• The worktop and furniture surrounding the appliance must be made of materials resistant to temperatures above
100°C.
• The appliance should not be installed directly above a dishwasher, fridge, freezer, washing machine or clothes
dryer.
• The appliance can be placed close to other furniture on condition that, in the area where the appliance is set up,
the furniture’s height does not exceed the height of the cooktop.
2.2 INSTALLATION OF THE COOKER
• If the kitchen furniture is higher than the cooktop, the kitchen furniture
must be at least 10 cm away from the sides of appliance for air circulation.
• There should be a minimum 2cm blank space around the appliance
for air circulation.
• If a cooker hood or cupboard is to be installed above the appliance,
the safety distance between cooktop and any cupboard/cooker hood
should be as shown below.
A (mm) Cupboard 600
B (mm) Cooker Hood 600
D (mm) Product Width
E (mm) 100
2.3 GAS CONNECTION
This appliance must be installed by an authorised person in accordance with this instruction manual, AS/NZS 5601
- Gas installations (installation and pipe sizing), local gas tting regulations, local electrical regulations, local water
regulations, local health regulations, Building Code of Australia and any other government authority. This appliance is
suitable for connection with rigid pipe or exible hose. The isolating manual shut-off valve connection point must be
accessible when the appliance is installed.
NATURAL GAS
The supplied regulator must be tted to the appliance inlet connection. Gas Pressure must be adjusted to 1.0 kPa
when approximately 50% of the burners are on high ame. Universal LPG: The supplied test point adapter must be
tted to the appliance inlet connection. Gas Pressure must be adjusted to 2.75 kPa when approximately 50% of the
burners are on high ame.
Gas leakage and operation of the appliance must be tested by the installer before leaving. Check burner ames are
blue in colour, stable and completely ignite at both high and low ame settings with no appreciable yellow tipping,
carbon deposition, lifting, oating, lighting back or objectionable odour.
Test burners individually and in combination, when satised with the operation of the cooker, please instruct the user
on the correct method of operation. Where the data plate is obscured by cabinetry when the cooker is in the installed
position, place the supplied duplicate data please to a suitable adjacent surface or within the instruction manual for
future reference. Gas connection is located 50mm from the rear, at the right-hand side. The top of the pan support is
10mm above the benchtop.
The exible hose assembly must be certied to AS/NZS 1869 class B or D, be of appropriate internal diameter for the
total gas consumption, be kept as short as possible (not exceeding 1200mm), must not be in contact with the oor or
any hot or sharp surfaces. The hose assembly must not be subject to strain, abrasion, kinking or deformation.
Overhead clearances -- Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s
relevant instructions. However, in no case shall the clearance between the highest part of the hob of the gas cooking
appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm. Side clearances --
Measured from the periphery of the nearest burner to any vertical combustible surface, or vertical combustible surface
covered with toughened glass or sheet metal, is less than 200 mm, the surface shall be protected to a height of not
less than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area.
