DU-1500T Antenna Tuner
User’s Manual
ARRAY SOLUTIONS
2611 N Belt Line Road - Suite 109
Sunnyvale, TX, 75182, USA
[phone] office
[phone] fax
[email protected]
www.arraysolutions.com

DU-1500T Antenna Tuner
FEATURES
The DU 1500T optimizes the performance of your antenna and transmitter or SWL receiver
by providing adjustable impedance matching.The DU1500T also measures the Power and
Standing Wave Ratio (SWR), which allows you to tune the indicted SWR to the lowest
possible ratio for the selected transmit frequency.
Specifications
Front Panel Indicators
Meter…………………………Crossed Needles Power and SWR meter.
Controls
Input Tuning………………….Continuous rotation 4.5 kV capacitor 330 pF
Antenna Tuning………………Continuous rotation 4.5kV capacitor 330 pF
Antenna Switch Selector………Five position ceramic switch: COAX 1, Tuned and
COAX 2 Tuned and BYPASS, COAX 1 DIRECT,
COAX 2 DIRECT
Power Range Switch…………..Two position: 200 W / 2 kW
Warning: On 1.8 MHz for an SWR higher than 3:1 Do not exceed 800 W!!
Rear Panel Connectors
Coax 1…………………………...SO-239 Teflon connector
Coax 2…………………………...SO-239 Teflon connector
Balanced Line……………………Dual high voltage ceramic terminal,
Includes 4:1 balun
Other
Frequency Coverage……………...1.8 - 30 MHz, continuously tunable
Power Rating ………………….1500 W CW
Input impedance………………….50 Ω
Output impedance……………… 25 - 600 Ωfor coaxial, for single wire 2000 Ω
Dimensions ……………………...H 4.7” (12 cm) W 13” (33 cm) x D 13” (33 cm)
Weight…………………………....10 lb (4.5 kg)

Controls and Connectors
DU1500T Front Panel
Front Panel Functions
1. Output (Transmitter)
Continously adjustable output capacitor
2. Power and SWR Meter
The dual needle meter displays FORWARD and REFLECTED Power in Watts.
The SWR in measured where the two needles intersect on the red curved scales.
3. INPUT (Antenna)
Continuously adjustable input capacitor.

4. DIRECT-TUNED MODE SWITCH
Five-position rotary switch an output coaxial connector.
1. TUNED COAX 1 selects the COAX 1 connector trough the impedace matching
circuit.
2. TUNED COAX 2 selects the COAX 2 connector trough the impedance matching
circuit.
3. DIRECT BYPASS selects BYPASS COAX connector bypassing the impedance
matching circuit but provinding SWR, FORWARD, and REFLECTED power
meter readings.
4. DIRECT COAX 1 select the COAX 1 connector bypassing the impedance
matching circuit but providing SWR, FORWARD, and REFLECTED meter
readings.
5. DIRECT COAX 2 selects the COAX 2 connector bypassing the impedance
matching circuit but providing SWR, FORWARD, and REFLECTED meter
readings.
6. TUNED WIRE/BAL selects the BAL.LINE+COAX 1 connector through the
impedance matching circuit.
5. POWER RANGE SWITCH
Two-position switch selects the range (200W or 2kW) of FORWARD and
REFLECTED Power displayed on the power meter.
When the METER ( power range) switch is on 200 W the FORWARD meter
scale reads 200 W full scale and the REFLECTED meter scale reads 40 W at
full scale.
When the METER switch is on 2 kW, the FORWARD meter scale reads 2 kW
full scale and the REFLECTED meter scale reads 400 W full scale.

Rear Panel Connectors
DU1500T Rear Panel
1. RF INPUT - Coaxial connector for input from SWL receiver or transmitter.
2 COAX 1 - Coaxial connector for output to Antenna One.
3. COAX 2 - Coaxial connector for output to Antenna Two.
4. BYPASS - Coaxial connector for output to dummy load or third coax output.
5. GROUND - Post/Wing-nut type ground connector.
6. BALANCED OUTPUT - Two ceramic post for output to RF balanced twin-lead
antennas.
7. Install Jumper to use the balanced output.

