Aruba 800-E User manual

Aruba 800-E
Access Multiplexer
Installation Guide

ii Aruba 800-E 0500191
Installation Guide November 2005
Copyright
© 2005 Aruba Wireless Networks, Inc. All rights reserved.
Aruba Networks and Aruba The Mobile Edge Company are trademarks of Aruba
Wireless Networks, Inc.
Specifications are subject to change without notice.
Trademarks
Sygate On-Demand Agent and Sygate Enforcer are trademarks of Sygate
Technologies.
All other trademarks or registered trademarks are the property of their respective
holders.
Legal Notice
The use of Aruba Wireless Networks, Inc. switching platforms and software, by
all individuals or corporations, to terminate Cisco or Nortel VPN client devices
constitutes complete acceptance of liability by that individual or corporation for
this action and indemnifies, in full, Aruba Wireless Networks, Inc. from any and all
legal actions that might be taken against it with respect to infringement of
copyright on behalf of Cisco Systems or Nortel Networks.

Aruba 800-E iii
Installation Guide
Electromagnetic Interference
FCC - Class A
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
their own expense.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This product complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Industry Canada - Class A
This digital apparatus does not exceed the Class A limits for radio noise
emissions from digital apparatus as set out in the interference-causing equipment
standard entitled “Digital Apparatus,” ICES-003 of the Department of
Communications.
Cet appareil numérique respecte les limites de bruits radioélectriques applicables
aux appareils numériques de Classe A prescrites dans la norme sur le matériel
brouilleur: “Appareils Numériques,” NMB-003 édictée par le ministère des
Communications.
VCCI - Class A
CE - Class A
WARNING:This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the user
may be required to take adequate measures.

iv Aruba 800-E 0500191
Installation Guide November 2005
EU - Class A
This product complies with EN55022 Class A and EN55024 standards.
Safety
Lithium Battery Notice
This product contains a lithium battery which is replaceable only by a trained
technician.
Laser Notice
The Aruba 800-E uses a laser transceiver on the fiber-optic uplink port.
This product complies with 21 CFR Chapter 1, Subchapter J, Part 1040.10, and
IEC 60825-1: 1993, A1: 1997, A2: 2001, IEC 60825-2: 2000.
CAUTION:The lithium battery may explode if it is incorrectly replaced. A
trained technician should replace the battery with the same or
equivalent type battery recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s
instructions.
CLASS 1
LASER PRODUCT
CAUTION:Use of controls or adjustments of performance or procedures
other than those specified in this manual may result in
hazardous radiation exposure.

Aruba 800-E v
Installation Guide
Contents
Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Overview of this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Related Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Text Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii
Chapter 1 System Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Physical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 2 Installing the Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Pre-Installation Checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Rack Mounting Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Selecting a Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Mounting the Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Verifying the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 3 Initializing the 800-E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Serial Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Prerequisite Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Initial Switch Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Logging Into the Web User Interface. . . . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 4 Configuring the 800-E From the WebUI . . . . . . . . . . . . . 21
Verify the Multiplexer IP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Configuring the VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Configuring Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connecting to the Mobility Controller. . . . . . . . . . . . . . . . . . . . . . . . 24
Verify the Access Multiplexer Settings. . . . . . . . . . . . . . . . . . . . . . . 25
Verifying the Status of the 800-E . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Chapter 5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Contents
vi Aruba 800-E 0500191
Installation Guide November 2005
Access Multiplexer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
User Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Privileged Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Monitoring Your 800-E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Monitoring Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Managing Your 800-E Software. . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Contacting Tech Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Appendix A Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
FE Network Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Serial & Power Over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Physical Description & LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Pin Outs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
GE Uplink Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Physical Description and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Serial Console Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Port & Adapter Pin Outs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Communications Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Appendix B Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Contacting Aruba Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Proper Disposal of Aruba Equipment . . . . . . . . . . . . . . . . . . . . . . . . 44

