should not be installed in an
outdoor environment, not even when the area is
sheltered, because it may be very dangerous to
leave it exposed to rain and thunderstorms.
 When the washing machine is installed, the mains
socket must be within easy reach.
 Do not use extensions or multiple sockets.
 The power supply cable must never be bent or
dangerously compressed.
 The power supply cable must only be replaced by
an authorised serviceman.
Warning! The company denies all liability if and when
these norms are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, setting the 90°C
programme without a pre-wash cycle.
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
65 - 100 cm
Technical details
Model AVSD 109
Dimensions
59.5 cm wide
85 cm high
40 cm deep
Capacity from 1 to 4,5 kg
Electric
connections
voltage 220/230 Volts 50 Hz
maximum absorbed power 1850 W
Water
connections
maximum pressure 1 MPa (10 bar)
minimum pressure 0.05 MPa (0.5 bar)
drum capacity 40 litres
Spin speed up to 1000 rpm
Control
programmes
according to
IEC45 directive
programme 3; temperature 60°C;
run with a load of 4,5 kg.
This appliance is compliant with the
following European Community
Directives:
- 73/23/CEE of 19/02/73 (Low
Voltage) and subsequent amendments
- 89/336/CEE of 03/05/89
(Electromagnetic Compatibility) and
subsequent amendments

4
GB
Control panel
Washing machine description
Control knob
Display
Detergent dispenser
Programme key
SPIN
button
TEMPERATURE
button
MODE button
SELECT
button
START/STOP
button
START/RESET
button
Detergent dispenser to add detergent and fabric
softener (see page 8).
Programme key to consult a straightforward chart
of the different programmes available: pull the grey
tab outwards to open it.
TEMPERATURE button to adjust the wash tempe-
rature (see page 7).
SPIN button to adjust the spin speed or exclude it
altogether (see page 7).
Display to programme the washing machine and
follow the wash cycle progress (see opposite page).
MODE button to choose the options for the
appliance personalisation (see page 7).
SELECT button to set the options for the appliance
personalisation (see page 7).
START/STOP button to turn the washing machine
on and off.
START/RESET button to start the programmes or
cancel any incorrect settings.
Control knob to select the wash programmes. The
retractable control knob: press the centre of the
knob for it to pop out. The knob stays still during the
cycle.

5
GB
Display
In addition to being a practical tool to programme your appliance (see page 7), the display provides useful
information concerning the wash cycle and status.
Once you have pressed the START/RESET button to
start the programme, the display will indicate the
amount of time left until the end of the wash cycle. If
a delayed start has been set (using the Delay Timer,
see page 7), the delay time will be indicated on the
display.
The following information is displayed during the
wash cycle:
Cycle phase under way:
Pre-wash Spin cycle
Wash cycle
Rinse Disabled symbol.
Fabric selected:
Cotton Wool
Colours Silk
Synthetics
Personalisation options:
The enabled options are bordered by a frame.
To choose the options, see page 7.
Disabled symbol.
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Door lock:
If the symbol is on, the washing machine door is locked to prevent it from being opened accidentally. To avoid
any damages, wait for the symbol to switch itself off before you open the appliance door.
This model is fitted with a device that allows you to open the appliance door during some of the programme
phases. This is possible when the symbol is not on.
At the end of the programme, the word END is displayed.
 In the event of an anomaly, an error code will appear, such as: F-01, which should be communicated to the
Service Centre (see page 12).

GB
Type of fabric and degree
of soil
Program-
mes
Wash
temp.
Detergent Fabric
softener
Bleaching
option/
bleach
Cycle
length
(minutes
Description of wash cycle
Pre-
wash Wash
Cotton
Extremely soiled whites
(sheets, tablecloths, etc.) 190°C    137 Pre-wash, wash cycle, rinse cycles,
intermediate and final spin cycles
Extremely soiled whites
(sheets, tablecloths, etc.) 290°C   Delicate/
Traditional 120 Wash cycle, rinse cycles,
intermediate and final spin cycles
Heavily soiled whites and
fast colours 360°C   Delicate/
Traditional 105 Wash cycle, rinse cycles,
intermediate and final spin cycles
Slightly soiled whites and
delicate colours (shirts,
jumpers, etc.) 440°C   Delicate/
Traditional 72 Wash cycle, rinse cycles,
intermediate and final spin cycles
Slightly soiled delicate
colours 530°C   Delicate/
Traditional 65 Wash cycle, rinse cycles,
intermediate and final spin cycles
Synthetics
Heavily soiled fast colours
(baby linen, etc.) 660°C   Delicate 77 Wash cycle, rinse cycles, anti-
crease or delicate spin cycle
Fast colours (all types of
slightly soiled garments) 640°C   Delicate 62 Wash cycle, rinse cycles, anti-
crease or delicate spin cycle
Heavily soiled fast colours
(baby linen, etc.) 750°C   Delicate 73 Wash cycle, rinse cycles, anti-
crease or delicate spin cycle
Delicate colours (all types
of slightly soiled garments) 840°C   Delicate 58 Wash cycle, rinse cycles, anti-
crease or delicate spin cycle
Delicate colours (all types
of slightly soiled garments) 930°C   30 Wash cycle, rinse cycles and
delicate spin cycl
Delicate
Wool 10 40°C   Delicate 50 Wash cycle, rinse cycles and
delicate spin cycle
Very delicate fabrics
(curtains, silk, viscose, etc.) 11 30°C   45 Wash cycle, rinse cycles, anti-
crease or draining cycle
PARTIAL PROGRAMMES
Rinse   Rinse cycles and spin cycle
Delicate rinse cycle   Rinse cycles, anti-crease or draining
Spin cycle Draining and heavy duty spin cycle
Delicate spin cycle Draining and delicate spin cycle
Draining Draining
Starting and Programmes
Programme table
Notes
For the anti-crease function: see Easy iron, opposite page. The information contained in the table is purely indicative.
Special programme
Daily 30' (programme 9 for Synthetics) is designed to wash lightly soiled garments in a short amount of time: it only
lasts 30 minutes and allows you to save on both time and energy. y setting this programme (9 at 30°C), you can
wash different fabrics together (except for woollen and silk items), with a maximum load of 3 kg.
e recommend the use of liquid detergent.
Briefly: starting a programme
1. Turn the washing machine on by pressing button .
2. Load your laundry into the washing machine and
shut the appliance door.
3. Set the knob to the desired programme. The
estimated duration of the selected programme is
displayed. The temperature and spin speed are
automatically set according to the programme
(to change them, see page 7).
4. Add the detergent and any fabric softener (see page 8).
5. Start he programme by pressing the START/RESET
button.
To cancel it, keep the START/RESET button
pressed for at least 2 seconds.
6. When the programme has ended, the word END is
displayed. Take out your laundry and leave the
appliance door ajar to allow the drum to dry
thoroughly.
7. Turn the washing machine off by pressing button .

7
GB
Option Effect Comments Enabled with
programmes:
Delay Timer
Delays the start
of the wash by
up to 24 hours.
Press (SELECT button) repeatedly until the desired delay is
displayed. OFF indicates no delay has been set. All
Bleaching
leaching cycle
designed to
remove the
toughest stains.
Please remember to pour the bleach into extra compartment 4
(see page 8). This option is incompatible with the EASY IRON
option.
2, 3, 4, 5,
6, 7, 8, 10,
Rinse cycles.
Easy iron
This option
reduces the
amount of
creasing on
fabrics, making
them easier to
iron.
If you set this option, programmes 6, 7, 8, 11 and Delicate Rinse
will be suspended, leaving the laundry to soak (Anti-crease) and
icon will flash:
- to conclude the cycle, press the START/RESET button;
- to run the draining cycle alone, set the knob to the relative
symbol and press the START/RESET button. This option is
incompatible with the LEACHING option.
All
programmes
except for
1, 2, 9, 10
and Draining.
Super
Wash
Allows for an
impeccable wash,
visibly whiter than
a standard Class
A wash.
This option is incompatible with the RAPID option. 1, 2, 3, 4,
5, 6, 7, 8
Rapid
Cuts the duration
of the wash cycle
by 30%. This option is incompatible with the SUPER WASH option. 1, 2, 3, 4,
5, 6, 7, 8
Extra Rinse
Increases the
efficiency of the
rinse.
Recommended when the appliance has a full load or with large
quantities of detergent.
1, 2, 3, 4, 5,
6, 7, 8, and
Rinse cycles.
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
Personalisations
1. Press the MODE button to scroll through the various options available; the enabled symbol will flash.
2. To select it, press the SELECT button, until the word ON is displayed (for the Delay Timer, the time will be
displayed: see table below).
3. Confirm your setting by pressing the MODE button again: the symbol for the option will stop flashing on the
display.
The selected options can be seen on the display, as they are bordered by a frame.
Setting the temperature
Press button and the maximum temperature allowed for
the programme set will be displayed. Press the same button
to lower this temperature. OFF indicates a cold wash.
The temperature adjustment is enabled with all wash
programmes.
Setting the spin cycle
Press button and the maximum spin speed allowed for
the programme set will be displayed. Press the same
button to lower the value down to OFF, which indicates
that the spin cycle has been excluded altogether (press it
again to go back to the maximum value).
The spin cycle exclusion is indicated by symbol .
The spin cycle setting is enabled with all the programmes
except for 11 and the Draining cycle.
Options
The various wash options available with this washing
machine will make for the desired results, every time.
To select the various options, the following procedure
should be followed at all times:

8
GB
Detergent dispenser
Good washing results also depend on the correct
dose of detergent: adding too much detergent won't
necessarily make for a more efficient wash, and may
in fact cause build up on the interior of your
appliance and even pollute the environment.
Open up the detergent
dispenser and pour in
the detergent and fabric
softener, as follows.
compartment 1: Detergent for pre-wash
(powder)
efore pouring in the detergent, make sure that
extra compartment 4 has been removed.
compartment 2: Detergent for the wash cycle
(powder or liquid)
Liquid detergent should only be poured in
immediately prior to the wash cycle start.
compartment 3: Additives (fabric softeners, etc.)
The fabric softener should not overflow from the grid.
extra compartment 4: Bleach
 Do not use hand wash detergent because it may
form too much foam.
Bleach cycle
 Traditional bleach should be used on sturdy
white fabrics, and delicate bleach for coloured
fabrics, synthetics and for wool.
Place extra
compartment 4,
provided, into
compartment 1.
When pouring in the
bleach, be careful not to
exceed the "max" level
indicated on the central
pivot (see figure).
To run the bleach cycle alone, pour the bleach into
extra compartment 4 and set the Rinse programme
(for Cotton fabrics) or delicate Rinse (for
Synthetic fabrics). To bleach during a wash cycle,
pour in the detergent and fabric softener, set the
desired programme and enable the leaching option
(see page 7).
The use of extra compartment 4 excludes the
possibility of using the pre-wash cycle. In addition,
the bleach cycle cannot be run with programmes 11
(Silk) and Daily 30' (see page 6).
Preparing your laundry
 Divide your laundry according to:
- the type of fabric/the symbol on the label.
- the colours: separate coloured garments from
whites.
 Empty all pockets and check for loose buttons.
 Do not exceed the weight limits stated below,
which refer to the weight when dry:
Sturdy fabrics: max 4,5 kg
Synthetic fabrics: max 2.5 kg
Delicate fabrics: max 2 kg
Wool: max 1 kg
How much does your laundry weigh?
1 sheet 400-500 g
1 pillow case 150-200 g
1 tablecloth 400-500 g
1 bathrobe 900-1,200 g
1 towel 150-250 g
Special items
Curtains: fold curtains and place them in a pillow
case or mesh bag. Wash them separately without
exceeding half the appliance load. Use programme
11 which excludes the spin cycle automatically.
Quilted coats and windbreakers: if they are
padded with goose or duck down, they can be
machine-washed. Turn the garments inside out and
load a maximum of 2-3 kg, repeating the rinse cycle
once or twice and using the delicate spin cycle.
Trainers: remove any mud. They can be washed
together with jeans and other tough garments, but
not with whites.
Wool: for best results, use a specific detergent,
taking care not to exceed a load of 1 kg.
Woolmark Platinum Care
As gentle as a hand wash.
Ariston sets a new standard of superior
performance that has been endorsed by
The Woolmark Company with the prestigious
Woolmark Platinum Care brand. Look for the
Woolmark Platinum Care logo on the washing
machine to ensure you can safely and effectively
wash wool garments labelled as "hand wash"
(M.00221):
Set programme 10 for all "Hand wash"
garments, using the appropriate detergent.
Detergents and laundry
MAX
1
2
4
3
MAX
MAX

9
GB
Precautions and advice
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description
 The washing machine was designed and built in
compliance with the applicable international safety
regulations. The following information is provided for
your safety and should consequently be read carefully.
General safety
 This washing machine should only be used by
adults and in accordance with the instructions
provided in this manual.
 Never touch the washing machine when barefoot
or with wet or damp hands or feet.
 Do not pull on the power supply cable to unplug
the appliance from the electricity socket. Pull the
plug out yourself.
 Do not open the detergent dispenser while the
appliance is in operation.
 Do not touch the drain water as it could reach
very high temperatures.
 Never force the washing machine door: this could
damage the safety lock mechanism designed to
prevent any accidental openings.
 In the event of a malfunction, do not under any
circumstances touch internal parts in order to
attempt repairs.
 Always keep children well away from the
appliance while in operation.
 The appliance door tends to get quite hot during
the wash cycle.
 Should it have to be moved, proceed with the
help of two or three people and handle it with the
utmost care. Never try to do this alone, because
the appliance is very heavy.
 efore loading your laundry into the washing
machine, make sure the drum is empty.
Disposal
 Disposing of the packaging material:
observe local regulations, so the packaging can
be re-used.
 Disposing of an old washing machine:
before scrapping your appliance, cut the power
supply cable and remove the appliance door.
Saving energy and respecting the
environment
Environmentally-friendly technology
If you only see a little water through your appliance
door, this is because thanks to the latest Ariston
technology, your washing machine only needs less
than half the amount of water to get the best
results: an objective reached to respect the
environment.
Saving on detergent, water,
energy and time
 To avoid wasting resources, the washing machine
should be used with a full load. A full load instead
of two half loads allows you to save up to 50% on
energy.
 The pre-wash cycle is only necessary on
extremely soiled garments. Avoiding it will save on
detergent, time, water and between 5 and 15%
energy.
 Treating stains with a stain remover or leaving
them to soak before washing will cut down the
need to wash them at high temperatures. A
programme at 60°C instead of 90°C or one at
40°C instead of 60°C will save up to 50% on
energy.
 Use the correct quantity of detergent depending
on the water hardness, how soiled the garments
are and the amount of laundry you have, to avoid
wastage and to protect the environment: despite
being biodegradable, detergents do contain
ingredients that alter the natural balance of the
environment. In addition, avoid using fabric
softener as much as possible.
 If you use your washing machine from late in the
afternoon until the early hours of the morning, you
will help reduce the electricity board's peak load.
The Delay Timer option (see page 7) helps to
organise your wash cycles accordingly.
 If your laundry has to be dried in a tumble dryer,
select a high spin speed. Having the least water
possible in your laundry will save you time and
energy in the drying process.

10
GB
Care and maintenance
Cutting off the water or electricity
supply
 Turn off the water tap after every wash. This will
limit the wear of your appliance's water system
and also prevent leaks.
 Unplug your appliance when cleaning it and
during all maintenance operations.
Cleaning your appliance
The exterior and rubber parts of your appliance can
be cleaned with a soft cloth soaked in lukewarm
soapy water. Do not use solvents or abrasives.
Cleaning the detergent dispenser
Remove the dispenser
by raising it and pulling it
out (see figure).
Wash it under running
water; this operation
should be repeated
frequently.
Caring for your appliance door and
drum
 Always leave the appliance door ajar to prevent
unpleasant odours from forming.
Cleaning the pump
The washing machine is fitted with a self-cleaning
pump that does not require any maintenance.
Sometimes, small items (such as coins or buttons)
may fall into the pre-chamber that protects the
pump, situated in the lower part of the same.
 Make sure the wash cycle has ended and unplug
the appliance.
To access the pre-chamber:
1. using a screwdriver,
remove the cover panel
on the lower front of the
washing machine (see
figure);
2. unscrew the lid
rotating it anti-
clockwise (see figure): a
little water may trickle
out. This is perfectly
normal;
3. clean the interior thoroughly;
4. screw the lid back on;
5. reposition the panel, making sure the hooks are
securely in place before you push it onto the
appliance.
Checking the water inlet hose
Check the water inlet hose at least once a year. If
you see any cracks, replace it immediately: during
the wash cycles, water pressure is very strong and
a cracked hose could easily split open.
 Never use hoses that have already been used.
1
2

11
GB
Your washing machine could fail to work. efore calling for Assistance (see page 12), make sure the problem
can't easily be solved by consulting the following list.
Troubleshooting
Problem
The washing machine won't
start.
The wash cycle won't start.
The washing machine fails to
load water (The wording H2O is
displayed).
The washing machine
continuously loads and unloads
water.
The washing machine does not
drain or spin.
The washing machine vibrates
too much during the spin cycle.
The washing machine leaks.
There is too much foam.
Possible causes/Solution:
 The appliance is not plugged into the socket, or not enough to
make contact.
 There has been a power failure.
 The appliance door is not shut properly (the word DOOR is
displayed).
 The button has not been pressed.
 The START/RESET button has not been pressed.
 The water tap is not turned on.
 A delayed start has been set (using the Delay Timer, see page 7).
 The water inlet hose is not connected to the tap.
 The hose is bent.
 The water tap is not turned on.
 There is a water shortage.
 The water pressure is insufficient.
 The START/RESET button has not been pressed.
 The drain hose is not fitted between 65 and 100 cm from the floor
(see page 3).
 The free end of the hose is underwater (see page 3).
 The wall drainage system doesn't have a breather pipe.
If the problem persists even after these checks, turn off the water tap,
switch the appliance off and call for Assistance. If the dwelling is on one of
the upper floors of a building, there may be drain trap problems causing the
washing machine to load and unload water continuously. In order to avoid
such an inconvenience, special anti-drain trap valves are available in shops.
 The programme does not foresee the draining: some programmes
require enabling the draining manually (see page 6).
 The Easy iron option is enabled: to complete the programme, press
the START/RESET button (see page 7).
 The drain hose is bent (see page 3).
 The drain duct is clogged.
 The drum was not unblocked correctly during installation (see page 2).
 The washing machine is not level (see page 2).
 The washing machine is closed in between furniture cabinets and
the wall (see page 2).
 The water inlet hose is not screwed on correctly (see page 2).
 The detergent dispenser is obstructed (to clean it, see page 10).
 The drain hose is not secured properly (see page 3).
 The detergent is not suitable for machine washing (it should bear
the definition "for washing machines" or "hand and machine wash",
or the like).
 You used too much detergent.
ServiceTroubleshootingPrecautions CareProgrammes DetergentsInstallation Description

