Art HeadAMP V User manual

Home recording studios have become a fact of life with more and
more finished products going straight from the spare room to the
distributor. As a result there is a need for flexible, professional
headphone monitoring sufficient for a number of performers,
all at a reasonable cost. Basic headphone amps offer one set
of stereo inputs and volume-controlled headphone outputs,
however more options are needed in the studio. For example,
it may be necessary to connect more than one stereo source –
possibly the aux. or monitor output from the mixer plus the stereo
output of a tape deck or CD player. It may also be necessary to
insert reverb or EQ on certain headphone channels, and to
interconnect two headphone amps for additional performers.
Naturally, there needs to be a level control for each headset,
clean, accurate reproduction and plenty of power.
Usage:
• Five headphone channels each with its own level control and
1⁄4” stereo out jack
• 1⁄4”TRS insert jacks on channels 1&2 for adding reverb,EQ,etc.
• Left & right RCA Inputs
• Left & right 1⁄4” inputs
•The right 1⁄4”input will also accept a stereoTRS connector
and stereo mix (tip = right,ring = left), such as the headphone
output from a mixer. If a mono jack is connected, only the right
earpieces will work
•The left 1⁄4” input will also accept a mono connector and mono mix
•A 1⁄4”TRS Link jack permits interconnecting two HeadAMPV’s
for 10 headphone
channels,four with inserts,and a total of four input sources
Specifications:
• Input Impedance: 10k Ohms
• Maximum Input Level: +18dBV
• Maximum Gain: 26dB/channel
• Maximum Output Power :300mW/channel
• Output Impedance: 10 Ohms
• Signal-to-noise: <90dB
• T.H.D.: <.008%
• IMD (SMPTE) = <.008%
• Power:12VDC
• Dimensions: 7.5” x 4.75” x 1.25” (190mm x 123mm x 30mm)
• Weight: 5lb (227g)
March 2003
HeadAMP V
5 Channel Headphone Mixer/Amplifier, Half-Rack
Creative audio solutions in cool little boxes.
ARTcessories
™
0010
10
2
5
8
010
10
2
5
8
010
10
2
5
8
010
10
2
5
8
010
10
2
5
8
Five-Channel Headphone Mixer/Amplifier Designed & Distributed by: APPLIED RESEARCH AND TECHNOLOGY
TM
PowerPower
DESIGNED & DISTRIBUTED BY:APPLIED RESEARCH ANDTECHNOLOGY • 215 Tremont Street• Rochester, NewYork 14608 • USA
For Customer Service,please call: 585.436.2720 • Email: [email protected] • www.artproaudio.com • ART-ARTcs-03/03
90 DAY
WARRANTY