Aruba 800-E vii
Installation Guide
Preface
This preface includes the following information:
An overview of the sections in this manual
A list of related documentation for further reading
A key to the various text conventions used throughout this manual
Aruba Networks support and service information
Overview of this Manual
This manual is for trained technicians responsible for installing the Aruba 800-E
Access Multiplexer. This manual is organized as follows:
Chapter 1, “System Overview”—Describes the main features of this product,
including physical diagrams.
Chapter 2, “Installing the Chassis”—Instructions for mounting the chassis and
attaching power.
Chapter 3, “Initializing the 800-E”—Instructions for completing the setup dialog
upon initial boot.
Chapter 4, “Configuring the 800-E From the WebUI”—Instructions for configuring
the Aruba 800-E.
Chapter 5, “Troubleshooting”—Instructions for solving common operational
problems.
Appendix A, “Ports.”—Describes interface, cable, and adapter specifications for
system ports.
Appendix B, “Specifications.”—Describes the system’s size, weight, storage and
operating environment, and certifications for electromagnetic compliance and
safety.

Preface
viii Aruba 800-E 0500191
Installation Guide November 2005
Related Documents
The following items are part of the complete documentation for the Aruba
system:
zAruba 800-E Access Multiplexer Installation Guide (this manual)
zArubaOS User Guide
Text Conventions
The following conventions are used throughout this manual to emphasize
important concepts:
TABLE 1 Text Conventions
Type Style Description
Italics This style is used to emphasize important terms and to
mark the titles of books.
System items This fixed-width font depicts the following:
zSample screen output
zSystem prompts
zFilenames, software devices, and certain commands when
mentioned in the text
Commands In the command examples, this bold font depicts text
that the user must type exactly as shown.
<Arguments> In the command examples, italicized text within angle
brackets represents items that the user should replace
with information appropriate to their specific situation.
For example:
# send <text message>
In this example, the user would type “send” at the
system prompt exactly as shown, followed by the text of
the message they wish to send. Do not type the angle
brackets.
[ Optional ] In the command examples, items enclosed in brackets
are optional. Do not type the brackets.
{ Item A | Item B } In the command examples, items within curled braces
and separated by a vertical bar represent the available
choices. Enter only one choice. Do not type the braces or
bars.
button Identifies the keyboard key to press.

Aruba 800-E 1
Installation Guide
System Overview 1
This chapter introduces you to the 800-E Access Multiplexer. It describes the
general features of the system and illustrates key physical elements. Once you are
familiar with the system, you can begin the installation process covered in the
next chapters.
The Aruba 800-E Access Multiplexer is a wired concentrator deployed in the
closet distribution switch to secure network ports located either in common
areas, conference rooms or cubes, and in office ports. All traffic traversing an
800-E will be tunneled over the network to an Aruba Mobility Controller, where
security services will be applied.
Features
The 800-E features include:
1 Gigabit Ethernet network uplink port
8 Fast Ethernet ports to provide 802.3af compliant POE as a PSE (used to
provide power to VoIP phones / etc.)
Each Access Multiplexer counts as one AP against the AP limit on the
Mobility Controller (regardless of the number of ports connected)
Upon discovery of an Aruba Mobility Controller, the 800-E will register with the
Mobility Controller. When the multiplexer ports have been configured, the 800-E
will then establish a secure GRE tunnel from each of these ports to the Mobility
Controller.

System Overview
Chapter 1
2 Aruba 800-E 0500191
Installation Guide November 2005
Physical Description
FIGURE 1-1 Aruba 800-E Access Multiplexer Systems
System Indicator LEDs
Eight FE ports
These network ports are used for connecting wired clients, such as VoIP phones,
as well as wired LAN segments. The ports provide 10/100 Mbps Fast Ethernet
connectivity, and in some cases, power and serial connectivity as well. See “FE
Network Ports” on page 33 for port, LED, and cable specifications.
8
GIGABIT
8
GIGABIT
8
SERIAL
LNK/
ACT
LNK/
ACT POE
ACCESS
POINT
STATUS
7654
4
5
6
7
LNK/
ACT POE
ACCESS
POINT
STATUS
3210
POWER
STATUS
0
1
2
3
SERIAL
LNK/
ACT
LNK/
ACT POE
ACCESS
POINT
STATUS
7654
4
5
6
7
LNK/
ACT POE
ACCESS
POINT
STATUS
3210
POWER
STATUS
0
1
2
3
4
7
1
6 6
5
2 3
Front Views
Rear View
HW-800-CHAS-SPOE-SX
HW-800-CHAS-SPOE-T
TABLE 1-1 System LEDs
LED State Description
Power Green Unit is receiving proper power.
Off Switch is powered off.
Status Green Switch has booted and is functioning
properly.
Off Switch is booting, loading software, or
has failed.
1
2