12
GB
Before calling for Assistance:
Check whether you can solve the problem on your own (see page 11);
Restart the programme to check whether the problem has been solved;
If this is not the case, contact an authorised Technical Service Centre on the telephone number
provided on the guarantee certificate.
Always request the assistance of authorised servicemen.
Notify the operator of:
 the type of problem;
 the appliance model (Mod.);
 the serial number (S/N).
This information can be found on the data plate situated on the rear of the washing machine.
Service
Service

!
CIS
ÐÓÑÑÊÈÉ
Ñîäåðæàíèå
Óñòàíîâêà, 14-15
Ðàñïàêîâêà è âûðàâíèâàíèå, 14
Ïîäêëþ÷åíèå ê âîäîïðîâîäíîé è ýëåêòðè÷åñêîé
ñåòè, 14-15
Ïðîáíûé öèêë ñòèðêè, 15
Òåõíè÷åñêèå õàðàêòåðèñòèêè, 15
Îïèñàíèå ñòèðàëüíî ìàøèíû, 16-17
Ïàíåëü ïðàâëåíèÿ, 16
Äèñïëåé, 17
Çàïóñê ìàøèíû. Ïðîãðàììû, 18
Êðàòêèå èíñòð êöèè: Ïîðÿäîê çàï ñêà ïðîãðàììû, 18
Òàáëèöà ïðîãðàìì, 18
Ïåðñîíàëèçàöèÿ ñòèðêè, 19
Âûáîð òåìïåðàò ðû, 19
Óñòàíîâêà ñêîðîñòè îòæèìà, 19
Äîïîëíèòåëüíûå ô íêöèè, 19
Ìîþùèå ñðåäñòâà è áåëüå, 20
Ðàñïðåäåëèòåëü ìîþùèõ ñðåäñòâ, 20
Îòáåëèâàíèå, 20
Ïîäãîòîâêà áåëüÿ, 20
Îñîáåííîñòè ñòèðêè îòäåëüíûõ èçäåëèé, 20
Woolmark Platinum Care, 20
Ïðåäóïðåæäåíèÿ è ðåêîìåíäàöèè, 21
Îáùèå ïðàâèëà áåçîïàñíîñòè, 21
Óòèëèçàöèÿ, 21
Ýêîíîìèÿ è îõðàíà îêð æàþùåé ñðåäû, 21
Îáñëóæèâàíèå è óõîä, 22
Îòêëþ÷åíèå âîäû è ýëåêòðè÷åñòâà, 22
Óõîä çà ñòèðàëüíîé ìàøèíîé, 22
Óõîä çà ðàñïðåäåëèòåëåì ìîþùèõ ñðåäñòâ, 22
Óõîä çà äâåðöåé ìàøèíû è áàðàáàíîì, 22
×èñòêà íàñîñà, 22
Ïðîâåðêà çàëèâíîãî øëàíãà, 22
Óñòðàíåíèå íåèñïðàâíîñòå , 23
Ñåðâèñíîå îáñëóæèâàíèå, 24
CIS
ÑÒÈÐÀËÜÍÀß ÌÀØÈÍÀ
AVSD 109
Ðóêîâîäñòâî ïî ýêïóàòàöèè

"
+15
 Ñîõðàíèòå äàííîå ð êîâîäñòâî. Îíî äîëæíî áûòü
â êîìïëåêòå ñî ñòèðàëüíîé ìàøèíîé â ñë ÷àå ïðî-
äàæè, ïåðåäà÷è îáîð äîâàíèÿ èëè ïðè ïåðååçäå
íà íîâ þ êâàðòèð , ÷òîáû íîâûé âëàäåëåö îáîð -
äîâàíèÿ ìîã îçíàêîìèòüñÿ ñ ïðàâèëàìè åãî ô íê-
öèîíèðîâàíèÿ è îáñë æèâàíèÿ.
 Âíèìàòåëüíî ïðî÷èòàéòå ð êîâîäñòâî: â íåì ñî-
äåðæàòñÿ âàæíûå ñâåäåíèÿ ïî ñòàíîâêå è áåçî-
ïàñíîé ýêñïë àòàöèè ñòèðàëüíîé ìàøèíû.
Ðàñïàêîâêà è âûðàâíèâàíèå
Ðàñïàêîâêà
1. Ðàñïàê éòå ñòèðàëüí þ ìàøèí .
2. Óáåäèòåñü, ÷òî îáîð äîâàíèå íå áûëî ïîâðåæäåíî
âî âðåìÿ òðàíñïîðòèðîâêè. Ïðè îáíàð æåíèè ïî-
âðåæäåíèé  íå ïîäêëþ÷àéòå ìàøèí  ñâÿæè-
òåñü ñ ïîñòàâùèêîì íåìåäëåííî.
3. Óäàëèòå ÷åòûðå
òðàíñïîðòèðîâî÷íûõ
âèíòà è ðåçèíîâûå
ïðîáêè ñ ïðîêëàäêàìè,
ðàñïîëîæåííûå â çàä-
íåé ÷àñòè ñòèðàëüíîé
ìàøèíû (ñì. ðèñ.).
4. Çàêðîéòå îòâåðñòèÿ
ïðèëàãàþùèìèñÿ ïëàñ-
òèêîâûìè çàãë øêàìè.
5. Çàêðîéòå ïðèëàãàþùåéñÿ çàãë øêîé òðè îòâåðñòèÿ
äëÿ âèëêè îáîð äîâàíèÿ (âî âðåìÿ åãî òðàíñ-
ïîðòèðîâêè), ðàñïîëîæåííûå â çàäíåé íèæíåé ïðà-
âîé ÷àñòè îáîð äîâàíèÿ
6. Ñîõðàíÿéòå âñå äåòàëè: îíè Âàì ïîíàäîáÿòñÿ ïðè
ïîñëåä þùåé òðàíñïîðòèðîâêå ñòèðàëüíîé ìà-
øèíû.
 Íå ðàçðåøàéòå äåòÿì èãðàòü ñ ïàêîâî÷íûìè
ìàòåðèàëàìè.
Âûðàâíèâàíèå
1. Óñòàíîâèòå ñòèðàëüí þ ìàøèí íà ðîâíîì è ïðî÷íîì
ïîë , òàê ÷òîáû îíà íå êàñàëàñü ñòåí, ìåáåëè è ïðî-
÷èõ ïðåäìåòîâ.
2. Ïîñëå ñòàíîâêè ìàøèíû íà ìåñòî îòðåã ëèð é-
òå åå ñòîé÷èâîå ïîëîæåíèå ï òåì âðàùåíèÿ ïå-
ðåäíèõ íîæåê (ñì.
ðèñ.). Äëÿ ýòîãî ñíà÷à-
ëà îñëàáüòå êîíòðãàéê ,
ïîñëå çàâåðøåíèÿ ðå-
ã ëèðîâêè êîíòðãàéê
çàòÿíèòå.
Ïîñëå ñòàíîâêè ìàøèíû
íà ìåñòî ïðîâåðüòå ïî
ðîâíþ ãîðèçîíòàëüíîñòü
âåðõíåé êðûøêè êîðï ñà,
îòêëîíåíèå ãîðèçîíòàëè
äîëæíî áûòü íå áîëåå 2°.
Ïðàâèëüíîå âûðàâíèâàíèå îáîð äîâàíèÿ ïîìîæåò
èçáåæàòü ø ìà, âèáðàöèé è ñìåùåíèé âî âðåìÿ ðà-
áîòû ìàøèíû.
Åñëè ñòèðàëüíàÿ ìàøèíà ñòîèò íà ïîë , ïîêðûòîì
êîâðîì, áåäèòåñü, ÷òî åå îñíîâàíèå âîçâûøàåò-
ñÿ íàä êîâðîì.  ïðîòèâíîì ñë ÷àå âåíòèëÿöèÿ
á äåò çàòð äíåíà èëè âîâñå íåâîçìîæíà.
Ïîäêëþ÷åíèå ê âîäîïðîâîäíî è
ýëåêòðè÷åñêî ñåòè
Ïîäñîåäèíåíèå çàëèâíîãî øëàíãà
1. Âñòàâüòå ïðîêëàäê À â
êîíåö çàëèâíîãî øëàíãà
è íàâåðíèòå åãî íà âû-
âîä âîäîïðîâîäà õîëîä-
íîé âîäû ñ ðåçüáîâûì îò-
âåðñòèåì 3/4 äþéìà (ñì.
ðèñ.).
Ïåðåä ïîäñîåäèíåíèåì
îòêðîéòå âîäîïðîâîäíûé
êðàí è äàéòå ñòå÷ü ãðÿç-
íîé âîäå.
2. Ïîäñîåäèíèòå çàëèâ-
íîé øëàíã ê ñòèðàëüíîé
ìàøèíå, íàâèíòèâ åãî
íà âîäîïðèåìíèê, ðàñ-
ïîëîæåííûé â çàäíåé
âåðõíåé ÷àñòè ñïðàâà
(ñì. ðèñ.).
3. Óáåäèòåñü, ÷òî øëàíã íå ïåðåêð ÷åí è íå ïåðå-
æàò.
Äàâëåíèå âîäû äîëæíî áûòü â ïðåäåëàõ çíà÷å-
íèé, êàçàííûõ â òàáëèöå Òåõíè÷åñêèõ õàðàêòå-
ðèñòèê (ñì. ñ. 3).
Åñëè äëèíà âîäîïðîâîäíîãî øëàíãà îêàæåòñÿ
íåäîñòàòî÷íîé, îáðàòèòåñü â Àâòîðèçîâàííûé
Ñåðâèñíûé öåíòð.
Óñòàíîâêà
A