Installation
Select a location for the DU 1500T that allows the connectors to be free of any possible
Contact during operation.
WARNING: Some balanced or end-fed antennas will produce high RF
voltages at the wing nut connector. RF burns may occur if touched
during transmission
1. Connect a coax cable from your transmitter or receiver to the RF INPUT connector on
the rear panel.Keep the cable as short as possible. If you use a linear amplifier,connect
your transmitter to the linear amplifier output to the DU 1500T.
2. Connect coax cable(s) from your antenna to COAX 1 or COAX 2 connectors on the rear
panel.Thes connectors are either direct from the transmitter or trough the tuned circuit
depending ont he setting of the OUTPUT SELECTOR switch ont he front panel.
3If you are using a balanced feed antenna,connect the INSTALL JUMPER in the COAX 1
connector and switch band switch TUNED COAX 1.
4. If using a single wire antenna, connect it to COAX 1 without installing the jumper.
5. Connect a dummy load to the BYPASS connector using a coax cable. This
lets you select the dummy load from the OUTPUT SELECTOR switch. Any antenna
that does not require the use o fan antenna tuner may be connected to the BYPASS
connector, if desired.
Before Operation
1. To avoid possible damage to the DU 1500T, set INPUT, OUTPUT, BAND SWITCH
and POWER RANGE switches as outlined in the next section before applying
transmitter power. (Tuning Section)
2. Begin tuning with your transmitter with a low power setting (30 to 50W)
WARNING: Do not operate the DU1500T with the cover removed!

TUNING
1. Select the band and frequency of desired operation.
2. Set INPUT, OUTPUT, and BAND SWITCH controls to the suggested settings before
applyng transmitter power. Actual settings may vary from antenna to antenna.
3. Set up your transmitter to a low power output. If your transmitter has a TUNE
position, select that position.
4. If you use a linear amplifier, set it to STANDBY. Do not use the linear amplifier
until the DU 1500T is tuned.
WARNING: Do not exceed 1500 W (Single tone or Keydown).
5. Set POWER RANGE switch to 200W.
6. Set OUTPUT SELECTOR switch to BYPASS, or to the position matching your antenna
connection. To tune your antenna, the switch selection must be set to: COAX 1 TUNED
COAX 2 TUNED, or BAL.LINE+COAX 1. Selecting COAX 1 DIRECT, COAX 2
DIRECT, or BYPASS.
7. Rotate the INPUT and OUTPUT controls for maximum noise or signal as heard
on your receiver.
8. Key your transmitter and adjust the power level for a reading of 50 to 100 watts on the
FORWARD scale. Adjust the INPUT and OUTPUT controls for a minimum
REFLECTED reading while maintaining a FORWARD reading of 50 to 100 watts using
your transmitter power control.
9. Read the SWR on the red scale at the point where the two needles intersect. Repeat step
8 until the lowest SWR reading is obtained. The SWR should be 2:1 or lower.
NOTE: This procedure takes patience the first time. The INPUT and OUTPUT
controls vary the capacitors and provide fine adjustments.

NOTES
1. An SWR of 1:1 is best, but an SWR as high as 2:1 may be acceptable. Check
you transmitter manual for details.
2. If you cannot get an acceptable SWR, lengthen or shorten you antenna and/
or check feedlines and retune.
3. If you get low SWR readings at more than one setting, use the setting that:
Gives the highest FORWARD power reading.
Gives the lowest REFLECTED power reading.
Uses the largest capacitance (highest number) on the TRANSMITTER and
ANTENNA controls.
Uses the least amount of inductance
4. Any time a new or different antenna is connected, it is necessary to repeat the tuning
procedure for each antenna.
