ARTESYN EMBEDDED TECHNOLOGIES SharpMedia 2U Platform Quick start guide

SharpMedia™ 2U Platform
Installation and Use
P/N: 6806800T07B
June 2016

© Copyright 2016 Artesyn Embedded Technologies, Inc.
All rights reserved.
Trademarks
Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of
Artesyn Embedded Technologies, Inc. All other names and logos referred to are trade names, trademarks, or registered trademarks
of their respective owners. © 2016 Artesyn Embedded Technologies, Inc. All rights reserved. For full legal terms and conditions,
please visit www.artesyn.com/legal.
Notice
While reasonable efforts have been made to assure the accuracy of this document, Artesyn assumes no liability resulting from any
omissions in this document, or from the use of the information obtained therein. Artesyn reserves the right to revise this document
and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or
changes.
Electronic versions of this material may be read online, downloaded for personal use, or referenced in another document as a URL to
an Artesyn website. The text itself may not be published commercially in print or electronic form, edited, translated, or otherwise
altered without the permission of Artesyn.
It is possible that this publication may contain reference to or information about Artesyn products (machines and programs),
programming, or services that are not available in your country. Such references or information must not be construed to mean that
Artesyn intends to announce such Artesyn products, programming, or services in your country.
Limited and Restricted Rights Legend
If the documentation contained herein is supplied, directly or indirectly, to the U.S. Government, the following notice shall apply
unless otherwise agreed to in writing by Artesyn.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (b)(3) of the Rights in
Technical Data clause at DFARS 252.227-7013 (Nov. 1995) and of the Rights in Noncommercial Computer Software and
Documentation clause at DFARS 252.227-7014 (Jun. 1995).
Contact Address
Artesyn Embedded Technologies Artesyn Embedded Technologies
Marketing Communications Lilienthalstr. 17-19
2900 S. Diablo Way, Suite 190 85579 Neubiberg/Munich
Tempe, Arizona 85282 Germany

Contents
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 3
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.2 Hardware Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.3 Software Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.4 Standard Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.5 Ordering/Support Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2 Hardware Preparation and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Unpacking and Inspecting the Server Platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Environmental, Thermal, and Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Installation of SharpMedia 2U Platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3 Software Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4 Advanced Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
A Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
A.1 Artesyn Embedded Technologies - Embedded Computing Documentation . . . . . . . . . . . . . . . . 23
Safety Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Contents

SharpMedia™ 2U Platform Installation and Use (6806800T07B)
Contents
4
Contents
Contents

List of Tables
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 5
Table 1-1 Standard and Regulatory Compliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table 1-2 Ordering Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table A-1 Artesyn Embedded Technologies - Embedded Computing Publications . . . . . . . . . . . . . . . 23

SharpMedia™ 2U Platform Installation and Use (6806800T07B)
6
List of Tables

SharpMedia™ 2U Platform Installation and Use (6806800T07B) 7
About this Manual
Overview of Contents
This manual is divided into the following chapters and appendices.
Introduction on page 11 gives a brief overview of the product features, standard safety
compliances and ordering information.
Hardware Preparation and Installation on page 15 includes a procedure for unpacking the
product, environmental and power requirements, additional required equipment,
installation, and removal instructions.
Software Initialization on page 19 describes how to access the server.
Advanced Settings on page 21 provides references to required information on how to
perform any custom-specific settings.
Related Documentation on page 23 provides a list of related product documentation,
manufacturer’s documents and industry standard specifications.
Safety Notes on page 25 describes the safety information which has to be regarded.
Sicherheitshinweise on page 29 provides a German translation of the chapter “Safety
Notes”.
Abbreviations
This document uses the following abbreviations.
Abbreviation Definition
DSP Digital Signal Processor
NEBS Network Equipment Building Standards
PCI Peripheral Component Interconnect
PCI-E Peripheral Component Interconnect Express

