Amigopod
Advanced Visitor Account
Naming

|March 2011 Amigopod |Technical Note
Copyright
© 2011 Aruba Networks, Inc. Aruba Networks trademarks include Airwave, Aruba Networks®, Aruba Wireless
Networks®, the registered Aruba the Mobile Edge Company logo, Aruba Mobility Management System®,
Mobile Edge Architecture®, People Move. Networks Must Follow®, RFProtect®, Green Island®. All rights
reserved. All other trademarks are the property of their respective owners.
Open Source Code
Certain Aruba products include Open Source software code developed by third parties, including software code
subject to the GNU General Public License (GPL), GNU Lesser General Public License (LGPL), or other Open
Source Licenses. The Open Source code used can be found at this site:
http://www.arubanetworks.com/open_source
Legal Notice
The use of Aruba Networks, Inc. switching platforms and software, by all individuals or corporations, to
terminate other vendors’ VPN client devices constitutes complete acceptance of liability by that individual or
corporation for this action and indemnifies, in full, Aruba Networks, Inc. from any and all legal actions that might
be taken against it with respect to infringement of copyright on behalf of those vendors.
Warranty
This hardware product is protected by the standard Aruba warranty of one year parts/labor. For more
information, refer to the ARUBACARE SERVICE AND SUPPORT TERMS AND CONDITIONS.
Altering this device (such as painting it) voids the warranty.
www.arubanetworks.com
1344 Crossman Avenue
Sunnyvale, California 94089
Phone: [phone]
Fax [phone]

Amigopod |Technical Note Advanced Visitor Account Naming|3
Table of Contents
Introduction..................................................................................................................................................... 4
Audience...................................................................................................................................................... 4
Document Overview .................................................................................................................................... 4
Configuring Visitor Account Creation ........................................................................................................... 5
Check Plugin Versions ................................................................................................................................. 5
Create New Visitor Account Form................................................................................................................ 5
Modify Form Fields ...................................................................................................................................... 6
Disable email field..................................................................................................................................... 6
Insert random_username_method field..................................................................................................... 6
Insert random_username_length field....................................................................................................... 7
Configure Operator Profile........................................................................................................................... 7
Create operator......................................................................................................................................... 8
Verify Visitor Account Creation .................................................................................................................... 8
Reference ...................................................................................................................................................... 10
Naming Options......................................................................................................................................... 10
Sequential numbering............................................................................................................................. 10
Password Options ..................................................................................................................................... 10
Picture String ............................................................................................................................................. 11
Examples ................................................................................................................................................ 11

4| Advanced Visitor Account Naming Amigopod |Technical Note
1Introduction
This technical note explains the configuration process for setting up visitor account provisioning
when fine-grained control over visitor account usernames is required.
In particular, the process for setting up random and sequential usernames is described.
Audience
This document is intended for network administrators and system integrators deploying an
Amigopod-based visitor management solution.
Basic familiarity with the Amigopod Visitor Management Appliance is assumed. For in-depth
information about the features and functions of the Amigopod appliance, refer to the Amigopod
Deployment Guide.
Document Overview
The first section of the document explains the configuration steps required to set up visitor
account creation with random usernames.
The next section contains a reference guide for the various fields and options related to random
and sequential username allocation.

Amigopod |Technical Note Advanced Visitor Account Naming|5
2Configuring Visitor Account Creation
Check Plugin Versions
Support for creating random or sequential usernames requires the following plugin versions:
•Guest Manager 2.0.5 or later
To verify you have the correct plugin versions installed, navigate to Administrator > Plugin
Manager > List Available Plugins and check the version number in the list.
Use the Check for Plugin Updates link to download and install updated plugins.
Create New Visitor Account Form
Navigate to Customization > Forms & Views and click the create_user form in the list.
Click the Duplicate icon link to make a copy of the form.
A new item named create_user_1 will be displayed.
Click the Edit link for the duplicated form, and update the title and description of the form as
shown in Figure 1.
Figure 1. Edited properties for create_user_1 form.
To modify the form’s fields, click the create_user_1 form in the list, and then click Edit Fields.

6| Advanced Visitor Account Naming Amigopod |Technical Note
Modify Form Fields
Disable email field
Click the email field in the list, and then click Disable Field. This field will be used as the account
username if it is available.
Insert random_username_method field
Click the Insert After link to insert a new field on the form. Select the field named
random_username_method. Make the following selections on the form:
•[x] Enable this field
•User Interface: Hidden field
•[x] Field value must be supplied
•Initial Value: nwa_digits_password
With these selections, the form should appear as shown in Figure 2.
Figure 2. Form field editor with settings for random_username_method.

Amigopod |Technical Note Advanced Visitor Account Naming|7
Click the Save Changes button to return to the list of form fields.
Insert random_username_length field
Click the Insert After link to insert a new field on the form. Select the field named
random_username_length. Make the following selections on the form:
•[x] Enable this field
•User Interface: Hidden field
•[x] Field value must be supplied
•Initial Value: 6
With these selections, the form should appear as shown below.
Figure 3. Form field editor with settings for random_username_length.
Click the Save Changes button to return to the list of form fields.
Configure Operator Profile
To use the new visitor account creation form, it must be assigned to an operator profile.
NOTE For more information about configuring operator profiles to use different forms and views, refer to
the Amigopod TechNote “Implementing Multiple Visitor Account Creation Forms”.
Navigate to Administrator > Operator Logins > Manage Operator Profiles and select the
Operations and Marketing profile.

