Aruba MSR2000 User manual

0511239-01
Aruba Networks
MSR2000 Installation Guide

MSR2000 Installation Guide 1
Copyright 2005–2012 by Aruba Networks, USA. All rights reserved.
Statement of Conditions
In the interest of improving internal design, operation function, and/or reliability, Aruba Networks reserves
the right to make changes to products described in this document without notice. Aruba Networks does not
assume any liability that may occur due to the use or application of the product(s) described herein.
DISCLAIMER: LIMITATION OF LIABILITY
1．Before installation, it is strongly recommended and requested that users pay particular attention to the
safety warnings in the sequentially detailed operation procedures within the manual. If there is any
uncertainty or incapability of solving problems, contact the company’s customer support center. Please DO
NOT incur any risk or try to verify situations by yourself. Otherwise, any consequence caused by the
attempt shall be completely due to the user himself.
2．Periodically check whether the installed MSR2000 is damaged, worn-out or poses any danger. Any
actual proof, sign or phenomenon of the afore-mentioned situations should be brought to the attention of
the company at point of sale. Please DO NOT attempt to repair the product or replace any component. The
company shall not be liable for any consequence arising out of or relating to the user’s attempt to repair the
product, including but not limited to damages, misuse, short circuit, fire, bodily injury, etc.
3. Users shall purchase or use the company’s MSR2000 voluntarily. Users shall understand on their own
initiative and abide voluntarily by policies, regulations, or laws of their respective nation or local territories.
The consequence arising out of or relating to any violation of the local laws or regulations by the user shall
be solely attributed to the user himself, and the company shall not be liable.
4. The company disclaims any and all warranties and guarantees, express, implied or otherwise, arising,
with respect to the MSR2000 products or services, including but not limited to the warranty of
merchandisability, the warranty of fitness for a particular purpose, and any warranty of non-infringement of
the intellectual property rights of any third party. Liability of the company for loss is limited to the total
amount paid to the company by the customer during the previous calendar year. The company will have no
obligation or liability, whether arising in contract (including warranty), tort (including active, passive, or
imputed negligence, strict liability or product liability) or otherwise for any special, incidental, consequential,
or indirect damages including but not limited to loss of use, loss of data, business interruption, loss of
revenue, loss of business, or other financial loss arising out of or in connection with any of the products or

MSR2000 Installation Guide 2
other goods or services furnished by the company under this manual, even if advised of the possibility of
such damages.
5．It shall never be understood that this manual expresses or implies to any customer or any third party
authorize or transfer any rights. The company reserves fully the final interpretation of the MSR2000 and
this manual.
Safety and Regulatory Compliance
Aruba Networks provides a multi-language document that contains country-specific restrictions and
additional safety and regulatory information for all Aruba access points. This document can be viewed or
downloaded from the following location: www.arubanetworks.com/safety_addendum
Safety Warnings
The MSR2000 must be installed by trained professional installation technicians. All warnings below must be
read and understood before installation.
General Safety Warnings
You can be killed or injured while performing antenna installation near electrical power lines.
Carefully read and follow all instructions in this guide. Make sure that there are no high voltage and
electronic fields nearby.
Working Aloft Warning
When working on a tower or a roof, individuals must wear safety belts. Tools must be tied to the
individual using them. Workers below must wear safety helmets.
Lightning Activity Warning
Make sure not to connect or disconnect cables during periods of lightning activity.
A surge protective device should be installed to prevent potential damage from very high surges, for
instance, the peak surges caused by lightning.

MSR2000 Installation Guide 3
Explosive Device Proximity Warning
Do not operate wireless network devices close to explosive merchandise or in explosive
environments if devices are not certified for operation in such an environment, for example, in the
vicinity of a gas station.
Antenna Placement Warning
Do not install any antenna near overhead power lines or other electric light, or where the
antenna can come into contact with such circuits.
Antenna Selection Warning
Please use DC grounding antenna with lightning protection to prevent surge and static electricity.
Grounding Warning
Please always remember to protect your MSR2000 system by installation of grounding lines.
The ground connection must be complete before connecting power to the MSR2000 enclosure. The
requirement of grounding is to make sure the resistance between the ground termination point and the
grounding tier is less than 5 ohm.
Power Installation Warning
The installation of the power switch must be performed by a trained professional technician.
The power switch is not supplied with the MSR2000. The power cord must be assembled by a
professional installer, and the final assembly must comply with the related requirements.
Solar Radiation and High Temperature Protection
Pay attention to level of sunlight. This could cause an increase in the working temperature of
the MSR2000. Make sure the working temperature of the MSR2000 is not higher than specifications
listed in this document.
A solar shield is provided in the Aruba standard package and should be installed to protect any outdoor
MSR2000. The Aruba Warranty policy does not cover those outdoor products for which solar shields
are not installed. ContactAruba technical support engineers for detailed information.