Aruba 800-E 3
Installation Guide
System Overview
Chapter 1
GE uplink port
This uplink port is used for high-speed connection to the wired LAN. The port
provides 1000 Mbps Gigabit Ethernet connection. Depending on the option
selected at time of purchase, one of the following interfaces is available:
1000BASE-T copper connector (standard model HW-800-CHAS-SPOE-T)
1000BASE-SX fiber-optic connector (optional model
HW-800-CHAS-SPOE-SX)
See “GE Uplink Port” on page 36 for port, LED, and cable specifications.
NOTE:The Gigabit interface is not user-replaceable. Do not remove the port
cover plate.
Serial Console port
This port is for connecting a local management console. It is required to access
the text-based Command-Line Interface (CLI) for initial configuration of the 800-E
Access Multiplexer. The CLI can also be used for switch management and
troubleshooting.
The port accepts an RS-232 serial cable, an RJ-45 male connector. See “Serial
Console Port” on page 39 for more port and cable specifications.
See the ArubaOS User’s Guide for information on using the features available
through this port.
Fans/heat exhaust (on side)
Three independent fans promote proper air circulation for cooling the 800-E
Access Multiplexer.
During operation, the air vents on the left and right sides of the chassis must
remain unobstructed by cables or mounting equipment. For proper air circulation,
leave at least 10 cm (4 inches) of clearance on the left and right of the chassis.
Holes for attaching rack mounting brackets (on side)
Power Input Socket (on back)
The power input socket on the back of the switch accepts a power cord with a
standard IEC320 connector. For proper safety and performance, the power cord
must be rated to 10 A and conform to grounded electrical standards in the
country where the product is operated.
CAUTION:This model uses a laser transceiver on the fiber-optic
uplink port. Use of controls or adjustments of
performance or procedures other than those specified
herein may result in hazardous radiation exposure.
3
4
5
6
7

System Overview
Chapter 1
4 Aruba 800-E 0500191
Installation Guide November 2005

Aruba 800-E 5
Installation Guide
Installing the Chassis 2
This chapter covers the following installation topics:
Precautions to observe during installation
800-E Access Multiplexer components and rack mounting requirements
Selecting a proper environment for the 800-E Access Multiplexer
Mounting the 800-E Access Multiplexer in a rack
Connecting power to the 800-E Access Multiplexer
Pre-Installation Checklist
During installation, you will need the following:
Aruba 800-E Access Multiplexer chassis
Two mounting brackets (included)
Six 6-32 flat head screws (included)
Four 12-24 screws (included) or screws as appropriate for your rack
Aruba power cord rated to at least 10 A with IEC320 connector (included)
Phillips or cross-head screwdriver
19-inch equipment rack, or equivalent
1U rack space with 10 cm (4 inches) clearance to the left and right of the rack
Electrical power: 90~132/180~264 VAC, 50 to 60 Hz, 3.5/2.0 A
Cool, non-condensing air 0 to 40 ºC (32 to 104 ºF). May require air
conditioning
Another person to help position the switch
Console terminal (or computer running emulation software) with RJ-45 or
DB-9 serial port
RS-232 serial cable with RJ-45 male connectors (straight-through Ethernet
patch cable)
Aruba serial adapter (included) if connecting to the console with DB-9
CAUTION:Installation should be performed by a trained technician.