#
CIS
Ïîäñîåäèíåíèå ñëèâíîãî øëàíãà
Ïîâåñüòå çàãí òûé êî-
íåö ñëèâíîãî øëàíãà íà
êðàé ðàêîâèíû, âàííû,
èëè ïîìåñòèòå â
ñïåöèàëüíûé âûâîä
êàíàëèçàöèè. Øëàíã íå
äîëæåí ïåðåãèáàòüñÿ.
Âåðõíÿÿ òî÷êà ñëèâíî-
ãî øëàíãà äîëæíà íà-
õîäèòüñÿ íà âûñîòå 65-
100 ñì îò ïîëà. Ðàñïî-
ëîæåíèå ñëèâíîãî
øëàíãà äîëæíî îáåñ-
ïå÷èâàòü ðàçðûâ ñòð è
ïðè ñëèâå (êîíåö øëàí-
ãà íå äîëæåí áûòü
îï ùåí â âîä ).
 ñë ÷àå êðåïëåíèÿ íà
êðàé âàííîé èëè ðàêî-
âèíû, øëàíã âåøàåòñÿ
ñ ïîìîùüþ íàïðàâëÿ-
þùåé (âõîäèò â êîìï-
ëåêò ïîñòàâêè), êîòîðàÿ
êðåïèòñÿ ê êðàí (ðèñ.).
 Íå ðåêîìåíä åòñÿ ïðèìåíåíèå äëèíèòåëåé äëÿ
ñëèâíîãî øëàíãà, ïðè íåîáõîäèìîñòè äîï ñêàåò-
ñÿ åãî íàðàùèâàíèå øëàíãîì òàêîãî æå äèàìåòðà
è äëèíîé íå áîëåå 150 ñì.
Ïîäñîåäèíåíèå ê ýëåêòðîñåòè
Âíèìàíèå! Îáîð äîâàíèå îáÿçàòåëüíî äîëæíî
áûòü çàçåìëåíî!
1. Ìàøèíà ïîäêëþ÷àåòñÿ ê ýëåêòðè÷åñêîé ñåòè ïðè ïî-
ìîùè äâ õïîëþñíîé ðîçåòêè ñ çàçåìëÿþùèì êîíòàê-
òîì (ðîçåòêà íå ïîñòàâëÿåòñÿ ñ ìàøèíîé). Ôàçíûé
ïðîâîä äîëæåí áûòü ïîäêëþ÷åí ÷åðåç àâòîìàò çàùè-
òû ñåòè, ðàññ÷èòàííûé íà ìàêñèìàëüíûé òîê (òîê ñðà-
áàòûâàíèÿ) 16 À, è èìåþùèé âðåìÿ ñðàáàòûâàíèÿ íå
áîëåå 0,1 ñ.
2. Ïðè íàëè÷èè âáëèçè îò ïðåäïîëàãàåìîãî ìåñòà ñòà-
íîâêè ìàøèíû ðîçåòêè ñ çàçåìëÿþùèì êîíòàêòîì,
èìåþùåé òðåõïðîâîäí þ ïîäâîäê êàáåëÿ ñ ìåäíûìè
æèëàìè ñå÷åíèåì íå ìåíåå 1,5 êâ. ìì (èëè àëþìèíè-
åâûìè æèëàìè ñå÷åíèåì íå ìåíåå 2,5 êâ. ìì), äîðà-
áîòêà ýëåêòðîñåòè íå ïðîèçâîäèòñÿ. Ïðè îòñ òñòâèè
êàçàííîé ðîçåòêè è ïðîâîäêè ñëåä åò ïðîâåñòè èõ ìîí-
òàæ.
3. Ïðîêëàäêà çàçåìëåíèÿ îòäåëüíûì ïðîâîäîì íå
äîï ñêàåòñÿ.
4. Äëÿ äîðàáîòêè ýëåêòðè÷åñêîé ñåòè ðåêîìåíä åòñÿ
ïðèìåíÿòü ïðîâîä òèïà ÏÏÂ 3õ1,5 380 ÃÎÑÒ 6223-79.
Äîï ñêàåòñÿ ïðèìåíåíèå äð ãèõ ìàðîê êàáåëÿ, îáåñ-
ïå÷èâàþùèõ ïîæàðî- è ýëåêòðîáåçîïàñíîñòü ïðè ýêñ-
ïë àòàöèè ìàøèíû.
Ïåðåä âêëþ÷åíèåì ìàøèíû â ñåòü óáåäèòåñü, ÷òî:
lðîçåòêà è ïðîâîäêà ñîîòâåòñòâ þò òðåáîâàíèÿì, èç-
ëîæåííûì â äàííîì ðàçäåëå èíñòð êöèè;
líàïðÿæåíèå è ÷àñòîòà òîêà ñåòè ñîîòâåòñòâ þò äàí-
íûì ìàøèíû;
lðîçåòêà è âèëêà îäíîãî òèïà;
lðîçåòêà çàçåìëåíà â ñîîòâåòñòâèè ñ íîðìàìè áåçî-
ïàñíîñòè, îïèñàííûìè â äàííîì ðàçäåëå èíñòð êöèè
äîï ñêàåòñÿ îðãàíèçàöèÿ çàçåìëåíèÿ ðàáî÷èì í -
ëåì, ïðè ñëîâèè, ÷òî çàùèòíàÿ ëèíèÿ íå èìååò ðàç-
ðûâà è ïîäêëþ÷åíà íàïðÿì þ â îáâîä êàêèõ-ëèáî
ïðèáîðîâ (íàïðèìåð, ýëåêòðè÷åñêîãî ñ÷åò÷èêà).
Åñëè âèëêà íå ïîäõîäèò ê ðîçåòêå, åå ñëåä åò çàìå-
íèòü íà íîâ þ, ñîîòâåòñòâ þù þ ðîçåòêå, èëè çàìåíèòü
ïèòàþùèé êàáåëü. Çàìåíà êàáåëÿ äîëæíà ïðîèçâî-
äèòüñÿ òîëüêî êâàëèôèöèðîâàííûì ïåðñîíàëîì.
Çàïðåùàåòñÿ èñïîëüçîâàíèå ïåðåõîäíèêîâ, äâîéíûõ
è áîëåå ðîçåòîê è äëèíèòåëåé (îíè ñîçäàþò îïàñíîñòü
âîçãîðàíèÿ). Åñëè Âû ñ÷èòàåòå èõ èñïîëüçîâàíèå íå-
îáõîäèìûì, ïðèìåíÿéòå îäèí åäèíñòâåííûé äëèíè-
òåëü, äîâëåòâîðÿþùèé òðåáîâàíèÿì áåçîïàñíîñòè.
Îáîðóäîâàíèå, ïîäêëþ÷åííîå ñ íàðóøåíèåì òðåáî-
âàíè áåçîïàñíîñòè áûòîâûõ ïðèáîðîâ áîëüøî
ìîùíîñòè, èçëîæåííûõ â äàííî èíñòðóêöèè, ÿâëÿ-
åòñÿ ïîòåíöèàëüíî îïàñíûì.
Ïðîèçâîäèòåëü íå íåñåò îòâåòñòâåííîñòè çà
óùåðá çäîðîâüþ è ñîáñòâåííîñòè, åñëè îí âûçâàí
íåñîáëþäåíèåì óêàçàííûõ íîðì óñòàíîâêè.
Ïåðâû öèêë ñòèðêè
Ïî çàâåðøåíèè ñòàíîâêè, ïåðåä íà÷àëîì ýêñï-
ë àòàöèè íåîáõîäèìî ïðîèçâåñòè îäèí öèêë ñòèð-
êè ñî ñòèðàëüíûì ïîðîøêîì, íî áåç áåëüÿ, ïî ïðî-
ãðàììå 90°C áåç ïðåäâàðèòåëüíîé ñòèðêè.
ÑåðâèñÍåèñïðàâíîñòè
Ìåðû
áåçîïàñíîñòè Îáñëóæèâàíèå
è óõîä
Ïðîãðàììû Ìîþùèå
ñðåäñòâà
Óñòàíîâêà Îïèñàíèå
65 - 100 cm
Òåõíè÷åñêèå õàðàêòåðèñòèêè
Ìîäåëü AVSD 109
Ðàçìåðû
øèð èí à 5 9,5 ñ ì
âûñîòà 85 ñì
ãëóáèíà 40 ñì
Çàãðóçêà 1 - 4,5 êã
Ýëåêòðè÷åñêèå
ïàðàìåòðû
íàïðÿ åíèå 220/230 Â 50 ÃÖ
max ìîùíîñòü 1850 Âàòò
Ãèäðàâëè÷åñêèå
ïàðàìåòðû
max äàâëåíèå 1 Ìïà (10 áàð)
min äàâëåíèå 0,05 Ìïà (0,5 áàð)
îáúåì áàðàáàíà 40 ë
Ñêîðîñòü
îòæèìà äî 1000 îá/ìèí
Kîíòðîëüíûå
ïðîãðàììû
ñîãëàñíî
íîðìàòèâó EC
456
ïðîãðàììà 3; òåìïåðàòóðà 60°Ñ;
ïðè çàãðóçêå äî 4,5 êã.
Ìàøèíà ñîîòâåòñ òâóåò ñëåäóþùèì
Äèðåêòèâàì Åâðîïåéñêîãî
Ýêîíîìè÷åñêîãî ñîîáùåñòâà:
- 73/2 23/ ÅÅÑ îò 19.02.73 (íèçêîãî
íàïðÿ åíèÿ) è ïîñëåäóþùèå ìîäè-
ôèêàöèè
- 89/336 /ÅÅÑ îò 03.05.89 (ýëåêòðî-
ìàãíèòíîé ñîâìåñòèìîñòè) è
ïîñëåäóþùèå ìîäèôèêàöèè

