BCVPIR60 SERIES Vandal Proof IR Bullet Cameras
PERFECT NIGHT TIME IMAGES
The ARM BCVPIR60 series bullet cameras are built to
survive some of the toughest outdoor conditions.
The dual layer, zinc-alloy housing can withstand
500lbs of direct force and stay on target. Toughness is
not their only asset, both 420 and 550 line models are
equipped with an aspherical 4.3mm lens not found in
most bullet style cameras. High quality images start
with a great lens, aspherical lenses create brighter
and clearer pictures. The cameras dual voltage design
can operate using either 12VDC or 24VAC power and
the cable management mount prohibits easy access
to power and video cables. The 550 line model is
equipped with a high quality chipset that generates
outstanding high resolution images. The ARM
BCVPIR60 series is feature-packed with:
Up to 550 Lines of Resolution
■
500lb of Force Mounting System■
Aspherical 4.3mm Lens■
60’ IR Range■
Dual Voltage Power■
Cable Management Mount■
Camera shown is
C550BCVPIR60
Good Looks,
Built Tough.
.

www.armelectronics.com 1. 888.771.4544 [email protected]
BCVPIR60 SERIES Vandal Proof IR Bullet Cameras
FEATURES + BENEFITS
High Performance
Up to 550 Lines of Resolution
State of the art imaging
devices create clear, high
quality images.
Aspherical Lens Technology
High quality images start with
a great lens. Aspherical lenses
create brighter and clearer
pictures by focusing more
light onto the cameras image
sensor.
60” IR Range
The 18 built-in infrared LED’s
allow you to see objects as
far as 60’ away in complete
darkness.
500LB of Force Mount
Extremely tough mounting
system can withstand 500lb of
force and still keep the camera
on-target.
Convenience
Dual Voltage Power
These cameras operate
eciently on both short 12VDC
or long 24VAC power runs.
Multiple Camera Models
Choose a resolution that
ts your application. The
420 line model provides
excellent pictures and the high
resolution 550 line models
picture quality is outstanding.
Auto Gain Control
No need for experimenting
with dip-switch congurations
for lighting. These cameras
automatically increase or
decrease Gain for any lighting
condition.
Total Security
Super Tough Housing
The dual layer, high-tech, zinc-
alloy housing is 1/4 inch thick
and protects the camera from
most attacks.
Heavy Duty Cable
Management Mount
Heavy duty mount keeps
your camera on target and
a pass-through cable design
eliminates the chance of
exposed wires being cut.
3-Axis Mount
Perfect positioning on any wall
or ceiling application is easy
for these cameras with the
included 3-axis mount.
IP66 Weather Proof Rating
Impervious to dust and strong
jets of water these cameras
operate perfectly, rain or shine.

I Need... C420BCVPIR60 C550BCVPIR60
STANDARD RESOLUTION 
HIGH RESOLUTION 
DAY/NIGHT IMAGES  
INFRARED LED'S 60’ RANGE 60’ RANGE
DUAL VOLTAGE  
3.3”
r 1.34”
2.6”
8.6”
ø3.3
www.armelectronics.com 1. 888.771.4544 [email protected]
BCVPIR60 SERIES Vandal Proof IR Bullet Cameras
MODEL NUMBERS | LINE ART | ACCESSORIES
LINE ART – BCVPIR60 SERIES
Both Units Include:
(1) User Manual
(1) Adjustment Wrench
(3) Mounting Screws
INCLUDED ACCESSORIES
CBL3BNC
3’ BNC Cable
Also Available in
6’, 25’, 50’ and 100’
VCCORD
1000’Twisted Pair
Video Balun with
15” BNC Cable
CSP1
5AMP Max Current
Coaxial Surge
Protector
LCD1920HG
19” LCD Monitor
Also Available
in 15” and 17”
RECOMMENDED ACCESSORIES

www.armelectronics.com 1. 888.771.4544 [email protected]
BCVPIR60 SERIES Vandal Proof IR Bullet Cameras
TECHNICAL SPECIFICATIONS
Specications C420BCVPIR60
Imaging Device 1/3" SONY CCD
TV System NTSC
Pixels 512(H)x492(V)
Scanning System 2:1 Interlace
Sync. System Internal
Resolution More than 420 TV lines
IR LED Wavelength 850nm
IR LED Range 60'
IR LED Count 18
Lens Aspherical Lens 4.3mm
Minimum Illumination 0.1 Lux / F1.6
Minimum Illumination (IR On) 0.0 Lux
S/N Ratio More than 48dB
Gamma Charateristic 0.45
Video Output 1 Vp-p, 75 Ohm Composite BNC
Electronic Shutter Auto and up to 1/100,000
Back Light Compensation Full Auto
Auto White Balance ATW With MCT (Multi-Color Temp.)
Auto Gain Control Full Auto
Power Supply DC12V / AC24V (Dual power -/+10%)
Consumption 550mA (IR On)
Operating Temperature 14°F to 113°F
Storage Temperature -22°F to 140°F
Dimensions (LxWxH) 2.64" x 3.35" x 8.9"
Weight 2.2lbs
Weatherproof Rating IP66
Specications C550VPIR60
Imaging Device 1/3" SONY Hi-Res Super HAD CCD
TV System NTSC
Pixels 768(H)x494(V)
Scanning System 2:1 Interlace
Sync. System Internal
Resolution More than 550 TV lines
IR LED Wavelength 850nm
IR LED Range 60'
IR LED Count 18
Lens Aspherical Lens 4.3mm
Minimum Illumination 0.2 Lux / F1.2
Minimum Illumination (IR On) 0.0 Lux
S/N Ratio More than 48dB
Gamma Charateristic 0.45
Video Output 1 Vp-p, 75 Ohm Composite BNC
Electronic Shutter Auto and up to 1/100,000
Back Light Compensation Full Auto
Auto White Balance ATW With MCT (Multi-Color Temp.)
Auto Gain Control Full Auto
Power Supply DC12V / AC24V (Dual power -/+10%)
Consumption 550mA (IR On)
Operating Temperature 14°F to 113°F
Storage Temperature -22°F to 140°F
Dimensions (LxWxH) 2.64" x 3.35" x 8.9"
Weight 2.2lbs
Weatherproof Rating IP66