Installing the Chassis
Chapter 2
6 Aruba 800-E 0500191
Installation Guide November 2005
Precautions
Requirements
CAUTION:Hazardous energy is always present while the Aruba
800-E Access Multiplexer is plugged into an electrical
outlet. Remove all rings, jewelry, and other potentially
conductive material before working with this product.
Never insert foreign objects into the chassis or any other
component, even when the 800-E Access Multiplexer is
unpowered or unplugged.
Main power is fully disconnected from the 800-E Access
Multiplexer by unplugging the power cord from the power
outlet. For safety reasons, verify the power outlet and plug
are within easy reach of the operator.
Do not handle electrical cables which are not insulated.
This includes any network cables.
To minimize electrical hazard, keep water and other fluids
away from the product.
Comply with electrical grounding standards during all
phases of installation and operation of the product. Do not
allow the 800-E Access Multiplexer chassis, network
ports, power source, or mounting brackets to contact any
device, cable, object, or person attached to a different
electrical ground. Also, never connect the device to
external storm grounding sources.
Installation or removal of the chassis must be performed in
a static-free environment. The proper use of anti-static
body straps and mats is strongly recommended.
Do not ship or store this product near strong
electromagnetic, electrostatic, magnetic, or radioactive
fields.
Do not disassemble the chassis. This product has no
internal serviceable parts. When service or repair is
needed, see “Contacting Aruba Networks” on page 43.

Aruba 800-E 7
Installation Guide
Installing the Chassis
Chapter 2
Rack Mounting Kit
Using the included rack mounting kit, you can mount the 800-E Access
Multiplexer in a standard 19-inch network equipment rack. The rack mounting kit
contains the following parts:
FIGURE 2-1 Rack Mounting Kit
NOTE:The four 12-24 screws are intended for securing the switch to the rack.
Some racks require different screws which are not included. Make sure
that you have the correct screws or fasteners for your rack system before
attempting to mount the switch.
Selecting a Location
The 800-E Access Multiplexer, like other network and computing devices,
requires an “electronics friendly” environment.
Reliable power
Make sure that your electrical outlet is compatible with the 800-E Access
Multiplexer. The switch power input is auto-ranging and accepts
90~132/180~264 VAC, 50 to 60 Hz, 3.5/2.0 A.
The power cords must be rated to 10 A and conform to grounded electrical
standards in the country where the product is operated.
Use of a power line conditioner or Uninterruptible Power Supply (UPS) can
decrease or mitigate problems caused by power service fluctuations. Make
sure that the output of any power shaping device is compatible with the
800-E Access Multiplexer power supply.
Cool, non-condensing ventilation
For proper operation, the 800-E Access Multiplexer requires an environment
with an ambient air temperature between 0 to 40 ºC (32 to 104 ºF). Humidity
must be kept at non-condensing levels between 5 and 95%.
x 4
Left
Bracket
Right
Bracket
x 6
6-32 Flat Head
Screws
12-24 Screws

Installing the Chassis
Chapter 2
8 Aruba 800-E 0500191
Installation Guide November 2005
Where a large number of electrical devices are working in the same area,
additional air conditioning or air circulation equipment may be required.
Ample space
For proper air circulation, leave at least 10 cm (4 inches) clearance for the
vents on the left and right of the chassis.
Leave additional space in front and back of the chassis to access power
cords, network cables, and indicator LEDs.
Limited electromagnetic interference
For best operation, keep the 800-E Access Multiplexer and all cords and
cables at least 0.7 meters (2 feet) from fluorescent lighting fixtures, and 2
meters (6 feet) from photocopiers, radio transmitters, electric generators, and
other sources of strong electromagnetic interference.
Mounting the Chassis
1. Make sure that your rack environment meets requirements (see “Selecting a
Location” on page 7).
2. Attach the rack mounting brackets to the switch chassis as shown in
Figure 2-2.
FIGURE 2-2 Attaching the Rack Mounting Brackets
8
GIGABIT
SERIAL
LNK/
ACT
LNK/
ACTPOE
ACCESS
POINT
STATUS
7
6
5
4
4
5
6
7
LNK/
ACTPOE
ACCESS
POINT
STATUS
3
2
1
0
POWER
STATUS
0
1
2
3
x 6
6-32
flat head
screws

