AS MOTOR Allmaher AS 28 2T ES User manual

Operator's Manual
Allmäher®
AS282TES
From serial number: 035019010001
Issued: 28 Jan 2019, V2.0
en-Translation of the Original Operator's Manual

2
dummy
Notes on the operating
manual
Dear customer,
Congratulations on your purchase. You have
acquired a reliable quality product by
”AS-Motor Germany”.
This product has been manufactured according
to modern manufacturing methods and com-
prehensive quality assurance measures. Only
when you are satisfied with your device have
we attained our goal.
These operating instructions contain important
information to help you avoid hazards and to
increase the reliability and the life span of the
device.
Read the operator’s manual be-
fore using the device. Share
these operating instructions with
other users of the device.
Contact
If you have questions about your device,
please contact your customer service.
For international AS partners, please see:
www.as‑motor.de.
Device data
Please fill in all data referring to your device.
When ordering spare parts, provide your
dealer with the serial and engine numbers.
Serial number (see manufacturer’s certificate
or type plate):
Engine number:
Date of purchase:
Address of dealer:
Intended use
The device is intended only for cutting grass or
similar vegetation in well-maintained grounds
in agriculture, forestry and preservation of the
countryside that are cut at least once a year.
Woody growth must not be older than maxim-
ally one year.
Any other use exceeding this purpose is inad-
missible.
Observe the instructions chapter for Mainten-
ance. Otherwise, operational safety is en-
dangered.
The user of the device is responsible for acci-
dents or damage that can happen to other per-
sons or their property.
The device must not be used:
– To cut hard objects, rocks, rubble, or pieces
of wood.
– To trim bushes, hedges, and shrubbery.
– To cut plants in flower pots or planters or on
rooftops.
– To clean (vacuum) footpaths.
– As shredder for shredding tree and hedge
cuttings.
– As drive unit for work tools and any type of
tool sets that are not authorised by
“AS-Motor Germany”.

3
Contents
Notes on the operating manual............. 2
Contact .................................................... 2
Device data.............................................. 2
Intended use............................................ 2
Explanation of the symbols................... 4
Symbols in the instructions...................... 4
Warnings................................................. 4
Signs on the device................................. 4
Safety instructions ................................. 6
Get informed!........................................... 6
User restrictions and hours of operation.. 6
Safe handling of fuel................................ 6
Check the device prior to use.................. 7
Danger area............................................. 7
Use caution during operation................... 8
Prior to mowing........................................ 8
Use caution when mowing....................... 8
Driving on slopes..................................... 9
When work is completed......................... 10
Use caution during maintenance and
repair....................................................... 10
Device description.................................. 11
Control elements .................................... 12
Information on mowing.......................... 13
Prior to starting....................................... 14
Fuel.......................................................... 14
Tanking up............................................... 14
Adjusting cutting height........................... 15
Locking steerable front wheel.................. 16
Starting.................................................... 16
Starting device......................................... 16
Driving ..................................................... 17
Driving..................................................... 17
Turning.................................................... 17
Switching off and parking...................... 17
Transport................................................. 18
Loading.................................................... 18
Unloading the device............................... 18
Maintenance............................................ 19
Maintenance overview............................. 20
Cleaning the device................................. 22
General inspection................................... 22
Grease lubrication................................... 22
Maintaining the engine............................ 22
Checking the spark plugs........................ 23
Maintaining the air filter........................... 23
Checking rear brake................................ 24
Checking the drive................................... 24
Checking the blade.................................. 25
Checking engine brake............................ 25
Assembly................................................. 26
Scope of delivery..................................... 26
Unpacking................................................ 26
Guide bar and handlebar......................... 26
Protection skirt and steerable front
wheel....................................................... 27
Fastening the air filter.............................. 28
Attaching the starter grip......................... 28
Storage .................................................... 28
Storing the device.................................... 28
Longer storage........................................ 28
Restarting................................................ 28
Spare parts.............................................. 29
Wear parts............................................... 29
Disposal................................................... 29
Warranty.................................................. 29
Troubleshooting ..................................... 30
Fuel ratios of fuel 2-stroke devices....... 33
Technical data......................................... 34
Accessories............................................. 35
Declaration of conformity...................... 36

4
dummy Inhaltsverzeichnis
Explanation of the symbols
Symbols in the instructions
In these operating instructions, the following
symbols are used to denote special dangers.
Warning.
These symbols denote special
dangers.
Prohibition sign.
These symbols denote inad-
missible procedures.
Directive sign.
These symbols denote required
protective measures.
Warnings
In these operating instructions, warning in-
structions are marked with signal words. The
signal words are used to indicate the following
hazards and potential consequences.
Danger
Imminent danger
Indicates an imminently hazardous situation
with a high level of risk that, if not avoided,
will result in minor or moderate injury.
Warning
Hazardous situation
Indicates a possibly hazardous situation
with a medium level of risk that, if not
avoided, could result in minor or moderate
injury.
Caution
Hazardous situation
Indicates a possibly hazardous situation
with a low level of risk that, if not avoided,
could result in minor or moderate injury.
Notice
Danger of property damage
Indicates a possible risk of damage of the
device and its surroundings.
Signs on the device
The following signs are attached to the device
to provide a reminder that during use of the
device, you will have to be careful and attent-
ive:
Working with the device requires
extreme cautiousness.
Read the operating instructions
before you use the device.
Min. 50 m.
Risk of injury!
Make sure that no one is within
the danger zone of the device.
Objects may be ejected. The
danger zone extends for at least
50 metres.
The quickly rotating blade can
cause life threatening injuries or
immense property damage! Be
especially careful to keep your
hands and feet away from the
blade when the device is put
into operation.
Prior to any repair and mainten-
ance work, pull off the spark
plug connector.

5
Clean the ventilation grid!
The cooling air of the mo-
tor is sucked in through
the ventilation grid of the
engine cover. Always
keep the entire surface
open and free!
Noise is causing health prob-
lems. Use personal ear protec-
tion to avoid hearing damage.
Hot surface. Do not touch the
engine or the silencer. They be-
come very hot during operation
and you can get burned.
Do not clean the device with wa-
ter spray or high-pressure
cleaner!
Type plate
The type plate on the device provides you
with information on the device type and the
technical data.
1 Name and address of the manufacturer
2 Device designation
3 Type designation
4 Rates power output in kW / engine speed
5 Weight
6 Year of manufacture
7 Serial number
8 CE marking

6
Safety instructions
Get informed!
For your safety, read these operating instruc-
tions carefully. Familiarize yourself with the
control elements and the proper use of the
device. Share these operating instructions with
other users of the device.
Have skilled personnel who were trained by
AS-Motor show you the safe handling of the
device before you work with it for the first time.
Get familiar with the device in a wide, open
and flat terrain first.
User restrictions and hours of
operation
Never allow children or persons who are not
familiar with the operating instructions to use
the device. Persons under 18 years of age
may operate the device only under proper su-
pervision. Local regulations determine the min-
imum age of the operator und the operating
times.
Unsuitable for operation of the device are per-
sons who
– are under the influence of alcohol, drugs or
reaction retarding medicines.
– have physical and mental/emotional impair-
ments.
– are tired or sick.
People fitted with pace makers
are not allowed to touch any cur-
rent carrying parts of the ignition
system.
Safe handling of fuel
Fuel is toxic and highly flammable. There is a
burn and explosion hazard!
Keep fuel away from ignition sources and do
not smoke during handling.
Do not inhale fuel vapours, they are dangerous
to your health.
Use gloves and avoid skin contact with the
fuel.
Always refuel outdoors when the engine is cold
and stopped completely. When doing so, al-
ways use a filler spout or a funnel.
Do not spill any fuel or do not let fuel enter
canalisation or drain away.
When fuel has overflown, do not start the
device until the fuel vapours have evaporated
(wipe dry). Move the device away from the
spilled fuel.
Always close the tank cap tightly and do not
open it while the engine is running or the
device is still hot.
Empty the fuel only when outdoors. Use the
approved container for this or run the fuel tank
empty.
Store the fuel away from children and keep it in
a suitable container in a dark, cool and dry
place.
Never store the device when there is fuel in the
tank inside a building where fuel vapours might
come into contact with open fire or sparks.
Immediately replace the fuel tank or tank cap if
they are damaged (authorised service centre).
First aid
When swallowing fuel or inhaling fuel vapours,
do not force vomiting and immediately consult
a doctor.
In case of skin contact, immediately wash with
water and soap. Change your soiled clothing
as soon as you can.
Measures in case of a fire
In case of a fire, use foam, dry powder extin-
guisher, or carbon dioxide (CO2). Never douse
with water!

7
Check the device prior to use
Prior to each use, check the blade, protection
skirt, covers, drive and fastening parts, cables
and cable connections for proper working con-
dition and firm seating by visual inspection.
Never use the device with defective or missing
covers or protection skirt or rollbar.
Do not remove, change or override any safety
devices or control elements.
Observe the maintenance instructions (see
chapter Maintenance).
Have an authorised service centre check your
device if the blade does not stop within
7seconds.
Danger area
Fig.1:
The danger zone extends for at least 50
metres.
Within the danger area of the device, there is a
risk of injury.
The rotating knife can cause injuries and ob-
jects can be thrown out. The area in front of
and to the right of the device is especially dan-
gerous.
On slopes, the device can topple over and
slide towards persons or run them over.
Make sure
– that nobody else besides the user is on the
mowing area.
– that people are never positioned in the direc-
tion of travel in front of the device.
– that nobody is positioned on the slope below
the device.
– that you have a complete overview of the
danger area at all times.
– that you keep your hands and feet away
from the rotating parts.

8
Use caution during operation
Danger of injury during motor start
Do not start the engine
– if fuel was spilled.
– in closed or poorly ventilated rooms (danger
of poisoning!).
– if there are other persons nearby.
Start the device only when your feet are at a
safe distance to the blade.
When the engine is started, do not tilt the
device.
Risk of injury when the motor is running
Switch off the engine and wait until the blade
stops
– before you tilt or transport the device.
– before you step away from the device, even
for just a short time.
– when you drive on surfaces other than
grass.
– before you adjust the cutting height.
– before you refuel.
Switch off the engine and wait until the blade
comes to a standstill, and pull off the spark
plug connector
– before you clean or check the device or be-
fore you carry out work on the device.
– before you unblock or unclog the discharge
area.
Risk of burns
Do not touch the engine or the silencer. These
parts become very hot during operation and
you can get burned. If a jumpy movement oc-
curs, the risk of additional injuries can result.
Prior to mowing
Personal protective measures
During mowing, always wear
safety shoes with good grip and
long trousers. Do not mow with
open sandals or while shoeless.
Wear safety gloves to protect
yourself against injuries and vi-
brations.
Noise is causing health prob-
lems. Use personal ear protec-
tion to avoid hearing damage.
Wear safety glasses and
headgear.
Ask your specialised dealer about suitable pro-
tective equipment.
Preparing the mowing area
Prior to mowing, carefully check the perimeter
of the lawn. Remove rocks, pieces of wood,
bones, wires, and other objects that could be
picked up and thrown out by the device.
Use caution when mowing
Risk of injury
Risk of injury caused by ejected objects. Never
mow when persons, children, pets or material
assets are in the danger area.
Keep your hands and feet away from the rotat-
ing parts. Keep a distance to the ejection area
while working with the device.
Make sure that help can be provided in case of
an emergency.
Only mow during daylight or with adequate arti-
ficial lighting. Never mow in the event of uncer-
tain weather conditions and risk of lightning.
Be especially carefully when mowing on soft
ground, nearby landfills, ditches, dikes and wa-
ter edges.

9
Fig.2:
Avoid mowing damp grass, there is a sliding
risk!
Be extremely cautious when turning the device
round or pulling it toward you and when mov-
ing in reverse.
Always walk slowly!
Never lift or carry the device when the engine
is running.
Pay attention to traffic when working close to
roads.
Vibrations
When the device is used over a longer period
of time, vibrations can cause disturbances in
the blood supply of the hands. A generally ac-
cepted usage time cannot be determined.
– Use gloves.
– Take breaks on time.
Have an authorised service centre check the
device
– when the blade has hit an object.
– if the device starts to vibrate unusually
severely.
Mowing surfaces with fire hazard
– Carry a sufficient amount of suitable extin-
guishing agent.
– If side inclination is too great, fuel may leak
from the carburetor or the tank. This poses a
fire hazard!
– Observe the mowed surface also after mov-
ing is completed to ensure that no fire will
start.
To avoid risk of fire, keep the following com-
ponents free of dirt, grass, hay, leaking oil,
grease, etc.:
– Engine
– Silencer (manifold, guard, clearances)
– Area around the fuel tank
Driving on slopes
Fig.3:
Risk of injury during mowing on slopes due to
tipping over or sliding.
– Mow on steep terrain only when safe opera-
tion can be guaranteed.
– Do not mow excessively steep slopes.
– Take suitable precautions on steep slopes,
e.g. by using step irons.
– Always mow crossways to the slope, never
upwards or downwards.
– Always make sure that you step safely, use
non-slip safety shoes.
– Be extremely cautious when changing the
direction.
– Mow only when the ground is dry and has a
good grip.
– Mow only when the steerable front wheel is
locked.
When facing downhill, the device can roll
away. Park the device on level ground only
and secure it against rolling away.
If the device tilts or slips
– If you attempt to stop a device that is tilting
or slipping, severe injuries can result. If tilt-
ing or sliding cannot be stopped in the be-
ginning without endangering anyone, do not
continue to try to stop the device.
– Remove leaking fluids (oil, fuel, battery acid)
from the device and the floor. Deposit of
contaminated soil environment friendly ac-
cording to the local regulation.
– Undetectable damage may have occurred to
the device. In case of malfunctions, there is
a risk of injury. Have an authorised service
centre check the device.

10
When work is completed
After mowing, always close the fuel valve and
the tank ventilation.
Prior to leaving the device, wait until the engine
comes to a standstill and pull off the spark plug
connector.
After switching it off, let the device cool down
for at least 20 minutes before you store it in a
dry, closed, sufficiently ventilated room.
Never store the device when there is fuel in the
tank inside a building where fuel vapours might
come into contact with open fire or sparks.
Use caution during maintenance
and repair
Only carry out work as described in these op-
erating instructions. Have an authorised ser-
vice centre perform all other work.
Only use the blades and spare parts author-
ised by “AS-Motor Germany”. Unauthorised
blades and spare parts can cause severe injur-
ies.
Prior to all maintenance work, wait until the en-
gine comes to a standstill and pull off the spark
plug connector.
We explicitly point out that, in accordance with
the Product Liability Act, we are not liable for
damages that were caused by our devices if
– worn or damaged parts were not repaired or
replaced on time.
– these damages were caused by improper
repair.
– when changing a part, our original parts or
parts authorised by us were not used.
– the repair work was not carried out by an au-
thorised service station.
The same applies for spare parts and
accessories.

11
Device description
4
1
2
3
56
7
14
11
10
9
8
15
12
13
17
18 16
1Steerable front wheel
2Interlock steerable front wheel
3Cutting height adjustment
4Choke
5Air filter
6Starter grip
7Lever for lateral adjustment of
handlebar
8Tie rod height of bar
9Tank ventilation
10 Tank filler spout
11 Fuel valve
12 Spark plug connector
13 Type plate
14 Silencer
15 Ventilation grid
16 Cover
17 Protection bow
18 Protection skirt

12
Control elements
1
62
3
5
4
Throttle lever (1)
With the accelerator lever, you change the
engine speed and thus control the engine
output.
1 2
1: Neutral position
2: Full throttle
Drive lever (2)
With the drive lever, you switch the drive on
and off.
Drive off (0):
Release the lever.
Drive on (I):
Press the lever towards
the handlebar and
continue to hold.
Engine brake lever(3)
The engine brake lever is a protection device.
When you release the lever, the engine shuts
down immediately, the blade comes to a
standstill within 7seconds.
M
I
0
Blade/engine on (I):
Press the lever towards the
handlebar and continue to
hold.
Blade/engine off (0):
Release the lever.
Lever for lateral adjustment of handlebar(4)
1. Release the eccentric tension lever.
2. Attention: Do not crush the Bowden cables
when pivoting the handlebar.
Swivel the handlebar to the side to the de-
sired position.
3. Clamp the handlebar with the eccentric ten-
sion lever.
Handlebar with height adjustment (5)
Pull the tie rod (5) backwards and move the
handlebar to a comfortable position.
Rear brake lever (6)
You need brakes when going downhill and
when you switch off the device. To brake you
must release the drive lever.
P
1
Brake off (0):
Release the lever.
Brake on (I):
Press the lever towards
the handlebar and con-
tinue to hold.
Parking brake on (I):
Pull the lever towards the
handlebar and press the
catch(1).

13
Carburetor with choke (4) and tickler
For cold start of the engine, you require the
choke (1) and the tickler (2).
Open the choke:
Turn clockwise as far as it
will go.
Close the choke:
Turn anti-clockwise as far
as it will go.
2
1
Filling carburetor with fuel:
Press the tickler briefly un-
til fuel flows out.
Fuel valve(11)
1
2
3
1: Reserve
2: Open
3: Closed
Switching lever
With the switching lever you adjust the driv-
ing speed.
Slow:
Pull the switching lever up-
wards.
Fast:
Press the switching lever
downwards.
Information on mowing
Prior to mowing, check your device for com-
pleteness, proper functioning, and cleanliness.
A dirty ventilation grid causes overheating of
the engine, this can damage the engine. A dirty
protective grid at the silencer poses a fire haz-
ard.
To keep the area well maintained, mow fre-
quently and keep the grass short.
Only mow with a sharp and undamaged blade.
Have the blade sharpened and balanced regu-
larly (by authorised service centre).
Do not mow when the grass is wet or when it is
raining. The turf may be damaged and there is
a danger of slipping!
Turn the device around only in already mown
sections. Do not leave the device unattended
while the engine is running.
For mowing, always turn the accelerator lever
to full throttle to achieve the best mowing per-
formance.
To avoid blockage during the ejection of grass,
we recommend, for flat terrain, to proceed ac-
cording to the mowing patterns. Mulch is
shredded into much smaller pieces when you
mow the terrain once again in the opposite dir-
ection.
If the grass is extremely high, mow twice at dif-
ferent cutting height settings.

14
Prior to starting
Fuel
The engine must be run on a mixture of petrol
and two-stroke oil.
For possible mixing ratios, see chapter Mixing
ratios fuel.
Use unleaded petrol (octane rating at least
ROZ 91). You can use E10 petrol. Do not store
E10 petrol longer than 30 days. Do not use
fuels with more than 10 % ethanol (e.g. E15,
E85).
Only use fully synthetic two-stroke oil intended
for mixing in ratio 1:50. Do not use any mineral
two-stroke oil.
AS-Motor recommendation:
Fully synthetic two-stroke oil TITAN 2T 100S in
ratio 1:100.
Your benefits:
–Halve oil consumption compared to 1:50 -
therefore more environmentally and cost
friendly.
– Optimum protection of the engine for a long
service life.
– Low engine wear.
– Maximum engine performance.
You can buy Fuchs “TITAN 2T 100S“ from
your AS-dealer:
Container ET no.
1 litres
(resealable bottle)
G00041042
100 ml
(disposable container)
G00041056
40 * 100 ml
(disposable containers in
box)
G00041058
Notice: You can find on the market ready
mixed two-stroke fuels. Based on our experi-
ence, the ready mixed fuels “STIHL Motomix
1:50”, “ASPEN 2-stroke” and “Oest Oecomix”
can be used. No guarantee can be given for
operation of the device with other fuels and
oils!
Do not use mixtures with more oil than 1:50
(e.g. 1:35).
Too much oil results in carbon deposits and re-
duces the service life of the engine.
Only use the fully synthetic two-stroke oils ex-
plicitly intended for mixing.
Use of engine oils or even waste oil results in
engine damage.
No warranty is given in these cases.
Storing fuel mixture
The fuel mixture ages and can cause engine
damages. Only mix as much fuel as you are
going to use up during the next mowing.
Tanking up
Warning
Fuel is ignited by hot engine parts.
► Prior to filling up, switch off the engine
and wait for at least 20minutes until the
engine has cooled down. Observe the
safety instructions regarding the fuel!
Filling up with fuel
1. For filling, use a canister with filler spout or
a funnel.
2. Open the canister carefully so that existing
excess pressure is slowly reduced.
3. Open the tank cap carefully so that existing
excess pressure is slowly reduced and no
fuel sprays out.
4. Fill the fuel tank.
5. Tightly close the tank cap again.

15
Adjusting cutting height
Adjust the cutting height setting only when the
engine is switched off.
Set the cutting height so that the blade does
not touch the ground even in case of terrain
unevenness. If the cutting height is set too
high, objects can be ejected and the “clean cut
appearance” can be destroyed.
The rear wheel height setting determines the
coarse setting of the cutting height. The height
of the steerable front wheel determines the fine
setting of the cutting height.
Height of rear wheels
1. Switch off the engine and wait until the
blade comes to a standstill.
2. Slightly lift the device at the handlebar.
3. With your foot, press down the rear spacer
against the locking springs.
4. By lifting or lowering the handlebar, you
change the cutting height.
5. Release the spacer and make sure the
catches engage into the wheel carriers.
6. The cutting height can be set in 4stages of
55mm to130mm.
Cutting height at steerable front wheel
Fig.4:
1. Reach with your hand below the guide bar
of the steerable front wheel and press with
the ball of your thumb the lever of the cut-
ting height adjustment downwards.
2. Lift or lower the guide bar to the desired
position.
3. Release the lever.

16
Locking steerable front wheel
On flat terrain, it is more comfortable to leave
the front wheel free to pivot. If you mow in hori-
zontal direction, it is necessary to always lock
the wheel.
1
3
2
Fig.5:
Releasing steerable front wheel
1. Lift off the cover (1) of the steering tube.
2. Pull the lock bar (2) of the steerable front
wheel interlock backwards next to the hand
lever (3).
3. Push the cover (1) back on.
Locking steerable front wheel
1. Align the steerable front wheel parallel to
the bar.
2. Lift off the cover (1) of the steering tube.
3. Pull the lock bar (2) of the steerable front
wheel interlock forward.
4. Push the cover (1) back on.
Starting
Warning
During startup, there is a risk of injury
caused by the rotating blade.
► Make sure that no one is within the
danger zone of the blade. Do not tip the
device over to one side during startup.
Warning
Danger of poisoning due to poisonous ex-
haust gases.
► Do not operate the engine in closed or
insufficiently ventilated rooms.
► Please observe the safety instruction re-
garding the poisoning risk.
Warning
If after startup the carburetor does not close
properly, fuel will overflow and a fire hazard
occurs.
► Close the fuel valve and contact an au-
thorised service centre.
Starting device
1. Place the device on even terrain, not in
high grass.
2. Pull the starter grip slowly to the rear and
attach it onto the starter grip holder.
3. Close the fuel valve and the tank ventila-
tion.
4. Plug in the plug connector.
5. Only for cold start: Close the choke at the
carburetor (turn anti-clockwise).
6. Press the tickler at the carburetor until fuel
flows.
7. Turn the accelerator lever to the lowest en-
gine speed.
8. Actuate and hold the engine brake bar.
9. Pull the starter grip slowly out until you feel
resistance and then pull out quickly – en-
gine starts to run.
10. Slowly bring the starter grip back and at-
tach it onto the starter grip holder.
11. Turn the accelerator lever to medium en-
gine speed.

17
12. Reopen the choke (turn clockwise).
13. For mowing, set the accelerator lever to the
maximum speed.
Driving
Warning
Risk of injury caused by tripping or sliding
while pushing the mower, moving it back-
wards and turning it round.
► Make sure that the area is clear of ob-
jects and watch for safe footing.
Notice
Driving when the drive and brake are simul-
taneously pressed damages the brake.
► Release the drive lever when you brake.
Driving
In case of a hazardous situation, switch off the
blade by releasing the engine brake lever.
Drive on:
1. Release the brake.
2. Press the drive lever towards the handlebar
– device starts moving.
Drive off:
1. Release the drive lever.
Controlling the speed:
1. Release the drive lever.
2. Shift the switching lever.
3. Press the drive lever again towards the
handlebar.
Driving on downhill slopes:
Control the speed with the brake when driving
on downhill slopes.
Beware: Release the drive lever when you
brake. Otherwise, the brake is damaged.
Turning
Turn the device round only where the grass
has been mowed already.
Turning round on an even surface:
1. Switch off the drive.
2. Turn the device to the desired side.
3. Switch the drive back on.
Turning round on a sloping area:
1. Keep the drive switched on.
2. Turn the device upslope.
3. Hold back the handlebar and the inner
wheel.
The drive prevents sliding and supports the
turn manoeuvre.
Switching off and parking
Warning
On a slope, the device can roll away.
► Put the device on even ground only or
secure it against rolling away.
1. Release the drive lever.
2. Turn the accelerator lever to the lowest en-
gine speed.
3. Release the engine brake lever.
4. Wait for the engine to stop completely be-
fore you step away from the device.
5. Close the fuel valve and the tank ventila-
tion.
6. Engage the parking brake when you park
the device on uneven terrain.
7. Pull off the plug connector.

18
Transport
Warning
Risk of injury due to the heavy weight of the
device. The device can fall over and fall
down and cause severe injuries.
► Observe the following notices.
Transport the device on a freight vehicle or a
trailer which is designed for a carrying capacity
of at least as great as the empty weight of the
device.
Switch off the engine and wait until the blade
stops before you lift the device. The device
may only be lifted by two people.
Prior to transport, let the device cool down for
at least 20 minutes. Close the tank ventilation
and the fuel valve.
For transport you fold down the lever and the
handlebar and remove the swivel wheel.
Loading
Use suitable ramps for loading that
– can carry the empty weight of the device +
200 kg.
– are wider than the device.
– have a slip-free surface.
Notice
Risk of damage due to incorrect fastening of
straps.
► Fasten the straps only at the points
shown in the figure.
► Do not overtighten the straps.
1. Put the device in front of the ramps and
make sure that the ramps
– are as wide as the wheel gauge of the
device.
– are tightly secured to the platform.
– are not steeper than 15°.
2. Carefully drive the device via the ramps
onto the platform.
3. Observe the instructions in chapter
Switching on and stopping.
4. Secure the device against rolling, sliding
and tilting. Use straps that support the
weight of the device.
Fig.6:
Fig.7:
5. Secure the device with belts to the frame
elements that can hold the weight
Unloading the device
1. Undo the transport fastenings.
2. Drive the device carefully down the ramps
of the platform.

19
Maintenance
Warning
Risk of injury due to unexpected movement.
When inspections are carried out, the
device can move unexpectedly.
► Make sure that no persons or objects are
in the danger area of the blade.
► Make sure that no further hazards result
from an unexpected movement.
Warning
Risk of injury during maintenance and
cleaning work when the engine is running.
► Perform maintenance tasks only then
with a running engine if this is required in
the Maintenance table.
Warning
Danger of poisoning due to poisonous ex-
haust gases.
► Do not operate the engine in closed or
insufficiently ventilated rooms.
► Please observe the safety instruction re-
garding the poisoning risk.
Prior to all maintenance and cleaning work
when the engine is not running:
Fig.8:
Caution
Risk of injury.
Guide bar can snap back.
► To provide secure stand, place the guide
bar onto the ground.
1. Let the device cool down for at least 20
minutes.
2. Pull off the plug connector.
3. Close the fuel valve and the tank ventila-
tion.
4. Release the handlebar by pulling it to-
wards the tie rod and flip the handlebar
forward (do not damage the Bowden
cables).
5. Tilt the device backwards onto the locking
segment of the spar as shown in the illus-
tration.
6. Place the guide bar on the floor.
Improper maintenance can make the device
unsafe for operation and result in accidents.
Regular maintenance keeps your device ready
for use.
Service the device according to the following
maintenance instructions.
Contact an authorised service centre if prob-
lems during maintenance occur or if you de-
termine deficiencies during one of the following
inspections.

20
Maintenance overview
Improper maintenance can make the device unsafe for operation and result in accidents. Regular
maintenance keeps you device ready for use.
Service the device according to the following maintenance instructions.
Contact an authorised service centre if problems during maintenance occur or if you determine de-
ficiencies during one of the following inspections.
Component Action Maintenance
interval
A B
Device Check for safe working condition (basic inspection). ■ ▲
Clean. ■
Customer service. ▲
Fuel Check fuel level. ■
Is the tank cap closed? ■
Tank, fuel valve,
and fuel line
Check parts for leaks and check for good condition. ■ ▲
Carburetor Does the carburetor close again after starting? ■ ▲
Ventilation grid Clean. ■ ▲
Engine cooling Clean. ▲
Spark plug Check/replace. ▲
Air filter Maintain. ■ ■▲
Blade and fastening
components
Check for wear and damage. See chapter Checking the
blade.
■ ▲
Change. ▲
Motor brake Does the blade stop within 7 seconds? □ ▲
Release the drive
lever
Does the device stop when the lever is in zero position? □ ▲
Drive Check. ■ ▲
V-belt Are the belts tensioned correctly, without fissures, and in
good condition?
▲
Bowden cables Check for proper function and ease of movement. ■ ▲
Acceleration lever Check for proper function. □ ▲
Chassis and impact
protection
Check for rust and fissures and check the welding seams. ■ ▲
Are all protective devices and covers in place, fastened cor-
rectly and properly functioning?
■ ▲
