Sirius Satellite Radio SC-FM1 User manual

SC-FM1 Universal FM Modulated
SIRIUS Satellite Radio Tuner
User Guide

SC-FM1 User Guide
2
CONGRATULATIONS! Your new SC-FM1 Universal FM Modulated SIRIUS®Satellite Radio Tuner lets
you enjoy SIRIUS Satellite Radio’s digital entertainment in your vehicle. Use this guide to familiarize
yourself with all of SC-FM1’s features and capabilities. For the latest information about this and other
SIRIUS products, please visit http://www.siriusradio.com
Table of Contents
Safety Precautions ........................................................... 3
FCC Warning .................................................................. 4
Cleaning the Display Control Unit ..................................... 5
Display Control Unit (DCU) Controls and Features .......... 7
Remote Control ................................................................ 8
Installing Batteries in the Remote: .................................... 8
Activating your SIRIUS Subscription ................................ 9
Basic Operation ............................................................... 10
Changing Channels ..................................................... 10
Display Button (DISP) .................................................. 10
Search Modes (Category, Channel, Artist,
Song Title) ............................................................... 10
Searching Channels .................................................... 10
Direct Tuning (Remote Control Only) ........................... 11
Advanced Features .......................................................... 12
Setting Channel Presets .............................................. 12
Recalling Channel Presets ........................................... 12
Searching for a Channel Preset (P.TUNE Mode) ......... 12
Preset Tune Mode ....................................................... 13
Memory (MEMO) and Song-seek (S-Seek) Functions . 14
Storing Song Titles or Sports Games ........................... 14
Viewing Programmed Information stored in Memory .... 16
Deleting a Song Title Stored into Memory ..................... 16
Activating the Song (S-Seek) Alert ............................... 16
Menu Display Options ...................................................... 18
SIRIUS ID ................................................................... 18
Game Alert .................................................................. 18
FM Frequency ............................................................. 20
Brightness Control and Contrast Control ...................... 20
Auto Select .................................................................. 21
Signal Indicator ............................................................ 21
Confirmation Tone ........................................................ 21
Add or Skip .................................................................. 22
To Skip a Channel ................................................... 22
To Add a Channel .................................................... 23
Channel Lock ............................................................... 23
To Lock or Unlock a Channel ................................... 23
To Change the Lock/Unlock Code ............................ 24

SC-FM1 User Guide 3
Safety Precautions
Warning
Take the following precautions to prevent fire and
avoid personal injury:
• Be sure the SC-FM1 system is installed as
described in the Installation Guide which
accompanies this product.
• The use suggestions contained in this user
guide are subject to any restrictions or
limitations that may be imposed by applicable
law—the purchaser should check applicable law
for any restrictions or limitations before installing
and/or operating this Tuner.
• Failure to follow these safety instructions and
warnings may result in a serious accident.
• To avoid short circuits, never put or leave any
metallic objects (coins, tools, etc.) inside the
Tuner or Display Control Unit.
• If the Tuner or Display Control Unit emits smoke
or unusual odors, turn the power off
immediately.
• Do not drop the Tuner or Display Control Unit or
Memory Options .......................................................... 25
To Set the Automatic Memory Search ...................... 25
To Clear All Items Stored in the Memory .................. 25
Time Based Features ................................................... 26
To Change the Clock Features ................................. 26
To Set the Time Zone ........................................... 26
To Set Daylight Savings Time .............................. 27
To Set the Alarm Clock ............................................ 27
To Turn the Alarm Clock ON or OFF .................... 28
To Set the Auto Shutdown ........................................ 28
To Set the Sleep Mode ............................................. 28
Factory Default ............................................................ 29
Troubleshooting ............................................................... 31
Specifications .................................................................. 32
Table of Contents (continued)
©2004 SIRIUS Satellite Radio Inc.
® “SIRIUS,” the SIRIUS dog logo, channel names and logos are
trademarks of SIRIUS Satellite Radio Inc. “NFL” and the NFL
Shield logo, and the NFL Sunday Drive name and logo are
registered trademarks of the National Football League. “NHL” and
the NHL Shield are registered trademarks of the National Hockey
League. “NBA” and the NBA silhouette logo are registered
trademarks of NBA Properties Inc. All other trademarks, service
marks and logos are the property of their respective owners. All
Rights Reserved.