Aruba 800-E 9
Installation Guide
Installing the Chassis
Chapter 2
Orient both brackets so that the narrow flange faces the front. When placed
properly, the brackets’ screw holes will match the holes on the side of the
chassis.
Use a Phillips or cross-head screwdriver to attach each bracket securely with
three 6-32 flat head screws (included).
3. Attach the 800-E Access Multiplexer to the rack.
NOTE:For proper operation, the 800-E Access Multiplexer requires an ambient
air temperature between 0 to 40 ºC (32 to 104 ºF). Make sure your rack
environment is in compliance.
CAUTION:To avoid personal injury or damage to equipment, get help
for lifting and positioning the 800-E Access Multiplexer.
Also, do not install the 800-E Access Multiplexer in any
fashion where instability or uneven mechanical loading
may occur.

Installing the Chassis
Chapter 2
10 Aruba 800-E 0500191
Installation Guide November 2005
Position the switch chassis in the equipment rack and align the brackets’
mounting holes with the corresponding holes in your rack frame.
FIGURE 2-3 Mounting the 800-E Access Multiplexer
Use a Phillips or cross-head screwdriver to secure the switch to the rack with
two 12-24 screws (included) for each mounting bracket.
NOTE:Some cabinets require different screws which are not included. Make
sure that you use the correct screws or fasteners for your rack system.
8
GIGABIT
SERIAL
LNK/
ACT
LNK/
ACTPOE
ACCESS
POINT
STATUS
7
6
5
4
4
5
6
7
LNK/
ACTPOE
ACCESS
POINT
STATUS
3
2
1
0
POWER
STATUS
0
1
2
3
x 4
12-24
screws

Aruba 800-E 11
Installation Guide
Installing the Chassis
Chapter 2
4. Adhere to clearance requirements.
FIGURE 2-4 “Keep Clear” Zones
For proper air circulation, leave at least 10 cm (4 inches) clearance for the
vents on the left and right of the chassis.
Leave additional space in front and back of the chassis to access power
cords, network cables, and indicator LEDs.
Connecting Power
1. Make sure you understand the procedure and all precautions.
Before beginning, read the entire procedure. Make sure you understand all the
precautions in these steps as well as those on page 6.
10 cm
8
GIGABIT
SERIAL
LNK/
ACT
LNK/
ACTPOE
ACCESS
POINT
STATUS
765
4
4
5
6
7
LNK/
ACTPOE
ACCESS
POINT
STATUS
3
2
10
POWER
STATUS
0
1
2
3
10 cm
Keep Open
to Access
Keep Clear
for Air Exhaust
Keep Clear for
Air Intake
Keep Open
to Access
CAUTION:This procedure should be performed by a trained
technician.

Installing the Chassis
Chapter 2
12 Aruba 800-E 0500191
Installation Guide November 2005
2. Make sure that your site’s electrical system is compatible with the switch.
The switch power input is auto-ranging and accepts 90~132/180~264 VAC,
50 to 60 Hz, 3.5/2.0 A.
NOTE:Use of a power line conditioner or Uninterruptible Power Supply (UPS)
can decrease or mitigate problems caused by power service fluctuations.
Make sure that the output of any power shaping device is compatible
with the 800-E Access Multiplexer power supplies.
3. Make sure that the switch power supply can handle the POE devices.
The total power drawn by all connected Power Over Ethernet (POE) devices
must not exceed 100 W total.
4. Attach the power cord to the power input socket at the back of the switch.
Plug an appropriate power cord into the power input socket. Use the included
power cord if it is compatible with your electrical outlet. Otherwise, replace
the power cord with the type appropriate for your country. The power input
socket accepts a power cord with a standard IEC320 connector.
5. Attach the power cord to a proper electrical outlet.
Once power is connected, the switch will automatically turn on and you can
perform the power-on test (see “Verifying the Installation” on page 13)
CAUTION:For proper safety and performance, the power cord must
be rated to 10 A and conform to grounded electrical
standards in the country where the product is operated.
