artisan ART2 Guide

2
PASTE SERIAL NUMBER
LABEL IN THIS LOCATION
NOTES:
BARBECUE SERIAL NUMBER LABEL:

3
GENERAL SAFETY PRECAUTIONS:
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or death.
WARNING: Do not try lighting this appliance without reading the LIGHTING INSTRUCTIONS
section of this manual.
WARNING: For outdoor use only. This cooking appliance is not intended to be installed in or
on recreational vehicles and / or boats.
FOR YOUR SAFETY:
 Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
 An LP cylinder not connected for use shall not be stored in the vicinity of this or
any other appliance.
TESTED IN ACCORDANCE WITH:
ANSI Z21.58a-1995 STANDARD FOR OUTDOOR COOKING GAS APPLIANCES.
Check your local building codes for the proper method of installation. In the absence of local codes,
this unit should be installed in accordance with the National Fuel Gas Code No. Z223.1 1988, or CAN/
CGA-B149-1 National Gas Installation code, or CAN/CGA-B149.2, Propane Installation code. All
components must be grounded in accordance with local codes or with the National Electrical Code
ANSI/NFPA 70-990 or Canadian Electrical code CSA C22.1
CALIFORNIA PROPOSITION 65 - WARNING
The burning of gas cooking fuel generates toxic by-products, which are on the list of substances which
are known by the State of California to cause cancer or reproductive harm. California law requires
businesses to warn customers of potential exposure to such substances. To minimize exposure to
these substances, always operate this unit according to the use and care manual, ensuring you
provide good ventilation when cooking with gas. This warning is issued pursuant to California Health &
Safety Code Sec. 25249.6
WARNING
ELECTRICAL PARTS
AND COMPONENTS
DISCONNECT ALL POWER
SUPPLIES AND BATTERIES
BEFORE SERVICING
WARNING
FLAMMABLE GAS
DISCONNECT ALL PROPANE
OR NATURAL GAS SUPPLIES
TO THIS UNIT BEFORE
SERVICING
3020914
A division of Superior Equipment Solutions, Inc.
7039 East Slauson Avenue
Commerce, CA. 90040
Ph.: [phone]
Fax: [phone]
Web:
Artisan
TM

4
READ THIS CARE AND USE MANUAL CAREFULLY AND COMPLETELY BEFORE USING YOUR
GRILL TO REDUCE THE RISK OF FIRE, BURN HAZARD OR OTHER INJURY. KEEP THIS
MANUAL FOR FUTURE REFERENCE.
When properly cared for, your ARTISAN™ Grill will give safe, reliable service for many years. However,
extreme care must be used since the grill produces intense heat, which can increase accident potential.
When using this appliance, basic safety practices must be followed, including but not limited to the
following:
 Begin by ensuring proper assembly. A qualified technician should perform all other service.
 All other service should be referred to and performed by a qualified technician.
 For personal safety, wear proper apparel while barbecuing.
 Loose fitting garments or sleeves should never be worn while using this appliance.
 Some synthetic fabrics are highly flammable and should not be worn while cooking.
 Never let clothing, pot holders or other flammable materials come in contact with or too close to any
grate, burner or hot surface until it has cooled down sufficiently. Fabrics may ignite and result in
personal injury.
 Use only dry potholders: moist or damp potholders on hot surfaces may cause personal burns from
steam. Do not use a towel or bulky cloth in place of potholders. Do not let potholders touch hot
portions of the grill rack.
 Only certain types of glass, heatproof glass ceramic, earthenware, or other glazed utensils are
suitable for grill use. These types of materials may break with sudden temperature changes. Use only
on low or medium heat settings and according to their manufacturer’s directions.
 Grease is flammable. Let hot grease cool before attempting to handle it.
 Avoid letting grease deposits collect in the bottom of the grill by cleaning the grease tray often.
Never while grill is on or hot from recent use; pan will not come out.
 Do not use aluminum foil to line the grill racks, nor to line the drip tray. This can severely upset
combustion airflow or trap excessive heat in the control area. The result of this can be melted knobs,
igniters and increased chance of personal injury. Never grill without the drip pan in place and pushed
all the way to the back of the grill. Without the drip pan, hot grease can leak downward creating a fire
or explosion hazard.
 Children should not be left alone or unattended in an area where the grill is being used. Never allow
them to sit, stand or play on or around the grill. Do not store items of interest to children around or
below the grill or in the cart. Never allow children to crawl inside of the cart.
 Do not heat unopened food containers that may cause the container to build-up pressure and burst.
 Protect your hand when opening a hot grill lid. Never lean over an open hot grill.