SC-FM1 User Guide
4
subject it to strong shocks.
• If the LCD display on the Display Control Unit
becomes damaged or broken, do not touch the
liquid crystal fluid. The fluid can be dangerous to
your health. If the liquid crystal fluid contacts
your body or clothing, immediately wash it off
with soap and water.
Caution
Take the following precautions to keep the Tuner
and Display Control Unit in proper working order:
• Do not open the Tuner or Display Control Unit.
• When replacing a fuse, use only a new one with
the proper rating. Using a fuse with the wrong
rating may cause the Tuner to malfunction.
• To prevent a short circuit when replacing a fuse,
first disconnect the wiring harness.
Note:
If the Tuner doesn’t seem to be working properly,
turn the Tuner’s power off, wait 5 – 10 seconds,
then turn the power on again.
FCC Warning
This equipment may generate or use radio
frequency energy. Changes or modifications to
this equipment may cause harmful interference
unless the modifications are expressly approved
in this user guide. The user could lose the
authority to operate this equipment if an
unauthorized change or modification is made.
Note:
This equipment has been tested and found to
comply with Part 15 of the FCC Rules. These
rules are designed to provide reasonable
protection against harmful interference. This
equipment may cause harmful interference to
radio communications if it is not installed and
used in accordance with these instructions.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by one

SC-FM1 User Guide 5
of more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and the SC-FM1 system.
• Connect the equipment to a different circuit from
the one to which the SC-FM1 system is
connected.
• Consult the dealer or an experienced radio
technician for help.
Warning
Do not operate the Display Control Unit in a way
that might divert your attention from driving
safely. As a driver, you alone are responsible for
safely operating your vehicle in accordance with
traffic safety laws at all times.
Cleaning the Display Control Unit
If the Display Control Unit becomes dirty, turn its
power off and wipe it clean with a soft dry cloth.
Do not use hard cloths, paint thinner, alcohol, or
other volatile solvents to clean the DSU. These
may cause damage to the plastic or remove
indicator characters.

SC-FM1 User Guide
6
Display Control Unit (DCU)
123456
MEMO
MENU
DISP
BAND
S-Seek
P-Tune
+
-
...
...
...
4
58 61
93
2
107

SC-FM1 User Guide 7
1. POWER Button : Turns the Display Control
Unit On and Off.
2. CHANNEL Buttons (+/–): Navigates through
channels and display screens, and highlights
items on the display. Pressing the + button
increases or moves up in the menus. Pressing
the – button decreases or moves down in the
menus.
3. CATEGORY Buttons (< >): Navigates through
the Category List Screen which displays SIRIUS
Channel Categories.
4. DISPLAY (DISP) Button: Toggles display
between category/channel name and time/date.
Holding this button down switches the display to
the channel list mode.
5. MENU Button: Used to access menu options to
make setup and feature changes.
6. SELECT Button: Selects an option on the
screen.
7. PRESET Number Buttons (1-6): Sets and
selects preset channels.
8. MEMORY (MEMO) Button (S-Seek Function):
Saves and recalls artist names and song titles.
You can store up to 20 artist name and song title
combinations, or sports games.
9. BAND Button (P.Tune): Pressing and releasing
switches between the five preset banks (A... E),
which hold six presets each. Pressing and
holding enables “Preset Tune Mode”, which
allows for viewing and listening of stored presets
with the Channel Buttons.
10. REMOTE Control Receiver: Receives signals
from the wireless remote control.
Display Control Unit (DCU) Controls and Features

SC-FM1 User Guide
8
14
6
3
13
12
2
9
7
10
8
11
5
Remote Control
1. POWER Button : Turns the Display Control Unit ON and OFF.
2. CHANNEL Buttons (< >): Navigate through channels and display screens.
3. CATEGORY Buttons: Navigates through categories and display screens.
4. MUTE Button: Mutes the audio.
5. DIRECT Button: Accesses channels directly by number.
6. SELECT (SEL) Button: Selects items highlighted on the display; hold-
down to jump to the previously received channel.
7. MENU Button: Enters and exits the Setup Mode.
8. MEMORY (MEMO) Button: Saves and recalls song and artist information.
Holding button down changes the display to memory recall mode.
9. DISPLAY Button: Toggles display between category/channel name and
time/date. Holding this button down switches the display to the channel
list mode.
10. BAND Button: Switches between preset bands A through E.
11. NUMBER Buttons (0-9): Used for selecting channels directly and by
preset.
12. PREVIOUS (PREV) Button: Tunes to the last tuned channel.
13. VOL+/ VOL- Buttons: Adjusts the volume up and down.
Installing Batteries in the Remote:
1. Remove the battery cover.
2. Install CR2025 battery. (+ positive side is up)
3. Replace the battery cover.