$
+15
Ïàíåëü óïðàâëåíèÿ
Îïèñàíèå ñòèðàëüíî ìàøèíû
Ðàñïðåäåëèòåëü ìîþùèõ ñðåäñòâ äëÿ çàãð ç-
êè ñòèðàëüíîãî ïîðîøêà è ñìÿã÷èòåëåé (ñì. ñ. 20).
Êðàòêèé ïåðå÷åíü ïðîãðàìì äîáåí äëÿ áûñò-
ðîé ñïðàâêè. ×òîáû îòêðûòü ïåðå÷åíü, ïîòÿíèòå çà
ñåðûé ÿçû÷îê.
Êíîïêà ÒÅÌÏÅÐÀÒÓÐÀ ñë æèò äëÿ âûáîðà òåìïå-
ðàò ðû ñòèðêè (ñì. ñ. 19).
Êíîïêà ÎÒÆÈÌ èñïîëüç åòñÿ äëÿ âûáîðà ñêîðîñ-
òè îòæèìà, à òàêæå äëÿ åãî èñêëþ÷åíèÿ (ñì. ñ. 19).
Äèñïëåé ñë æèò äëÿ ïðîãðàììèðîâàíèÿ ñòèðàëü-
íîé ìàøèíû è äëÿ êîíòðîëÿ çà öèêëàìè ñòèðêè
(ñì. ñ. 17).
Ïðîãðàììàòîð
Äèñïëåé
Ðàñïðåäåëèòåëü
ìîþùèõ ñðåäñòâ
Ïåðå÷åíü
ïðîãðàìì
Êíîïêà ÎÒÆÈÌ
Êíîïêà
ÒÅÌÏÅÐÀÒÓÐÀ
Êíîïêà ÐÅÆÈÌ
(Mode)
Êíîïêà ÂÛÁÎÐ
ÔÓÍÊÖÈÈ (Select)
Êíîïêà ÂÊËÞ×ÅÍÈÅ/
ÂÛÊËÞ×ÅÍÈÅ
Êíîïêà ÏÓÑÊ/ÑÁÐÎÑ
(Start/Reset)
Êíîïêà ÐÅÆÈÌ èñïîëüç åòñÿ äëÿ âûáîðà äîïîë-
íèòåëüíûõ ô íêöèé äëÿ ïåðñîíàëèçàöèè öèêëîâ
ñòèðêè (ñì. ñ. 19).
Êíîïêîé ÂÛÁÎÐ âûáèðàþòñÿ äîïîëíèòåëüíûå
ô íêöèè äëÿ ïåðñîíàëèçàöèè öèêëîâ ñòèðêè
(ñì. ñ. 19).
Êíîïêà ÂÊËÞ×ÅÍÈÅ/ÂÛÊËÞ×ÅÍÈÅ ñë æèò äëÿ
âêëþ÷åíèÿ è âûêëþ÷åíèÿ ñòèðàëüíîé ìàøèíû.
Êíîïêà ÏÓÑÊ/ÑÁÐÎÑ èñïîëüç åòñÿ äëÿ çàï ñêà
ïðîãðàìì èëè äëÿ îòìåíû îøèáî÷íîãî ïðîãðàì-
ìèðîâàíèÿ.
Ïðîãðàììàòîð ñë æèò äëÿ âûáîðà ïðîãðàìì. Ð -
êîÿòêà ìîæåò áûòü òîïëåíà â ïàíåëü ïðàâëåíèÿ:
äëÿ åå èñïîëüçîâàíèÿ ñëåãêà íàæìèòå íà íåå â
öåíòðå  ð êîÿòêà âûäâèíåòñÿ íàð æ .
 ïðîöåññå âûïîëíåíèÿ ïðîãðàììû ðóêîÿòêà
îñòàåòñÿ íåïîäâèæíî .

%
CIS
Äèñïëå
Äèñïëåé  äîáíîå ñòðîéñòâî äëÿ ïðîãðàììèðîâàíèÿ îáîð äîâàíèÿ (ñì. ñ. 19), êîòîðîå òàêæå èíôîðìèð åò
ïîëüçîâàòåëÿ î öèêëå ñòèðêè è òåê ùåì ñîñòîÿíèè ìàøèíû.
Ïðè íàæàòèè êíîïêè ÏÓÑÊ/ÑÁÐÎÑ (Start/Reset) äëÿ
çàï ñêà ïðîãðàììû íà äèñïëåå ïîêàçûâàåòñÿ ïðè-
áëèçèòåëüíîå âðåìÿ, îñòàþùååñÿ äî çàâåðøåíèÿ
öèêëà.  ñë ÷àå ñòàíîâêè îòëîæåííîãî ñòàðòà ïðî-
ãðàììû (ï ñê ïî òàéìåð , ñì. ñ. 19) äèñïëåé á äåò
ïîêàçûâàòü âðåìÿ, îñòàâøååñÿ äî íà÷àëà ñòèðêè.
 ïðîöåññå âûïîëíåíèÿ öèêëà ñòèðêè äèñïëåé
ïîêàçûâàåò ñëåä þùèå ñâåäåíèÿ:
Òåêóùàÿ ôàçà öèêëà:
Ïðåäâàðèòåëüíàÿ Îòæèì
ñòèðêà
Ñòèðêà
Ïîëîñêàíèå Ñèìâîë
íå çàäå ñòâîâàí.
Âûáîð òèïà áåëüÿ:
Õëîïîê Øåðñòü
Öâåòíîå áåëüå Øåëê
Ñèíòåòèêà
Äîïîëíèòåëüíûå ôóíêöèè
äëÿ ïåðñîíàëèçèðîâàííî ñòèðêè:
Ñèìâîëû äîñò ïíûõ äîïîëíèòåëüíûõ ô íêöèé
âûäåëÿþòñÿ ðàìêîé. Äëÿ âûáîðà äîïîëíèòåëüíûõ
ô íêöèé ñì. ñ. 19.
Ñèìâîë íå çàäå ñòâîâàí.
Áëîêèðîâêà äâåðöû:
Ãîðÿùèé ñèìâîë ïîêàçûâàåò  äâåðöà çàáëîêèðîâàíà, ÷òîáû èñêëþ÷èòü åå ñë ÷àéíîå îòêðûâàíèå.
Âî èçáåæàíèå ïîâðåæäåíèé ïðåæäå, ÷åì îòêðûòü äâåðö , ïîäîæäèòå ïîêà ñèìâîë ïîãàñíåò.
Äàííàÿ ìîäåëü îñíàùåíà ñòðîéñòâîì, ïîçâîëÿþùèì îòêðûòü äâåðö òàêæå â ïðîöåññå âûïîëíåíèÿ íå-
êîòîðûõ ôàç öèêëà. Ýòî âîçìîæíî, êîãäà ñèìâîë íå ãîðèò.
Ïî çàâåðøåíèè ïðîãðàììû íà äèñïëåå ïîÿâëÿåòñÿ ñîîáùåíèå END (Êîíåö).
  ñë ÷àå íåèñïðàâíîñòè íà äèñïëåå ïîÿâëÿåòñÿ êîä îøèáêè, íàïðèìåð: F-01, êîòîðûé íåîáõîäèìî ñîîá-
ùèòü â Àâòîðèçîâàííûé Ñåðâèñíûé öåíòð (ñì. ñ. 24).
ÏðîãðàììûÓñòàíîâêà Îïèñàíèå ÑåðâèñÍåèñïðàâíîñòè
Ìåðû
áåçîïàñíîñòè Îáñëóæèâàíèå
è óõîä
Ìîþùèå
ñðåäñòâà