5
(Safety, cont.)
 When lighting a burner, always pay close attention to what you are doing. Be certain you are
depressing the correct button, labeled for the igniter.
 When using the grill: do not touch the grill rack, burner grate, hood or immediate surrounding area as
these areas become extremely hot and could cause burns. Use only the handles and knobs provided
for operation of the grill.
 For proper lighting and performance of the burners keep the ports clean. It is necessary to clean
them periodically for optimum performance. The burners will only operate in one position and must
be mounted correctly for safe operation.
 Clean the grill with caution. Avoid steam burns; do not use a wet sponge or cloth to clean the grill
while it is hot. Some cleaners produce noxious fumes or can ignite when applied to a hot surface.
 INSECT WARNING: Spiders and insects can nest in the burners of this and other grills, and cause
the gas to flow from the front of the burner. This is a very dangerous condition, which can cause a fire
to occur behind the valve panel, thereby damaging the grill and making it unsafe to operate. Inspect
the grill at least twice a year.
 Be sure all grill controls are turned off and the grill is cool before using any type of aerosol cleaner on
or around the grill. The chemical that produces the spraying action could, in the presence of heat,
ignite or cause metal parts to corrode.
 Do not operate the grill under unprotected combustible construction. Use only in well ventilated
areas. Do not use in buildings, garages, sheds, breezeways or any enclosed areas.
 Keep the area surrounding the grill free from combustible materials, trash, or combustible fluids and
vapors such as gasoline or charcoal lighter fluid. Do not obstruct the flow of combustion gases and
ventilation airways.
 Keep the back of the cart free and clear from debris.
 If the unit is stored indoors, ensure that it is cool. If propane is used, the cylinder must be unhooked
and the propane cylinder stored outside in a well-ventilated area, out of reach of children.
 Never use the grill in windy conditions. If located in a consistently windy area, oceanfront,
mountaintop, etc... a windbreak will be required. Always adhere to the specified clearances.
 Keep any electrical supply cord, away from the heated areas of the grill.
 Do not use the grill for cooking excessively fatty meats or products, which promote flare-ups.
WARNING
FOR OUTDOOR USE ONLY
NOT TO BE INSTALLED IN OR
ON RECREATIONAL
VEHICLES AND / OR BOATS.
WARNING
NEVER USE A DENTED OR
RUSTED LIQUID PROPANE
TANK. SHUT OFF TANK
WHEN NOT IN USE.

6
LOCATING AND ASSEMBLING THE GRILL:
When determining a suitable location for your grill, take into account concerns such as exposure to wind,
rain, sprinklers, proximity to traffic paths and keeping any gas supply line runs as short as possible.
Locate the grill only in a well ventilated area. Never locate the grill in a building, garage, breezeway,
shed or other such enclosed area without an approved ventilation system. Never locate the grill over,
under or next to unprotected combustible construction. During heavy use, the grill will produce a lot of
smoke.
CLEARANCES:
TO NON-COMBUSTIBLE CONSTRUCTION:
A minimum of 2 1/2” clearance from the back of the grill to non-combustible construction is required to
allow the hood to be opened fully.
TO COMBUSTIBLE CONSTRUCTION:
A minimum of 12” clearance must be maintained between the barbecue and any combustible materials.
ASSEMBLY:
BUILT-IN MODELS:
Before locating your ARTISAN™ Grill into your Non-combustible enclosure, complete the following
steps:
1. Remove all packaging materials.
2. Ensure that the burners are positioned correctly on their orifices, and are fully seated onto
their supports.
3. Position the tile trays onto their support ledge.
4. Make the connection to the gas regulator according to the instructions on pages 8 - 11 for
your gas type.
5. To comply with safety and service requirements, main gas shut off valve must be
accessible from front of grill without using any tools.
Your Artisan™ Grill has provision for mounting onto a mobile cart if you choose to do so.
Contact your Artisan™ dealer for the appropriate cart for your grill.
FREE STANDING MODELS:
Complete the following steps:
1. Remove all packaging materials.
2. Ensure that the burners are positioned correctly on their orifices, and are fully seated onto
their supports.
3. Position the tile trays onto their support ledge.
4. Make the connection to the gas regulator according to the instructions on pages 8 - 11 for
your gas type.
5. Allow a minimum of 3” clearance around all sides of grill cart for proper air movement.
6. Lock the front casters to prevent unwanted grill movement.
FOR INSTALLING / REPLACING THE BATTERY: SEE PAGE 27.