SC-FM1 User Guide 9
Activating your SIRIUS Subscription
Before you can listen to the SIRIUS service, you
must subscribe to the SIRIUS Satellite Radio
service.
1. Make sure that the SC-FM1 Tuner and Display
Control Unit is properly connected and that its
antenna is oriented to receive the SIRIUS
satellite signal.
2. Press the POWER button to turn the Display
Control Unit ON. After displaying the SIRIUS
logo, the unit will update all the SIRIUS channels.
The display will read “UPDATING CHANNELS”
on the top line and “X% Completed” (0%-20%-
40%-60%-80%-100%) on the bottom line until
the update completes.
NOTE: Don’t push any buttons or perform any
operations until updating has been
completed.
3. Once updated and the SIRIUS channels are
received, the display will change to “Call 1-888-
539-SIRIUS to Subscribe” and will place you in
The Preview Channel. Channel 184 is SIRIUS’
preview channel. You will not be able to tune to
any other channels until you activate your
SIRIUS subscription.
4. Press the MENU button to enter the “Menu
Options” mode. The “SIRIUS ID” menu option
will now be highlighted.
5. Push the Select button to select “SIRIUS ID”.
This will display your Tuner’s unique 12-digit
SIRIUS ID Number (SID). This SID number
should also be available on the SC-FM1
packaging. Write the number down and have
your credit card handy. A space has been
provided at the end of this manual to write your
SID.
6. Contact SIRIUS on the Internet:
https://activate.siriusradio.com/
Follow the prompts to activate your subscription,
or you can also call SIRIUS toll-free at:
1-888-539-SIRIUS (1-888-539-7474).

SC-FM1 User Guide
10
Basic Operation
After you have successfully activated your SIRIUS
subscription, the Default screen will appear ( shown
below ). Use the +and –buttons to highlight
channels.
• The selected channel will automatically start
playing. The artist name and song title of the
currently playing song will display.
Changing Channels
Pressing the +button will increase or move up to
the next channel. Pressing the – button will
decrease or move to the previous channel.
CH NAME
Artist Name
Song Title
12:00 A
001
Display Button (DISP)
Pressing the DISPLAY (DISP) button from the
default display toggles the top line of the display
between the channel name and time and the
category and date.
CH NAME
Artist Name
Song Title
12:00 A
001 CATEGORY
Artist Name
Song Title
Dec 01 A
001
Pressing and holding the DISPLAY (DISP) button
for 1½ seconds will enter Channel List mode,
described in the next section.
Search Modes (Category, Channel, Artist,
Song Title)
The Display Control Unit has several ways to
search for and select music: by channel, by
category, by artist, and by song title.
Searching Channels
If you want to find a different channel to listen to,
press and hold the DISPLAY (DISP) button to
enter Channel List mode:
Clock
Channel Name
Auto Sizing/
Scrolling
Artist Name
Band/Preset
Bank Number
Default Screen
Auto Sizing/
Scrolling
Song Title
Channel
Number

SC-FM1 User Guide 11
CATEGORY
002 Artist Name
001 Artist Name
CATEGORY
002 Artist Name
001 Artist Name
CATEGORY
002 CH Name
001 CH Name
Press DISPLAY (DISP)
again to show the Song
Title
Note: If you are viewing a sports category
channel list (NFL®, NBA®, NHL®, COLLEGE),
pressing the DISPLAY (DISP) button will toggle
between the team names and the current score of
any live play-by-play game.
Direct Tuning (Remote Control Only)
Channels can be directly accessed by pressing
the DIRECT button on the remote control and
then using the 0-9 keys to enter the desired
channel number. Once the desired number has
been entered, the channel will change and the
display will revert to the default screen for the new
channel. The display will change immediately if
three numbers are entered (ex. “0”, ”0”, “7”), but if
just one or two digits are entered, the unit will wait
for 3 seconds before changing the channel.
CH NAME
Artist Name
12:00 A
001
Song Title
Enter Channel #
__ __ __
1. Use the <and >buttons to scroll through the
music and entertainment categories.
2. Use the +and –buttons to scroll through the
available channels in each category.
3. When the channel you want is highlighted,
press the SELECT button to tune to the channel.
The channel will change and the display will
revert to the default screen for the new channel.
Pressing the DISPLAY (DISP) button while in the
Channel List Mode will change between Channel
Name, Artist Name, and Song Title to preview
what is playing on other channels before
selecting. To exit this mode without changing to a
new channel, press and hold the DISPLAY (DISP)
button for 1½ seconds.
Press DISPLAY (DISP) to
show the Artist Name
Press one of the < or >
buttons to activate the
category list.