SharpMedia™ 2U Platform Installation and Use (6806800T07B)
About this Manual
8
About this Manual
Conventions
The following table describes the conventions used throughout this manual.
Notation Description
0x00000000 Typical notation for hexadecimal numbers (digits are
0 through F), for example used for addresses and
offsets
0b0000 Same for binary numbers (digits are 0 and 1)
bold Used to emphasize a word
Screen Usedforon-screenoutput andcoderelated elements
or commands in body text
Courier + Bold Used to characterize user input and to separate it
from system output
Reference Used for references and for table and figure
descriptions
File > Exit Notation for selecting a submenu
<text> Notation for variables and keys
[text] Notation for software buttons to click on the screen
and parameter description
... Repeated item for example node 1, node 2,..., node
12
.
.
.
Omission of information from example/command
that is not necessary at the time being
.. Ranges, for example: 0..4 means one of the integers
0,1,2,3, and 4 (used in registers)
| Logical OR

About this Manual
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 9
Summary of Changes
This manual has been revised and replaces all prior editions.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury
Indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury
Indicates a property damage message
No danger encountered. Pay attention to important
information
Notation Description
Part Number Publication Date Description
6806800T07B June 2016 Re-branded to new Artesyn template.
6806800T07A December 2015 Initial version

SharpMedia™ 2U Platform Installation and Use (6806800T07B)
About this Manual
10
About this Manual

Chapter 1
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 11
Introduction
The SharpMedia™ Platform is an integrated solution that consists of a Carrier grade 2U server
and SharpMedia™ PCIE-8120 acceleration cards. The SharpMedia platform server is installed
with CentOS 7.x 64-bit Operating System.
SharpMedia™PCIE-8120 acceleration cards are PCI Express based and are designed using the
Octasic OCT2224M multi-core Digital Signal Processors (DSPs) along with Vocallo Media
Gateway firmware (MGW). The DSP array performs the media processing acceleration for host
server, supporting both voice and video conferencing and transcoding applications. The
OCT2224M DSP supports high-density media processing at a fraction of the power of
competing devices. With a nominal power consumption of 4 Watts, the OCT2224M can
transcode hundreds of audio streams or multiple HD video streams.
For more information about the functional description of SharpMedia™ PCIE-8120, refer to
SharpMedia™ PCIE-8120 Installation and Use manual.
1.1 Features
The following are the main features of SharpMedia™ Platform:
Configurable for up to four single slot full-length full-height PCI Express cards with x4
interface.
High performance media processing core based on power-efficient DSPs.
Support for 720p and 1080p video conferencing.
Designed to comply with NEBS, GR63-CORE, and GR-1089-CORE.
The SharpMedia Platform and its SharpMedia PCIE-8120 acceleration cards are used for the
following applications:
Session border controllers (adding voice or video transcode)
Media gateways
Media servers/media resource function
Video/content optimization (transcode and transrating)
WebRTC voice applications
Interactive voice and video response systems

Introduction
SharpMedia™ 2U Platform Installation and Use (6806800T07B)
12
1.2 Hardware Components
The following are the main hardware components of the SharpMedia Platform:
Dell™ PowerEdge™ R730 Carrier Grade server
SharpMedia™ PCIE-8120 Accelerator cards
For more information about Carrier Grade Server, refer to Dell PowerEdge R730 Owner's Manual.
1.3 Software Components
The following software components are installed on the SharpMedia 2U Platform:
CentOS 7.x 64-bit Operating System
SharpMedia drivers and utilities
Octasic DSP support packages
1.4 Standard Compliances
The SharpMedia 2U Platform meets the following standards, when installed in an appropriate
system environment.
Table 1-1 Standard and Regulatory Compliances
Standard Description
EN 55024 European standard for Immunity
EN55024 (EU) Information Technology Equipment -
Immunity Characteristics - Limits and Methods of
Measurements
FCC47 Part 15 Class A (ANSI C63.4) American standard for Radiated and conducted emission
EN 55022 Class A (EU) European standard for Radiated and conductive emission
Information Technology Equipment - Radio Disturbance
Characteristics - Limits and Methods of Measurements
UL/CSA No. 60950-1 Safety of Information Technology Equipment
EN 60950-1 Safety of Information Technology Equipment