7
WARNING:
To prevent harm and ensure proper operation of your grill, it is imperative that the burners are properly
installed with respect to the gas orifices. Be certain that the orifice is inserted completely into the
burner’s inlet and that the burner rests firmly on its support bracket.
The burner should not rock side-to-side nor top-to-bottom if properly installed. If excessive burner
movement is present, reseat burner or contact your authorized service provider.
NOTES CONCERNING GFCI USE AND LOCATION:
1. Do not attempt to circumvent using a GFCI receptacle, it is for your safety.
2. Ensure that the GFCI receptacle is located in an easily accessed location.
3. Follow the manufacturer’s instructions for installation and testing (must comply with local and
national codes).
WARNING
IMPORTANT ELECTRICAL INSTRUCTIONS:
THE GRILL’S LIGHTS ARE WIRED TO A SINGLE THREE-PRONG (GROUNDING)
PLUG FOR YOUR PROTECTION AGAINST SHOCK HAZARD. THE GRILL SHOULD
BE PLUGGED DIRECTLY INTO A PROPERLY GROUNDED GFCI THREE-PRONG
RECEPTACLE.

8
TILE TRAY INSTALLATION:
GAS CONNECTION - LIQUID PROPANE (LP):
NOTE: THIS APPLIES TO LP MODELS ONLY. LP MODELS HAVE THE LETTERS “LP” IN THE
MODEL NUMBER.
NEVER CONNECT THE GRILL TO AN UNREGULATED GAS SUPPLY.
Before proceeding, ensure the unit is fitted for LP gas. Connecting to an improper gas type will result in
poor performance and increased risk of damage or injury.
The installation of this appliance must conform with local codes or, in the absence of local codes, to the
national fuel gas code, ANSI Z223.1a-1988. Installation in Canada must be in accordance with the
Standard CAN/ CGA-B149.1 Natural Gas Installation or CAN/CGA-B149.2, Propane Installation Code.
Manifold pressure with LP Operating: 10.0” W.C. Non-operating: 11.2” W.C.
L.P. TANK REQUIREMENTS:
Use only a standard 20 Lb. (5 Gal.) propane gas cylinder (18-1/4” H x Ø12-1/4”). The tank must be
installed in the upright position. Do not use a dented or rusty LP tank as it may be hazardous and should
be checked by your LP supplier. Never use a cylinder with a damaged valve.
Remove top grill.
Tile tray located over
the gas burners

9
WARNING
ENSURE THAT THE GAS
SUPPLY HOSE DOES
NOT COME IN CONTACT
WITH THE GRILL BODY
The LP gas cylinder must be constructed and marked in accordance with the specifications for LP gas
cylinders of the U.S. Department of Transportation (DOT). The cylinder must be provided with a shut off
valve terminating in an LP gas supply cylinder valve outlet specified, as applicable, for connection type
QCC1 in the standard for compressed gas cylinder valve outlet and inlet connections ANSI/CGA-V-I.
LP GAS CONNECTION TO LP TANKS:
Your ARTISAN™ Grill for use with LP gas is supplied with a high capacity, hose/regulator assembly for
connection to a standard 20 Lb. LP cylinder. The LP gas pressure regulator and hose supplied with this
unit must be used without alteration.
To connect the regulator / hose assembly follow the next steps:
1. Locate the gas connection under the rear right side of
your BBQ unit.
2. Fasten the hose connection to a 1/2” MPT x 3/8” COMP
(compression flare fitting) connected to the elbow.
(see figure # 2).
1/2” FPT X 3/8” FLARE
BRASS FITTING
TYPICAL ARTISAN™ BBQ
Figure # 2
TYPICAL LP
GAS TANK LP REGULATOR AND HOSE
ASSEMBLY (PRESET TO 10” WC)