SC-FM1 User Guide
12
Advanced Features
Setting Channel Presets
You can store up to 30 of your favorite channels as
presets, for quick access. Presets are stored in 5
banks, each containing 6 channel presets,
numbered 1 to 6.
1. Press the BAND button to activate the preset
bank you want. The selected bank is shown in
the top right corner of the default screen.
2. Select the channel you want to preset (see the
Basic Operation and Changing Channels
section).
3. Hold the numbered preset button in which you
want the channel stored for at least 1½ seconds.
You will hear a beep and the preset bank
number will indicate the memory location to
which the channel has been stored. If the preset
button already has a channel stored in it, the
stored channel will be replaced by the new
channel.
Recalling Channel Presets
The 6 presets in the active bank (A through E) can
be selected by pressing the “1” – “6” buttons.
1. Press the BAND button to activate the preset
bank you want. The selected bank is shown in
the top right corner of the Default screen.
2. Press the desired preset button (1 – 6) to recall
the preset. The channel will change and the
display will revert to the Default screen for the
new channel.
Searching for a Channel Preset (P.TUNE Mode)
It is possible to quickly search through all of your
presets using the +or –button.
1. Press and hold the BAND button to enter the
Preset Tune Mode (P.TUNE).
2. “Preset Tune Mode” will momentarily be
displayed and the top corners of the display will
invert to indicate Preset Tune Mode.
3. Use the +or –button to move up or down
through your presets. Only channels stored in
your presets will be displayed, regardless of
which bank they are stored in. Presets will be
grouped and displayed by preset bank and
number (ex. A-1, A-2...B-1, B-2) and rotate back
to the beginning.

SC-FM1 User Guide 13
CH NAME
Artist Name
Song Title
12:00 A
001 CH NAME
Artist Name
Song Title
12:00 A
001
Default Display P.TUNE Display
To exit the Preset Tune Mode and return to
Channel Tune Mode, press and hold the BAND
button.
Preset Tune Mode
In the Preset Tune Mode, you can view your list of
presets showing Channel Name, artist Name, or
Song Title just like in the Channel List Mode:
1. Press and hold the BAND button to enter the
Preset Tune Mode (P.TUNE).
2. Press the DISPLAY (DISP) button for 1½
seconds which will bring up the Preset Tune
Mode displaying up to 4 preset channel names.
Pressing the DISPLAY (DISP) button while in
this mode will change between Channel Name,
Artist Name and Song Title list modes. The
name field will scroll only if the length of the
Artist Name or Song Title cannot be viewed in its
entirety.
3. Use the +or –button to highlight the desired
preset.
4. Push the SELECT button to select the channel. The
channel will change and the display will revert to
the P.TUNE Display.
CH NAME 12:00 A
001
Preset Tune Mode
A-3 CH Name
A-1 CH Name
A-2 CH Name
P.TUNE Channel Name List Display
A-3 Artist Name
A-1 Artist Name
A-2 Artist Name
P.TUNE Artist Name List Display
A-3 Song Title
A-1 Song Title
A-2 Song Title
P.TUNE Song Title List Display