Introduction
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 13
1.5 Ordering/Support Information
The following table lists the product variants and accessories that were available as of the time
of writing this manual. Consult your local Artesyn sales representative for the availability of
further variants.
ETSI EN 300 386 Class A Electromagnetic compatibility and Radio spectrum Matters
(ERM); Telecommunication network equipment; Electro-
Magnetic Compatibility (EMC) requirements, Class A.
Table 1-1 Standard and Regulatory Compliances (continued)
Standard Description
Table 1-2 Ordering Numbers
Order Number Description
SMSRV01-71AC-1V12 SharpMedia Server, 1X PCIE-8120-V12, Single Processor, 32GB, AC
SMSRV02-72AC-2V12 SharpMedia Server, 2X PCIE-8120-V12, Dual Processor, 64GB, AC

Introduction
SharpMedia™ 2U Platform Installation and Use (6806800T07B)
14

Chapter 2
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 15
Hardware Preparation and Installation
This chapter provides a brief description about how to unpack and inspect SharpMedia 2U
Platform. It also provides environmental, thermal, and power requirements information.
2.1 Unpacking and Inspecting the Server Platform
Shipment Inspection
To inspect the shipment, perform the following steps:
1. Verify that you have received all items of your shipment:
One SharpMedia™ 2U Platform
One printed copy of Quick Start Guide
Any optional items ordered
2. Check your shipment and report any damage or differences to the contact center
at [e-mail].
Damage of Circuits
Electrostatic discharge and incorrect installation and removal of the platform can damage
SharpMedia PCIE-8120 accelerator cards installed in it.
Before touching card or electronic components, make sure that you are working in an ESD-
safe environment.

Hardware Preparation and Installation
SharpMedia™ 2U Platform Installation and Use (6806800T07B)
16
3. Remove the desiccant bag shipped with the platform and dispose it according to
your country’s legislation.
2.2 Environmental, Thermal, and Power
Requirements
For more information about environmental, thermal, and power requirements of SharpMedia
2U Platform, refer to Dell PowerEdge R730 Owner's Manual.
For more information about environmental, thermal, and power requirements of SharpMedia
PCIE-8120 card, refer to Artesyn’s SharpMedia PCIE-8120 Installation and Use guide.
The platform is thoroughly inspected before shipment. If any damage has occurred during
transportation, contact our Contact Center immediately.
Operating temperatures refer to the temperature of the air circulating around the server
platform and not to the component temperature.
Server fans are set to run at 100% by default to meet maximum environmental conditions.
Card Damage
High humidity and condensation on the card surface causes short circuits.
Do not operate the card outside the specified environmental limits. Make sure that the card
is completely dry and there is no moisture on its surface before applying power.

Hardware Preparation and Installation
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 17
2.3 Installation of SharpMedia 2U Platform
For more information on how to install or setup a SharpMedia 2U Platform, refer to Dell
PowerEdge R730 Documentation.
For more information on how to install or remove a PCIe card into or from a SharpMedia 2U
Platform, refer to Dell PowerEdge R730 Owner's Manual.

Hardware Preparation and Installation
SharpMedia™ 2U Platform Installation and Use (6806800T07B)
18

Chapter 3
SharpMedia™ 2U Platform Installation and Use (6806800T07B) 19
Software Initialization
This chapter explains the various modes of accessing a SharpMedia 2U server. The SharpMedia
2U server comes with pre-configured settings. You can access the SharpMedia 2U either
through Ethernet mode or through Serial Console mode.
Ethernet - 1G on-board server management port (eno1) labeled as 1 on the server, which is
pre-configured with Static IP address, 192.168.0.100.
Serial Console - Serial Console with the following port settings:
Set Serial Port Address: COM1, Serial
Baud Rate: 115200
Terminal Type: VT100/VT220
Data bits: 8
Stop bits: 1
Parity: None
Flow control: None
If you want to access the server, the default login is root with Artesyn as password.

Software Initialization
SharpMedia™ 2U Platform Installation and Use (6806800T07B)
20