10
GAS CONNECTION - NATURAL GAS (NG):
NOTE: THIS APPLIES TO NATURAL GAS MODELS ONLY. FOR LP MODELS, SEE PAGE 8.
NEVER CONNECT THE GRILL TO AN UNREGULATED GAS SUPPLY.
Before proceeding, ensure the unit is fitted for natural gas. Connecting to an improper gas type will result
in poor performance and increased risk of damage or injury. The installation of this appliance must
conform with local codes or, in the absence of local codes, to the national fuel gas code, ANSI Z223.1a-
1988. Installation in Canada must be in accordance with the Standard CAN/ CGA-B149.1 Natural Gas
Installation or CAN/CGA-B149.2, Propane Installation Code.
Manifold pressure with NG: Operating: 4.0” W.C. (.14 PSI)
Non-operating: 4.5” W.C. (.16 PSI)
Optimum pressure: 7.0” W.C. (.25 PSI)
NOTE: To ensure proper heating performance of this appliance, verify that the gas line supply pressure
is adequate (7.0” W.C. supply pressure is preferred) to maintain 4.5” W.C. manifold pressure.
Use a minimum 1/2” ID flex hose to prevent gas starvation.
NATURAL GAS CONNECTION:
Ensure that the service pipe supplying the Grill is fitted with a shut
off valve conveniently positioned and easily accessible as an
emergency gas shutoff.
Your ARTISAN™ Grill for use with Natural Gas comes equipped
with its own regulator which is shipped loose but must be
installed.
CAUTION
CYLINDERS MUST BE STORED OUTDOORS IN A WELL VENTILATED AREA OUT OF THE
REACH OF CHILDREN.
DISCONNECTED LP CYLINDERS MUST HAVE THREADED VALVE PLUGS TIGHTLY INSTALLED, AND MUST NOT
BE STORED IN A BUILDING, GARAGE OR ANY OTHER ENCLOSED AREA. THE GAS MUST BE TURNED OFF AT
THE SUPPLY CYLINDER WHEN THE UNIT IS NOT IN USE. IF THE APPLIANCE IS STORED INDOORS, THE CYL-
INDER MUST BE DISCONNECTED AND REMOVED FROM THE APPLIANCE.
WARNING
ENSURE THAT THE GAS
SUPPLY HOSE DOES
NOT COME IN CONTACT
WITH THE GRILL BODY
LP GAS CONNECTION TO LP PIPED SYSTEMS:
An LP piped system is one with a large central LP tank that feeds the entire household. Those systems
are normally equipped with a high pressure regulator by the large LP tank and low pressure regulators
close to the home.
WARNING
YOUR ARTISAN™ GRILL’S PRESSURE REGULATOR
HAS A MAXIMUM INPUT PRESSURE OF 14” WC.
(OR APPROX. .5 PSI) , AND A SAFETY LIMIT OF 69”
WC. (2.5 PSI).
REGULATOR NOTICE
Exposure to pressures above the safety limit
of 69” WC. will permanently damage the gas
regulator requiring a replacement. OVER
PRESSURE DAMAGE IS NOT COVERED BY
YOUR ARTISAN™ WARRANTY

11
LEAK TESTING:
GENERAL:
Although all gas connections on your ARTISAN™ Grill are leak tested at the factory prior to shipment, a
complete gas tightness check must be performed at the installation site due to possible mishandling in
shipment, or excessive pressure unknowingly being applied to the unit.
Periodically check the whole system for leaks, or immediately check if the smell of gas is detected.
BEFORE TESTING:
 Make sure that all packing material is removed from the grill.
 Make sure the burner tie-down straps are removed from the unit.
 Do not smoke while leak testing.
 Never leak test with an open flame.
GAS PRESSURE REGULATOR
SUPPLIED BY ARTISAN™ -
MUST BE USED.
TYPICAL ARTISAN™ BARBECUE
(32” MODEL SHOWN)
SHUT OFF HAND VALVE MUST BE
LOCATED IN ACCESSIBLE AREA
INCOMING NG SUPPLY
Figure # 3
NG FLEXIBLE HOSE OR HARD
PIPING BY CUSTOMER
To connect the regulator / hose assembly follow the next steps:
1. Locate the regulator and gas connection point in the rear right side of your barbecue unit (remove
the rear panel from the barbecue cart to gain access - in cart mounted models).
2. Connect the supplied gas pressure regulator to the 1/2” MPT barbecue connection, using either
hard piping or a flexible Ø1/2” gas hose (available from DIY/Home stores) no longer than 48”.

