Art DAM-E3352 User manual

DAM-E3352
User’s Manual
BeijingART Technology Development Co., Ltd.

DAM-E3352 User’s Manual V6.011
2
DAM-E3352 Module
Terminal Distribution
Features
Five Interfaces Ethernet Switch with POE Function
¾Network ports: 5-ch, 10/100Mbps, RJ-45 interface
¾POE port: 2-ch, 10/100MBase-TX, with POE power supply function, compatible with the
IEEE802.3af standard
¾LED displays: 8 (1 for power supply, 5 for RJ45, and 2 for POE)
¾Supports MDI / MDIX auto crossover
¾Power supply: +48~+60V
¾Operating temperature: -10℃~65℃
¾Operating humidity: 20~95% (non-condensed)
¾Power Consumption: 3W (without using POE power supply), each POE interface can max load 13W
device

DAM-E3352 User’s Manual V6.011
3
HardwareDescription
¾Power Terminal: 3.81mm pitch, 2-pin green terminal
¾Power Line: recommended to use more than 0.5 mm2(AWG20) wire
¾Network Cable: CAT-5 series cable
¾Ground terminal (Earth): when we use it, the module must be connected to the earth to prevent electrostatic damage
¾Indicator: there are eight indicators, one power indicator (POWER), five Network indicators (100/10M (Ports 1 to
5)) and two POE indicators , the following is the specific status:
Indicator Color Status Description
on +10~+30V power supply is connected
POWER Green
off No power
on Connected to the Ethernet
flashing working
Green（Link）
off Ethernet is not connected
on Connect to the 100MbpsNetwork
100/10M (Ports 1 to 5)
Yellow (Speed）off Connect to the 10MbpsNetwork
on Port4 connect with POE powered device, the
output voltage is 48V
LED1(Port4)
Red
off Port4 does not connect with POE powered
device, no voltage output
on Port5 connect with POE powered device, the
output voltage is 48V
LED2(Port5)
Red
off Port5 does not connect with POE powered
device, no voltage output

DAM-E3352 User’s Manual V6.011
4
Wiring Diagram
Ethernet Interface
RJ45 pin definition: 1, 2 pins are differential output signal TX +, TX-, 3,6-pin are the differential input signal RX +, RX-,
when 4,5 and 7,8 pins connect with the common network device are idle, however, it is the positive port when connect
with network device with POE function. Using the CAT-5 twisted cable to connect with other Ethernet devices (such as
computers, routers, switches, etc.), both the cross-cable or direct-cable is ok.

DAM-E3352 User’s Manual V6.011
5
Installation Instruction
DAM-E3352can be installed in standard DIN rail inside the cabinet, it also can be installed by stacking
mode.
Fig.1 standard DIN installation
Fig.2 stack installation