MSR2000 Installation Guide 4
RF Device Protection
Before powering up the MSR2000, we recommend that the RF ports are connected to antennas
or valid loads. RF modules with less than 100mW power may work in a test environment without
antennas or load connections, provided the duration of operation is less than 30 minutes.
Protection on unused RF module
The unused RF interface must be closed via configuration command and its protective cap must be
wrapped up by waterproof PVC tape to prevent it from falling off. Otherwise, the RF module may be
damaged.Aruba will not take any responsibility for such damage.
FCC Certificate
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
REMINDER
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.

MSR2000 Installation Guide 5
RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits. This equipment should be installed and
operated with a minimum distance of 13.78 inches (35 cm) between the radiator and your body for 2.4 GHz
and 5 GHz operations. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter. When operated in the 5.15 to 5.25 GHz frequency range, this device is restricted to
indoor use to reduce the potential for harmful interference with co-channel Mobile Satellite Systems.
IC notice
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropic radiated power (EIRP) is not more than that permitted for successful
communication.
Proper Disposal of Aruba Equipment
For the most current information about Global Environmental Compliance and Aruba products, see our
website at www.arubanetworks.com.
Waste of Electrical and Electronic Equipment
Aruba products at end of life are subject to separate collection and treatment in the EU
Member States, Norway, and Switzerland and therefore are marked with the symbol
shown at the left (crossed-out wheelie bin). The treatment applied at end of life of these
products in these countries shall comply with the applicable national laws of countries
implementing Directive 2002/96EC on Waste of Electrical and Electronic Equipment
(WEEE).

MSR2000 Installation Guide 6
MSR2KP

MSR2000 Installation Guide 7
MSR2KAC/ MSR2KDC

MSR2000 Installation Guide 8
Table of Contents
1PRODUCT OVERVIEW .................................................................................................................................9
1.1 INTERFACES.......................................................................................................................................9
1.2 LED STATUS INDICATORS.................................................................................................................10
2INSTALLATION PREPARATIONS .............................................................................................................15
2.1 PACKAGE CONTENTS........................................................................................................................15
2.2 PREPARING INSTALLATION TOOLS......................................................................................................16
2.3 EXAMINING THE INSTALLATION SITE...................................................................................................16
3WEATHERPROOFING CONNECTIONS ....................................................................................................17
3.1 REQUIRED ITEMS AND TOOLS............................................................................................................17
3.2 TYPES OF CONNECTIONS ..................................................................................................................17
3.3 IMPORTANT POINTS TO REMEMBER ...................................................................................................19
3.4 WEATHERPROOFING ANTENNAS CONNECTED DIRECTLY TO THE MSR2000 ........................................19
3.5 WEATHERPROOFING CABLE CONNECTIONS........................................................................................23
4MSR2000 INSTALLATION..........................................................................................................................26
4.1 MOUNTING BRACKET ASSEMBLY .......................................................................................................27
4.2 INSTALLING THE MSR2000 ON A POLE ..............................................................................................29
4.3 INSTALLING THE MSR2000 ON A WALL..............................................................................................30
4.4 GROUNDING THE MSR2000..............................................................................................................31
4.5 CONNECTING THE RF CABLE .............................................................................................................32
4.6 CONNECTING THE ETHERNET CABLE .................................................................................................34
4.6.1 Connecting the Ethernet Cable (MSR2KP)………………………………………………………….34
4.6.2 Connecting the Ethernet Cable (MSR2KAC/MSR2KDC)………………………………………….35
4.7 CONNECTING THE POWER CABLE (MSR2KAC/MSR2KDC)…………………………………………….36
4.7.1 Powering the MSR2KAC/MSR2KDC………………………………………………………………...37
4.7.2 Best Practices for Outdoor Connection to AC Mains………………………………………………37
4.7.3 Using the CKIT-AC-M and CKIT-DC-M……………………………………………………………...38
4.7.4 AC/DC power connector PIN OUT on MSR2KAC/MSR2KDC…………………………………….38
4.7.5 Connecting the Power Cable to the MSR2KAC/MSR2KDC……………………………………….39
4.8 FIXING THE SOLAR SHIELD ON THE MSR2000 ....................................................................................40
5PRODUCT SPECIFICATIONS.....................................................................................................................42
6CONTACTING SUPPORT ...........................................................................................................................44

MSR2000 Installation Guide 9
1 Product Overview
There are three versions of the MSR2000, which mainly differ in the way they receive power.
MSR2KP: PoE powered
MSR2KAC: AC powered (100-240VAC)
MSR2KDC: DC powered (12-48VDC)
1.1 Interfaces
Figure 1-1 Interfaces on the MSR2KP
1
Antenna 1 (Radio 1)
5
Antenna 2 (Radio 0)
2
USB console interface
6
Antenna 2 (Radio 1)
3
Reserved
7
Ethernet interface (plus POE-PD input)
4
Antenna 1 (Radio 0)
8
Grounding hole

MSR2000 Installation Guide 10
Figure 1-2 Interfaces on the MSR2KAC/MSR2KDC
1
Antenna 1 (Radio 1)
5
Antenna 2 (Radio 0)
2
USB console interface
6
Antenna 2 (Radio 1)
3
Power interface
7
Ethernet interface (plus POE-PSE output)
4
Antenna 1 (Radio 0)
8
Grounding hole
1.2 LED Status Indicators
The MSR2000 includes visual indicators for power, link, and radio status. The LED layout is different for the
three versions of MSR2000.
Figure 1-3 MSR2KP LED Location

MSR2000 Installation Guide 11
Figure 1-4 MSR2KP LED Layout
The following table lists the meanings of the LEDs on the MSR2KP:
Table 1-1 MSR2KP LED Status Indicators
LED
Color
QTY
Definition
R0
Orange
5
Displays the Radio 0 RF Strength status:
•All dark: Radio 0 is not providing either access (SSID) or
backhaul (mesh) service
•Single LED orange: Radio 0 is providing access (SSID)
service or providing very weak backhaul (mesh) link
•Multiple LED orange: Radio 0 is providing backhaul (mesh)
link to another node; the more LEDs are orange, the stronger
the link signal
R1
Blue
5
Displays the Radio 1 RF Strength status:
•All dark: Radio 1 is not providing either access (SSID) or
backhaul (mesh) service
•Single LED blue: Radio 1 is providing access (SSID) service
or providing very weak backhaul (mesh) link
•Multiple LED blue: Radio 1 is providing backhaul (mesh) link
to another node; the more LEDs are blue, the stronger the
link signal
P/S
Orange/Green
1
Displays the power or connection status:
•Dark: No power to the unit
•Orange: Unit has power but does not yet have a mesh
network routing path to a gateway (portal) node
•Green: Unit has power and has found a mesh network routing
path to a gateway (portal) node
POE
1
Not currently used
ETH
Yellow/Green
1
Displays the Gigabit-Ethernet 0 link status:
•Dark: No uplink on the Ethernet port
•Green: The link speed is 1000M
•Yellow: The link speed is 10M or 100M
•Flashing: Data is being transmitted or received

MSR2000 Installation Guide 12
Figure 1-5 MSR2KAC/MSR2KDC LED Location
Figure 1-6 MSR2KAC/MSR2KDC LED Layout
The following table lists the meanings of the LEDs on the MSR2KAC/ MSR2KDC.

MSR2000 Installation Guide 13
Table 1-2 MSR2KAC/MSR2KDC LED Status Indicators
LED
Color
QTY
Definition
R0
Orange
5
Displays the Radio 0 RF Strength status:
•All dark: Radio 0 is not providing either access (SSID) or
backhaul (mesh) service
•Single LED orange: Radio 0 is providing access (SSID)
service or providing very weak backhaul (mesh) link
•Multiple LED orange: Radio 0 is providing backhaul (mesh)
link to another node; the more LEDs are orange, the stronger
the link signal
R1
Blue
5
Displays the Radio 1 RF Strength status:
•All dark: Radio 1 is not providing either access (SSID) or
backhaul (mesh) service
•Single LED blue: Radio 1 is providing access (SSID) service
or providing very weak backhaul (mesh) link
•Multiple LED blue: Radio 1 is providing backhaul (mesh) link
to another node; the more LEDs are blue, the stronger the
link signal
P/S
Orange/Green
1
Displays the power or connection status:
•Dark: No power to the unit
•Orange: Unit has power but does not yet have a mesh
network routing path to a gateway (portal) node
•Green: Unit has power and has found a mesh network routing
path to a gateway (portal) node
Heat
Blue
1
Displays the heating status of low temperature
•Dark: Unit is not in heating status
•Flashing: Unit is pre-heating
POE
Green
1
Displays PSE power output status
•Dark: Non-powered device (0Ω<Rport<200Ω) or Port open
(Rport>1MΩ)
•Green: Port on (25kΩ)
•1 Flash: Low signature resistance (300Ω<Rport<15kΩ)
•2 Flashes: High signature resistance (33kΩ<Rport<500kΩ)
•5 Flashes: Port overload fault
•9 Flashes: Power management allocation exceeded
ETH
Yellow/Green
1
Displays the Gigabit-Ethernet 0 link status:
•Dark: No uplink on the Ethernet port
•Green: The link speed is 1000M
•Yellow: The link speed is 10M or 100M
•Flashing: Data is being transmitted or received

MSR2000 Installation Guide 14
Note
Starting with MeshOS 4.5, you can turn off the LEDs in the MSR2000 devices using the WMI and
CLI. The LEDs are enabled by default. This option may be used to disable the LED lights in a
MSR2000 device that is mounted in an elevated place on the city streets or residential areas, to
avoid unwanted attention or disturbance. This feature turns off only the LED lights that indicate the
software status, for example the RF. The LEDs that indicate the hardware status, for example
Power, P/S, POE, and ETH, cannot be turned off using this feature. For additional details, refer to
the Aruba MeshOS User Guide and the Aruba MeshOS Command Reference Guide.

MSR2000 Installation Guide 15
2 Installation Preparations
This chapter describes the preparations for MSR2000 installation, including checking package contents,
preparing installation tools, and selection of installation sites.
2.1 Package Contents
•Aruba MSR2000 AirMesh Router
•MSR2000 Mounting Bracket
•Solar Shield
•Pole Anchors x 2
•M4 x 16 bolts, flat washers, and spring washers x4 (These bolts are attached to the solar shield)
•M6 x 20 bolts, flat washers, and spring washers x2
•M4 x 12 bolt, external-tooth washer, and OT copper lug x1
•M8 x 110 bolt, flat washers, spring washers, and nuts x4
•Metal Weatherproof Caps x2 for use on unused antenna interfaces
•RJ-45 Connector Kit with plastic RJ-45 connector (MSR2KP only)
•RJ-45 Connector Kit with metal RJ-45 connector (MSR2KAC/ MSR2KDC only)
•USB Console Cable
•Installation Guide
•Quick Start Guide
Note
Inform your supplier if there are any incorrect, missing, or damaged parts. If possible, retain the
carton, including the original packing materials. Use these materials to repack and return the unit
to the supplier if needed.

MSR2000 Installation Guide 16
2.2 Preparing Installation Tools
The following tools may be required while installing a MSR2000:
Table 2-1 Installation tools
Type
Tools
General tools
Screwdriver, adjustable spanner, vice, safety belt, hard hat, power
board (220 VAC or as required by local regulation), POE power
injector, crimping pliers, electric soldering iron, welding wire, PVC
insulation tape, adhesive insulation tape, strap, insulation tools
2.3 Examining the Installation Site
1. For sites that are providing mesh connections to other units, installation location should be selected
to provide line-of-sight (LOS) with clearance of obstacles of at least 60% of the first Fresnel zone.
2. If no LOS secured, area in non-line-of-sight (NLOS) area could be covered as well, but the distance
of coverage and area of coverage are decreased; more sites are needed to provide coverage for
same area than in the LOS scenario.
3. Interference must be considered in site selection. New site should avoid known interference, unless
the interference is controllable.
4. Keep the MSR2000 away from places that are susceptible to high temperature, dust, harmful gas,
inflammable, explosive, electromagnetic interference (high power radar, radio station and
transformer), unstable voltage, heavy vibration, or loud noise. In engineering design, the site
should be selected according to the network planning and technical requirements of
communications equipment, as well as the considerations such as climate, hydrology, geology,
earthquake, electric power, and transportation.

MSR2000 Installation Guide 17
3 Weatherproofing Connections
Weatherproofing your antenna and/or cable connections on your outdoor router is essential for the reliability
and longevity of your product. This process prevents water from entering the router or antennas through the
connectors.
A good weatherproofing job consists of three wrappings:
1. Electrical tape
2. Butyl rubber
3. Electrical tape
The first wrapping of tape should be at least two layers, followed by a single wrap of butyl rubber, and four-
layer wrap of electrical tape. This provides good protection from water, heat, and other potential hazards
that could damage your router or antennas.
Additionally, wrap your connections such that water is always directed down and away from connections.
3.1 Required Items and Tools
•3/4” (19 mm) Vinyl Electrical Tape
•Butyl Rubber Tape
•Knife or Box Cutter
3.2 Types of Connections
The following sections provide guidance on weatherproofing directly connected antennas (Figure 3-1) and
cable connections (Figure 3-2). The same materials are needed for weatherproofing both types of
connections but the procedure is slightly different. For weatherproofing directly connected antennas, see
the Weatherproofing Antennas Connected Directly to the MSR2000 section. For weatherproofing cable
connections, see the Weatherproofing Cable Connections section.

MSR2000 Installation Guide 18
Figure 3-1 Antennas Connected Directly to the MSR2000
Figure 3-2 Cable Connections

MSR2000 Installation Guide 19
3.3 Important Points to Remember
•Do not cover the weep holes on the antennas. Doing so can restrict the release of condensation
from the antennas.
•Proper weatherproofing is not a fast process. Set aside ample time to complete the steps outlined in
the following section.
•When wrapping, make each layer of tape as flat as possible. Wrinkles and folds in the tape create
places for water and moisture to gather.
3.4 Weatherproofing Antennas Connected Directly to the MSR2000
Note
The following instructions assume that you have installed a lightning arrestor between your router
and the antennas.