12
 Make a soap solution of one part liquid detergent and one part water for leak testing purposes.
 Apply the solution to the gas fittings by using a spray bottle, or brush.
 For LP units, always check with a full cylinder.
TO TEST:
 Make sure all control valves are in the “OFF” position.
 Apply the soap solution described above to all fittings.
 Turn the gas supply on.
 Check all connections from the supply line, or LP cylinder up to and including the manifold pipe
assembly.
 Soap bubbles will appear where a leak is present.
 If a leak is present, immediately turn off gas supply, tighten any leaking fittings, turn the gas
supply back on, and recheck.
 If you cannot stop a gas leak turn off the gas supply and call the dealer where you purchased
your grill.
 Do not use the grill until all connections have been checked and do not leak.
 Only those parts recommended by the manufacturer should be used on the Grill.
 Substitution can void the grill’s warranty.
IMPORTANT NOTE:
ALWAYS CHECK FOR LEAKS AFTER EVERY LP TANK CHANGE.
If a leak is present, or if the connection hose shows signs of wear, these conditions must be corrected
prior to using your grill.
Check all gas supply fittings for leaks before each use. It is handy to keep a spray bottle of soapy water
near the shut-off valve of the gas supply line. Spray all the fittings. Bubbles indicate leaks.
LIGHTING INSTRUCTIONS:
BEFORE LIGHTING…
The pressure regulator and hose assembly supplied with the unit
must be used. Never substitute regulators for those supplied with
the grill. If a replacement is necessary, contact the factory for
proper replacement.
Screw the regulator (Type QCC1) into the LP tank. Leak check the
hose and regulator connections with a soap and water solution
before operating as explained on the LEAK TESTING section of
this manual.
GRILL BURNERS LIGHTING:
Turn all knobs to “OFF” then turn on the gas supply.
Always keep your face and body as far away from the grill as possible when lighting. Open the lid,
depress the igniter button for the burner you are trying to light, and immediately push and turn the burner
control knob counter-clockwise to the “HI” position and wait for the burner to light. (See illustration on
next page)
NOTE: The first burner may take longer to light while air is purged from the gas supply system.
If the burner does not light within 4 seconds, turn knobs to “OFF” and wait 5 minutes to allow any
accumulated gas to dissipate before trying again. If the burner will not light after several attempts, then it
can be lit with a match.
WARNING
HOOD MUST BE OPEN WHEN
LIGHTING GRILL.
HOOD SHOULD NOT BE
CLOSED FOR LONG PERIODS
WHEN IR BURNERS ARE IN USE.
WARNING
DO NOT ATTEMPT TO LIGHT
THE GRILL IF THE ODOR OF
GAS IS PRESENT.

13
PUSH TO
IGNITE
PUSH & TURN TO “HI”
Keep your face away from the grill as far as possible and pass a lit,
long stem match through the notch in the grill rack to the ports of
the burner you are trying to light. When attempting to light a burner
with a match, ensure that the correct burner control knob is used.
Position the match near the burner ports. Push and turn the control
knob to “HI”. Repeat procedure on each burner if necessary. If the
burner does not light in 4 seconds turn the knob OFF, wait 5
minutes and try again. If the burner will not light after several
attempts see page 25: Troubleshooting.
To assure that an IR burner is lit, very carefully
place your hand 8-10 inches away from the
burner surface. If you do not feel the heat of
the burner, shut off control knob, wait five
minutes, and attempt to relight.
BUTTON SYMBOLS AND LOCATIONS:
IGNITER BUTTON SWITCH
(on RIGHT side)
LIGHT FIXTURES SWITCH
(on RIGHT side)
CAUTION
IN SUNNY ENVIRONMENTS,
THE FLAME FROM AN IR
BURNER MAY BE IMPOSSIBLE
TO SEE.
ROTISSERIE INSTALLATION:
ATTACH ROTISSERIE MOTOR TO
EITHER END USING THE HARDWARE
PROVIDED

14
SIDE BURNER LIGHTING:
When lighting, always keep your face and body as far away as possible from the burners.
Push and turn the side burner right hand control knob to the “HI” position and immediately depress the
igniter button. You’ll hear a snapping sound from the spark which is being generated at the side burners.
It is necessary to keep the igniter button depressed until the burner is lit.
If the burner does not light in 4 seconds, turn knobs to “OFF” and wait 5 minutes to allow any
accumulated gas to dissipate before trying again. If the burner will not light after several attempts, then it
can be lit with a match
NOTE:To ensure proper spark ignition, do not change the gap between the electrode wires and the
burners. The optimum gap is preset at the factory between 1/8” and 3/16”.
ROTISSERIE BURNER LIGHTING:
Open the lid, press the igniter button (see page 13) and then turn the control knob to the “HI” position. If
the burner does not light within 4 seconds, turn the control knob to “Off”, wait five minutes and attempt to
relight. If the igniter does not function, you can light the burner by holding a lit match to the burner (with
the control knob at the “HI” position).
After your first use of the rotisserie burner it is likely that the stainless steel adjacent and directly above
the burner will darken to a dark blue color. This is a normal property of the corrosion resistant, type 304
stainless steel used in the manufacturing of your barbecue, and is not detrimental to its operation.
PREHEATING THE GRILL (U-BURNERS):
Preheating the grill is important for best performance. To preheat the grill when cooking with the U-
burners, close the hood after lighting the burners as described above. Set the grill control knobs on “HI”
for 15 minutes.
PREHEATING THE GRILL (IR-BURNERS):
Preheating the IR burners is important to protect them from food drippings. After lighting the IR burners
as described above, allow to preheat on “HI” for four minutes before beginning to grill.
If your grill is equipped with a SEAR-ZONE™ IR BURNER, light and preheat the U-BURNERS first, then
light and preheat the SEAR-ZONE™ IR BURNER.
PREHEATING THE ROTISSERIE BURNER:
Light the rotisserie burner as described in the lighting instructions. Once lit, the rotisserie burner will
reach cooking temperatures in about 1 minute.
BURNER ADJUSTMENTS:

15
AIR SHUTTER
ADJUSTMENT CAP
LOCKING SCREW
U-BURNER
1” MAXIMUM
3/8” MAXIMUM
Figure # 4
FLAME SIZE
NOTE: Artisan™ grills are available with both U-burners and IR burners. The following instructions apply
only to the U-burners. IR burners do not require adjustment and need only be checked visually for proper
performance. On high, an IR burner should glow red evenly over its entire surface.
U-BURNER AIR ADJUSTMENT:
Each grill burner is tested and adjusted at the factory prior to shipment; however, variations in the local
gas supply, elevation and other factors might make it necessary to adjust the burners. The flames of the
burners should be visually checked and compared with Figure 4.
Flames should be blue and stable with no yellow tips, excessive noise or lifting.
If any of these conditions exist, check if dirt, debris, spider webs, etc., are blocking the air shutter or
burner ports. Proceed with air shutter adjustment.
AIR SHUTTER ADJUSTMENT:
A sheet metal cap at the inlet of the burner called the “AIR SHUTTER” regulates the amount of air that
enters into the burner for combustion.
The air shutter is locked in place by a screw, which must be loosened prior to lighting the burner for
adjustment. The air shutter adjustment screws are accessible with a flat screwdriver by removing the
burner. Loosen the screw of the air shutter. Reinstall the burner. Make certain that the burners are sitting
properly on the orifices taking care not to move or damage the igniter electrode.
Light the burners and adjust according to the following directions:
 Turn the valve on “HI”, light the burner and allow it to “WARM UP” for 10 minutes.
 If the flame is yellow, indicating insufficient air, turn the air shutter counter-clockwise to
allow more air into the burner.
 If the flame is noisy and tends to lift away from the burner, (WITH THE TILE TRAYS IN
POSITION) indicating too much air, turn the air shutter clockwise to reduce the amount
of air to the burner.
 Retighten the locking screw of the air shutter cap.
NOTE: Be careful, as the burner could be and / or will become very hot after lighting it.

16
Figure # 6
LOW HEAT SETTING ADJUSTMENT:
NOTE:
THE LOW HEAT SETTING ON YOUR
GRILL IS PRESET AT THE FACTORY.
ADJUST ONLY IF ALTITUDE OR ENVI-
RONMENTAL FACTORS ARE CAUSING
POOR, LOW HEAT, PERFORMANCE.
ADJUSTMENT STEPS:
1. Follow lighting instructions by setting the control
knob on “HI” and allow the burner to preheat for 10
minutes.
2. Turn the control knob to “LOW” and wait for the
burner temperature to drop and stabilize.
3. Attempting adjustment at any setting other than
LOW can create a dangerous condition.
4. Remove knob by pulling straight away from control
panel.
5. Insert a small blade screwdriver into the valve stem
to begin the adjustment.
6. Turn counter-clockwise to INCREASE the low heat
flame using pliers to hold the stem securely. (see
figure # 5)
7. Adjust the flames so the burner is fully lit around the
perimeter when the knob is in the LOW position.
Once proper adjustment is reached, reattach the
knob by pushing onto stem.
OPERATING THE GRILL:
BEFORE USING THE GRILL:
 Make sure the grill has been leak tested and is properly located.
 Remove any packing material.
 Read and understand the instructions in this manual.
U-BURNERS:
The grill burners encompass the entire cooking area and
are side ported to minimize blockage from falling grease
and debris. Above the burners are stainless steel tile trays
with ceramic tiles. The tile tray is a fundamental part for the
performance of the grill. Make sure the tile tray is installed
properly before lighting the burner. Each grill burner has its
own igniter. The igniter push button is located on the front
control panel.
WARNING
NEVER ADJUST THE BURNER SO LOW THAT IT MAY
GO OUT DURING USE. DO NOT OPERATE THE
GRILL WITH THE LOW HEAT SCREW REMOVED.
GAS CAN ESCAPE AND CAUSE A POTENTIALLY
HAZARDOUS CONDITION.
Figure # 5