&
+15
Çàïóñê ìàøèíû. Ïðîãðàììû
Òàáëèöà ïðîãðàìì
Ïðèìå÷àíèå
«Îñòàíîâêà ñ âîäîé»: ñì. äîïîëíèòåëüí þ ô íêöèþ «Ëåãêàÿ ãëàæêà» íà ñ. 19. Äàííûå â òàáëèöå, ÿâëÿþòñÿ ñïðàâî÷íû-
ìè è ìîã ò ìåíÿòüñÿ â çàâèñèìîñòè îò êîíêðåòíûõ ñëîâèé ñòèðêè (îáúåì ñòèðêè, òåìïåðàò ðà âîäû â âîäîïðîâîäíîé
ñèñòåìå, òåìïåðàò ðà â ïîìåùåíèè è äð.).
Ñïåöèàëüíàÿ ïðîãðàììà
Ïîâñåäíåâíàÿ ñòèðêà 30' ìèí (ïðîãðàììà 9 äëÿ Ñèíòåòè÷åñêèõ òêàíåé) ïðåäíàçíà÷åíà äëÿ áûñòðîé ñòèðêè ñëàáîçàã-
ðÿçíåííîãî áåëüÿ: öèêë äëèòñÿ âñåãî 30 ìèí ò, ÷òî ïîçâîëÿåò ñýêîíîìèòü âðåìÿ è ýëåêòðîýíåðãèþ. Óñòàíîâèâ ýò
ïðîãðàìì (9 ïðè òåìïåðàò ðå 30°Ñ), Âû ìîæåòå ñòèðàòü ðàçëè÷íûå âèäû òêàíåé âìåñòå (çà èñêëþ÷åíèåì øåðñòè è
øåëêà) ïðè ìàêñèìàëüíîé çàãð çêå áåëüÿ 3 êã. Ìû ðåêîìåíä åì èñïîëüçîâàòü æèäêîå ìîþùåå ñðåäñòâî.
Êðàòêèå èíñòðóêöèè: Ïîðÿäîê
çàïóñêà ïðîãðàììû
1. Âêëþ÷èòå ñòèðàëüí þ ìàøèí , íàæàâ êíîïê .
2. Çàãð çèòå áåëüå è çàêðîéòå äâåðö ìàøèíû.
3. Óñòàíîâèòå ð êîÿòê ïðîãðàììàòîðà íà í æí þ
ïðîãðàìì . Íà äèñïëåå ïîÿâèòñÿ ïðîãíîçèð åìàÿ
ïðîäîëæèòåëüíîñòü âûáðàííîãî öèêëà. Òåìïåðàò -
ðà è ñêîðîñòü îòæèìà çàäàþòñÿ àâòîìàòè÷åñêè â
ñîîòâåòñòâèè ñ âûáðàííîé ïðîãðàììîé (êàê èçìå-
íèòü èõ ñì. íà ñ. 19).
4. Äîáàâüòå â ðàñïðåäåëèòåëü ìîþùåå ñðåäñòâî,
îïîëàñêèâàòåëü, îòáåëèâàòåëü (ñì. ñ. 20).
5. Çàï ñòèòå ïðîãðàìì , íàæàâ êíîïê ÏÓÑÊ/ÑÁÐÎÑ
(Start/Reset).
Äëÿ îòìåíû çàï ñêà äåðæèòå íàæàòîé êíîïê ÏÓÑÊ/
ÑÁÐÎÑ (Start/Reset) â òå÷åíèå 2-õ ñåê íä.
Ïî îêîí÷àíèè ïðîãðàììû íà äèñïëåå ïîÿâèòñÿ ñî-
îáùåíèå END (Êîíåö). Ïîäîæäèòå ïîêà íà äèñïëåå
ïîãàñíåò ñèìâîë áëîêèðîâêè äâåðöû. Âûêëþ÷èòå ñòè-
ðàëüí þ ìàøèí , íàæàâ êíîïê . Îòêðîéòå äâåðö
ìàøèíû. Âûí â áåëüå, îñòàâüòå äâåðö ìàøèíû ïðè-
îòêðûòîé, ÷òîáû äàòü èñïàðèòüñÿ îñòàâøåéñÿ âëàãå.
Îáÿçàòåëüíî ïåðåêðîéòå êðàí ïîäà÷è âîäû è îòêëþ-
÷èòå ìàøèí èç ñåòè.
Òêàíü è ñòåïåíü çàãðÿçíåíèÿ Ïð îã-
ðàììa
Òåìïå-
ðàòóðà
Ìîþùåå ñðåäñòâî Ñìÿã-
÷èòåëü
Îòáåëèâà-
íèå
(Ô óí êöèÿ )/
Îòáåëèâà-
òåëü
Äëèòå-
ëüíîñòü
öèêëà,
ìèí
Îïèñàíèå öèêëà ñòèðêè
ïðåäâ.
ñòèðêà
îñíîâíàÿ
ñòèðêà
Õëîïîê
Î÷åíü ñèëüíî çàãðÿçíåííîå
áåëîå áåëüå (ïðîñòûíè,
ñêàòåðòè è ò.ä.)
190°C  137
Ïðåäâàðèòåëüíàÿ ñòèðêà, ñòèðêà
ïðè âûñîêîé òåìïåðàòóðå,
ïîëîñêàíèå, ïðîìå óòî÷íûé è
îêîí÷àòåëüíûé îò èì
Î÷åíü ñèëüíî çàãðÿçíåííîå
áåëîå áåëüå (ïðîñòûíè,
ñêàòåðòè è ò.ä.)
290°C 
Äåëèêàò./
Îáû÷íûé 120
Ñòèðêà ïðè âûñîêîé òåìïåðàòóðå,
ïîëîñêàíèå, ïðîìå óòî÷íûé è
îêîí÷àòåëüíûé îò èì
Ñèëüíî çàãðÿçíåííîå áåëîå è
ïðî÷íî îêðàøåííîå öâåòíîå áåëüå 360°C 
Äåëèêàò./
Îáû÷íûé 105 Ñòèðêà ïðè 60°C, ïîëîñêàíèå,
ïðîìå óòî÷íûé è îêîí÷àòåëüíûé îò èì
Ñëàáî çàãðÿçíåííîå áåëîå è
ëèíÿþùåå öâåòíîå áåëüå
(ðóáàøêè, ìàêè è ïð.)
440°C 
Äåëèêàò./
Îáû÷íûé 72 Ñòèðêà ïðè 40°C, ïîëîñêàíèå, ïðîìå óòî÷íûé è îêîí÷àòåëüíûé îò èì
Ñëàáî çàãðÿçíåííîå
ëèíÿþùåå öâåòíîå áåëüå 530°C 
Äåëèêàò./
Îáû÷íûé 65 Ñòèðêà ïðè 30°C, ïîëîñêàíèå, ïðîìå óòî÷íûé è îêîí÷àòåëüíûé îò èì
Ñèíòåòèêà
Ñèëüíî çàãðÿçíåííàÿ, ïðî÷íî
îêðàøåííàÿ öâåòíàÿ (äåòñêàÿ
îäå äà è ïð.)
660°C  Äåëèêàòí. 77
Ñòèðêà ïðè 60°C, ïîëîñêàíèå,
îñòàíîâêà ñ âîäîé èëè äåëèêàòíûé
îò èì
Ñèëüíî çàãðÿçíåííàÿ, ïðî÷íî
îêðàøåííàÿ öâåòíàÿ öâåòíàÿ
(ëþáàÿ îäå äà)
640°C 
Äåëèêàòí. 62
Ñòèðêà ïðè 40°C, ïîëîñêàíèå,
îñòàíîâêà ñ âîäîé èëè äåëèêàòíûé
îò èì
Ñèëüíî çàãðÿçíåííàÿ, ïðî÷íî
îêðàøåííàÿ öâåòíàÿ (äåòñêàÿ
îäå äà è ïð.)
750°C 
Äåëèêàòí. 73
Ñòèðêà ïðè 50°C, ïîëîñêàíèå,
îñòàíîâêà ñ âîäîé èëè äåëèêàòíûé
îò èì
Ñëàáî çàãðÿçíåííàÿ, äåëèêàòíàÿ
öâåòíàÿ (ëþáàÿ îäå äà) 840°C 
Äåëèêàòí. 58
Ñòèðêà ïðè 40°C, ïîëîñêàíèå,
îñòàíîâêà ñ âîäîé èëè äåëèêàòíûé
îò èì
Ñëàáî çàãðÿçíåííàÿ, äåëèêàòíàÿ
öâåòíàÿ (ëþáàÿ îäå äà) 930°C  30 Ñòèðêà ïðè 30°C, ïîëîñêàíèå è
äåëèêàòíûé îò èì
Äåëèêàòíûå òêàíè
Øåðñòü 10 40°C  Äåëèêàòí. 50 Ñòèðêà ïðè 40°C, ïîëîñêàíèå è
äåëèêàòíûé îò èì
Îñîáî äåëèêàòíûå òêàíè è îäå äà
(çàíàâåñè, øåëê, âèñêîçà è ïð.) 11 30°C  45 Ñòèðêà ïðè 30°C, ïîëîñêàíèå,
îñòàíîâ êà ñ âîäîé èëè ñëèâ
×ÀÑÒÈ×ÍÛÅ ÏÐÎÃÐÀÌÌÛ
Ïîëîñêàíèå  Ïîëîñêàíèå è îò èì
Äåëèêàòíîå ïîëîñêàíèå  Ïïîëîñêàíèå, îñòàíîâêà ñ âîäîé
èëè ñëèâ
Îò èì Ñëèâ è ñèëüíûé îò èì
Äåëèêàòíûé îò èì Ñëèâ è äåëèêàòíûé îò èì
Ñëèâ Ñëèâ