SC-FM1 User Guide
14
Memory (MEMO) and Song-seek (S-Seek)
Functions
This feature allows the user to capture and store
information about the programming (Artist/Song
or sports team) on the currently tuned channel, up
to a total of 20 listings. The Display Control Unit
also has the capability to continuously search all
incoming SIRIUS channels and alert the user
when a saved program is being played.
When a team (or teams) are stored in memory, at
the time unit is initially powered on, you will be
alerted when your teams are playing in a game
being broadcast. Also, while listening to your
SIRIUS receiver, should one of your teams begin
to play a game, you will be alerted.
Storing Song Titles or Sports Games
1. Song Titles: While the Display Control Unit is
in the default display mode, momentarily
pressing and releasing the MEMO button stores
the current program data information within the
Display Control Unit’s memory. A “Stored”
pop-up screen, followed by “X Used/Y Empty”
will appear for 1 and 2 seconds respectively, X
being the total number of listings saved in
memory, and Ybeing the total number of
memory listings still available for storage.
CH NAME 12:00 A
001
Stored
CH NAME 12:00 A
001
X Used/Y Empty
2. Sports Games: If the current tuned channel is
an NFL, NBA, NHL, or college play-by-play
sports broadcast, pressing the MEMO button
will allow you to select one of the teams playing
to be stored in memory.
135
Giants @ Cowboys
NFL NYG 7 DAL 3 OT
NYG
DAL
CH NAME 12:00 A
001
Use the +or –buttons to highlight the team
you wish to store in memory and press the
SELECT button.
The next screen will ask which kind of alert you
wish to have.

SC-FM1 User Guide 15
Alert Type
Initial Game Alert
All Score Updates
“Initial Game Alert” will sound an alert when
the team you have chosen is playing a game.
“All Score Updates” will sound an alert when
the team you have chosen is playing a game,
and also when the scores are updated for the
team.
Use the +or –buttons to highlight the team
you wish to store in memory and press the
SELECT button.
3. If the MEMO button is pressed and all of the
memory spaces are full, “S-Seek Full” will flash
on the display for one second.
CH NAME 12:00001
S-Seek Full
A
A screen displaying the Replace-Cancel options
will follow. This prompt allows you to make the
following Replace-Cancel choices.
S-Seek Full
Cancel
Replace
Replace: The list of stored memory items
will appear.
Replace
Artist Name/Song
Artist Name/Song
Use the +or –buttons to highlight the data
that you would like to overwrite with the new
Artist/Song Title or sports game. After
highlighting the selected title in the list, press
the SELECT button to delete the stored Artist/
Song Title or sports team and replace it with
the updated information. The display will show
the “Stored” screen
.
Replace
Stored
Cancel: The prompt screen will disappear
and revert to the original screen. Nothing will
be stored.

SC-FM1 User Guide
16
Viewing Programmed Information stored in
Memory
1. Press and hold the MEMO button for 1½
seconds to enter S-Seek Mode. The program
information stored in memory will be displayed
one-at-a-time in page format.
2. Use the +or –buttons to scroll through the
listings. This function allows you to review
previously stored program information.
Memory
Artist Name
Song Title
SX/Y
Deleting a Song Title Stored in Memory
1. Press the SELECT button while in S-Seek
Mode. A pop-up screen displaying two
selectable options - “Delete” and “S-Seek” - is
displayed.
Memory Recall
Delete
S-Seek
2. Use the +or -buttons to highlight the “Delete”
option.
3. Press the SELECT button and a Delete
confirmation screen will appear.
4. To permanently delete the program from your
list, highlight “Yes” using the +or –buttons and
press the SELECT button to confirm.
Delete
Yes
No
Activating the Song (S-Seek) Alert
1. Press and hold the MEMO button for 1½
seconds to enter the S-Seek Mode.
2. Press and release the SELECT button. A pop-up
screen displaying two selectable options,
“Delete” and “S-Seek” will display.
Memory Recall
Delete
S-Seek
3. Use the +and –buttons to highlight the “S-
Seek” option.
4. Press the SELECT button and a S-Seek

SC-FM1 User Guide 17
confirmation screen will appear. Highlight the
“Yes” option using the +and – buttons and
press the SELECT button to confirm.
S-Seek
On
Off
With the S-Seek option enabled, whenever the
Display Control Unit is turned on, it automatically
searches the incoming channels to determine if a
match exists with the program information stored
in Display Control Unit’s memory. If one or more
matches are found, a pop-up screen momentarily
appears for 2 seconds and displays “S-Seek
Alert”.
CH NAME 12:00 A
001
S-Seek Alert
An audible beep tone will be heard indicating that
a match has been found. The display then reverts
to the S-Seek Alert or My Game Zone screen
which displays the current matches.
S-Seek Alert
Artist Name/Song
Artist Name/Song
My Game Zone
Giants @ Cowboys
Bulls @ Cavaliers
You can now select the Artist/Song Title or sports
game that you wish to listen to. No stored match
alert is provided for the currently selected
channel. To ensure that no duplicate entries are
stored in memory, the Display Control Unit will
check the stored input data to ensure the
information about to be stored is not already in
memory.
• If one or more matches are found, a list
appears. You can scroll through the list and
select a program using the +and – buttons.
Your selection will be tuned and the display will
revert to the last active display mode.
• If a selection is not chosen within 10 seconds,
the screen will revert to the last active display
and tuning modes.
NOTE: Play of the current selection will continue
until a new selection is made.