17
USING THE GRILL:
Grilling requires high heat for searing and proper browning. Most foods are cooked at the “HI” heat
setting for the entire cooking time. However, when grilling large pieces of meat or poultry, it may be
necessary to turn the heat to a lower setting after the initial browning. This method will cook the food
through without burning the outside. Foods cooked for a long time or basted with a sugary marinade may
need a lower heat setting near the end of the cooking time.
NOTE: The hot grill sears the food, sealing in the juices. The longer the preheat period, the faster
the meat browns and the darker the sear marks. Place the food on the grill and cook to the
desired brown level. Adjust heat setting, if necessary. The control knob may be set to any
position between “HI” and “LOW”.
DO NOT leave the grill unattended while cooking.
SEAR-ZONE™ - IR BURNERS:
An IR grill works by producing intense heat which quickly sears
the meat. Searing locks in flavor and juices while allowing the
outer surface to absorb smoke and food aroma that is produced
as grease and drippings are vaporized by the burner. The result
is a crisp, flavorful outside with a tender, juicy inside. Just the
result you want with most grilled foods.
USING THE GRILL:
Grilling requires high heat for searing and proper browning. The intense infrared heat produced by your
Artisan™ Grill meets these requirements perfectly. Meat is cooked evenly throughout, while juices
grease and food particles are vaporized upon contact with the burner, giving added flavor to your food.
NOTE: The hot grill sears the food, sealing in the juices. Proper preheating browns the meat and
produces darker sear marks. Place the food on the grill and sear both sides as recommended
on the “Infrared Grilling Tips” section on page 19.
DO NOT leave the grill unattended while cooking.
ROTISSERIE BURNERS:
Your ARTISAN™ Grill is capable of performing back burner rotisserie cooking. The location of the rear
burner allows the placement of the rotisserie basting pan (not included) beneath the food to collect juices
and drippings for basting and gravy. To flavor the contents of the basting pan, you can add herbs, onion,
garlic, or spices.
Figure # 7
CAUTION
IN SUNNY ENVIRONMENTS,
THE FLAME FROM AN IR
BURNER MAY BE IMPOSSIBLE
TO SEE.
NOTICE
AVOID WATER DAMAGE TO BURNER
NEVER ALLOW WATER TO CONTACT
THE IR BURNER AS DAMAGE TO THE
CERAMIC PANEL WILL RESULT.
WATER DAMAGE IS NOT COVERED BY
YOUR ARTISAN™ WARRANTY

18
To assure that an IR burner is lit, very carefully place your hand 8-10 inches away from the burner sur-
face. If you do not feel the heat of the burner, shut off control knob, wait five minutes, and attempt to re-
light.
ROTISSERIE MOTOR:
The rotisserie motor is capable of turning up to a 25 Lb. cut of meat or poultry, with a maximum diameter
of 10”.
SKEWER:
The skewer for the rotisserie is assembled into the skewer coupler (located in the motor) by placing the
pointed end into the square opening of the coupler. The other end of the skewer (round shaft end) rests
in the slot in the opposite end of the barbecue.
To load the skewer, slide the meat holders with the prongs facing towards the center the skewer bar.
Push the skewer through the center of the food, and then slide the second meat holder (prongs toward
the food) onto the skewer.
Center the product to be cooked on the skewer then push the meat holders firmly together. Tighten the
thumb nuts of the meat holders with pliers. It may also be necessary to wrap the food with butcher’s
string (never use nylon or plastic string) to secure any loose portions. Once the food is secure, insert the
skewer into the coupler.
Start the motor with the switch located on the end of the motor.
ROTISSERIE BASTING PAN:
Place a pan onto the grill racks (or, if necessary, directly onto the tiles if the grill racks are removed to
accommodate large cuts of meat). This pan is required to catch drippings from the meat being cooked,
preventing grease build-up on the briquettes or Sear-Zone™ IR Burner.
ROTISSERIE GENERAL COOKING INSTRUCTIONS:
As a general rule, rotisserie cooking will take 15 ~ 20
minutes per pound of meat. Keep the hood closed as
much as possible to improve performance.
NOTICE
ALWAYS USE BASTING PAN WITH
ROTISSERIE TO KEEP DRIPPINGS
OFF BURNERS AND TILES.
DO NOT USE WHILE GRILLING.