8| Advanced Visitor Account Naming Amigopod |Technical Note
Click the Edit link to display the Edit Operator Profile form.
Select the checkbox at Customization: [x] Override the application’s forms and views, and in
the Customization list, select the create_user_1 form for the New Visitor Account screen. The
form should appear as shown in Figure 4.
Figure 4. Form customizations on the Edit Operator Profile screen.
Click the Save Changes button to return to the list of operator profiles.
Create operator
If you have not already done so, create an operator login using the Operations and Marketing
profile.
Verify Visitor Account Creation
Log into the Amigopod using the operator login and profile created in the previous step.
Observe that the New Visitor Account form no longer includes a field for the visitor’s email
address.

Amigopod |Technical Note Advanced Visitor Account Naming|9
Figure 5. Completed visitor account creation form.
After completing the form, using settings such as that shown in Figure 5, the guest account will be
created. A receipt for the guest account is then displayed.
Figure 6. Visitor account receipt showing randomly created username.
Observe that the newly created account now has a username consisting of six random digits.

10| Advanced Visitor Account Naming Amigopod |Technical Note
3Reference
Naming Options
The following options may be used as the value of the random_username_method field.
Value Description
nwa_digits_password Creates usernames using random digits
nwa_letters_password Creates usernames using random letters (a
through z)
nwa_lettersdigits_password Creates usernames using random letters and
digits (a through z and 0 through 9)
nwa_alnum_password Creates usernames using random alphanumeric
characters (a-z, A-Z and 0-9)
nwa_words_password Creates usernames using two random words
separated by a small number
nwa_picture_password Creates usernames using the format picture
specified in the random_username_picture field
nwa_sequence Creates usernames sequentially
The random_username_length field specifies the number of characters in the generated
username, with the following exceptions:
•For nwa_words_password, the random_username_length is the maximum length of the
random words to use. Two random words will be used to create the username, joined together
with a small number (up to 2 digits).
•For nwa_picture_password, the random_username_length is ignored.
•For nwa_sequence, the random_username_length is the length of the sequence number in the
username; the sequence number will be zero-padded. For example, specifying a length of 4 will
result in sequence numbers 0001, 0002, etc.
Sequential numbering
When using the nwa_sequence option, at least one additional field must be specified.
The multi_prefix field is required and must be a non-empty string. This string will be used as the
initial string for sequentially-numbered account names. For example, setting multi_prefix to
“user” will create visitor accounts named user0001, user0002, user0003 and so on.
The multi_initial_sequence field may be provided. This value can be used to specify the initial
sequence number. If not provided, the default initial sequence number is 1.
The random_username_length field specifies the length of the sequence number part of the
username. Sequence numbers are padded with zeroes. For example, specifying a length of 4 will
result in sequence numbers 0001, 0002, etc.
Password Options
The following options may be used as the value of the random_password_method field.
Value Description

Amigopod |Technical Note Advanced Visitor Account Naming|11
nwa_digits_password Creates passwords using random digits
nwa_letters_password Creates passwords using random letters (a
through z)
nwa_lettersdigits_password Creates passwords using random letters and
digits (a through z and 0 through 9)
nwa_alnum_password Creates passwords using random alphanumeric
characters (a-z, A-Z and 0-9)
nwa_strong_password Creates passwords using random letters, digits
and symbols
nwa_words_password Creates passwords using two random words
separated by a small number
nwa_picture_password Creates passwords using the format picture
specified in the random_password_picture field
The random_password_length field specifies the number of characters in the generated
password, with the following exceptions:
•For nwa_words_password, the random_password_length is the maximum length of the
random words to use. Two random words will be used to create the password, joined together
with a small number (up to 2 digits).
•For nwa_picture_password, the random_password_length is ignored.
Picture String
When using the value nwa_picture_password, a “picture string” should be provided to specify
the format of generated username or password, using the random_username_picture and
random_password_picture fields.
The picture string is used as the username or password, with the following symbols replaced with
a random character:
Symbol Replacement
# Random digit (0-9)
$ or ? Random letter (A-Z, a-z)
_ Random lowercase letter (a-z)
^ Random uppercase letter (A-Z)
* Random letter or digit (A-Z, a-z, 0-9)
! Random punctuation symbol, excluding apostrophe and quotation marks
& Random character (letter, digit or punctuation excluding apostrophe and
quotation marks)
@ Random letter or digit, excluding vowels
Any other alphanumeric characters in the picture string will be used in the resulting username or
password.
Examples
Picture String Sample Password
#### 3728
user#### user3728
v^^#__ vQU3nj

12| Advanced Visitor Account Naming Amigopod |Technical Note
@@@@@ Bh7Pm