'
CIS
Ïåðñîíàëèçàöèÿ ñòèðêè
Óñòàíîâêà òåìïåðàòóðû
Ïðè íàæàòèè êíîïêè íà äèñïëåå ïîêàçûâàåòñÿ ìàêñèìàëü-
íàÿ äîï ñòèìàÿ òåìïåðàò ðà äëÿ âûáðàííîé ïðîãðàììû. Íà-
æìèòå íà ýò æå êíîïê , ÷òîáû ïîíèçèòü òåìïåðàò ð .
OFF îáîçíà÷àåò ñòèðê â õîëîäíîé âîäå. Ðåã ëèðîâê òåì-
ïåðàò ðû ìîæíî âûïîëíÿòü äëÿ âñåõ ïðîãðàìì ñòèðêè.
Óñòàíîâêà ñêîðîñòè îòæèìà
Ïðè íàæàòèè êíîïêè íà äèñïëåå ïîêàçûâàåòñÿ ìàêñèìàëü-
íàÿ äîï ñòèìàÿ ñêîðîñòü îòæèìà äëÿ âûáðàííîé ïðîãðàììû.
Êàæäîå íàæàòèå êíîïêè ìåíüøàåò ñêîðîñòü îòæèìà
âïëîòü äî åãî èñêëþ÷åíèÿ  «OFF» (âûêëþ÷åíî). Íàæìèòå
êíîïê åùå ðàç äëÿ âîçâðàòà ê ìàêñèìàëüíîì çíà÷åíèþ.
Èñêëþ÷åíèå îòæèìà îáîçíà÷àåòñÿ ñèìâîëîì . Ðåã ëè-
ðîâê ñêîðîñòè îòæèìà ìîæíî âûïîëíÿòü äëÿ âñåõ ïðî-
ãðàìì ñòèðêè, êðîìå ïðîãðàììû 11 è Ñëèâ.
Äîïîëíèòåëüíûå ôóíêöèè
Ñòèðàëüíàÿ ìàøèíà èìååò ðàçëè÷íûå äîïîëíèòåëüíûå
ô íêöèè, êîòîðûå ïîìîã ò Âàì ïîë ÷èòü æåëàåìûå ðåç ëü-
òàòû ñòèðêè. Âûáîð äîïîëíèòåëüíûõ ô íêöèé âñåãäà îñ -
ùåñòâëÿåòñÿ â ñëåä þùåé ïîñëåäîâàòåëüíîñòè:
1. Íàæìèòå êíîïê ÐÅÆÈÌ (Mode), ÷òîáû ïðîñìîòðåòü ðàçëè÷íûå èìåþùèåñÿ äîïîëíèòåëüíûå ô íêöèè.
Äîñò ïíûé ñèìâîë á äåò ìèãàòü.
2. ×òîáû âûáðàòü ô íêöèþ, íàæèìàéòå êíîïê ÂÛÁÎÐ (Select) äî òåõ ïîð, ïîêà íà äèñïëåå íå ïîÿâèòñÿ ñîîá-
ùåíèå ON (ÂÊËÞ×ÅÍÎ) (äëÿ çàï ñêà ïðîãðàììû ïî òàéìåð ïîÿâèòñÿ çíà÷åíèå âðåìåíè: ñì. ïðèâåäåííóþ
íèæå òàáëèöó)
3. Ïîäòâåðäèòå âûáîð ïîâòîðíûì íàæàòèåì êíîïêè ÐÅÆÈÌ (Mode): ñèìâîë äîïîëíèòåëüíîé ô íêöèè íà
äèñïëåå ïåðåñòàíåò ìèãàòü.
Âûáðàííûå äîïîëíèòåëüíûå ô íêöèè âûäåëÿþòñÿ íà äèñïëåå ðàìêîé.
ÏðîãðàììûÓñòàíîâêà Îïèñàíèå ÑåðâèñÍåèñïðàâíîñòè
Ìåðû
áåçîïàñíîñòè Îáñëóæèâàíèå
è óõîä
Ìîþùèå
ñðåäñòâà
Äîïîëíèòåëüíàÿ
ôóíêöèÿ Íàçíà÷åíèå Èñïîëüçîâàíèå Äîñòóïíà ñ
ïðîãðàììàìè:
Òàéìåð îòñðî÷êè
Îòñðî÷êà çàïóñêà
ïðîãðàììû âïëîòü
äî 24 ÷.
Íà èìàéòå íåîäíîêðàòíî êíîïêó ( ÂÛÁÎÐ  SELECT) âïëîòü äî
ïîëó÷åíèÿ íà äèñïëåå åëàåìîãî âðåìåíè îòñðî÷êè. OFF îáîçíà÷àåò,
÷òî îòëî åííûé ñòàðò ïðîãðàììû íå áûë óñòàíîâëåí.
Ñî âñåìè
ïðîãðàììàìè
Îòáåëèâ àíèå
Öèêë îòáåëèâàíèÿ
äëÿ óäàëåíèÿ
íàèáîëåå ñòîéêèõ
çàãðÿçíåíèé.
Íàëåéòå îòáåëèâàòåëü â äîïîëíèòåëüíóþ âñòàâêó 4 (ñì. ñ. 20).
Îïöèÿ íå èñïîëüçóåòñÿ ñ ôóíêöèåé «ËÅÃKÀß ÃËÀÆKÀ».
2, 3, 4, 5,
6, 7, 8, 10,
Ïîë îñ êàí èå .
Ëåãêàÿ ãëàæêà
Óìåíüøåíèå
ñòåïåíè
ñìèíàåìîñòè
òêàíåé,
îáëåã÷åíèå
ïîñëåäóþùåãî
ãëà åíèÿ.
Ïðè âûáîðå ýòîé ôóíêöèè ïðîãðàììû 6,7,8,11 è Äåëèêàòíîå
ïîëîñêàíèå áóäóò ïðåðâàíû  áåëüå îñòàåòñÿ çàìî÷åííûì â âîäå
(îñòàíîâêà ñ âîäîé), ñèìâîë áóäåò ìèãàòü:
 ×òîáû çàâåðøèòü öèêë, íà ìèòå êíîïêó ÏÓÑK/ÑÁÐÎÑ (Start/Resert).
 ×òîáû çàêîí÷èòü ïðîãðàììó ñëèâîì óñòàíîâèòå ðóêîÿòêó
ïðîãðàììàòîðà íà ñîîòâåòñòâóþùèé ñèìâîë è íà ìèòå êíîïêó
ÏÓÑK/ÑÁÐÎÑ (St art/ Res ert ).
Äàííàÿ îïöèÿ íå èñïîëüçóåòñÿ ñ ôóíêöèåé «ÎÒÁÅËÈÂÀÍÈÅ».
Âñå ïðîãðàììû,
êðîìå 1, 2, 9, 10
è Ñëèâ
Ñóïåð ñòèðêà
Ïîçâîëÿåò ïîëó÷èòü
áåçóïðå÷íî ÷èñòîå
áåëüå, çàìåòíî
áîëåå áåëîå ïî
ñðàâíåíèþ ñî
ñòàíäàðòîì ëàññà À.
Îïöèÿ íå èñïîëüçóåòñÿ ñ ôóíêöèåé «ÁÛÑÒÐÀß ÑÒÈÐKÀ». 1, 2, 3, 4,
5, 6, 7, 8
Áûñòðàÿ ñòèðêà
Ñîêðàùàåò
ïðîäîë èòåëüíîñò-
ü öèêëà ñòèðêè
ïðèìåðíî íà 30%.
Îïöèÿ íå èñïîëüçóåòñÿ ñ ôóíêöèåé «ÑÓÏÅÐ ÑÒÈÐKÀ». 1, 2, 3, 4,
5, 6, 7, 8
Äîïîëíèòåëüíîå
ïîëîñêàíèå
Ïîâ ûøàåò
ýôôåêòèâíîñòü
ïîëîñêàíèÿ.
Ïðèìåíåíèå ýòîé ôóíêöèè ðåêîìåíäóåòñÿ ïðè ïîëíîé çàãðóçêå ìàøèíû
èëè ïðè èñïîëüçîâàíèè áîëüøîãî êîëè÷åñòâà ìîþùåãî ñðåäñòâà.
1, 2, 3, 4,
5, 6, 7, 8,
Ïîë îñ êàí èå .


+15
Ðàñïðåäåëèòåëü ìîþùèõ ñðåäñòâ
Õîðîøèé ðåç ëüòàò ñòèðêè çàâèñèò òàêæå îò ïðàâèëü-
íîé äîçèðîâêè ìîþùåãî ñðåäñòâà: åãî èçáûòîê íå
ãàðàíòèð åò áîëåå ýôôåêòèâí þ ñòèðê , íàïðîòèâ ìî-
æåò ïðèâåñòè ê îáðàçîâàíèþ íàëåòîâ âí òðè ìàøè-
íû è çàãðÿçíåíèþ îêð æàþùåé ñðåäû.
Âûäâèíüòå ðàñïðåäåëè-
òåëü è çàïîëíèòå åãî
îòäåëåíèÿ ìîþùèì
ñðåäñòâîì è ñìÿã÷èòå-
ëåì:
Îòäåëåíèå 1: ìîþùåå ñðåäñòâî äëÿ ïðåäâà-
ðèòåëüíî ñòèðêè (ïîðîøîê)
Ïåðåä çàãð çêîé ñòèðàëüíîãî ïîðîøêà áåäèòåñü,
÷òî îòäåëåíèå 4 äëÿ îòáåëèâàòåëÿ â íåì íå ñòà-
íîâëåíî.
Îòäåëåíèå 2: ìîþùåå ñðåäñòâî äëÿ ñòèðêè
(ïîðîøîê èëè æèäêîå)
Æèäêîå ñðåäñòâî äëÿ ñòèðêè çàëèâàåòñÿ íåïîñðåä-
ñòâåííî ïåðåä çàï ñêîì ìàøèíû.
Îòäåëåíèå 3: Äîáàâêè (ñìÿã÷èòåëè, àðîìàòè-
çàòîðû è ïð.)
Íå çàïîëíÿéòå îòäåëåíèå 3 äëÿ îïîëàñêèâàòåëåé
âûøå ðåøåòêè.
Äîïîëíèòåëüíîå îòäåëåíèå 4:
Îòáåëèâàòåëü è äåëèêàòíû îòáåëèâàòåëü
 Íå èñïîëüç éòå ìîþùèå ñðåäñòâà, ïðåäíàçíà÷åí-
íûå äëÿ ð ÷íîé ñòèðêè  îáðàç þùàÿñÿ îáèëüíàÿ
ïåíà õ äøàåò ðåç ëüòàò ñòèðêè è ìîæåò âûâåñòè
èç ñòðîÿ ñòèðàëüí þ ìàøèí .
Îòáåëèâàíèå
 Îáû÷íû îòáåëèâàòåëü ïðèìåíÿþò ïðè ñòèðêå
ïðî÷íûõ áåëûõ òêàíåé; äåëèêàòíû îòáåëèâàòåëü
ìîæíî èñïîëüçîâàòü äëÿ öâåòíûõ, ñèíòåòè÷åñêèõ è
øåðñòÿíûõ òêàíåé.
Ëîòîê 4 äëÿ îòáåëèâàòå-
ëÿ âñòàâëÿåòñÿ â îòäå-
ëåíèå 1 ðàñïðåäåëèòåëÿ
ìîþùèõ ñðåäñòâ. Íå
çàïîëíÿéòå ëîòîê 4
âûøå îòìåòêè max (ñì.
ðèñ.).
Äëÿ îñ ùåñòâëåíèÿ
òîëüêî îòáåëèâàíèÿ
íàëåéòå îòáåëèâàòåëü â
äîïîëíèòåëüí þ âñòàâ-
ê 4 è âûáåðèòå ïðîãðàìì Ïîëîñêàíèå (äëÿ
õëîïêîâûõ òêàíåé) èëè Äåëèêàòíîå ïîëîñêàíèå
(äëÿ ñèíòåòè÷åñêèõ òêàíåé). Äëÿ îòáåëèâàíèÿ â
ïðîöåññå ñòèðêè äîáàâüòå ñòèðàëüíûé ïîðîøîê è
ñìÿã÷èòåëü, âûáåðèòå í æí þ ïðîãðàìì è çàäåé-
ñòâ éòå ô íêöèþ «Îòáåëèâàíèå» (ñì. ñ. 19).
Èñïîëüçîâàíèå äîïîëíèòåëüíîé âñòàâêè 4 èñêëþ÷à-
åò âîçìîæíîñòü ïðèìåíåíèÿ ïðåäâàðèòåëüíîé ñòèð-
êè. Êðîìå òîãî, îòáåëèâàíèå íå ìîæåò áûòü ïðîâå-
äåíî ñ ïðîãðàììàìè 11 (Øåëê) è Ïîâñåäíåâíàÿ ñòèð-
êà 30 ìèí. (ñì. ñ. 18).
Ïîäãîòîâêà áåëüÿ
 Ðàçáåðèòå áåëüå:
- â ñîîòâåòñòâèè ñ òèïîì òêàíè / îáîçíà÷åíèÿ íà ýòèêåòêå.
- ïî öâåò : îòäåëèòå öâåòíîå áåëüå îò áåëîãî.
 Âûíüòå èç êàðìàíîâ âñå ïðåäìåòû è ïðîâåðüòå
õîðîøî ëè äåðæàòñÿ ï ãîâèöû.
 Íå ïðåâûøàéòå ìàêñèìàëüíîå íîðìû çàãð çêè
áàðàáàíà, êàçàííûå äëÿ ñ õîãî áåëüÿ:
Ïðî÷íûå òêàíè: ìàêñ. 4,5 êã
Ñèíòåòè÷åñêèå òêàíè: ìàêñ. 2,5 êã
Äåëèêàòíûå òêàíè: ìàêñ. 2 êã
Øåðñòü: ìàêñ. 1 êã
Âåñ áåëüÿ
1 ïðîñòûíÿ 400  500 ã
1 íàâîëî÷êà 150 -200 ã
1 ñêàòåðòü 400  500 ã
1 õàëàò 900 1,200 ã
1 ïîëîòåíöå 150 -250 ã
Îñîáåííîñòè ñòèðêè
îòäåëüíûõ èçäåëè
Çàíàâåñêè: ñâåðíèòå è ïîëîæèòå â íàâîëî÷ê èëè â
ñåò÷àòûé ìåøî÷åê. Ñòèðàéòå îòäåëüíî, íå ïðåâûøàÿ
ïîëîâèíû çàãð çêè áàðàáàíà. Âûáåðèòå ïðîãðàìì
11, àâòîìàòè÷åñêè èñêëþ÷àþù þ îòæèì.
Ñòåãàííûå êóðòêè è ïóõîâèêè: åñëè ï õîâèê íà òè-
íîì èëè ã ñèíîì ï õ , åãî ìîæíî ñòèðàòü â ñòèðàëü-
íîé ìàøèíå. Âûâåðíèòå ê ðòê íàèçíàíê , çàãð çèòå
â áàðàáàí íå áîëåå 2-3 êã èçäåëèé. Ïîâòîðèòå ïîëîñ-
êàíèå 1-2 ðàçà, èñïîëüç éòå äåëèêàòíûé îòæèì.
Ïàðóñèíîâûå òóôëè: Ïàð ñèíîâûå ò ôëè
ïðåäâàðèòåëüíî î÷èñòèòå îò ãðÿçè è ñòèðàéòå ñ
ïðî÷íûìè òêàíÿìè èëè äæèíñàìè, åñëè ïîçâîëÿåò öâåò.
Íå ñòèðàéòå ñ áåëûìè âåùàìè.
Øåðñòü: Äëÿ äîñòèæåíèÿ íàèë ÷øèõ ðåç ëüòàòîâ
ñòèðêè çàãð æàéòå íå áîëåå 1 êã áåëüÿ è èñïîëü-
ç éòå ñïåöèàëüíûå æèäêèå ñðåäñòâà, ïðåäíàçíà-
÷åííûå äëÿ ñòèðêè øåðñòÿííûõ èçäåëèé.
Woolmark Platinum Care
(Ïëàòèíîâû êàøåìèð 
äåëèêàòíîñòü ðó÷íî ñòèðêè)
Ariston ñòàíîâèë íîâûé ñòàíäàðò âûñîêîýô-
ôåêòèâàíîé ñòèðêè, ïðèçíàííûé Êîìïàíèåé
Woolmark ñ ïðåñòèæíîé ìàðêîé Woolmark
Platinum Care. Åñëè íà âàøåé ñòèðàëüíîé ìà-
øèíå èìååòñÿ ëîãîòèï Woolmark Platinum Care, â íåé
ìîæíî ñòèðàòü ñ îòëè÷íûì ðåç ëüòàòîì øåðñòÿíûå èçäå-
ëèÿ íà ýòèêåòêå êîòîðûõ íàïèñàíî «òîëüêî ð ÷íàÿ ñòèð-
êà» (M.00221).
Âûáåðèòå ïðîãðàìì 10 äëÿ âñåõ èçäåëèé ñ ýòèêåòêîé
«Ð ÷íàÿ ñòèðêà»( ) è èñïîëüç éòå ñïåöèàëüíûå
ñðåäñòâà äëÿ ñòèðêè øåðñòè.
Ìîþùèå ñðåäñòâà è áåëüå
MAX
12
4
3
MAX
MAX