SC-FM1 User Guide
18
Menu Display Options
To enter the Menu Options page, press the MENU
button. The “Menu Options” list will be displayed.
Menu Options
Sirius ID
Game Alert
Using the +and – buttons, highlight the option you
wish to adjust and press the SELECT button. The
following options are available:
Sirius ID Confirmation Tone
Game Alert Add or Skip
FM Frequency Channel Lock
Brightness Control Memory Options
Contrast Control Time Based Features
Auto Select Factory Default
Signal Indicator
Note: If a button is not pressed within 10 seconds,
the Display Control Unit will exit the “Menu
Options” function and revert back to the Default
display screen, except for the Sirius ID display
screen which will remain displayed.
Sirius ID
Displays your 12 digit SIRIUS ID (SID). The SID
is unique to your SC-FM1 Tuner and is required to
activate your service. It is recommended that you
write this number in the space provided on the
last page of this user guide. No adjustments are
allowed in this mode. To exit this option, press the
SELECT or MENU button.
Sirius ID
ESN 000123456789
Game Alert
Game Alert allows you to store your favorite
sports teams in memory. The Display Control Unit
will constantly scan the SIRIUS channels and will
sound an alert when a team you stored in memory
is playing, or when there is a score update for a
team, depending on which option you have
chosen for the team.
Teams which you have selected and are currently
playing will be displayed in a category called “My
Game Zone”.

SC-FM1 User Guide 19
You may select one team from each sports league
and the college category, however, more teams
may be chosen by using the MEMORY (MEMO)
function. (See the section titled, “Memory (MEMO)
and Song Seek (S-Seek) Functions” for more
information to add additional teams.)
To choose teams to add to your stored game
alerts:
1. Use the +and – buttons to highlight “Game
Alert” and press the SELECT button.
2. Use the +and – buttons to highlight the sports
league or college category of the team you wish
to add, and press the SELECT button.
NFL
NBA
NHL
Game Alert
3. Use the +and – buttons to highlight the league
team name or college team name you wish to
add, and press the SELECT button.
Anaheim Mighty Ducks
None
NHL
Atlanta Thrashers
None
COLLEGE
Colorado
Auburn
Note that for college teams, you will receive an
alert for all teams playing for that college.
4. Use the +and – buttons to highlight which type
of an alert you want, and press the SELECT
button.
Alert Type
Initial Game Alert
All Score Updates
When the unit is powered on, and while it is
playing, “Initial Game Alert’ will sound an alert
when the team you have chosen is playing a
game. “All Score Updates” does the same but
also sounds an alert when the scores are
updated for the chosen team.
To exit the Game Alert menu, press the MENU
button.

SC-FM1 User Guide
20
FM Frequency
The FM frequency that the SC-FM1 Tuner
transmits on can be changed with this option. For
best performance, first find a frequency on your
FM radio that is clear of any broadcast station,
and then select the corresponding frequency on
the Display Control Unit. If you would like to
select a FM frequency:
1. Use the +and – buttons to highlight “FM
Frequency”. Press the SELECT button.
Frequency
88.1 MHz
2. Use the +and – buttons and the <and >buttons
to adjust the FM frequency.
• The +and – buttons adjust in 0.2 MHz
increments
• The <and >buttons adjust in 1 MHz
increments.
To exit the FM Frequency menu, press the MENU
button.
Brightness Control and Contrast Control
It is possible to adjust the brightness and contrast
of the Display Control Unit’s display.While in the
“Menu Options” list, use the +and – buttons to
highlight the display setting you wish to adjust,
brightness or contrast. Press the SELECT button
to select the choice.
“Brightness Control”: Adjusts the overall
intensity of the display to help with viewing in
different lighting conditions. Use the +and –
buttons to adjust brightness up or down. The
bar graph will move to indicate the change.
Brightness
_+
“Contrast Control”: Adjusts the relationship
between the background and the text on the
LCD display. Use the +and – buttons to adjust
the contrast up or down. The bar graph will
move to indicate the change.
To exit the Brightness Control or Contrast Control