19
INFRARED GRILLING TIPS:
Even for an experienced chef, infrared cooking can, at first, present a bit of a challenge. By following
these simple tips, you will soon be producing juicier, more flavorful foods than you have ever experi-
enced before. As a general rule, foods will cook in less time than they would take on an ordinary grill.
By turning food frequently (approximately every 2 minutes), excessive charring is simply avoided.
ARTISAN™ RECOMMENDS THAT YOU TURN FOOD BEING GRILLED ON A SEAR
ZONE™ IR-BURNER EVERY TWO MINUTES DURING THE COOKING PERIOD.
NEVER ALLOW FOOD TO COOK MORE THAN 2 1/2 MINUTES WITHOUT TURNING.
SEARING IS THE KEY:
An infrared grill works by producing intense heat which quickly sears meats. Searing locks in flavor and
juices while allowing the outer surface to absorb smoke and food aroma that is produced as grease and
drippings are vaporized by the burner. The result is a crisp, flavorful outside with a tender, juicy inside.
Just the result you want with most grilled foods.
HOW TO GRILL WITH IR:
Properly pre-heat the grill by following the lighting instructions on page 12. Place food on grill grids and
turn every 2 to 2 1/2 minutes until food is cooked to desired taste. Do not let food cook more than 2 1/2
minutes without turning. Perfect cross sear marks can be made by rotating food 90° at each turn.
APPROXIMATE SEAR-ZONE™ COOKING TIMES:
These are recommended times only. Due to the variations on the cuts of meats and personal taste,
your cooking times may be different. Use your discretion when cooking with ARTISAN™ Sear-Zone™
IR-Burners.
FOOD ITEM APPROXIMATE COOKING TIME
(MINUTES) 
RARE MEDIUM WELL
HAMBURGER -1/2” THICK 456
STEAK - 1” THICK” 6810
CHICKEN BREAST (BONELESS) 8 ~ 10
CHICKEN BREAST (BONE-IN) 20 ~ 24

20
STAINLESS STEEL CARE:
Stainless Steel is widely used for catering and residential kitchen equipment because of its strength, its
ability to resist corrosion and its ease of cleaning. In fact, stainless steel ranks alongside glass and new
china in terms of “ease of cleaning” and in percentage removal of bacteria during washing. As a result of
these virtues, the metal is often taken for granted and it is assumed that no problems will arise during its
usage. However, some care is required to ensure that the stainless steel can live up to this reputation.
DAY TO DAY CARE:
To maintain the original appearance of your ARTISAN™ Grill, a regular cleaning routine should be
carried out using the following guidelines:
1. After use, following the safety precautions detailed on page 4 and 5, wipe the Grill with
a soft damp soapy cloth and rinse with clean water, preferably warm/hot water. This
should remove most substances encountered during the grilling process.
2. For more tenacious deposits, including oil, grease and water-borne deposits, use a multi
purpose cream cleanser and apply with a soft damp cloth. Rinsing with fresh water, as
described above, should follow as a last step.
3. For really stubborn dirt or burned-on grease, a nylon-scouring pad may be used in
conjunction with the cream cleanser. On no account should “wire wool” pads be used
unless they are made of stainless steel.
4. Harsh abrasives and scouring materials should not be used for cleaning stainless steel
as they will leave scratch marks in the surface and damage the appearance of the Grill.
Likewise do not use wire brushes, scrapers or contaminated scouring pads.
5. Your ARTISAN™ Grill has a directional polished grain, any cleaning with abrasives
should be carried out along this grain direction and not across it.
6. After use, always remove wet cleaning aids (such as cloths, pads, containers) from the
surface, to avoid formation of water marks or stains.
7. If necessary, dry the Grill after use with a soft dry cloth or towel.
If the preceding guidelines are adhered to, your ARTISAN™ Grill should offer excellent life and should
live up to its reputation of being “stainless”.
Neglect of this practice, however, can lead to deterioration of the surface and, in some extreme cases,
corrosion of the steel itself. The two most common types of corrosion that may be encountered,
particularly on stainless steel, are rust marks and pitting of the surface.
RUST-BROWN MARKS:
When this type of staining occurs it is unlikely that rusting of the stainless steel itself caused the marks.
Similar marks can be found with both porcelain and plastic sinks. The rust marks are more likely to be
the result of small particles of “ordinary-steel” which have become attached to the surface; these have
subsequently rusted in the damp environment. The most common source of such particles is from “wire-
wool” scouring pads, but contamination may also occur from carbon steel utensils and old cast iron
water supply pipes.
These brown marks are only superficial stains, which will not harm the Grill; they should be removable
using a soft damp cloth and a multi-purpose cream cleanser.
Occasionally, it may be necessary to resort to a proprietary stainless steel cleanser, to return the surface
of the Grill to its original condition. To avoid re-occurrence of any “rust-staining” it is essential that the
source of the contamination be eliminated.
PITTING:
Another form of corrosion, which occasionally occurs in stainless steel, is pitting of the surface. The
reason for this corrosive attack can usually be attributed to certain household products, for example:
