Prepared by ASCOR Inc.
4384 Enterprise Place
Fremont, CA. 94538
[phone]
FAX [phone]
Copyright ©1999 by ASCOR Inc., Fremont, California. Printed in the United States of
America. All rights reserved. Contents of this publication may not be reproduced in any
form without permission of the copyright owner.
MODEL 3000-53/53A
General Purpose
Switching Module
Technical Manual
A Giga-tronics Company
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Product Warranty
Your ASCOR VXI module comes with a 3 year limited warranty. ASCOR warranty
obligations are described by and limited to the terms set forth below and apply only in the
United States of America. ASCOR warrants this VXI module against defect in material
and workmanship for a period of three (3) years from the date of purchase
from ASCOR or an authorized ASCOR agent. This warranty applies only to the original
purchaser of the VXI module and is not transferable unless authorized in writing by
ASCOR in advance of such transfer. This warranty does not cover any incompatibilities
due to the user’s test environment, hardware, software or any other related system
configuration in which the ASCOR VXI module interfaces. Proof of purchase will be
required BEFORE any warranty consideration by ASCOR occurs.
This warranty does not cover any damage caused by negligence, non-authorized
modifications, or parts installed or removed without prior written permission from
ASCOR.
This warranty does not apply if the VXI module has been damaged by accident, abuse,
misuse, or misapplication, nor as a result of service to the product by anyone other than
ASCOR or an authorized ASCOR representative. ASCOR VXI products are not
designed for or permitted to be used in on-line control systems in hazardous environments
such as operation of nuclear facilities, aircraft navigation or control or direct life support.
If you use the ASCOR products in such hazardous environments, this warranty is
immediately null and void.
ASCOR IS NOT RESPONSIBLE FOR ANY LOST PROFITS, LOST SAVINGS OR ANY
OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGE ARISING OUT OF THE USE OF,
OR INABILITY TO USE, THIS PRODUCT. THIS INCLUDES DAMAGE TO PROPERTY,
AND TO THE EXTENT PERMITTED BY LAW, DAMAGES FOR PERSONAL INJURY.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
No ASCOR employee, distributor, agent, seller, reseller or person(s) alleging to
represent ASCOR is authorized to make any modification, extension or addition to this
warranty.
Some states may not allow limitation of implied warranties, or exclusion or limitation of
incidental or consequential damages, so the above limitations may not apply to you. This
warranty gives you specific legal rights. You may have other rights which may vary from
state to state.
This warranty applies to all ASCOR VXI modules and is governed by the laws of the State
of California.
6/99
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents
Introduction
Section 1
Introduction .............................................................................7
General Description ...............................................................7
Weight and Dimensions .........................................................7
Electrical Specification ...........................................................9
ASCOR Model 53 Features...................................................11
ASCOR Model 53A Features................................................13
Register Map Configuration ............................................... 14
Programming ..........................................................................15
Register Map, 16 Bit .............................................................16
Register Map, 32 Bit .............................................................17
Register Description For 3000-53 and 3000-53A ..............18
Connector Pin Configuration ............................................. 32
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction
This User Guide provides a basic description of the Model 3000-53, General Purpose
Switching module. Also included are installation and input connection procedures,
programming information, service and maintenance information.
NOTE: The Model 3000-53 is supplied under two configuration:
Part No: 90400530 Model 3000-53 (Motherboard SCH85006520,
One Daughterboard P/N. SCH85006530).
Part No: 90400530-101 Model 3000-53A (Motherboard SCH85004180,
Two Daughterboards P/N. SCH85004190).
General Description
This module contains ninety six (96) independently programmable form “C” SPDT
Relays (Single Pole Double Throw Relays) for Model 3000-53 and one-hundred forty four
(144) independently programmable form “C” SPDT Relays (Single Pole Double Throw
Relays) for Model 3000-53A. The interface and mechanical constructions meet the
specification of the VXIbus System Specification, Rev: 1.2
and 1.3.
Weight and Dimensions
3000-53 3000-53A
Width 1.2 inches 2.4 inches
Height 10.317 10.37 inches
Depth 13.78 inches 13.78 inches
Weight 3 lb.. 10 lb.
This page intentionally left blank.
Section 1
Model 3000-53 General Purpose Switch
7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Electrical Specification
Electrical:
Number of Connections: 420 Connections from 140 Form
“C” Relays.
Frequency Range (-3dB) >5 MHz
Maximum Switchable Current: 1.0A
Maximum Carry Current: 1.0 A on adjacent pins
1.5 A with 2 adjacent “open path”
pins of isolation
Maximum Switchable Voltage: 220 Vdc / 220 Vac
Maximum Switching Power: 30 Wdc
Switching + Settling Time: 20 ms
Relay Life Expectancy: 1 M cycles
Closed Path Resistance: <0.5 Ohms
Connector:
AMP 50 pin shrouded header, P/N 2-103166-3
Environmental Specification:
Operating Temperature: 10 to 45 degrees C.
Non-Operating Temperature: -20 to +45 degrees C.
Relative Humidity: 30 to 90% RH non-condensing over
operating temp.
Shock: Designed to meet 15G, 11 ms.
Vibration: Industrial Standards.
Cooling: External Cooling Air Required.
This page intentionally left blank.
Section 1
8 Model 3000-53 General Purpose Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

ASCOR Model 3000-53
Features (P/N. 90400530)
ASCOR’s Model 3000-53 is a general purpose VXI Switch Module
supporting
96 SPDT relays.
•The unit is a C size VXI Module;
fits into one slot of a VXI chassis.
•Voltage 220 VDC / 220 VAC
•Current 1.0 Amp
•Power 30 Watts DC
•Internal Self Test capabilities.
•96 Independently Programmable
form “C” SPDT Relays.
Section 1
Model 3000-53 General Purpose Switch
9
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Section 1
10 Model 3000-53 General Purpose Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

ASCOR Model 3000-53A
Features (P/N 90400530-001)
ASCOR’s Model 3000-53A is a general purpose VXI
Switch Module supporting 144 SPDT relays.
•The unit is a C size VXI Module;
fits into two slots of a VXI chassis.
•Voltage 220 VDC / 220 VAC
•Current 1.0 Amp
•Power 30 Watt DC
•Internal Self Test capabilities.
•144 independently programmable
form “C” SPDT relays.
Section 1
Model 3000-53 General Purpose Switch
11
PWR BUS
J
1
J
4
J
2
J
5
J
3
J
6
ASCOR
INCORPORATED
3000
-53
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Register Map -16 Bit Configuration
A16 Registers
Offset Value
00h CFB5
C = Register Based, A16 / A24 Module
FB5 = VXI Manufacturer ID, ASCOR
02h 7D09h
7 = A24 space requirement
D09 = Model Number for this Module
04h FFFCh
Bit 0, reset, is supported. Toggling this bit will clear all relay registers.
Care should be taken to only modify bit “0"
06h (assigned by Resource Manager)
Control Bit
3Eh 0 Low true output enable to the coil driver IC’s.
1 When low enables read back of relay coil state
When high enables read back of data registers.
2 Reserved
3-15 Don’t Care
Section 1
12 Model 3000-53 General Purpose Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Programming
The Model 3000-53 and 3000-53A is a VXI register based module. The switch paths are
controlled via VXIMAX™which is the 16/32 bit data controller. The Model 3000-53 and
3000-53A can be programmed in 16 bit or 32 bit wide data. Through your VXI
controller, write the data to the appropriate register as
shown on the register map for the relay or relays in the
register that is being closed. When the data bit is true, the
relay chosen will be closed. The state of the relays in a
register can be determined by reading the desired register.
The data read back represents the value at the coil of the
relay. This allows verification that the program register
has correctly controlled the relay coil.
The following register maps are shown in the
configurations: 16 bit mode and 32 bit mode. In each
section, 16 bit and 32 bit, the register map is organized to
show the relay designation in each register. It is followed
by the register’s functionality and the path connections to
the front panel.
Note: See separate ASCOR programming guide for
additional information.
For example:
To close relay K15 is to set the register to:
Register 8000h
1
5
1
4
1
3
1
2
1
1
1
09876543210
0000000000000001
Section 1
Model 3000-53 General Purpose Switch
13
ASCOR
INCO RPORATED
ASCOR
INCO RPORATED
bus
3000-53A
J9
J6
J7J4
J3
BUS
J1
PWR
J8
J5
J2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Section 1
14 Model 3000-53 General Purpose Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Register Map, 16 Bit
DESCRIPTION: 48 SPDT RELAYS, MOTHERBOARD #1
PCB NUMBER: 85006520 (For 3000-53)
PCB NUMBER: 85003220 (For 3000-53A)
ADDRESS OFFSET: 8000h
MSB LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K16 K15 K14 K13 K12 K11 K10 K9 K8 K7 K6 K1 K4 K3 K2 K1
ADDRESS OFFSET: 8002h
MSB LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K32 K31 K30 K29 K28 K27 K26 K25 K24 K23 K22 K21 K20 K19 K18 K17
ADDRESS OFFSET: 8004h
MSB LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K48 K47 K46 K45 K44 K43 K42 K41 K40 K39 K38 K37 K36 K35 K34 K33
Section 1
Model 3000-53 General Purpose Switch
15
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Register Map, 32 Bit
DESCRIPTION: 48 SPDT RELAYS, MOTHERBOARD #1
PCB NUMBER: 85006520 (For 3000-53)
PCB NUMBER: 85003220 (For 3000-53A)
ADDRESS OFFSET: 8000h
LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K16 K15 K14 K13 K12 K11 K10 K9 K8 K7 K6 K5 K4 K3 K2 K1
MSB
32 32 30 29 28 27 26 25 24 23 22 20 19 18 17 16
K32 K31 K30 K29 K28 K27 K26 K25 K24 K23 K22 K21 K20 K19 K18 K17
ADDRESS OFFSET: 8004h
LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K48 K47 K46 K45 K44 K43 K42 K41 K40 K39 K38 K37 K36 K35 K34 K33
MSB
32 32 30 29 28 27 26 25 24 23 22 20 19 18 17 16
n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Section 1
16 Model 3000-53 General Purpose Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Register Description For 3000-53 and
3000-53A
REGISTER: 8000h MODE: 16/32 bit
FUNCTION: Relays K1-16
BIT CONNECTION RELAY
0nc: J1-48 no: J1-50, c: J1-49 K1
1nc: J1-45, no: J1-47, c: J1-46 K2
2nc: J1-42, no: J1-44, c: J1-43 K3
3nc: J1-39, no: J1-41, c: J1-40 K4
4nc: J1-36, no: J1-38, c: J1-37 K5
5nc: J1-33, no: J1-35, c: J1-34 K6
6nc: J1-30, no: J1-32, c: J1-31 K7
7nc: J1-27, no: J1-29, c: J1-28 K8
8nc: J1-24, no: J1-26, c: J1-25 K9
9nc: J1-21, no: J1-23, c: J1-22 K10
10 nc: J1-18, no: J1-20, c: J1-19 K11
11 nc: J1-15, no: J1-17, c: J1-16 K12
12 nc: J1-12, no: J1-14, c: J1-13 K13
13 nc: J1-9, no: J1-11, c: J1-10 K14
14 nc: J1- 6, no: J1-8, c: J1-7 K15
15 nc: J1- 3, no: J1-5, c: J1-4 K16
REGISTER: 8000h MODE: 32 bit, BITS 16-31
REGISTER: 8002h MODE: 16 bit
FUNCTION: K17-32
BIT CONNECTION RELAY
0 (16) nc: J2-48 no: J2-50, c: J2-49 K17
1 (17) nc: J2-45, no: J2-47, c: J2-46 K18
2 (18) nc: J2-42, no: J2-44, c: J2-43 K19
3 (19) nc: J2-39, no: J2-41, c: J2-40 K20
4 (20) nc: J2-36, no: J2-38, c: J2-37 K21
5 (21) nc: J2-33, no: J2-35, c: J2-34 K22
6 (22) nc: J2-30, no: J2-32, c: J2-31 K23
7 (23) nc: J2-27, no: J2-29, c: J2-28 K24
8 (24) nc: J2-24, no: J2-26, c: J2-25 K25
9 (25) nc: J2-21, no: J2-23, c: J2-22 K26
10 (26) nc: J2-18, no: J2-20, c: J2-19 K27
11 (27) nc: J2-15, no: J2-17, c: J2-16 K28
12 (28) nc: J2-12, no: J2-14, c: J2-13 K29
13 (29) nc: J2-9, no: J2-11, c: J2-10 K30
14 (30) nc: J2- 6, no: J2-8, c: J2-7 K31
15 (31) nc: J2-3, no: J2-5, c: J2-4 K32
Section 1
Model 3000-53 General Purpose Switch
17
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Section 1
18 Model 3000-53 General Purpose Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Register Description For 3000-53 and
3000-53A (Continued)
REGISTER: 8000h MODE: 32 bit, BITS 16-31
REGISTER: 8004h MODE: 16 bit
FUNCTION: K33-48
BIT CONNECTION RELAY
0 (16) nc: J3-48 no: J3-50, c: J3-49 K33
1 (17) nc: J3-45, no: J3-47, c: J3-46 K34
2 (18) nc: J3-42, no: J3-44, c: J3-43 K35
3 (19) nc: J3-39, no: J3-41, c: J3-40 K36
4 (20) nc: J3-36, no: J3-38, c: J3-37 K37
5 (21) nc: J3-33, no: J3-35, c: J3-34 K38
6 (22) nc: J3-30, no: J3-32, c: J3-31 K39
7 (23) nc: J3-27, no: J3-29, c: J3-28 K40
8 (24) nc: J3-24, no: J3-26, c: J3-25 K41
9 (25) nc: J3-21, no: J3-23, c: J3-22 K42
10 (26) nc: J3-18, no: J3-20, c: J3-19 K43
11 (27) nc: J3-15, no: J3-17, c: J3-16 K44
12 (28) nc: J3-12, no: J3-14, c: J3-13 K45
13 (29) nc: J3-9, no: J3-11, c: J3-10 K46
14 (30) nc: J3- 6, no: J3-8, c: J3-7 K47
15 (31) nc: J3-3, no: J3-5, c: J3-4 K48
Section 1
Model 3000-53 General Purpose Switch
19
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Register Map, 16 Bit
DESCRIPTION: 48 SPDT RELAYS, DAUGHTERBOARD #1
PCB NUMBER: 85006530 (For 3000-53)
PCB NUMBER: 85003230 (For 3000-53A)
ADDRESS OFFSET: 8020h
MSB LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K16 K15 K14 K13 K12 K11 K10 K9 K8 K7 K6 K1 K4 K3 K2 K1
ADDRESS OFFSET: 8022h
MSB LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K32 K31 K30 K29 K28 K27 K26 K25 K24 K23 K22 K21 K20 K19 K18 K17
ADDRESS OFFSET: 8024h
MSB LSB
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
K48 K47 K46 K45 K44 K43 K42 K41 K40 K39 K38 K37 K36 K35 K34 K33
Section 1
20 Model 3000-53 General Purpose Switch
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
